DECLARATION OF CONFORMITY
Per FCC Part 2 Section 2. 1077(a)
Responsible Party Name: G.B.T. INC.
Address: 18305 Valley Blvd., Suite#A
LA Puent, CA 91744
Phone/Fax No: (818) 854-9338/ (818) 854-9339
hereby declares that the product
Product Name:
Mother Board
Model Number:
GA-6CXC
Conforms to the following specifications:
FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a),
Class B Digital Device
Supplementary Information:
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful
and
(2)
this device must accept any inference received, including
that may cause undesired operation.
Representative Person's Name:
ERIC LU
Eric Lu
Eric Lu
Signature:
Date:
Dec.03,1999
reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the
following measures:
-Reorient or relocate the receiving antenna
-Move the equipment away from the receiver
-Plug the equipment into an outlet on a circuit different from that to which
the receiver is connected
-Consult the dealer or an experienced radio/television technician for
additional suggestions
You are cautioned that any change or modifications to the equipment not
expressly approve by the party responsible for compliance could void Your
authority to operate such equipment.
This device complies with Part 15 of the FCC Rules. Operation is subjected to
the following two conditions 1) this device may not cause harmful interference
and 2) this device must accept any interference received, including
interference that may cause undesired operation.
FCC Compliance Statement:
This equipment has been tested and found to
comply with limits for a Class B digital device ,
pursuant to Part 15 of the FCC rules. These
limits are designed to provide reasonable
protection against harmful interference in
residential
installations.
generates,
uses,
frequency energy, and if not installed and used
in accordance with the instructions, may cause
harmful interference to radio communications.
However,
there
interference will not occur in a particular
installation. If this equipment does cause
interference to radio or television equipment
This
equipment
and
can
radiate
is
no
guarantee
radio
that

Advertisement

Table of Contents
loading

Summary of Contents for Gigabyte GA-6CXC

  • Page 1 Phone/Fax No: (818) 854-9338/ (818) 854-9339 hereby declares that the product Product Name: Mother Board Model Number: GA-6CXC Conforms to the following specifications: FCC Part 15, Subpart B, Section 15.107(a) and Section 15.109(a), Class B Digital Device Supplementary Information: This device complies with part 15 of the FCC Rules. Operation is subject to the...
  • Page 2: Declaration Of Conformity

    Safety of household and similar electrical appliances (Stamp) Declaration of Conformity We, Manufacturer/Importer (full address) G.B.T. Technology Träding GMbH declare that the product Mother Board GA-6CXC is in conformity with EN 61000-3-2* EN60555-2 EN61000-3-3* EN60555-3 EN 50081-1 EN 50082-1 EN 55081-2...
  • Page 3 6CXC/6CXC-1 Pentium II / III Processor Motherboard USER'S MANUAL Pentium II / III Processor MAINBOARD REV. 3.1 First Edition R-31-01-000120...
  • Page 4 How this manual is organized This manual is divided into the following sections: 1) Revision List 2) Item Checklist 3) Features 4) Hardware Setup 5) Performance & Block Diagram 6) Suspend to RAM & Dual BIOS 7) BIOS Setup 8) Appendix Manual revision information Product item list Product information &...
  • Page 5: Table Of Contents

    Revision History Item Checklist Summary of Features 6CXC/6CXC-1 Motherboard Layout Page Index for CPU Speed Setup / Connectors / Panel and Jumper Definition Performance List Block Diagram Suspend to RAM Installation Dual BIOS Introduction Memory Installation Page Index for BIOS Setup Appendix Table Of Content P.28...
  • Page 7: Revision History

    6CXC/6CXC-1 Motherboard Revision History Revision Revision Note Initial release of the 6CXC/6CXC-1 motherboard user’s manual. The author assumes no responsibility for any errors or omissions that may appear in this document nor does the author make a commitment to update the information contained herein. Third-party brands and names are the property of their respective owners.
  • Page 8: Item Checklist

    Item Checklist Item Checklist þThe 6CXC/6CXC-1 Motherboard þCable for IDE / Floppy device þCD (IUCD) for motherboard utilities oInternal COMB Cable (Optional) oInternal USB Cable (Optional) oCable for SCSI device þ6CXC/6CXC-1 User’s Manual...
  • Page 9: Summary Of Features

