OWNER'S MANUAL
WASHER-
DRYER
Before beginning installation, read these instructions carefully. This will simplify
installation and ensure that the product is installed correctly and safely. Leave
these instructions near the product after installation for future reference.
EN
ENGLISH
WDV9142*RP
F4V9RCP**
F4V9VCP**
MFL71408081
Rev.00_092319
Copyright © 2019 LG Electronics Inc. All Rights Reserved
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG F4V9VCP Series
Summary of Contents for LG F4V9VCP Series
- Page 1 Before beginning installation, read these instructions carefully. This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. ENGLISH WDV9142*RP F4V9RCP** F4V9VCP** MFL71408081 www.lg.com Rev.00_092319 Copyright © 2019 LG Electronics Inc. All Rights Reserved...
-
Page 2: Table Of Contents
Adding Detergents and Softeners ..............18 Control Panel ....................21 Programme Table ....................22 Extra Options and Functions ................27 SMART FUNCTIONS ..............31 Using LG SmartThinQ Application ..............31 Using Smart Diagnosis..................33 MAINTENANCE ................34 Cleaning After Every Wash ................34 Cleaning the Appliance Periodically ..............34 TROUBLESHOOTING ..............37... -
Page 3: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. - Page 4 Technical Safety • This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
- Page 5 Installation • Never attempt to operate the appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug. • This appliance should only be transported by two or more people holding the appliance securely. •...
- Page 6 • Never reach into the appliance while it is operating. Wait until the drum has completely stopped. • In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. • Do not push down the door excessively, when the appliance door is open.
- Page 7 • If the drain hose or inlet hose is frozen during winter, use it only after thawing. • Keep all washing detergents, softener and bleach away from children. • Do not touch the power plug or the appliance controls with wet hands. •...
-
Page 8: Caring For The Environment
• You can take your appliance either to the shop where you purchased the product, or contact your local government waste office for details of your nearest authorised WEEE collection point. For the most up to date information for your country, please see www.lg.com/global/recycling. -
Page 9: Installation
INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Rear View Control Panel Power plug Detergent dispenser drawer Transit bolts Drum Drain hose Door Cover cap Drain pump filter Drain plug Adjustable feet... - Page 10 Accessories * This feature is only available on some models. Cold water inlet hose* Spanner Caps for covering transit bolt holes* Anti-slip sheets* Elbow bracket for securing drain hose* Tie strap* Specifications Model WDV9142*RP F4V9RCP** F4V9VCP** Power Supply 220 - 240 V~, 50 Hz Dimension (Width x Depth x 600 mm X 560 mm X 850 mm Height)
-
Page 11: Installation Place Requirements
(e.g. wooden floor), the warranty does not cover any damages and cost occured due to the installation on the unstable floor. NOTE • You can purchase rubber cups (Part No.4620ER4002B) from the LG Electronics 20 mm 20 mm service centre. -
Page 12: Unpacking The Appliance
• Repairs to the appliance must only be carried out by the qualified personnel. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning. Contact your LG Electronics service centre. • The power plug must be plugged into an... -
Page 13: Levelling The Appliance
Install the hole caps. Check if the appliance is perfectly level using a spirit level a. • Locate the hole caps b included in the accessory pack or attached on the back. Secure the adjusting feet with the lock nuts b by turning counterclockwise against the bottom Levelling the Appliance of the appliance. -
Page 14: Connecting The Water Inlet Hose
Put the appliance on the anti-slip sheets. • Do not attach the adhesive side a of anti-slip sheets to the feet of the appliance. NOTE • Additional anti-slip sheets are available at LG Electronics service centre. Connecting Hose to Water Tap Connecting the Water Inlet... - Page 15 NOTE Push the supply hose vertically upwards so that the rubber seal within the hose can adhere • Before connecting the inlet hose to the water completely to the tap and then tighten it by tap, turn on the water tap to flush out foreign screwing it to the right.
-
Page 16: Installing The Drain Hose
Installing the Drain Hose Pull the connector latch plate down, push the supply hose onto the adapter, and release the connector latch plate. Make sure the adapter For Model with Drain Pump locks into place. The drain hose should not be placed higher than 100 cm above the floor. -
Page 17: Operation
OPERATION Operation Overview End of cycle. • When the cycle is finished, a melody will sound. Immediately remove your clothing Using the Appliance from the appliance to reduce wrinkling. Check around the door seal when removing Before the first wash, select the Cotton wash the load for small items that may be caught programme and add a half amount of the detergent. -
Page 18: Adding Detergents And Softeners
NOTE • Remove items from the flexible gasket to prevent clothing and door seal damage. • The dashes under the symbol give you information about the type of fabric and the maximum allowance of mechanical stress. Checking the Clothes before Loading •... - Page 19 Adding Detergent Tablet − For better washing results of white and pale garments, use powdered detergent with Detergent tablet is also available when washing bleach. laundry. − Detergent is flushed from the dispenser at the beginning of the wash cycle. Open the door and put detergent tablets into the drum.
- Page 20 • Do not leave the fabric softener in the detergent drawer for more than 2 days (Fabric softener may harden). • Softener will automatically be added during the last rinse cycle. • Do not open the drawer when water is being supplied.
