Smart Sensor
Data Storage Unit
ZG2-DSU
User's Manual
Cat.No
Z289-E1-01

Advertisement

Table of Contents
loading

Related Manuals for Omron ZG2-WDS8T

Summary of Contents for Omron ZG2-WDS8T

  • Page 1 Smart Sensor Data Storage Unit ZG2-DSU User’s Manual Cat.No Z289-E1-01...
  • Page 2 Introduction Thank you for purchasing the ZG2 Data Storage Unit (ZG2-DSU). This manual provides information regarding functions, performance and operating methods that are required for using the ZG2-DSU. When using the ZG2-DSU, be sure to observe the following: • The ZG2-DSU must be operated by personnel knowledgeable in electrical engineering. •...
  • Page 3 READ AND UNDERSTAND THIS DOCUMENT (Please Read) BEFORE USE User's Manual LOGGING FUNCTIONS EXTERNAL BANK FUNCTIONS SETTING ADDITIONAL FUNC- TIONS COMMUNICATION WITH EXTER- NAL DEVICES APPENDICES Smart Sensor Data Storage Unit ZG2-DSU...
  • Page 4 WAY CONNECTED WITH THE PRODUCTS, WHETHER SUCH CLAIM IS BASED ON CONTRACT, WARRANTY, NEGLIGENCE, OR STRICT LIABILITY. In no event shall responsibility of OMRON for any act exceed the individual price of the product on which liability is asserted. IN NO EVENT SHALL OMRON BE RESPONSIBLE FOR WARRANTY, REPAIR, OR OTHER CLAIMS REGARDING THE PRODUCTS UNLESS OMRON’S ANALYSIS...
  • Page 5 Performance data given in this document is provided as a guide for the user in determining suitability and does not constitute a warranty. It may represent the result of OMRON’s test conditions, and the users must correlate it to actual application requirements. Actual performance is subject to the OMRON Warranty and Limitations of Liability.
  • Page 6 Meanings of Signal Words The following signal words are used in this manual. Indicates a potentially hazardous situation which, if not avoided, will result in minor or moderate injury, or may result in serious injury or death. Additionally there may be significant property damage.
  • Page 7 Precautions for Safe Use The following points are important to ensure safety, so make sure that they are strictly observed. 1. Installation Environment • Do not use the product in environments where it can be exposed to inflammable/ explosive gas. •...
  • Page 8 Precautions for Correct Use Observe the following precautions to prevent failure to operate, malfunctions, or undesirable effects on product performance. 1. Installation Site Do not install this product in locations subjected to the following conditions: • Ambient temperature outside the rating •...
  • Page 9 Editor’s Note ■ Meaning of Symbols Menu items that are displayed on the Data Storage Unit’s LCD screen, and windows, dialog boxes and other GUI elements displayed on the PC are indicated enclosed by brackets “[ ]”. ■ Visual Aids Indicates points that are important to achieve the full product performance, Important such as operational precautions or tips.
  • Page 10 MEMO ZG2-DSU User’s Manual...

  • Page 11: Table Of Contents

    CONTENTS 1.BEFORE USE Data Storage Unit ......14 System Configuration ......14 Part Names and Functions .
  • Page 12 Logging at Individual Fixed Counts ....33 Specify the Logging Cycle by an External Signal ..33 Starting and Ending Logging ....34 Starting Logging .
  • Page 13 5.COMMUNICATION WITH EXTERNAL DEVICES List of Output Data ......52 Communication Using I/O Signals ....53 Using the Controller I/O Cable .
  • Page 14 MEMO ZG2-DSU User’s Manual...
  • Page 15 BEFORE USE Data Storage Unit Mounting and Connecting Devices Functions of the Data Storage Unit Initializing Controller Settings Saving Setup Data...

  • Page 16: Data Storage Unit

    Data Storage Unit The Data Storage Unit collects and acquires measurement values and profiles from the Sensor Controller installed on site, and can save this data to Memory Card. Data saved on Memory Card can be easily loaded to a PC for use in data analysis and operations. Measurement conditions for up to 4096 banks (16 banks x 256 files) can be registered to an inserted Memory Card as an external bank for the Sensor Controller.