    6CXC/6CXC-1 Motherboard Summary of Features Form factor Ÿ Ÿ Ÿ Chipset Ÿ Ÿ Ÿ Clock Generator Ÿ Ÿ Memory Ÿ I/O Control Ÿ Slots Ÿ Ÿ Ÿ Ÿ On-Board IDE Ÿ Ÿ On-Board Ÿ Peripherals Ÿ Ÿ Ÿ Ÿ Hardware Monitor Ÿ...
  • Page 10 Summary of Features interface To be continued…...
  • Page 11 BIOS Ÿ Ÿ Additional Features Ÿ Ÿ Ÿ Ÿ Ÿ Ÿ Ÿ Licensed AMI BIOS, 4M bit FWH Support Dual BIOS(Optional) Internal/External Modem Wake up STR (Suspend-To-RAM) Wake On LAN PS/2 Keyboard Password Wake up PS/2 Mouse Wake up System after AC back Poly fuse for keyboard, USB, Game port over- current protection Summary of Feature...
  • Page 13: 6Cxc/6Cxc-1 Motherboard Layout

    6CXC/6CXC-1 Motherboard 6CXC/6CXC-1 Motherboard Layout PS/2 JP27 SPDIF AC97 PCI1 PCI2 AUREAL PCI3 PCI4 W83627HF JP28 JP16 PCI5 ISA1 JP31 82805 82820 JP13 6CXC ICH 82801 W83628F JP18 JP34 BAT1 IR/CIR FP USB JP32 JP24 JP15 JP33 JP22 W83629D...
  • Page 14: Page Index For Cpu Speed Setup / Connectors / Panel And Jumper

    Page Index for CPU Speed Setup/Connectors/Panel and Jumper Definition CPU Speed Setup Connectors GAME & Audio Port COMA / COMB / LPT Port USB Connector PS/2 Keyboard & PS/2 Mouse Connector J2 (CPU Cooling FAN Power Connector) J1 (Power Cooling FAN Power Connector) J13 (System Cooling FAN Power Connector) ATX Power Floppy Port...
  • Page 15 6CXC/6CXC-1 Motherboard JP31 (Over Voltage CPU Speed Up) [Optional] JP32 (Front USB Device Wake Up Selection) [Optional] P.24 P.25...
  • Page 16 JP33 (FWH Write Protection) JP24 (Internal Buzzer Connector) [Optional] JP9 (AMR Select) [Optional] JP34 (Over Clock Voltage Control) BAT 1(Battery) 6CXC/6CXC-1 Motherboard Layout P.25 P.26 P.26 P.27 P.27...
  • Page 17: Cpu Speed Setup

    CPU Speed Setup The system bus frequency can be switched at 100MHz and 133MHz by adjusting JP13 & SW 1. The CPU Frequency is control by BIOS. JP13 / SW1 Select the System Speed at 100MHz and 133MHz. AGPCLK CPUCLK JP13 66.6 100.3 73.3...
  • Page 18: Connectors

    6CXC/6CXC-1 Motherboard Connectors GAME & Audio Port GAME Port MIC In Line Out Line In COM A / COM B / LPT Port LPT Port COM A COM B...
  • Page 19: Ps/2 Keyboard & Ps/2 Mouse Connector

    6CXC/6CXC-1 Motherboard CN3 : USB Connector (Back) PS/2 Keyboard & PS/2 Mouse Connector Pin No. 1 2 3 4 PS/2 Mouse PS/2 Mouse/ Keyboard Pin No. PS/2 Keyboard Definition USB V0 USB D0- USB D0+ USB V1 USB D1- USB D1+ Definition Data VCC(+5V)
  • Page 20: Definition

    J2 : CPU Cooling FAN Power Connector J1 : Power Cooling FAN Power Connector Pin No. Definition Control +12V SENSE Pin No. Definition Control +12V SENSE Connectors...
  • Page 21: J13 (System Cooling Fan Power Connector)

