- Page 1 ™ USER MANUAL 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com Snapshot OK on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave Autoswitching Transformer Replaceable Fuse User Serviceable Duty Cycle...
-
Page 2: Table Of Contents
ABLE OF ONTENTS 1. Before You Begin ... 3 What is included ... 3 Unpacking Instructions ... 3 AC Power ... 3 Contact Us ... 3 Safety Instructions ... 4 2. Introduction ... 5 Features ... 5 DMX Channel Summary ... 5 Product Overview ... -
Page 3: Before You Begin
0% to 100% switch. Contact Us W o r l d W i d e General Information Technical Support World Wide Web Vue™ 4.1 User Manual EGIN CHAUVET 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115 fax: 954.929.5560 toll free: 800.762.1084... -
Page 4: Safety Instructions
There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. Vue™ 4.1 User Manual 7/11/2008 11:57 AM... -
Page 5: Introduction
2. I NTRODUCTION Features • 9-channel DMX-512 LED rotating moon flower • Blackout/static/strobe • Individual control of red, green, blue, white and amber LEDs within each cluster (6 total) • Variable speed of motor • Built-in automated programs via DMX •... -
Page 6: Product Overview
Product Overview Tilt Adjustment Knob Slide Rail Digital Display Microphone DMX Input Connector Output Connector Vue™ 4.1 User Manual Hanging Bracket Front Lens Sound Sensitivity Knob Power Output Connector AC Power Input & Fuse 7/11/2008 11:57 AM... -
Page 7: Setup
Maximum recommended number of fixtures on a serial data link: 32 fixtures Data Cabling To link fixtures together you must obtain data cables. You can purchase CHAUVET-certified DMX cables directly from a dealer/distributor or construct your own cable. If you choose to create your own cable please use data-grade cables that can carry a high quality signal and are less prone to electromagnetic interference. -
Page 8: Cable Connectors
If you use a controller with a 5 pin DMX output connector, you will need to use a 5 pin to 3 pin adapter. Note! Note! CHAUVET Model No: DMX5M, or DMX5F. CHAUVET Model No: DMX5M, or DMX5F. The chart below details a proper cable conversion:... -
Page 9: Master/Slave Fixture Linking
Master/Slave Fixture Linking 1. Connect the (male) 3 pin connector side of the DMX cable to the output (female) 3 pin connector of the first fixture. 2. Connect the end of the cable coming from the first fixture which will have a (female) 3 pin connector to the input connector of the next fixture consisting of a (male) 3 pin connector. -
Page 10: Operating Instructions
4. O PERATING Display Options Menu Functions UNCTION ELECTION SET.d d:001-d:512 SET.S S:001-s:100 SET.f F:000-f:100 SET.A A:000-a:042 SUND AUTO Navigating the menu 1. Press Mode to scroll through the menu options. 2. Press Enter to select a function to modify. 3. -
Page 11: Operation
Operation Stand-Alone Mode (Sound-Active, Auto Mode): This mode allows a single unit to run to the beat of the music, or the unit will auto change in Auto Mode. There is an LED indicator on the rear of the fixture which will indicate this mode. SET.A to choose the desired program. -
Page 12: Dmx Channel Values
DMX Channel Values HANNEL ALUE Vue™ 4.1 User Manual UNCTION Control/Operating Mode Individual cluster control with channels 2~7 Auto 1 Auto 2 Auto 3 Auto 4 Auto 5 Auto 6 Auto 7 Auto 8 Auto 9 Auto 10 Auto 11 Auto 12 Auto 13 Auto 14... - Page 13 Vue™ 4.1 User Manual Cluster 1~6 Blackout Red 1 White 1 Red 2 Green 1 Blue 1 Amber 1 Red/White Red/Red Red/Green Red/Blue Red/Amber Red/White Green/White Blue/White Amber/White Green/Red Blue/Red Amber/Red Blue/Green Amber/Green Amber/Blue Red/Red/White Red/Green/White Red/Blue/White Red/Amber/White Red/Green/Red Red/Blue/Red Red/Amber/Red Red/Blue/Green Red/Amber/Green...
-
Page 14: Setting The Starting Address
SETTING TH E STAR TING ADDRESS This DMX mode enables the use of a universal DMX controller device. Each fixture requires a "start address" from 1 to 512. A fixture requiring one or more channels for control begins to read the data on the channel indicated by the start address. - Page 15 DMX Address Quick Reference Chart DMX DIP #9 0 0 0 SWITCH SET 0=OFF #8 0 0 0 1=ON #7 0 0 1 X=OFF or ON #6 0 1 0 #1 #2 #3 #4 #5 0 0 0 0 0 32 64 96 128 160 192 224 256 288 320 352 384 416 448 480 1 0 0 0 0 1 33 65 97 129 161 193 225 257 289 321 353 385 417 449 481...
-
Page 16: Blow-Out Diagram
Blow-out Diagram Description 1 LED PCB assembly 2 Front Fresnel lens 3 Bracket adjustment knob (of 2) 4 Electronic transformer 5 Display PCB 6 Master PCB 7 Stepper motor Vue™ 4.1 User Manual Part Number P222‐VUE41 P150‐VU2LNS P111‐VUEBRT P140‐ VUEIITR P172‐VUE41 P177‐VUE41 P110‐VUE41 7/11/2008 11:57 AM... - Page 17 Vue™ 4.1 User Manual 7/11/2008 11:57 AM...
- Page 18 Vue™ 4.1 User Manual 7/11/2008 11:57 AM...
- Page 19 Display PCB Schematics Display PCB Schematics Vue™ 4.1 User Manual 7/11/2008 11:57 AM...
- Page 20 Vue™ 4.1 User Manual 7/11/2008 11:57 AM...
-
Page 21: Vue 4.1 Maintenance Guide
-Note: In the event of Master PCB failure, a replacement PCB can be ordered directly from CHAUVET If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. -
Page 22: Technical Support
XLR male to female connectors. The shield connection is pin 1, while pin 2 is Data Negative (S-) and pin 3 is Data positive (S+). CHAUVET carries 3-pin XLR DMX compliant cables, DMX-10 (33’), DMX-4.5 (15’) and DMX-1.5 (5’) Vue™... -
Page 23: General Maintenance
Package must be clearly labeled with a Return Merchandise Authorization Number (RMA #). Products returned without an RMA # will be refused. Call CHAUVET and request RMA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 24: Technical Specifications
Technical Specifications WEIGHT & DIMENSIONS Length... 11.3 in (286 mm) Width ... 12.4 in (315 mm) Height ... 10.4 in (264 mm) Weight ... 7.5 lbs (3.4 kg) POWER Auto-switching AC power ... 100V-240V AC 50/60Hz Fuse ... 2A 250V Power Consumption ...