  • Page 17: Part Names And Functions

    Part Names and Functions (10) (11) (12) (14) (13) Name Function (1) CF power LED Displays the status of the power supplied to the Memory Card. This LED turns ON when power is ON, and turns OFF when power is OFF.
  • Page 18 Name Function (7) Control keys These keys are for setting logging conditions and other information. Control key functions change according to the selected operation mode. List of Key Operations p.82 (8) Mode switch This switch selects the operation mode. FUN: This mode displays the menu for setting logging conditions.

  • Page 19: Mounting And Connecting Devices

    Mounting and Connecting Devices This section describes installation of the Data Storage Unit. Cautions Regarding the Mounting Orientation To improve heat radiation, install the Data Storage Unit only in the orientation shown below. Do not install the Data Storage Unit in the following orientations: Important •Do not block the ventilation holes at the top and bottom of the Data Storage Unit body.

  • Page 20: Gang-Mounting To A Controller

    Gang-mounting to a Controller For details on how to gang-mount and install devices, refer to the ZG2 series User's Manual. CH number when Controllers are gang-mounted In the gang-mounted arrangement, the Data Storage Unit must be located at the leftmost end viewed from the front.

  • Page 21: Attaching The Ferrite Core

    Attaching the Ferrite Core Attach the ferrite core (supplied) to the Data Storage Unit's I/O cable. Ferrite core Connecting the Power Supply Connect the power wire (brown) and GND wire (blue) of the Sensor Controller's I/O cable to the 24 ±...

  • Page 22: Inserting And Removing Memory Cards

    Inserting and Removing Memory Cards Important The following Memory Cards can be used on this unit. •F160-N128S (128 MB) •F160-N256S (256 MB) Inserting Memory Cards Press the EJECT button at the side of the Memory Card slot. Remove the protective dummy Protective dummy card card from the unit.
  • Page 23 Select [OK]. Eject CF? The CF power LED turns OFF. CANCEL Press the EJECT button at the side of the Memory Card slot. Remove the Memory Card. Memory Card EJECT button Important When Memory Cards are not to be used on the unit for a long time, insert the protective dummy card.

  • Page 24: Functions Of The Data Storage Unit

    Functions of the Data Storage Unit Logging Function Measurement values and profile data can be saved on the Data Storage Unit.Saved data can be loaded to a PC from a Memory Card or via USB/serial communication for use in managing production logs, monitoring trends and analyzing trouble that may occur. Memory Card Host PC USB/RS-232C...

  • Page 25: Initializing Controller Settings

    Initializing Controller Settings Important The settings of all banks and logging data are initialized regardless of the currently saved bank No. and logging data. To save settings and data, back them up to a personal computer before performing initialization. Acquiring setup data <DATAGET command> p.66 Switch to the FUN mode.

  • Page 26: Saving Setup Data

    Saving Setup Data Bank settings and system settings made on the Data Storage Unit can be saved internally on the Data Storage Unit. Important •The settings of all banks are saved regardless of the currently selected bank No. •After you have made settings, be sure to save the setup data. All settings will be deleted if you turn the power OFF without saving the data.
  • Page 27 LOGGING FUNCTIONS Logging Procedure How Logging Works Select the Logging Target Setting Logging Conditions Starting and Ending Logging Loading Logging Data to an External Device35...

  • Page 28: Logging Procedure

    Logging Procedure Step 1 Measurement value p.31 Select the logging target. Profile p.31 Step 2 Only at an NG/only at an OK p.32 Set conditions to be used for Log by all conditions p.32 logging. Log at a fixed cycle p.33 Log at individual fixed counts p.33 Specify the logging cycle by an external signal p.33...

  • Page 29: How Logging Works

    How Logging Works The Data Storage Unit logs measurement values and profiles by the following mechanism. Data Storage Unit Sensor Controller (2) Logging execution (1) Logging start Internal START signal/↑ key memory (measurement result/profile) (3) Logging end (4) Copy to Memory Card STOP key/↓...

  • Page 30: Possible Number Of Logging Data

    Possible Number of Logging Data Possible Number of Logs to Internal Memory Logged Data Number of Saves to Internal Memory Measurement values only Max. 65,000 times (*1) Profiles only Max. 5,120 times (*2) Both measurement values and profiles Max. total 5,120 times (*2) *1 Logging is possible up to 65,000 times regardless of the number of connected Sensor Controllers and number of preset tasks.