    6CXC/6CXC-1 Motherboard J13 : System Cooling FAN Power Connector ATX Power Pin No. Definition Control +12V SENSE Pin No. 3,5,7,13,15-17 1,2,11 4,6,19,20 5V SB stand by+5V PS-ON(Soft On/Off) Definition 3.3V +12V -12V Power Good...
  • Page 22: Floppy Port

    Connectors Floppy Port RED LINE IDE1(Primary) , IDE2 (Secondary) Port RED LINE IDE 2 IDE 1...
  • Page 23: Ir/Cir

    6CXC/6CXC-1 Motherboard IR/CIR CN9 : USB Port Connector (Front) (Optional) Pin No. Definition IRRX IRTX CIRRX Pin No. Definition USB D0- USB D0+ USB D1- USB D1+...
  • Page 24: Jp2 (Str Led Connector& Dimm Led)

    JP2 : STR LED Connector & DIMM LED J20 : SPDIF (The SPDIF output is capable of providing digital audio to external speakers or compressed AC3 data to an external Dolby digital decoder.) (Optional) STR LED Connector External. DIMM LED Pin No.
  • Page 25: J19 (Aux_In)

    6CXC/6CXC-1 Motherboard J19 : AUX IN J10 : CD Audio Line In Pin No. Definition AUX-L AUX-R Pin No. Definition CD-L CD-R...
  • Page 26: J16 (Tel)

    J16 : TEL(The connector is for internal modem card with voice connector) J14: Wake on LAN Pin No. Definition Signal-In Signal-Out Pin No. Definition +5V SB Signal Connectors...
  • Page 27: J15: Ring Power On

    6CXC/6CXC-1 Motherboard J15: Ring Power On J21 : External SMBUS Device Connector Pin No. Definition Signal Pin No. Definition SMB CLK SMB DATA...
  • Page 29: Panel And Jumper Definition

    6CXC/6CXC-1 Motherboard Panel and Jumper Definition J9 : For 2X11 Pins Jumper GN (Green Switch) GD (Green LED) HD (IDE Hard Disk Active LED) SPKR (Speaker Connector) RE (Reset Switch) P+P P (Power LED) PW (Soft Power Connector) Open: Normal Operation Close: Entering Green Mode Pin 1: LED anode(+) Pin 2: LED cathode( )
  • Page 30: Jp27 (Back Usb Device Wake Up Selection)

    JP27 : Back USB Device Wake up Selection (USB Connector à CN3) JP3 : PS/2 Keyboard Power On Panel and Jumper Definition Pin No. Definition USB Device 1-2 close Wake up 2-3 close Normal (Default) (If you want to use “USB KB/Mouse Wake from S3” function, you have to set the BIOS setting “USB KB/Mouse Wake from S3”...
  • Page 31: Jp1 (Str Selection)

    6CXC/6CXC-1 Motherboard JP1 : STR Selection JP16 : Case Open Pin No. Definition open NON STR (Default) close Pin No. Definition Signal...
  • Page 32: Jp28 (Onboard Sound Function Selection) [Optional]

    JP28 : Onboard Sound Function Selection (Optional) JP15 : Top Block Lock Panel and Jumper Definition Pin No. Definition 1-2 close Onboard Sound Enable(Default) 2-3 close Onboard Sound Disable Pin No. Definition close Top Block Unlock (Default) open Top Block lock...
  • Page 33: Jp18 (Clear Cmos Function)

    6CXC/6CXC-1 Motherboard JP18 : Clear CMOS Function JP21: Safe mode / Recovery / Normal Pin No. Definition 1-2 close Clear CMOS 2-3 close Normal (Default) Pin No. Definition 1-2close Normal(Default) 2-3close Safe mode 1-2-3open Recovery...
  • Page 34: Jp22 (Timeout Reboot Function)

    JP22 : Timeout Reboot Function Panel and Jumper Definition Pin No. open Timeout reboot close No Reboot on timeout (Default) Pin No. close close close close 9-10 close 11-12 close Definition Normal (Default)
  • Page 35: Jp33 (Fwh Write Protection)

