  • Page 2 Manual iBASE IB918 3,5“Single-Board Computer with AMD®Ryzen™V1000 / R1000 Embedded Processor The information contained in this document has been carefully researched and is, to the best of our knowledge, accurate. However, we assume no liability for any product failures or damages, immediate or consequential, resulting from the use of the information provided herein.
  • Page 3 IB918F AMD Ryzen™ Embedded V1000/R1000 3.5” Disk-Size SBC User’s Manual Version 1.0A...
  • Page 4 Copyright © 2020 IBASE Technology, Inc. All rights reserved. No part of this publication may be reproduced, copied, stored in a retrieval system, translated into any language or transmitted in any form or by any means, electronic, mechanical, photocopying, or otherwise, without the prior written consent of IBASE Technology, Inc.
  • Page 5 Compliance This is a class B product. In a domestic environment, this product may cause radio interference in which case users may be required to take adequate measures. This product has been tested and found to comply with the limits for a Class B device, pursuant to Part 15 of the FCC Rules.
  • Page 6 Important Safety Information Carefully read the precautions before using the board. Environmental conditions: • Use this product in environments with ambient temperatures between 0˚C and 60˚C. • Do not leave this product in an environment where the storage temperature may be below -20° C or above 80° C. To prevent from damages, the product must be used in a controlled environment.
  • Page 7 Warranty Policy • IBASE standard products: 24-month (2-year) warranty from the date of shipment. If the date of shipment cannot be ascertained, the product serial numbers can be used to determine the approximate shipping date. • -party parts: 12-month (1-year) warranty from delivery for the 3 -party parts that are not manufactured by IBASE, such as CPU, CPU cooler, memory, storage devices, power adapter, panel and touchscreen.

  • Page 8: Table Of Contents

    Table of Contents Chapter 1 General Information ..........1 Introduction ..................2 Features ....................2 Packing List ..................3 Optional Accessories ................3 Specifications ..................4 Block Diagram ..................6 Board Pictures ..................7 Dimensions ..................9 Chapter 2 Hardware Configuration ........11 Installations ..................
  • Page 9 Chapter 3 Drivers Installation ..........33 Introduction ..................34 AMD Ryzen™ V1000 Graphics Drivers ..........34 AMD Ryzen™ R1000 Graphics Drivers..........36 HD Audio Driver Installation ...............38 LAN Driver Installation ...............39 Observer ....................42 Chapter 4 BIOS Setup............45 Introduction ..................46 BIOS Setup ..................46 Main Settings ..................47 Advanced Settings ................47 Chipset Settings .................57...
  • Page 10 This page is intentionally left blank. viii IB918F User’s Manual...

  • Page 11: Chapter 1 General Information

    Chapter 1 General Information The information provided in this chapter includes: • Features • Packing List • Specifications • Block Diagram • Board Pictures • Board Dimensions...

  • Page 12: Introduction

    Introduction The IB918 3.5-inch SBC is powered by AMD Ryzen Embedded V1000/R1000 SoC and supports up to 32GB DDR4-2400 ECC memory modules. Storage and expansion sockets include a M.2 M-key interface, two M.2 slots for type 2280/2230 architectures. It is also equipped with 2x HDMI, 1x eDP, 2x GbE ports, 4x USB 3.1, 1x SATA III and a 12V~24V DC input.

  • Page 13: Packing List

    General Information Packing List Your product package should include the items listed below. If any of the items below is missing, contact the distributor or dealer from whom you purchased the product. • IB918F SBC • Disk (including chipset drivers) •...

  • Page 14: Specifications

    Specifications Product Name IB918F-1605 IB918F-1202 IB918F-1606G IB918F-1505G Form Factor 3.5” disk-size SBC • Windows 10 (64-bit) Operating System • Linux CPU & Chipset AMD Ryzen™ Embedded V1000 / R1000 APU onboard V1605B V1202B R1606G R1505G CPU TYPE 2 x DDR4-2400 SO-DIMM, expandable up to 32 GB, ECC Memory compatible Storage...
  • Page 15 General Information 4 x USB 3.1 I/O coastline connectors 1 x USB 3.1: via an on-board 1 x USB 2.0: via an on-board pin headers(V1000 only) pin headers(R1000 only) 4 x COM ports: • COM1: RS-232/422/485 (edge I/O connectors, jumper-less Serial selection) •...

  • Page 16: Block Diagram

    Block Diagram IB918F User’s Manual...

