CONTENTS SAFETY PRECAUTIONS................................2 SERVICE HINTS ..................................3 ALIGNMENT PROCEDURE AND OPTION SETTINGS......................4 WAVEFORM PATTERN TABLE ...............................5 BLOCK DIAGRAMS ..................................6 PARTS LOCATION ...................................7 REPLACEMENT PARTS LIST ..............................8 SCHEMATIC DIAGRAMS ...............................16 CONDUCTOR VIEWS................................18 SAFETY PRECAUTIONS GENERAL GUIDE LINES It is advisable to insert an isolation transformer in the X-RADIATION WARNING a.c.
SERVICE HINTS How to remove the rear cover 1. Remove the 10 screws as shown in Fig.2. SCREWS SCREWS Fig.2. LOCATION OF CONTROLS Y-Board E-Board Focus Screen Fig.3.
ALIGNMENT PROCEDURE AND OPTION SETTING Entering SERVICE mode Service mode is entered by selecting the “mute” remote key and local “down” simultaneously with the sharpness DAC set to Minimum and programme position 99 selected. Service mode 2 is selected by pressing the Recall remote key while in service mode 1. Service mode navigation - Up /Down remote keys :cycle through the service items available.
REPLACEMENT PARTS LIST Important Safety Notice Components Identified by mark have special characteristics important for safety. * When replacing any of these components, use only manufacturers specified parts. In case of ordering these spare parts, please always add the complete Model-Type number to your order.
SCHEMATIC DIAGRAMS FOR MODELS TX-14B4TC/14B4TF TX-14B4RC/B TX-14B4RF/B TX-14B4RC (Z-185 CHASSIS) IMPORTANT SAFETY NOTICE Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. NOTE RESISTOR All resistors are carbon ¼W resistor, unless marked otherwise.