    6CXC/6CXC-1 Motherboard JP32 : Front USB Device Wake up Selection (Optional) (USB Port à CN9) JP33 : FWH Write Protection Pin No. Definition USB Device Wake 1-2 close 2-3 close Normal (Default) (If you want to use “USB KB/Mouse Wake from S3” function, you have to set the BIOS setting “USB KB/Mouse Wake from S3”...
  • Page 36: Jp24 : Internal Buzzer Connector(Optional)

    JP24 : Internal Buzzer Connector(Optional) JP9 : AMR Select (Optional) Panel and Jumper Definition Pin No. Definition open Internal Buzzer Disable close Internal Buzzer Enable (Default) Definition Pin No. (Onboard CDOEC) 1-2close Primary AC’97 Disabled 2-3close (Disabled Onboard CODEC) Note: 6CXC: If M/B has hardware audio (AU8810), your modem riser has been set to “Primary”...
  • Page 37: Jp34 (Over Clock Voltage Control)

    6CXC/6CXC-1 Motherboard JP34 : Over Clock Voltage Control BAT1 : Battery Pin No. Definition 1-2close Over Clock 2-3close Normal Danger of explosion if battery is incorrectly replaced. + Replace only with the same or equivalent type recommended by the manufacturer. + Dispose of used batteries according to the manufacturer’s instructions.
  • Page 38: Performance List

    Performance List The following performance data list is the testing results of some popular benchmark testing programs. These data are just referred by users, and there is no responsibility for different testing data values gotten by users. (The different Hardware & Software configuration will result in different benchmark testing results.) Pentium DRAM...
  • Page 39 6CXC/6CXC-1 Motherboard Hi-End Winstone99 32.8...
  • Page 41: Block Diagram

    6CXC/6CXC-1 Motherboard Block Diagram PCI Bus PCI to ISA Bridge AUREAL W83628F/ AU8810 283629D AC97 L-IN CODEC L-OUT Winbond 81181D Port Port Port 66 MHz 100 / 133 MHz Slot 1 Host Bus INTEL FW82820 (MCH) 300/400MHz 66MHz 33MHz 33MHz INTEL FW82801 48MHz...
  • Page 42: Suspend To Ram Installation

    Suspend to RAM Installation Suspend to RAM Installation A.1 Introduce STR function: Suspend-to-RAM (STR) is a Windows 98 ACPI sleep mode function. When recovering from STR (S3) sleep mode, the system is able, in just a few seconds, to retrieve the last “state” of the system before it went to sleep and recover to that state.
  • Page 43 6CXC/6CXC-1 Motherboard Step 2: (If you want to use STR Function, please set jumper JP1 (Closed.) Step 3: Power on the computer and as soon as memory counting starts, press <Del>. You will enter BIOS Setup. Select the item “POWER MANAGEMENT SETUP”, then select “ACPI Sleep Type: S3 /STR”.
  • Page 44 A.3 How to put your system into STR mode? There are two ways to accomplish this: 1. Choose the “Stand by” item in the “Shut Down Windows” area. A. Press the “Start” button and then select “Shut Down” B. Choose the “Stand by” item and press “OK” Suspend to RAM Installation...
  • Page 45 6CXC/6CXC-1 Motherboard Define the system ”power on” button to initiate STR sleep mode: A. Double click “My Computer” and then “Control Panel” B. Double click the “ Power Management” item.
  • Page 46 C. Select the “Advanced” tab and “Standby” mode in Power Buttons. Step 4: Restart your computer to complete setup. Now when you want to enter STR sleep mode, just momentarily press the “Power on” button.. A.4 How to recover from the STR sleep mode? There are seven ways to “wake up”...
  • Page 47 6CXC/6CXC-1 Motherboard A.5 Notices : In order for STR to function properly, several hardware and software requirements must be satisfied: A. Your ATX power supply must comply with the ATX 2.01 specification (provide more than 720 mA 5V Stand-By current). B.
  • Page 48: Dual Bios Introduction