  • Page 17: Board Pictures

    General Information Board Pictures Top and bottom View ＊The photos above are for reference only. Some minor components may differ. IB918F User’s Manual...
  • Page 18 I/O View Name COM1 Port (CN2) Dual GbE LAN Ports (CN3) HDMI Port (CN4) HDMI Port (CN5) USB 3.1 Ports (CN6) USB 3.1 Ports (CN7) IB918F User’s Manual...

  • Page 19: Dimensions

    General Information Dimensions IB918F User’s Manual...
  • Page 20 This page is intentionally left blank. IB918F User’s Manual...

  • Page 21: Chapter 2 Hardware Configuration

    Chapter 2 Hardware Configuration This section provides information on jumper settings and connectors on the board in order to set up a workable system. The topics covered are: • Memory Installation • Jumper and connector locations • Jumper settings and connectors information...

  • Page 22: Installations

    Installations 2.1.1 Installing the Memory To install the modules, locate the memory slot (J4, J7) on the board and perform the following steps: Align the key of the memory module with that on the memory slot and insert the module slantwise. Gently push the module in an upright position until the clips of the slot close to hold the module in place when the module touches the bottom of the slot.

  • Page 23: Setting The Jumpers

    Hardware Configuration Setting the Jumpers Set up and configure your board by using jumpers for various settings and features according to your needs and applications. Contact your supplier if you have doubts about the best configuration for your use. 2.2.1 How to Set Jumpers Jumpers are short-length conductors consisting of several metal pins with a non-conductive base mounted on the circuit board.

  • Page 24: Jumper & Connector Locations On Ib918F

    Jumper & Connector Locations on IB918F IB918F User’s Manual...

  • Page 25: Jumpers Quick Reference

    Hardware Configuration Jumpers Quick Reference Function Jumper Page LCD Panel Power Selection PWM Backlight Control Level eDP Panel Power Selection ATX / AT Power Selection Clear CMOS Data 2.4.1 LCD Panel Power Selection (JP2) Function Pin closed Illustration 3.3V (default) IB918F User’s Manual...

  • Page 26: Pwm Backlight Control Level (Jp3)

    2.4.2 PWM Backlight Control Level (JP3) Function Pin closed Illustration 3.3V (default) 2.4.3 eDP Panel Power Selection (JP1) Function Pin closed Illustration 3.3V (default) IB918F User’s Manual...

  • Page 27: Atx / At Power Selection (Jp5)

    Hardware Configuration 2.4.4 ATX / AT Power Selection (JP5) Function Pin closed Illustration ATX Mode AT Mode IB918F User’s Manual...

  • Page 28: Clear Cmos Data (Jp4)

    2.4.5 Clear CMOS Data (JP4) Function Pin closed Illustration Normal (default) Clear CMOS IB918F User’s Manual...

  • Page 29: Connectors Quick Reference

    Hardware Configuration Connectors Quick Reference Function Connector Name Page eDP Connector COM2/COM3 & COM4 RS-232 J18(COM2) / J16(COM3) Ports / J15(COM4) COM1 RS-232/422/485 Ports DC-In Power Connector LCD Backlight Connector J3 (Channel A), LVDS Connector J5 (Channel B) SATA Power Connector Digital I/O Connector Front Panel Settings Connector Speaker Connector...

  • Page 30: Edp Connector (Cn1)

    2.5.1 eDP Connector (CN1) Signal Signal +3.3V (default) / +5V TXN0 +3.3V (default) / +5V TXP0 +3.3V (default) / +5V Ground +3.3V (default) / +5V AUXP +3.3V (default) / +5V AUXN Ground Ground VCC3 Ground VCC12 Ground HOT PLUG Ground Ground VCC5 Brightness...

  • Page 31: Com2 (J18) & Com3 (J16) & Com4 (J15) Rs-232 Ports

    Hardware Configuration 2.5.2 COM2 (J18) & COM3 (J16) & COM4 (J15) RS-232 Ports Signal Signal DCD, Data carrier detect RXD, Receive data TXD, Transmit data DTR, Data terminal ready Ground DSR, Data set ready RTS, Request to send CTS, Clear to send RI, Ring indicator Not Used IB918F User’s Manual...

  • Page 32: Com1 Rs-232/422/485 Ports (Cn2)

    2.5.3 COM1 RS-232/422/485 Ports (CN2) COM1 RS-232/422/485 ports are jumper-less and configurable in BIOS. Signal Name Signal Name DCD, Data carrier detect DSR, Data set ready RXD, Receive data RTS, Request to send TXD, Transmit data CTS, Clear to send DTR, Data terminal ready RI, Ring indicator Ground...

