Quick Start Guide
Serial Adapter Cable
Model: B055-001-SER
The B055-001-SER Adapter Cable connects a serial device to the KVM switch.
Configuration
To configure the B055-001-SER to interact with the connected device, you need to set
its serial parameters to match the parameters of the device:
Note: The B055-001-SER settings cannot be directly accessed from the Web Browser OSD. When in the Web
Browser OSD, you must access a connected computer/server, and then re-open the OSD using the GUI icon
.
You will then be able to access the B055-001-SER settings via the steps below. The Local Console and Non-
Browser OSDs allow you to directly access these settings.
1. In the Port Access page sidebar, select the port that the B055-001-SER is connected to.
2. Select the Port Configuration tab on the menu bar.
1111 W. 35th Street, Chicago, Il 60609 USA • www.tripplite.com/support
Copyright © 2013 Tripp Lite. All rights reserved. All trademarks are the property of their respective owners.
13-01-153-932934-revB.indd 1
1/30/2013 3:28:33 PM