    Dual BIOS Introduction What is Dual BIOS Technology? Dual BIOS means that there are two system BIOS (ROM) on the motherboard, one is the Main BIOS and the other is Backup BIOS. Under the normal circumstances, the system works on the Main BIOS. If the Main BIOS is corrupted or damaged, the Backup BIOS can take over while the system is powered on.
  • Page 49 6CXC/6CXC-1 Motherboard b. AMI Dual BIOS Flash ROM Programming Utility AMI Dual BIOS Flash ROM Programming Utility Boot From……………………….. Main Type………………… Backup Type……………… Wide Range Protection Auto Recovery Halt On Error Copy Main ROM Data to Backup c. Dual BIOS Item explanation: BIOS will auto detect: Boot From : Main BIOS Main ROM Type : Intel N82802AB...
  • Page 50 Boot From : Main BIOS (Default), Backup BIOS Status 1: The user can set to boot from main BIOS or Backup BIOS. Auto Recovery : Enabled(Default), Disabled When one of the Main BIOS or Backup BIOS occurs checksum failure, the working BIOS will automatically recover the BIOS of checksum failure.
  • Page 51 6CXC/6CXC-1 Motherboard DualBIOS Technology FAQ GIGABYTE Technology is pleased to introduce DualBIOS technology, a hot spare for your system BIOS. This newest “Value-added” feature, in a long series of innovations from GIGABYTE, is available on GA-6CXC/6CXC-1 motherboard. Future GIGABYTE motherboards will also incorporate this innovation.
  • Page 52 I. Q: What is DualBIOS technology? Answer: DualBIOS technology is a patented technology from Giga-Byte Technology. The concept of this technology is based on the redundancy and fault tolerance theory. DualBIOS simply means there are two system BIOSes (ROM) integrated onto the motherboard. One is a main BIOS, and the other is a backup BIOS.
  • Page 53 6CXC/6CXC-1 Motherboard III. Q: How does DualBIOS Answer: 1. DualBIOS technology provides a wide range of protection during the boot up procedure. It protects your BIOS during system POST, ESCD update, and even all the way to PNP detection/assignment. 2. DualBIOS provides automatic recovery for the BIOS.
  • Page 54 2. During or after a BIOS upgrade, if DualBIOS backup BIOS will take over the boot-up process automatically. Moreover, it will verify the main and backup BIOS checksums when booting-up. DualBIOS checksum of the main and backup BIOS while the system is powered on to guarantee your BIOS operates properly.
  • Page 55: Memory Installation

    6CXC/6CXC-1 Motherboard Memory Installation The motherboard has 4 dual inline memory module (DIMM) sockets. The BIOS will automatically detects memory type and size. To install the memory module, just push it vertically into the DIMM Slot .The DIMM module can only fit in one direction due to the two notch.
  • Page 56: Page Index For Bios Setup

    $ Page index for BIOS Setup The Main Meun Standard CMOS Setup BIOS Features Setup Chipset Features Setup Power Management Setup PNP/ PCI Configuration Load BIOS Defaults Load Setup Defaults Integrated Peripherals Hardware Monitor Setup Supervisor / User Password IDE HDD Auto Detection Save &...
  • Page 57: Entering Setup

    6CXC/6CXC-1 Motherboard BIOS Setup BIOS Setup is an overview of the BIOS Setup Program. The program that allows users to modify the basic system configuration. This type of information is stored in battery-backed CMOS RAM so that it retains the Setup information when the power is turned off. ENTERING SETUP Power On the computer and press <Del>...
  • Page 58: Getting Help

    GETTING HELP Main Menu The on-line description of the highlighted setup function is displayed at the bottom of the screen. Status Page Setup Menu / Option Page Setup Menu Press F1 to pop up a small help window that describes the appropriate keys to use and the possible selections for the highlighted item.
  • Page 59: Supervisor Password

    6CXC/6CXC-1 Motherboard Standard CMOS Setup This setup page includes all the items in standard compatible BIOS. BIOS Features Setup This setup page includes all the items of AMI special enhanced features. Chipset Features Setup This setup page includes all the items of chipset special features. Power Management Setup This setup page includes all the items of Green function features.
  • Page 60 BIOS Setup Save & Exit Setup Save CMOS value settings to CMOS and exit setup. Exit Without Saving Abandon all CMOS value changes and exit setup.
  • Page 61: Standard Cmos Setup