  • Page 33: Dc-In Power Connector (J14)

    Hardware Configuration 2.5.4 DC-In Power Connector (J14) Signal Signal +12V ~ +24V Ground 2.5.5 LCD Backlight Connector (J6) Signal Signal +12V Brightness Control Backlight Enable Ground IB918F User’s Manual...

  • Page 34: Lvds Connector (J3, J5)

    2.5.6 LVDS Connector (J3, J5) Signal Signal Name TX0+ TX0- Ground Ground TX1+ TX1- Ground Ground TX2+ TX2- Ground Ground TXC+ TXC- Ground Ground TX3+ TX3- +3.3 / +5V +3.3 / +5V IB918F User’s Manual...

  • Page 35: Sata Power Connector (J13)

    Hardware Configuration 2.5.7 SATA Power Connector (J13) Signal Signal Ground Ground +12V 2.5.8 Digital I/O Connector (J19) Signal Signal Ground OUT3 OUT1 OUT2 OUT0 IB918F User’s Manual...

  • Page 36: Front Panel Settings Connector (J12)

    2.5.9 Front Panel Settings Connector (J12) Signal Signal Power BTN- Power BTN+ HDD LED+ HDD LED- Reset BTN- Reset BTN+ Power LED+ Power LED- J12 is utilized for system indicators to provide light indication of the computer activities and switches to change the computer status. It provides interfaces for the following functions.

  • Page 37: Speaker Connector (J2)

    Hardware Configuration 2.5.10 Speaker Connector (J2) Signal Signal Speaker-L+ Speaker-R- Speaker-L- Speaker-R+ IB918F User’s Manual...

  • Page 38: Audio Connector (J1)

    2.5.11 Audio Connector (J1) Signal Signal Lineout_L Lineout_R JD_FRONT Ground LINEIN_L Linein_R JD_LINEIN Ground MIC_L MIC-R JD_MIC1 Ground IB918F User’s Manual...

  • Page 39: Fan Power Connectors (Cpu_Fan1)

    Hardware Configuration 2.5.12 Fan Power Connectors (CPU_FAN1) CPU_FAN1: CPU fan power connector Signal Name Signal Name Ground Rotation detection +12V Control 2.5.13 SATA III Connector (SATA1) IB918F User’s Manual...

  • Page 40: Dual Gbe Lan Port (Cn3)

    2.5.14 Dual GbE LAN Port (CN3) 2.5.15 HDMI Ports (CN4, CN5) 2.5.16 Dual USB 3.1 Ports (CN6, CN7) Remarks: For the IB918F R1000 version, CN7 will not achieve the USB 3.1 Gen 2 transfer speed. IB918F User’s Manual...

  • Page 41: E Key) 2230 Slot (J8)

    Hardware Configuration 2.5.17 M.2 (E key) 2230 Slot (J8) 2.5.18 M.2 (M key) 2280 Slot (J11) IB918F User’s Manual...

  • Page 42: Usb 3.1 /2.0 Ports (J10)

    2.5.19 USB 3.1 /2.0 Ports (J10) USB 3.1: via an on-board pin headers (V1000 only) USB 2.0: via an on-board pin headers (R1000 only) Signal Signal VCC5 Ground VCC5 Ground Ground Ground IB918F User’s Manual...

  • Page 43: Chapter 3 Drivers Installation

    Chapter 3 Drivers Installation This chapter introduces installation of the following drivers: • AMD Ryzen™ V1000/R1000 Graphics Driver • HD Audio Driver • LAN Driver...

  • Page 44: Introduction

    Introduction This section describes the installation procedures for software and drivers. The contents of this section include the following: AMD Ryzen™ V1000 Graphics Drivers Insert the disk enclosed in the package. Click AMD on the left pane and then AMD Ryzen V1000 Drivers on the right pane. Click AMD Ryzen V1000 Graphics Drivers.
  • Page 45 Driver Installation Now click Accept and Install to proceed. Choose and click on either Express Install or Custom Install. When the software driver has been installed, restart the computer for changes to take effect. IB918F User’s Manual...