-
Page 21: Control Panel
Control Panel Control Panel Features Power Button • Press the Power button to turn on or off the appliance. Programme Knob • Programmes are available according to the laundry type. • The lamp will light up to indicate the selected programme. Start/Pause Button •... -
Page 22: Programme Table
• AI DD M provides the desired washing and spinning. • M is activated when Cotton, Mixed Fabric, Easy Care programmes are selected and operated. Display • The display shows the settings, estimated remaining time, options, and status messages. When the appliance is turned on, the default settings in the display will illuminate. - Page 23 Programme Mixed Fabric Max. Load 4 kg Description Enables various fabrics to be washed simultaneously. Use for various kind of fabrics except special garments (silk/delicate, sports wear, dark clothes, wool, duvet/curtains). Proper Temperature 40 °C (Cold to 60 °C) Max. Spin Speed 1400 rpm Programme Easy Care...
- Page 24 Programme Speed 14 Max. Load 2 kg Description Provides fast washing time for small loads and lightly soiled clothes. Proper Temperature 20 °C (20 °C to 40 °C) Max. Spin Speed 1400 rpm Programme Dry Only Max. Load Rating (Dry) Description Uses the automatic programmes to dry most loads.
- Page 25 Drying Programme Programme Normal % Description Reduces the drying time and energy usage during dry cycle for cottons. Use for cotton or linen fabrics such as cotton towels, T-shirts. Max. Load Rating Programme Iron - Description Suitable for ironing to dry clothes easily in damp condition. Use for cotton or linen fabrics which is ready to get ironing at the end of programme.
- Page 26 Extra Options Wrinkle Turbo Programme Steam Rinse+ EcoHybrid Add Item Pre Wash Care Wash Cotton Cotton+ TurboWash 39 Mixed Fabric Easy Care Allergy Care Steam Refresh Delicates Hand/Wool Speed 14 Dry Only Wash+Dry Tub Clean * This option is automatically inserted in the programme and cannot be deselected.
-
Page 27: Extra Options And Functions
Extra Options and Rinse Functions Use this option to select the number of rinse by pressing the Rinse+ button. This option is * This feature is only available on some models. recommended for people with detergent allergies. You can use the extra options and functions to customize the programmes. - Page 28 EcoHybrid ) Woolen Articles Do not tumble dry woolen articles. Pull them to their Use this feature for air condensing without water original shape and dry them flat. consumption. Press the Power button. Woven and Loopknit Materials Some woven and loopknit materials may shrink, by Select a drying programme.
- Page 29 Wi-Fi f Child Lock When WLAN is connected, the Wi-Fi icon on the Use this function to disable the controls. This control panel is lit. function can prevent children from changing cycles or operating the appliance. Add Item NOTE • Once this function is set, all buttons are locked Use this option to add or remove the laundry after except the Power button.
- Page 30 Spin p Use this option to change the spin strength. Press the Spin button repeatedly to change the speed level. Press the Power button. Select a washing programme. Press the Spin button to select spin speed. Press the Start/Pause button. NOTE •...
-
Page 31: Smart Functions
Before Using LG SmartThinQ • LG SmartThinQ is not responsible for any network connection problems or any faults, Check the distance between the appliance and malfunctions, or errors caused by network the wireless router (WLAN network). - Page 32 Installing LG SmartThinQ NOTE • If you change your wireless router, internet Search for the LG SmartThinQ application from service provider, or password, delete the the Google Play Store or Apple App Store on a registered appliance from the LG SmartThinQ smartphone.
-
Page 33: Using Smart Diagnosis
Once the countdown is over and the tones LG Electronics will also provide open source code have stopped, resume your conversation with to you on CD-ROM for a charge covering the cost... -
Page 34: Maintenance
MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the finish. - Page 35 Cleaning the Drain Pump Filter Press the Start/Pause button to start. The drain filter collects threads and small objects After the programme is complete, leave the left in the laundry. Check regularly that the filter is door open to dry the door opening, gasket, and clean to ensure smooth running of your appliance.
- Page 36 After cleaning the drain pump filter, take the To clean the drawer opening, use a cloth or drain pump filter out and insert the drain plug. small, non-metal brush to clean the recess. • Remove all residue from the upper and lower Close the cover cap.
-
Page 37: Troubleshooting
Before Calling for Service You can remedy most of the problems by yourself, consequently save time and money, since you do not need to call LG Electronics service centre. The following table should assist you by troubleshooting. Error Messages The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. - Page 38 Possible Cause & Solution Door sensor malfunctions. dE dE1 dEz dE4 DOOR ERROR • Please call LG Electronics service centre. You can find your local LG Electronics service centre phone number in the warranty card. This is a control error. CONTROL ERROR •...
- Page 39 Symptoms Possible Cause & Solution Thumping sound Wash load may be out of balance. • Pause the cycle and redistribute the load after the door unlocks. Vibrating noise Package materials are not removed. • Remove package materials. Wash load may be unevenly distributed in the drum. •...
- Page 40 Symptoms Possible Cause & Solution Appliance does not Control needs to be reset. operate. • Press the Power button, then reselect the desired programme and press the Start/Pause button. Start/Pause was not pressed after a cycle was set. • Press the Power button, then reselect the desired programme and press the Start/Pause button.
- Page 41 Symptoms Possible Cause & Solution Cycle time is longer Heavy articles are mixed with lighter items. than usual. • Always try to wash articles with similar weight in order to allow the appliance to evenly distribute the weight of the load for spinning. The load is out of balance.
- Page 42 Performance Symptoms Possible Cause & Solution Poor stain removal Previously set stains. • Articles that have been previously washed may have stains which have been set. These stains may be difficult to remove and may require hand washing or pre-treating to aid in stain removal. Staining Bleach or softener is dispensed too soon.
- Page 43 • Find the Wi-Fi network connected to your smartphone and remove it, then not connected to the register your appliance on LG SmartThinQ. Wi-Fi network. Mobile data for your smartphone is turned on. • Turn off the Mobile data of your smartphone and register the appliance using the Wi-Fi network.