    6CXC/6CXC-1 Motherboard Standard CMOS Setup The items in Standard CMOS Setup Menu (Figure 2) are divided into 10 categories. Each category includes no, one or more than one setup items. Use the arrows to highlight the item and then use the <PgUp> or <PgDn> keys to select the value you want in each item. AMIBIOS SETUP –...
  • Page 62 Primary Master, Slave / Secondary Master, Slave The category identifies the types of hard disk from drive C to F that has been installed in the computer. There are two types: auto type, and user definable type. User type is user- definable;...
  • Page 63 6CXC/6CXC-1 Motherboard Boot Sector Virus Protection If it is set to enable, the category will flash on the screen when there is any attempt to write to the boot sector or partition table of the hard disk drive. The system will halt and the following error message will appear in the mean time.
  • Page 64 BIOS Setup...
  • Page 65: Bios Features Setup

    6CXC/6CXC-1 Motherboard BIOS Features Setup AMIBIOS SETUP – BIOS FEATURES SETUP ( C ) 1998 American Megatrends, Inc. All Rights Reserved Quick Boot Boot Device Boot Device Boot Device Try Other Boot Devices Floppy Access Control Hard Disk Access Control S.M.A.R.T.
  • Page 66 Try Other Boot Device Enabled other device to boot system. (Default Value) Disabled other device to boot system. Floppy Access Control Read-Write Set Floppy Access Control : Read-Write. (Default Value) Read-Only Set Floppy Access Control : Read Only. Hard Disk Access Control Set Hard Disk Access Control : Read-Write.
  • Page 67 6CXC/6CXC-1 Motherboard Password Check Setup Set Password Check to Setup. (Default Value) Always Set Password Check to Always. Boot To OS/2 > 64MB Enabled Boot To OS/2. Disabled Boot To OS/2. (Default Value) CPU Serial Number Disabled CPU Serial Number. (Default Value) Disabled Enabled CPU Serial Number.
  • Page 68: Chipset Features Setup