  • Page 31: Format Of Data Saved To Memory Card

    Format of Data Saved to Memory Card When logging is executed, the "OMRON" folder for storing data is automatically created on the Memory Card. Each time logging starts and ends, folders are automatically created and appended with a running number, and logging data is automatically stored in each of these folders.
  • Page 32 File Format Measurement value One measurement value is output to one row of the file. Log___.csv Acquisition time is output Only the measurement values of as "hh:mm:ss". the task whose setting is ON are output. Measurement count (max. 65,000 times) TIME, CH1 TASK1, CH1 TASK2,...

  • Page 33: Select The Logging Target

    Select the Logging Target Measurement values and profiles can be selected as logging targets. Logging Measurement Values  FUN mode-[SOURCE]-[VALUE]-[CH1 or CH2]-[TASK1 to TASK8] Setting value Description OFF/ON Sets the channel (CH) and task No. of the Sensor Controller targeted for logging to ON. Note CH2 is not displayed when it is not connected.

  • Page 34: Setting Logging Conditions

    Setting Logging Conditions Set which data is to be logged. You can select from the following five logging conditions. • Only at an NG/only at an OK • All conditions • At a fixed cycle • At individual fixed counts •...

  • Page 35: Logging At A Fixed Cycle

    Logging at a Fixed Cycle Logging is performed at a specified time cycle.  FUN mode-[SOURCE]-[LOGGING]-[TIME] Setting value Description 00:00:00 Specifies the time interval. Logging at Individual Fixed Counts Logging is performed at a specified count interval.  FUN mode-[SOURCE]-[LOGGING]-[POINT] Setting value Description 1 - 999,999...

  • Page 36: Starting And Ending Logging

    Starting and Ending Logging The following describes the procedure for starting and ending logging. Starting Logging Switch to the RUN mode. TEACH Either input the START signal or Available MB ←→  press the key. Stopping ↑ START Logging is started. Note ...

  • Page 37: Loading Logging Data To An External Device

    Loading Logging Data to an External Device There are two ways of loading logging data stored on Memory Card to an external device. Removing the Memory Card and Copying Logging Data Important Before removing a Memory Card from the unit, make sure that the CF power LED and access LED are both OFF.
  • Page 38 MEMO Loading Logging Data to an External Device ZG2-DSU User’s Manual...

  • Page 39: External Bank Functions

    EXTERNAL BANK FUNCTIONS Saving Bank Data to Memory Cards Transferring Bank Data to the Controller...

  • Page 40: Saving Bank Data To Memory Cards

    Saving Bank Data to Memory Cards Bank data on Sensor Controllers can be saved on a Memory Card inserted on the Data Storage Unit. 16 sets of bank data on the Sensor Controller are saved to a single file on the Data Storage Unit.

  • Page 41: Transferring Bank Data To The Controller

    Transferring Bank Data to the Controller Bank data stored on Memory Cards can be transferred to the current bank of the specified channel.   RUN mode-MENU key-[BANK]-[CF CONT] Setting value Description File Selects the bank file number to transfer. (BANK0 to 255) Selects the channel of the Sensor Controller at the transfer destination.
  • Page 42 MEMO Transferring Bank Data to the Controller ZG2-DSU User’s Manual...

  • Page 43: Setting Additional Functions

    SETTING ADDITIONAL FUNCTIONS Judging Measurement Values (Alarm Outputs) Setting System Conditions Display Settings during Operation Bank Functions...

  • Page 44: Judging Measurement Values (Alarm Outputs)

    Judging Measurement Values (Alarm Outputs) Specifying Tasks When outputting the judgment results of measurements as alarms, specify the channel and task to be used for judgment.  FUN mode-[I/O SET]-[SOURCE] Setting value Description Selects the channel of the Sensor Controller targeted for alarm judgment.
  • Page 45 Switch to the TEACH mode. TEACH Switch the threshold selection switch to H . Set the HIGH threshold. THRESH : 2 5 0. 0 0 0 Note ←→ DIG↑↓VAL SET : OK To change numerical values, use the key/  ...

  • Page 46: Setting System Conditions

    Setting System Conditions Setting the System Clock Set the Data Storage Unit's system clock.  FUN mode-[SYSTEM]-[CLOCK] Setting value Description DATE Sets the date. HOUR Sets the time. Locking Keys The keylock disables all key input on the Data Storage Unit. Key input cannot be accepted until the keylock is canceled.

  • Page 47: Changing The Display Language

    Removing Memory Cards For details on removing Memory Cards, see "Inserting and Removing Memory Cards." p.20 Changing the Logging Folder Start No. When a logging file is saved to Memory Card, a folder with a running No. is automatically created. The start No. for this folder can be changed. Important Note that when an existing folder No.