  • Page 46: Amd Ryzen™ R1000 Graphics Drivers

    AMD Ryzen™ R1000 Graphics Drivers Insert the disk enclosed in the package. Click AMD on the left pane and then AMD Ryzen R1000 Drivers on the right pane. Click AMD Ryzen R1000 Graphics Drivers. IB918F User’s Manual...
  • Page 47 Driver Installation Read the software license agreement and click Accept and Install to proceed. Choose and click on either Express Install or Custom Install. When the software driver has been installed, restart the computer for changes to take effect. IB918F User’s Manual...

  • Page 48: Hd Audio Driver Installation

    HD Audio Driver Installation Insert the disk enclosed in the package with the board. Click AMD on the left pane and then Realtek High Definition Audio Driver on the right pane. On the Welcome screen of the InstallShield Wizard, click Next. Follow the steps accordingly.

  • Page 49: Lan Driver Installation

    Driver Installation LAN Driver Installation Insert the disk enclosed in the package. Click LAN Card on the left pane and Intel LAN Controller Drivers on the right pane. Click Intel(R) I21x Gigabit Networks Drivers. IB918F User’s Manual...
  • Page 50 When the Welcome screen appears, click Next. Choose “I accept the terms in the license agreement” and click Next. Click Next after selecting the program features as shown below. IB918F User’s Manual...
  • Page 51 Driver Installation On the next screen, click Install to install the program. When the wizard has successfully installed the Program, restart your computer for changes to take effect. IB918F User’s Manual...

  • Page 52: Observer

    Observer Insert the disk enclosed in the package with the board. Click Tools on the left pane and then Observer on the right pane. Click Next when the Welcome screen appears and to continue installing the Observer on your computer. IB918F User’s Manual...
  • Page 53 Driver Installation The next screen shows the destination location where Observer will be installed. Click Next. Setup is now ready to begin installing Observer on your computer. Click Install. IB918F User’s Manual...
  • Page 54 To complete the installation of Observer, Setup must restart your computer. Restart the computer (click Finish) for changes to take effect. IB918F User’s Manual...

  • Page 55: Chapter 4 Bios Setup

    Chapter 4 BIOS Setup This chapter describes the different settings available in the AMI BIOS that comes with the board. The topics covered in this chapter are as follows: • Main Settings • Advanced Settings • Chipset Settings • Boot Settings •...

  • Page 56: Introduction

    4.1 Introduction The BIOS (Basic Input/Output System) installed in the ROM of your computer system supports AMD APU. The BIOS provides critical low-level support for standard devices such as disk drives, serial ports and parallel ports. It also provides password protection as well as special support for detailed fine-tuning of the chipset controlling the entire system.

  • Page 57: Main Settings

    BIOS Setup 4.3 Main Settings BIOS Setting Description Sets the date. Use the <Tab> key to switch System Date between the data elements. Set the time. Use the <Tab> key to switch System Time between the data elements. 4.4 Advanced Settings This section allows you to configure, improve your system and allows you to set up some system features according to your preference.
  • Page 58 4.4.1 Trusted Computing Settings BIOS Setting Description Enables or Disables BIOS support for security Security Device device. OS will now show Security Device. TCG Support EFI protocol and INT1A interface will not be available (Default: Enable) Enable or Disable (Default: Enable) SHA-1 PCR Bank SHA-256 PCR Bank Enable or Disable (Default: Enable)
  • Page 59 BIOS Setup 4.4.2 ACPI Settings BIOS Setting Description Enables / Disables BIOS ACPI auto Enable ACPI Auto Configuration configuration. Enables / Disables the system ability to Enable Hibernation hibernate (OS/S4 Sleep State). This option may be not effective with some OS. Selects an ACPI sleep state where the system ACPI Sleep State will enter when the Suspend button is pressed.
  • Page 60 4.4.4 LVDS Configuration BIOS Setting Description Enables / Disables the LVDS function. LVDS Control When enabled, LVDS Control will show the following items with their options: 1. Panel Color Depth: 18 BIT / 24 BIT 2. LVDS Channel Type: Single / Dual 3.
  • Page 61 BIOS Setup IB918F User’s Manual...
  • Page 62 4.4.6 Hardware Monitor BIOS Setting Description CPU Fan Smart Fan Enables / Disables the CPU smart fan feature. Control Temperatures / Fan The values are read-only values as monitored by Speed / Voltages the system and show the PC health status. CPU Shutdown Enables / Disables the CPU shutdown Temperature...
  • Page 63 BIOS Setup 4.4.7 CPU Configuration BIOS Setting Description Node 0 Information Displays the memory information related to Node 0. 4.4.8 AMI Graphic Output Protocol Policy BIOS Setting Description Output Select Allows you to select an output interface. IB918F User’s Manual...
  • Page 64 4.4.9 USB Configuration BIOS Setting Description Enables Legacy USB support. • Auto disables legacy support if there is no Legacy USB Support USB device connected. • Disable keeps USB devices available only for EFI applications. This is a workaround for OSes without XHCI XHCI Hand-off hand-off support.
  • Page 65 BIOS Setup 4.4.10 CSM Configuration BIOS Setting Description CSM Support Enables / Disables CSM support. Controls the execution of UEFI and Legacy PXE OpROM. Network Options: Do not launch UEFI / Legacy 4.4.11 NVMe Configuration 4.4.12 Network Stack Configuration BIOS Setting Description Network Stack Enables / Disables UEFI Network Stack.
  • Page 66 4.4.13 AMD CBS BIOS Setting Description This is for the NB configuration for IOMMU NB Common Options settings and system configuration. FCH Common Here you can set the AC loss control method with options of: Always Off / Always On Options IB918F User’s Manual...

