All about the
Use
of your
Important Safety Instructions ........................... 2-5
Operating Instructions ................................... 6-10
Care and Cleaning ............................................ 11
Solutions to Common Problems .....................12-13
www.frigidaire.com USA 1-800-944-9044
&
Dryer
TA B L E O F C O N T E N T S
www.frigidaire.ca Canada 1-800-265-8352
Care
Warranty ......................................................... 14
Français ........................................................... 15
Español ........................................................... 29
Advertisement
Related Manuals for Frigidaire FFRE4120S
Summary of Contents for Frigidaire FFRE4120S
- Page 1 TA B L E O F C O N T E N T S Important Safety Instructions ......2-5 Warranty ............14 Operating Instructions ........6-10 Français ............15 Care and Cleaning ..........11 Español ............29 Solutions to Common Problems .....12-13 www.frigidaire.com USA 1-800-944-9044 www.frigidaire.ca Canada 1-800-265-8352...
- Page 2 IMPORTANT SAFETY INSTRUCTIONS WARNING For your safety the following information in this manual must be followed to minimize the risk of fi re or explosion or to prevent property damage, personal injury or death. Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appliance.
- Page 3 IMPORTANT SAFETY INSTRUCTIONS Product Record WARNING Please read all instructions before using this dryer. Record Your Model and Serial Numbers The model and serial numbers of your dryer are found on the dryer serial plate located inside the door opening. Record and retain these numbers.
- Page 4 IMPORTANT SAFETY INSTRUCTIONS 240 v Electric Dryer 240 v Electric Dryer 120 v Gas Dryer 120 v Gas Dryer Grounding type Grounding type wall receptacl ll receptacle 10-30R 10-30R UL-approved service UL-approved service 3-wire 3-wire Do not, Do not, under under an any cir y circumstances,...
- Page 5 IMPORTANT SAFETY INSTRUCTIONS PROTECT CHILDREN • ALWAYS disconnect the dryer from the electrical supply • Do not allow children to play on or in the dryer. Close before attempting any service or cleaning. Failure to do supervision of children is necessary when the dryer is so can result in electrical shock or injury.
- Page 6 OPERATING INSTRUCTIONS Normal Operating Sounds You may or may not hear the following sounds from your new dryer: A. SUSPENSION ROLLERS The dryer drum is supported by a set of suspension rollers. At times there may be a thumping or rolling sound when the dryer starts.
- Page 7 OPERATING INSTRUCTIONS Operating Your Dryer Load the dryer and close the door. WARNING • Load items loosely. The average wet load will To reduce the risk of fi re, electric shock or injury to fi ll the drum 1/3 to 1/2 full. Items need room to persons, read the IMPORTANT SAFETY INSTRUCTIONS tumble freely for even drying and less wrinkling.
- Page 8 OPERATING INSTRUCTIONS This manual covers many models and not all cycles, options, or features listed are available on every model. Console shown above for reference only. Your model may differ. Cycle Selection Turn the cycle selector in either direction to the cycle Auto Dry Cycles desired.
- Page 9 OPERATING INSTRUCTIONS Cycle Settings Cycle Options wrinkle release For best results Select wrinkle release if the dried load might not be removed promptly at the end of the cycle. The dry Follow the fabric care label load will continue tumbling without heat to help reduce instructions on items wrinkling.
- Page 10 OPERATING INSTRUCTIONS Dryer Settings Chart These Temperatures and Options are available with the following cycles: temp high normal air dry options chime chime/wrinkle release wrinkle release = Available selections. If an unavailable temperature setting is selected by the user, the nearest available temperature will be substituted.
- Page 11 CARE AND CLEANING WARNING WARNING FIRE HAZARD To reduce risk of fi re or serious injury to persons or A clothes dryer produces combustible lint. The dryer property, comply with the basic warnings listed in the must be connected to an outdoors exhaust. Regularly Important Safety Instructions and those listed below.
- Page 12 SOLUTIONS TO COMMON PROBLEMS Common Drying Problems Many drying problems involve poor cleaning results, poor soil and stain removal, residues of lint and scum, and fabric damage. For satisfactory drying results, follow these suggestions provided by The Soap and Detergent Association. PROBLEM POSSIBLE CAUSES SOLUTIONS...
- Page 13 SOLUTIONS TO COMMON PROBLEMS Avoid Service Checklist Before calling for service, review this list. It may save both time and expense. The list includes common occurrences that are not the result of defective workmanship or materials in this dryer. OCCURRENCE POSSIBLE CAUSE SOLUTION Dryer does not start.
- Page 14 MAJOR APPLIANCE WARRANTY INFORMATION Your appliance is covered by a one year limited warranty. For one year from your original date of purchase, Electrolux will pay all costs for repairing or replacing any parts of this appliance that prove to be defective in materials or workmanship when such appliance is installed, used and maintained in accordance with the provided instructions.