  • Page 48: Display Settings During Operation

    Display Settings during Operation Setting the Digital Display Set details to be displayed on the Data Storage Unit during logging in the RUN mode. To set the display details, first switch to the RUN mode and then display the top menu. Digital display LCD screen Changing the Number of Display Digits on the Digital Display...

  • Page 49: Lcd Screen Settings

    LCD Screen Settings Hiding the LCD Screen To hide the LCD screen, select [OFF] or [AUTO OFF].  RUN mode-MENU key-[LCD]-[ON/OFF] Setting value Description Displays the LCD screen at all times. (default value) AUTOOFF Hides the LCD screen if the unit has not been operated for one minute.
  • Page 50 Changing the LCD Screen Display Details Customized characters can be displayed on the LCD screen.  RUN mode-MENU key-[LCD]-[CUSTOM] Setting value Description ON/OFF Set this item to ON to display characters set by [CUSTOM] on the LCD screen. (default value: OFF) CUSTOM Edits the characters to display in the LCD screen.

  • Page 51: Bank Functions

    Bank Functions Up to four setups can be stored on the Data Storage Unit, and these can be switched when setting up the unit. A set of these settings is called a "bank." Switching Banks Bank 1 is selected as the default. However, other banks 2 to 4 can be selected. ...
  • Page 52 MEMO Bank Functions ZG2-DSU User’s Manual...
  • Page 53 COMMUNICATION WITH EXTERNAL DEVICES List of Output Data Communication Using I/O Signals Timing Charts Serial Communication...

  • Page 54: List Of Output Data

    List of Output Data The Data Storage Unit can output judgment values to external devices. Use of serial communication enables measurement values to be output. Judgment value Output path Description Controller I/O cable Captures the measurement results of tasks specified at [I/O SET], and outputs the results of judging the judgment conditions on the Data Storage Unit.

  • Page 55: Communication Using I/O Signals

    Communication Using I/O Signals Using the Controller I/O Cable By using the Data Storage Unit's I/O cable, you can output judgment results to external devices, or input a control signal from external devices. A predetermined I/O signal is assigned to each signal wire of the I/O cable. Wiring Brown Power supply (24 V)
  • Page 56 Assignment of input signal wires Function Signal Description Logging start START Starts logging. Logging end STOP Ends logging. Logging trigger TRIG When the logging condition is set to [TRIGGER], data during input of the TRIG signal is logged and saved. I/O Circuit Diagrams NPN type (ZG2-DSU11) Brown...
  • Page 57 NPN type (ZG2-DSU41) Brown 24 V DC HIGH Green PASS Load Black Load Pink ERROR Load Gray BUSY 24 V Load Load Blue GND (0 V) Yellow TRIG Light blue Purple START White STOP Orange Communication Using I/O Signals ZG2-DSU User’s Manual...

  • Page 58: Timing Charts

    Timing Charts This section explains the timing charts of the I/O signals that are exchanged between the Data Storage Unit and external devices. Logging Logging start Logging end START signal or ↑ key Copy to (1) Logging Memory Card (2) Logging cycle STOP signal or ↓...

  • Page 59: Transferring Bank Data

    Note Measurement cycle When the Data Storage Unit is connected, the measurement cycle of the Sensor Controllers increases according to the display mode of the Sensor Controller. • Profile display: approx. 150 to 300 ms (varies according to profile shape) •...

  • Page 60: Serial Communication

    Serial Communication You can use the USB port or RS-232C connector of the Data Storage Unit to perform serial communication with external devices such as a personal computer. Serial communication functions in the RUN mode. Serial communication functions are not available in the FUN mode or TEACH mode.

  • Page 61: Communication Commands

    Communication Commands Command/Response Format <Command> Command data Delimiter <Response> When processing ends successfully Response data Delimiter Delimiter When processing fails Delimiter Command data Specifies the command and parameters. Response data Stores the acquired data. Delimiter This control code indicates the end of the data. Configuration of measurement value data Acquired measurement values are output as a data structure of variable length of up to 12 characters (when the number of digits past the decimal point is set to 5) including...
  • Page 62 Sign The sign (+, -) of the measurement value is stored. When the integer section of the measurement value is less Integer than 3 characters, it is prefixed with spaces for the number of insufficient data. When the number of digits past the decimal point is reduced, the length of the text string decreases proportionately.