  • Page 67: Chipset Settings

    BIOS Setup 4.5 Chipset Settings 4.5.1 SB USB Configuration BIOS Setting Description SB USB Configuration Options for SB USB Configuration. 4.5.1.1. XHCI Ports BIOS Setting Description Enables / Disables the XHCI0 & XHCI1 ports XHCI0 & XHCI1 Ports (XHCI/EMCI). IB918F User’s Manual...

  • Page 68: Security Settings

    4.6 Security Settings BIOS Setting Description Administrator Sets an administrator password for the setup Password utility. User Password Sets a user password. Single Thread Indirect Branch Predictor (STIBP) is a method to mitigate indirect branch target STIBP Status injection attacks on AMD products. Options: Disabled, Enabled Secure Boot feature is Active if Secure Boot is enabled.

  • Page 69: Boot Settings

    BIOS Setup 4.7 Boot Settings BIOS Setting Description Setup Prompt Number of seconds to wait for setup activation Timeout key. 65535(0xFFFF) means indefinite waiting. Bootup NumLock Selects the keyboard NumLock state. State Quiet Boot Enables / Disables Quiet Boot option. Boot mode select Selects a Boot mode, Legacy / UEFI.

  • Page 70: Save & Exit

    4.8 Save & Exit BIOS Setting Description Save Changes and Exits system setup after saving the changes. Exit Discard Changes and Exits system setup without saving any changes. Exit Save Changes and Resets the system after saving the changes. Reset Discard Changes and Resets system setup without saving any Reset...

  • Page 71: Appendix

    Appendix This section provides the mapping addresses of peripheral devices, the sample code of watchdog timer configuration, and types of on-board connectors.

  • Page 72: I/O Port Address Map

    I/O Port Address Map Each peripheral device in the system is assigned a set of I/O port addresses which also becomes the identity of the device. The following table lists the I/O port addresses used. Address Device Description 0x00000A00-0x00000A0F Motherboard resources 0x00000A10-0x00000A1F Motherboard resources 0x00000A20-0x00000A2F...
  • Page 73 Appendix Address Device Description 0x00000022-0x0000003F Motherboard resources 0x00000063-0x00000063 Motherboard resources 0x00000065-0x00000065 Motherboard resources 0x00000067-0x0000006F Motherboard resources 0x00000072-0x0000007F Motherboard resources 0x00000080-0x00000080 Motherboard resources 0x00000084-0x00000086 Motherboard resources 0x00000088-0x00000088 Motherboard resources 0x0000008C-0x0000008E Motherboard resources 0x00000090-0x0000009F Motherboard resources 0x000000A2-0x000000BF Motherboard resources 0x000000B1-0x000000B1 Motherboard resources 0x000000E0-0x000000EF Motherboard resources 0x000004D0-0x000004D1...
  • Page 74 Address Device Description 0x00000900-0x0000090F Motherboard resources 0x00000910-0x0000091F Motherboard resources 0x00000061-0x00000061 System speaker 0x00000081-0x00000083 Direct memory access controller 0x00000087-0x00000087 Direct memory access controller 0x00000089-0x0000008B Direct memory access controller 0x0000008F-0x0000008F Direct memory access controller 0x000000C0-0x000000DF Direct memory access controller IB918F User’s Manual...

