- Page 1 OWNER'S MANUAL IPS LED MONITOR (LED MONITOR*) *LG LED Monitors are LCD Monitors with LED Backlighting. Please read the safety information carefully before using the product. IPS LED Monitor (LED Monitor) Model List 32UD89 32MU89 www.lg.com...
-
Page 2: Table Of Contents
- How to Use the Joystick Button Input Connector Moving and Lifting the Monitor SPECIFICATIONS Installing the Monitor 32UD89/32MU89 - Assembling the stand base Factory Support Mode (Preset Mode, PC) - Using the cable holder HDMI - Installing onto a table... -
Page 3: License
LICENSE LICENSE Each model has different licenses. Visit www.lg.com for more information on the license. The terms HDMI and HDMI High-Definition Multimedia Interface, and the HDMI Logo are trademarks or registered trademarks of HDMI Licensing Administrator, Inc. VESA, VESA logo, DisplayPort compliance logo and DisplayPort compliance logo for dual-mode source devices are all registered trademarks of the Video Electronics Stan- dards Association. -
Page 4: Assembling And Preparing
The product warranty will not cover damage or injury caused by the use of counterfeit components. It is recommend that use the supplied components. If you use generic cables not certified by LG, the screen may not display or there may be image noises. NOTE Note that the components may look different from those shown here. -
Page 5: Supported Drivers And Software
ASSEMBLING AND PREPARING Supported Drivers and Software You can download and install the latest version from the LGE website ( www.lg.com ). Drivers and Software Installation Priority 32UD89 / 32MU89 Monitor Driver Recommended OnScreen Control Recommended Dual Controller Optional... -
Page 6: Component And Button Description
ASSEMBLING AND PREPARING Component and Button Description Joystick Button Power LED On: power is on Off: power is off How to Use the Joystick Button You can easily control the functions of the monitor by pressing the joystick button or moving it left/right with your finger. -
Page 7: Input Connector
ASSEMBLING AND PREPARING Input Connector... -
Page 8: Moving And Lifting The Monitor
ASSEMBLING AND PREPARING Moving and Lifting the Monitor CAUTION When moving or lifting the monitor, follow these in- As far as possible, avoid touching the monitor structions to prevent the monitor from being scratched screen. This may result in damage to the screen or or damaged and to ensure safe transportation regard- some of the pixels used to create images. -
Page 9: Installing The Monitor
ASSEMBLING AND PREPARING Installing the Monitor Assembling the stand base Turn the screw clockwise to secure the stand base. Please put a soft cloth on a low table or box to protect the screen of the monitor. Please put the monitor on the soft cloth with the screen facing down. -
Page 10: Using The Cable Holder
ASSEMBLING AND PREPARING Using the cable holder CAUTION Arrange the cables using the cable holder as shown in Illustrations in this document represent typical the illustration. procedures, so they may look different from the actual product. Do not carry the monitor upside down by just holding the stand base. -
Page 11: Installing Onto A Table
ASSEMBLING AND PREPARING Installing onto a table Cautions When Connecting Power Cord Lift the monitor and place it on the table in an up- right position. Place at least 100 mm away from the wall to ensure sufficient ventilation. 100 mm 100 mm 100-240 V~ 100 mm... -
Page 12: Adjusting The Angle
ASSEMBLING AND PREPARING Adjusting the angle Adjusting the Stand Height Place the monitor in an upright position, mounted Handle the monitor with both hands for safety. on the stand base. Adjust the angle of the screen. The angle of the screen can be adjusted forwards or backwards for a comfortable viewing experience. -
Page 13: Pivot Feature
ASSEMBLING AND PREPARING Pivot Feature Rotate the monitor clockwise as shown in the figure. The pivot feature allows the monitor to rotate 90° clockwise. Head Complete the installation by rotating the monitor 90° as shown below. Stand WARNING To avoid scratching the stand base, make sure that when rotating the monitor using the pivot feature, the stand does not make contact with the monitor. -
Page 14: Using The Kensington Lock
ASSEMBLING AND PREPARING WARNING NOTE Take care when rotating the monitor if the cable The left or right side of the monitor head can be is connected. slightly rotated up or down (up to 3°). Adjust the To avoid injury when rotating the display, do not horizontal level of the monitor head. -
Page 15: Detaching The Stand Body
If you use improper screw, the product might be dam- Installing the wall mount plate aged and drop from mounted position. In this case, LG Electronics is not responsible for it. This monitor supports the specification of the standard wall mount plate or compatible device. - Page 16 Installing the monitor on the ceiling or on a slanted wall may result in the monitor falling off, which could lead to injury. Please use the genu- ine LG wall mounting bracket. For more informa- tion, contact your local retail store or a qualified installer.