  • Page 63: Measurement Value Acquisition/Profile Acquisition Com

    Bank Control Commands Command Description Refere name BANKGET Acquires the current bank No. p.69 BANKSET Switches to the specified bank No. p.69 Utility commands Command Description Refere name CFFORMAT Initializes the Memory Card. p.70 Measurement Value Acquisition/Profile Acquisition Commands Acquire Logged Measurement Value <CFLOGGET command> This command acquires the measurement values saved on the Memory Card.
  • Page 64 <Response format> When processing ends successfully , • • • Acquisition time Measurement value of CH2 task 8 Measurement value of CH1 task 1 • • • Acquisition time Measurement value of CH1 task 1 Measurement value of CH1 task 2 Measurement value of CH2 task 8 •...
  • Page 65 Acquire Logged Profile <CFPRFGET command> This command acquires the profiles saved on the Memory Card. The specified file is received by XMODEM protocol. Important This command can be used only when the Data Storage Unit is connected with the USB cable. <Command format>...
  • Page 66 Acquire Measurement Value <MEASURE command> This command acquires measurement values set at [I/O SET]. <Command format> S U R E <Response format> When processing ends successfully Measurement value When processing fails <Explanation of parameters> Measurement value Measurement values set at [I/O SET] are acquired. Serial Communication ZG2-DSU User’s Manual...

  • Page 67: Bank Data Transfer Commands

    Bank Data Transfer Commands Transfer Bank Data to the Controller <BKMC2CTR command> This command transfers bank data stored on the Memory Card to a specified Sensor Controller. <Command format> B K M C 2 C T R Target Sensor Controller CH Bank file No.

  • Page 68: Setting Acquisition/Change Commands

    Setting Acquisition/Change Commands Acquire Setup Data <DATAGET command> This command acquires the setup data on the Data Storage Unit. <Command format> D A T A G E T Data No. Unit No. <Response format> When processing ends successfully DATA When processing fails Note For details on parameters, see "Parameter List (p.71)."...
  • Page 69 Save All Bank Data on the Data Storage Unit <DATASAVE command> This command saves all bank data to the Data Storage Unit's flash memory. <Command format> D A T A S A V E <Response format> When processing ends successfully When processing fails Acquire Version No.
  • Page 70 Acquire Number of Connected Devices <CHGET command> This command acquires the number of gang-mounted Sensor Controllers and Data Storage Units. <Command format> C H G E T Parameter No. <Response format> When processing ends successfully Number When processing fails <Explanation of parameters> Parameter No.

  • Page 71: Bank Control Commands

    Bank Control Commands Acquire Bank No. <BANKGET command> This command acquires the current bank No. <Command format> B A N K G E T <Response format> When processing ends successfully Bank No. (max. 1 digit) When processing fails <Explanation of parameters> Bank No.

  • Page 72: Utility Commands

    Utility Commands Initialize Memory Card <CFFORMAT command> This command initializes the Memory Card. <Command format> C F F O R M <Response format> When processing ends successfully When processing fails Serial Communication ZG2-DSU User’s Manual...

  • Page 73: Parameter List

    Parameter List Parameters Common to the DATAGET/DATASET Commands Targets for acquiring measurement values from Parameter Unit No. Parameter No. Measurement value/ acquisition value Measurement value of CH1 task 1 16 0: OFF, 1: ON Measurement value of CH1 task 2 Measurement value of CH1 task 3 Measurement value of CH1 task 4 Measurement value of CH1 task 5...
  • Page 74 Logging triggers Parameter Unit No. Parameter No. Measurement value/ acquisition value Logging condition 0 0: MEAS, 1: TRIGGER, 2: TIME, 3: POINT Channels targeted by 4 0: CH1, 1: CH2 measurement result trigger Measurement results 6 0: ALL, 1: NG+ERR, 2: targeted by NG, 3: ALL-PASS measurement result...
  • Page 75 APPENDICES Specifications and External Dimensions 74 Error Messages and Corrective Actions Menu List Basic Knowledge for Operation Updating the Firmware INDEX...

