Page 1: Table Of Contents
Adjusting Oven Temperature ..21 Before You Call 22-23 Solutions to Common Problems ....Questions? 1-800-944-9044 (United States) 1-800-668-4606 (Canada) Warranty ......Back Page Visit the Frigidaire Web Site at: http://www.frigidaire.com p/n 316423402 rev A (0512) READ AND SAVE THESE INSTRUCTIONS...
Page 2: Welcome
Welcome & Congratulations Congratulations on your purchase of a new range! At Electrolux Home Products, we are very proud of our product and are completely committed to providing you with the best service possible. Your satisfaction is our number one priority. We know you’ll enjoy your new range and Thank You for choosing our product.
Page 3: Important Safety Instructions
Important Safety Instructions Read all instructions before using this appliance. Save these instructions for future reference. This manual contains important safety symbols and instructions. Please pay attention to these symbols and follow all instructions given. This symbol will help alert you to situations that may cause serious bodily harm, death or property damage. This symbol will help alert you to situations that may cause bodily injury or property damage.
Page 4 Important Safety Instructions IMPORTANT INSTRUCTIONS FOR USING YOUR IMPORTANT INSTRUCTIONS FOR USING YOUR OVEN COOKTOP • Use Care When Opening Oven Door or Warmer Drawer (if • Know which knob controls each surface heating unit. Place a equipped)—Stand to the side of the range when opening the door pan of food on the unit before turning it on, and turn the unit off of a hot oven.
Page 5: Features At A Glance
Features At A Glance Your Electric Range Features Include: 1. Electronic Oven Control with Kitchen Timer. 2. Left Front Single Radiant Element Control (some models) or Dual Radiant Element Control (some models). 3. Left Rear Single Radiant Element Control (some models) or Dual Radiant Element Control (some models).
Page 6: Before Setting Oven Controls
Before Setting Oven Controls Oven Vent Location The oven vent is located under the left side of the control panel (See Fig. 1). When the oven is on, warm air passes through the vent. This venting is necessary for proper air circulation in the oven and good baking results.
Page 7 Before Setting Oven Controls About the Ceramic Glass Cooktop The ceramic cooktop has radiant surface elements located below the surface of the glass. The design of the ceramic cooktop outlines the area of the surface element underneath. Be sure to match the pan size with the diameter of the element outline on the cooktop.
Page 8: Setting Surface Controls
Setting Surface Controls Using proper cookware The size and type of cookware used will influence the setting needed for best cooking results. Cookware should have flat bottoms that make good contact with the entire surface heating element (See Fig. 1). Check for flatness by rotating a ruler across the bottom of the cookware (See Fig.
Page 9 Setting Surface Controls To Operate Dual Radiant Surface Elements (some models) Symbols on the backguard are used to indicate which coil of the Dual Radiant element will heat. The symbol indicates the inner coil only. The symbol indicates both inner and outer coils will heat (See Figs. 1 & 2 and Suggested Radiant Surface Element Settings Table on previous page).
Page 10: Oven Control Functions
Oven Control Functions READ THE INSTRUCTIONS CAREFULLY BEFORE USING THE OVEN. For satisfactory use of your oven, become familiar with the various pad functions of the oven as described below. CLOCK BAKE TIME UP and DOWN ARROW PADS— Used along BAKE PAD—Used PAD—...
Page 11: Setting Oven Controls
Setting Oven Controls Note: The time of day must first be set in order to operate the oven. To Set the Clock When the range is first plugged in, or when the power supply to the range has been interrupted, the display will flash "12:00".
Page 12 Setting Oven Controls To Set or Change the Temperature for Baking The oven can be programmed to bake at any temperature from 170°F to 550°F (77°C to 287°C). To Set the Controls for Baking: 1. Press . "— — —" appears in the display. 2.
Page 13 Setting Oven Controls To Set the Timed Bake and Delay Start (Delayed Timed Bake) Features BAKE TIME and START TIME pads operate the features that will turn the oven ON and OFF at the times you select in advance. The oven can be programmed to start immediately and shut off automatically (Timed Bake) or to begin baking at a later time with a delayed start time (Delayed Timed Bake).
Page 14 Setting Oven Controls Speed Bake™ Cooking System Benefits of Speed Bake™ Cooking System: —Foods cook up to 25 to 30% faster, saving time and energy. —Multiple rack baking. —No special pans or bakeware needed. How the Speed Bake™ Cooking System works (some models) Speed Bake™...
Page 15 Setting Oven Controls To Set for Broiling: 1. Arrange the oven rack while oven is still cool. Position the rack as suggested in the Broil Rack Position Table below. 2. Press . " — — "will appear in display. 3. Press and hold the until the desired broil setting level appears in the display.
Page 16: Self Cleaning (Speed Clean)
Self-Cleaning During the Self-Cleaning cycle, the outside of the range can become very hot to the touch. DO NOT leave small children unattended near the appliance. The health of some birds is extremely sensitive to the fumes given off during the Self-Cleaning cycle of any range.
Page 17 Self-Cleaning Starting the Self-Clean Cycle or a Delayed Start Self-Clean Cycle (including Speed Clean) For satisfactory results, press the (Speed Clean) pad for a 2 hour Self-Clean cycle (for lighter soils). Press the (Clean) pad for a 3 hour cycle (for heavier soils). NOTE: The kitchen area should be well ventilated using an open window, ventitlation fan or exhaust hood during the 1st Self-Clean cycle.
Page 18: General Care & Cleaning
Care & Cleaning (Cleaning Table) Surfaces How to Clean Aluminum (Trim Pieces) & Vinyl Use hot, soapy water and a cloth. Dry with a clean cloth. Painted and Plastic Control Knobs, For general cleaning, use hot, soapy water and a cloth. For more difficult soils and Body Parts, and Decorative Trim built-up grease, apply a liquid detergent directly onto the soil.
Page 19 Consistent and proper cleaning is essential to maintaining your ceramic glass cooktop. Note: Additional cooktop cleaning cream may be ordered by visiting the Frigidaire website at www.frigidaire.com Prior to using your cooktop for the first time, apply some of the cooktop cleaning cream supplied with your new range. Buff with a non-abrasive cloth or no-scratch cleaning pad.
Page 20 Care & Cleaning Cleaning Recommendations for the Ceramic Glass Cooktop (cont’d) Do not use the following on the ceramic glass cooktop: • Do not use abrasive cleaners and scouring pads, such as metal and some nylon pads. They may scratch the cooktop, making it more difficult to clean. •...
Page 21: Adjusting Oven Temperature
Care & Cleaning Changing the Oven Light The oven light automatically turns ON when the door is opened. The oven light may also be manually operated by pressing the pad. The oven light bulb is located at the rear of the oven and is covered with a glass shield held by a wire holder.
Page 22: Before You Call
Before You Call Solutions to Common Problems Before you call for service, review this list. It may save you time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this appliance. OCCURRENCE POSSIBLE CAUSE/SOLUTION Range is not level.
Page 23 Before You Call Solutions to Common Problems POSSIBLE CAUSE/SOLUTION OCCURRENCE Oven light does not work. Replace or tighten bulb. See Changing Oven Light section in this Use & Care Manual. Oven smokes excessively during broiling. Control(s) not set properly. Follow instructions under Setting Oven Controls. Make sure oven door is opened to broil stop position.
Page 24: Warranty
Major Appliance Warranty Information Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.