    Chipset Features Setup AMIBIOS SETUP – CHIPSET FEATURES SETUP ( C ) 1998 American Megatrends, Inc. All Rights Reserved SDRAM CAS Latency Memory Buffer Strength CPU BIST Enable Memory Hole ICH Delayed Transaction ICH DCB Enable VGA Frame Buffer USWC PCI Frame Buffer USWC Graphics Aperture Size ClkGen Spread Spectrum...
  • Page 69 6CXC/6CXC-1 Motherboard ICH Delayed Transaction Disabled ICH Delayed Transaction. Disabled Enabled ICH Delayed Transaction .(Default Value) Enabled ICH DCB Enable Disable ICH DCB. (Default Value) Disabled Enabled Enable ICH DCB. VGA Frame Buffer USWC Disable VGA Frame Buffer USWC. (Default Value) Disabled Enabled Enable VGA Frame Buffer USWC.
  • Page 70 CPU Ratio Selection 2.0x(Safe)/2.5x/3.0x/3.5x/4.0x/4.5x/5.0x/5.5x/6.0x/6.5x/7.0x/7.5x/8.0x USB Function Disabled Disable USB Function. Enable USB Function. (Default Value) Enabled USB Legacy Support USB Legacy Support can be set when USB Function is Enable. Disabled Disable USB Legacy Support. (Default Value) Keyb+ USB Keyboard and Mouse Support. Mouse Keyboard USB Keyboard Support.
  • Page 71 6CXC/6CXC-1 Motherboard Power Management Setup AMIBIOS SETUP – POWER MANAGEMENT SETUP ( C ) 1998 American Megatrends, Inc. All Rights Reserved ACPI Sleep Type USB KB/MS Wakeup From S3 Power Management/APM Video Power Down Mode Hard Disk Power Down Mode Standby Time Out (Minute) Suspend Time Out (Minute) K/B &...
  • Page 72 Video Power Down Mode Disabled Disabled Video Power Down Mode Function. Set Video Power Down Mode to Suspend. (Default Value) Suspend Stand By Set Video Power Down Mode to Stand By. Hard Disk Power Down Mode Disabled Disabled Hard Disk Power Down Mode Function. Set Hard Disk Power Down Mode to Suspend.
  • Page 73 6CXC/6CXC-1 Motherboard K/B & PS/2 Mouse Access Monitor Monitor Keyboard & PS/2 Mouse Access. (Default Value) Ignore Ignore Keyboard & PS/2 Mouse Access. FDC/LPT/COM Port Access Monitor Monitor FDC/LPT/COM Port Access. (Default Value) Ignore Ignore FDC/LPT/COM Port Access. SB/MSS Audio Ports Access Monitor Monitor SB/MSS Audio Ports Access.
  • Page 74 PIRQ[A] IRQ Active Monitor Monitor PIRQ[A] IRQ Active. Ignore PIRQ[A] IRQ Active. (Default Value) Ignore PIRQ[B] IRQ Active Monitor Monitor PIRQ[B] IRQ Active. Ignore PIRQ[B] IRQ Active. (Default Value) Ignore PIRQ[C] IRQ Active Monitor Monitor PIRQ[C] IRQ Active. Ignore PIRQ[C] IRQ Active. (Default Value) Ignore PIRQ[D] IRQ Active Monitor...
  • Page 75 6CXC/6CXC-1 Motherboard PME Event Wake Up Disabled Disable PME Event Wake Up. (Default Value) Enabled Enabled PME Event Wake Up. RTC Alarm Power On You can set “RTC Alarm Power On” item to enabled and key in date/time to power on system.
  • Page 76 PNP/PCI Configuration AMIBIOS SETUP – PNP / PCI CONFIGURATION ( C ) 1998 American Megatrends, Inc. All Rights Reserved Plug and Play Aware O/S Clear NVRAM Primary Graphics Adapter PCI VGA Palette Snoop DMA Channel 0 DMA Channel 1 DMA Channel 3 DMA Channel 5 DMA Channel 6 DMA Channel 7...
  • Page 77 6CXC/6CXC-1 Motherboard DMA Channel( 0,1,3,5,6,7 ) ISA/ EISA The resource is used by Legacy ISA device. The resource is used by PnP device. IRQ ( 3,4,5,7,9, 10,11,14,15 ), assigned to ( “ISA / EISA” or “PCI/PnP” ) ISA/ EISA The resource is used by Legacy ISA device. PCI / PnP The resource is used by PCI/ PnP device.
  • Page 78: Power Management Setup

    Load BIOS Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.20 ( C ) 1998 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION Load BIOS Defaults (Y/N)? LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item (Shift) F2 : Change Color F5 : Old Values : Load BIOS Defaults...
  • Page 79: Load Setup Defaults

    6CXC/6CXC-1 Motherboard Load Setup Defaults AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.20 ( C ) 1998 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION Load Setup Defaults (Y/N)? LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item (Shift) F2 : Change Color F5 : Old Values...
  • Page 80: Integrated Peripherals

    Integrated Peripherals AMIBIOS SETUP – INTEGRATED PERIPHERALS ( C ) 1998 American Megatrends, Inc. All Rights Reserved OnBoard IDE OnBoard AC’97 Audio OnBoard AC’97 Modem OnBoard FDC OnBoard Serial Port A OnBoard Serial Port B Serial Port B Mode IR Duplex Mode IR Pin Select OnBoard CIR Port CIR IRQ Select...
  • Page 81 6CXC/6CXC-1 Motherboard OnBoard FDC Auto Set OnBoard FDC is Auto. (Default Value) Disabled Disabled OnBoard FDC. Enabled Enabled OnBoard FDC. On Board Serial Port A BIOS will automatically setup the port A address. (Default Value) Auto 3F8/COM1 Enable on Board Serial port A and address is 3F8. 2F8/COM2 Enable on Board Serial port A and address is 2F8.
  • Page 82 On Board CIR port Disabled Disabled On board CIR port. (Default Value) Enabled Enabled On board CIR port. CIR IRQ Select IRQ 3 / 4 / 9 / 10 (Default Value) / 11 On Board Parallel port Enable On Board LPT port and address is 378. Enable On Board LPT port and address is 278.
  • Page 83 6CXC/6CXC-1 Motherboard On Board Game Port Disabled Disabled On Board game port. Set onboard game port is 201. (Default Value) Set onboard game port is 209. Keyboard Power On Function Disable this function. (Default Value) Disabled Specific Key Set specific key to power on by keyboard. Any Key Set any key to power on the system.
  • Page 84: Hardware Monitor Setup