  • Page 76: Specifications And External Dimensions

    Specifications and External Dimensions Data Storage Unit Specifications Item ZG2-DSU11 ZG2-DSU41 I/O type Number of connected Sensor Controllers 2 (*1) Applicable Sensor Controllers ZG2-WDC11/WDC41 External I/F I/O signal wire Logging start/end ON: Short- ON: Supply input circuited with 0 V voltage short- or 1.5 V max., circuited or supply...
  • Page 77 Item ZG2-DSU11 ZG2-DSU41 Ratings Power supply voltage 21.6 V to 26.4 VDC (including ripple) Current consumption 0.5 A or less Operation Ambient temperature range Operating: 0 to 50°C environment Storage: 0 to 60°C robustness (with no icing or condensation) Ambient humidity range Operating and storage: 35% to 85% (with no condensation) Material...
  • Page 78 External Dimensions (Unit: mm) 59.85 52.50 10.80 13 10 Specifications and External Dimensions ZG2-DSU User’s Manual...

  • Page 79: Error Messages And Corrective Actions

    Transfer failed Bank file communication error Check the connection between Sensor Controllers. Dead Battery The clock backup battery has Please contact your OMRON run down. sales representative. Disp range Error The measurement results Change the number of digits exceed the displayed number of past the decimal point setting.
  • Page 80 Glossary Term Explanation Memory Card Media for saving and storing logging data. The Data Storage Unit uses compact flash cards. CSV file CSV stands for "Comma Separated Values". CSV files are documents containing individual data elements separated by a comma as their delimiter. CSV files can be browsed in generally available spreadsheet software.

  • Page 81: Menu List

    Menu List FUN Mode This mode is for setting the logging conditions. p.31 SOURCE VALUE TASK p.31 PROFILE p.32 • CH LOGGING MEAS •JUDGE p.33 TRIGGER p.33 TIME p.33 POINT • CH p.42 I/O SET SOURCE •TASK p.49 BANK CHANGE p.49 CLEAR p.20...
  • Page 82 RUN Mode This mode is for executing logging. It is also for setting up the content of the digital display and other display-related settings, and for making settings when using Memory Cards as an external bank. p.39 BANK CF→Controller p.38 Controller←CF p.46 DIGITAL...

  • Page 83: Basic Knowledge For Operation

    Basic Knowledge for Operation How to Select Menus Select items displayed on the LCD screen directly with the functions keys. Digital display LCD screen VALUE PROFILE LOGGING Select directly with the function keys. MENU Control keys TEACH Digital display Menu setting items are displayed using the following alphabet characters. Correspondence between alphabet A ...
  • Page 84 List of Key Operations Key functions differ according to the currently selected mode. FUN mode RUN mode TEACH mode During setup During measurement Function keys These keys directly set the No. These keys preceding the items displayed can be used on the LCD screen.

  • Page 85: Updating The Firmware

    Update the firmware by connecting the Data Storage Unit to the PC with the USB cable and using Warp Engine Zero. For the firmware update and Warp Engine Zero, please contact your OMRON represenatative. The update procedure is the same as that for the Sensor Controller. Refer to the Sensor Controller User's Manual.
  • Page 86 MEMO Updating the Firmware ZG2-DSU User’s Manual...

  • Page 87: Index

    INDEX Assignment ECO setting I/O cable External bank Saving Transferring Bank Clearing Switching Ferrite core BANKGET command Format BANKSET command FUN mode BKCTR2MC command BKMC2CTR command Gang-mounting CFFORMAT command CFLOGGET command CFPRFGET command CH number I/O circuit diagrams CHGET command Initialization Command format Communication commands...
  • Page 88 Conditions Ending How it works VERGET command Measurement value Number of Data Procedure Profile Starting Wiring MEASURE command Memory Card 20, 35, 44 File No. Folder structure Initializing NODE Output data Response format RS-232C RUN mode Save Serial communication 35, 58 System clock System Configuration TEACH mode...
  • Page 89 MEMO INDEX ZG2-DSU User’s Manual...

  • Page 90: Revision History

    Revision History A manual revision code appears as a suffix to the catalog number at the bottom of the front and back covers of this manual. Cat. No. Z289-E1-01 Revision code Revision code Revision date Revised content December 2008 First edition Revision History ZG2-DSU User’s Manual...
  • Page 91 Sensing Devices Division H.Q. Tel: (1) 847-843-7900/Fax: (1) 847-843-7787 Application Sensors Division Shiokoji Horikawa, Shimogyo-ku, OMRON ASIA PACIFIC PTE. LTD. Kyoto, 600-8530 Japan No. 438A Alexandra Road # 05-05/08 (Lobby 2), Tel: (81) 75-344-7068/Fax: (81) 75-344-7107 Alexandra Technopark, Singapore 119967...