  • Page 75: Interrupt Request Lines (Irq)

    Appendix Interrupt Request Lines (IRQ) Peripheral devices use interrupt request lines to notify CPU for the service required. The following table shows the IRQ used by the devices on board. Level Function IRQ 4294967292 PCI Express Root Port IRQ 0 High precision event timer IRQ 0 System timer...
  • Page 76 Level Function IRQ 53 AMD Audio CoProcessor IRQ 54 AMD High Definition Audio Controller IRQ 54 Microsoft ACPI-Compliant System IRQ 55 Microsoft ACPI-Compliant System IRQ 55 AMD SFH KMDF I2C IRQ 56 ~ IRQ 204 Microsoft ACPI-Compliant System IRQ 256 ~ IRQ 511 Microsoft ACPI-Compliant System IRQ 4294967294 PCI Express Root Port...
  • Page 77 Appendix Level Function IRQ 4294967286 Intel(R) I211 Gigabit Network Connection #5 IRQ 4294967285 Intel(R) I211 Gigabit Network Connection #5 IRQ 4294967284 Intel(R) I211 Gigabit Network Connection #5 IRQ 4294967283 Intel(R) I211 Gigabit Network Connection #5 IRQ 4294967282 Intel(R) I211 Gigabit Network Connection #5 IRQ 4294967281 Intel(R) I211 Gigabit Network Connection #6 IRQ 4294967280...

  • Page 78: Watchdog Timer Configuration

    Watchdog Timer Configuration The Watchdog Timer (WDT) is used to generate a variety of output signals after a user programmable count. The WDT is suitable for use in the prevention of system lock-up, such as when software becomes trapped in a deadlock.
  • Page 79 Appendix Sample Code: The file MAIN.CPP //--------------------------------------------------------------------------- // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE.
  • Page 80 void WDTEnable(unsigned char NewInterval) unsigned char bBuf; Set_NCT6116D_LD(0x08); //switch to logic device 8 Set_NCT6116D_Reg(0x30, 0x01); //enable timer bBuf = Get_NCT6116D_Reg(0xF0); bBuf &= (~0x08); Set_NCT6116D_Reg(0xF0, bBuf); //count mode is second Set_NCT6116D_Reg(0xF1, NewInterval); //set timer //--------------------------------------------------------------------------- void WDTDisable(void) Set_NCT6116D_LD(0x08); //switch to logic device 8 Set_NCT6116D_Reg(0xF1, 0x00);...
  • Page 81 Appendix Sample Code: The file NCT6116D.CPP //--------------------------------------------------------------------------- // THIS CODE AND INFORMATION IS PROVIDED "AS IS" WITHOUT WARRANTY OF ANY // KIND, EITHER EXPRESSED OR IMPLIED, INCLUDING BUT NOT LIMITED TO THE // IMPLIED WARRANTIES OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR // PURPOSE.
  • Page 82 void Lock_NCT6116D (void) outportb(NCT6116D_INDEX_PORT, NCT6116D_LOCK); //--------------------------------------------------------------------------- void Set_NCT6116D_LD( unsigned char LD) Unlock_NCT6116D(); outportb(NCT6116D_INDEX_PORT, NCT6116D_REG_LD); outportb(NCT6116D_DATA_PORT, LD); Lock_NCT6116D(); //--------------------------------------------------------------------------- void Set_NCT6116D_Reg( unsigned char REG, unsigned char DATA) Unlock_NCT6116D(); outportb(NCT6116D_INDEX_PORT, REG); outportb(NCT6116D_DATA_PORT, DATA); Lock_NCT6116D(); //--------------------------------------------------------------------------- unsigned char Get_NCT6116D_Reg(unsigned char REG) unsigned char Result; Unlock_NCT6116D();...

  • Page 83: Onboard Connector Types

    Appendix Onboard Connector Types Connector Compatible Mating Function Onboard Type Name Type for Reference DC-In Power JST B2P-VH JST VHR-2N Connector LCD Backlight E-Call Connector 0110-161-040 PHR-4 LVDS Hirose Hirose J3, J5 Connector DF20F-20DP-1V DF20A-20DS-1C SATA Power Hao Guo Xing Ye Connector WAFER25-104S-2442-ST XHP-4...
  • Page 84 Our company network supports you worldwide with offices in Germany, Austria, Switzerland, the UK and the USA. For more information please contact: Headquarters Germany FORTEC Elektronik AG Augsburger Str. 2b 82110 Germering Phone: +49 89 894450-0 E-Mail: info@fortecag.de Internet: www.fortecag.de Fortec Group Members Distec GmbH Office Vienna Austria...