-
Page 17: Using The Monitor
NOTE There may be no video or audio output depending on the DP version of the PC. If you use generic cables not certified by LG, the screen may not display or there may be image noises. NOTE If you use HDMI PC, it can cause compatibility problem. -
Page 18: Usb-C Connection
USING THE MONITOR Connecting to AV Devices USB-C connection Transmits digital video and audio signals from your PC HDMI connection to the monitor. Connect the monitor to your PC using the USB-C cable Transmits the digital video and audio signals from your as shown in the illustration below. -
Page 19: Connecting To External Devices
USING THE MONITOR Connecting to External Devices Service only port Connecting Headphones The port is used only for “Service” . Connect peripherals to the monitor via the headphones port. Connect as illustrated. SERVICE ONLY (sold separately) NOTE Peripheral devices are sold separately. If you use angled earphones, it may cause a prob- lem with connecting another external device to the monitor. -
Page 20: User Settings
User Settings USER SETTINGS Activating the Main Menu Press the joystick button on the bottom of the monitor. Move the joystick up/down ( ▲ / ▼ ) and left/right( ◄ / ► ) to set the options. Press the joystick button once more to exit the main menu. Joystick Button Button Menu Status... -
Page 21: User Settings
User Settings User Settings Menu Settings To view the OSD menu, press the joystick button at the bottom of the monitor and then enter the Menu. Configure the options by moving the joystick up/down/left/right. To return to the upper menu or set other menu items, move the joystick to ◄ or pressing ( / Ok) it. - Page 22 User Settings Picture Mode FPS Game 1 This mode is optimized for FPS games. FPS Game 2 It has a higher Black Stabilizer value than FPS Game 1. It is suitable for very dark FPS games. RTS Game This mode is optimized for RTS Game. Custom (Game) In this mode, users can customize various elements including game-related options.
- Page 23 User Settings Game Adjust Response Time Sets a response time for displayed pictures based on the speed of the screen. For a normal environment, it is recommended that you use Normal. For a fast-moving picture, it is recommended that you use Fast. Setting to Fast may cause image sticking.
- Page 24 User Settings Menu > General Description Language Sets the menu screen to the desired language. SMART ENERGY High Saves energy using the high-efficiency SMART ENERGY SAVING feature. SAVING Saves energy using the low-efficiency SMART ENERGY SAVING feature. Disables the SMART ENERGY SAVING feature. Power LED Turns the power LED on the front of the monitor on or off.
-
Page 25: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING Nothing is displayed on the screen. Is the monitor's power cord plugged in? Check if the power cord is correctly plugged into the power outlet. Is the power LED on? Check the power cable connection and press the power button. Check that the connected input is enabled (Menu >... - Page 26 Do you see an "Unrecognized monitor, Plug&Play (VESA DDC) monitor found" message? Be sure to install the display driver from our web site: http://www.lg.com . Have you installed the display driver? Make sure to check if the video card supports Plug&Play function.
-
Page 27: Specifications
SPECIFICATIONS SPECIFICATIONS 32UD89/32MU89 LCD Screen Type TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Screen Pixel Pitch 0.18159 mm x 0.18159 mm Resolution Maximum Resolution 3840 x 2160 @ 60 Hz Recommended Resolution 3840 x 2160 @ 60 Hz Video Signal... -
Page 28: Factory Support Mode (Preset Mode, Pc)
SPECIFICATIONS Factory Support Mode (Preset Mode, PC) HDMI Horizontal Vertical Display Modes (Resolution) Polarity(H/V) Remarks Frequency(kHz) Frequency(Hz) 640 x 480 31.469 59.94 800 x 600 37.879 60.317 1024 x 768 48.363 1152 x 864 54.347 60.05 1280 x 720 1280 x 1024 63.981 60.02 1600 x 900... - Page 29 In addition to the source code, all referred license terms, warranty disclaimers and copyright notices are available for download.LG Electronics will also provide open source code to you on CD-ROM for a charge covering the cost of performing such distribution (such as the cost of media, shipping, and handling) upon email request to opensource@lge.com.