    Hardware Monitor Setup AMIBIOS SETUP – HARDWARE MONITOR SETUP ( C ) 1998 American Megatrends, Inc. All Rights Reserved ACPI Shut Down Temp. CPU Temp. Alarm CPU Fan Fail Alarm Power Fan Fail Alarm System Fan Fail Alarm Reset Case Open Status Case Status Current CPU Temp.
  • Page 85 6CXC/6CXC-1 Motherboard CPU Temp. Alarm 65 C / 149 F Monitor CPU Temp. at 65 C / 149 F. Monitor CPU Temp. at 70 C / 158 F. (Default Value) 70 C / 158 F 75 C / 167 F Monitor CPU Temp.
  • Page 86: Supervisor / User Password

    Supervisor / User Password When you select this function, the following message will appear at the center of the screen to assist you in creating a password. AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.20 ( C ) 1998 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP...
  • Page 87: Ide Hdd Auto Detection

    6CXC/6CXC-1 Motherboard IDE HDD AUTO Detection AMIBIOS SETUP – STANDARD CMOS SETUP ( C ) 1998 American Megatrends, Inc. All Rights Reserved Date (mm/dd/yyyy) : Fri Dec 25, 1998 Time (hh/mm/ss) : 10:36:24 TYPE SIZE CYLS HEAD PRECOMP LANDZ SECTOR MODE Pri Master : Auto Pri Slave : Auto...
  • Page 88: Save & Exit Setup

    Save & Exit Setup AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.20 ( C ) 1998 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item (Shift) F2 : Change Color F5 : Old Values : Load BIOS Defaults Save Data to CMOS &...
  • Page 89: Exit Without Saving

    6CXC/6CXC-1 Motherboard Exit Without Saving AMIBIOS SIMPLE SETUP UTILITY-VERSION 1.20 ( C ) 1998 American Megatrends, Inc. All Rights Reserved STANDARD CMOS SETUP BIOS FEATURES SETUP CHIPSET FEATURES SETUP POWER MANAGEMENT SETUP PNP/PCI CONFIGURATION LOAD BIOS DEFAULTS LOAD SETUP DEFAULTS ESC : Quit : Select Item (Shift) F2 : Change Color F5 : Old Values : Load BIOS Defaults...
  • Page 90: Appendix

    6CXC/6CXC-1 Motherboard Appendix Appendix A : AU8810 Driver Installation A. DRIVER INSTALLATION If you have older drivers in your system, please uninstall them first as described in Section C below. 1. Power on the system, placing the "Intel chipset Series Mainboard Utility CD" in the CD-ROM drive.
  • Page 91 6CXC/6CXC-1 Motherboard...
  • Page 92 2. Open the "Multifunction Adapters" tree and select "Vortex Multifunction PCI Platform" 3. Press the "Remove" button at the bottom of the Device Manager window pane. 4. The drivers are now removed from memory, but are still on the hard disk.
  • Page 93 C:\utility\ AWDFlash or AMIFlash <filename of the BIOS binary file intended for flashing> Once the process is finished, reboot the system ü MNote: Please download the newest BIOS from our website (www.gigabyte.com.tw) or contact your local dealer for the file.
  • Page 94 Appendix C: Acronyms Acor. Meaning ACPI Advanced Configuration and Power Interface POST Power-On Self Test Local Area Network Extended Capabilities Port Advanced Power Management Direct Memory Access Megahertz ESCD Extended System Configuration Data Central Processing Unit Symmetric Multi-Processing Universal Serial Bus Operating System Error Checking and Correcting Integrated Dual Channel Enhanced...
  • Page 95 6CXC/6CXC-1 Motherboard Acor. Meaning Peripheral Component Interconnect RIMM Rambus in-line Memory Module Dual Retention Mechanism Industry Standard Architecture Memory Translation Hub CRIMM Continuity RIMM...
