AIR
CONDITIONER
Please read this manual carefully before operating
your set and retain it for future reference.
TYPE : LO-STATIC CEILING DUCT TYPE AIR CONDITIONER
For Single LO-Static duct models
P/No. : MFL62760204_v1
CUSTOMER CARE
1800-180-3575 (Toll Free)
(9:00 AM – 9:00 PM)
12 x 7
CALL
Regd. Office : LG Electronics India Pvt. Ltd., A Wing (3rd Floor), D-3, District Center, Saket, New Delhi - 110017
MFL62760204
www.lg.com/in/support
cac.service@lgepartner.com
CLICK
To know more about LG, visit www.lg.com
For Corporate/Instutional enquiries,
please write to enquiries@lgindia.com
Advertisement
Related Manuals for LG JBNQ18GB2A1
Summary of Contents for LG JBNQ18GB2A1
- Page 1 1800-180-3575 (Toll Free) For Corporate/Instutional enquiries, www.lg.com/in/support please write to enquiries@lgindia.com cac.service@lgepartner.com (9:00 AM – 9:00 PM) 12 x 7 CALL CLICK Regd. Office : LG Electronics India Pvt. Ltd., A Wing (3rd Floor), D-3, District Center, Saket, New Delhi - 110017...
- Page 2 Low Static Hide Away Type Air Conditioner Owner's Manual TABLE OF CONTENTS or Your Records Write the model and serial numbers here: Model # Page no. Serial # 1. Safety Precautions You can find them on a label on the side of each unit. 2.
- Page 3 Safety Precautions Precautions To prevent injury and property damage, follow these instructions. Incorrect operation due to ignoring instructions will cause harm or damage, the seriousness of which is indicated by the following symbols. This symbol shows the possibility of death or serious injury. WARNING This symbol indicates the possibility of injury or damage to property.
- Page 4 CAUTION CAUTION • Contact the authorized Service technician for repair or maintenance of this unit. • Contact the installer for installation of this unit. • The air conditioner is not intended for use by young children or infirm persons without supervision.
- Page 5 2. Operating Instructions A) Indoor Unit, Outdoor Unit Wired Remote Wireless Remote Receiver & Controller Controller (Optional) (Standard) Operation of Indication Lamps 1 Emergency Operation button :Turns the indoor unit on or off even when remote control is not working. 2 Signal Detector : Receives the signal from remote control 3 Timer lamp (Green) : Lights up during the timer operation.
- Page 6 Outdoor Unit Air Intake Connecting Wire (side, rear) Power Wire Air Outlet Vents Connection Tube Cooling model: Low static Type Air Conditioner for cooling B) Remote Control Preparation...
- Page 7 C) Remote Control Operations INDOOR FAN SPEED SELECTION Button Used to select fan speed in three steps low, medium and high. * Function not applicable for Lo-Static Duct Model.
- Page 8 Cooling Mode...
- Page 9 Auto Operation Mode...
- Page 10 Dehumidification Mode...
- Page 11 Fan Mode Set the fan speed again. You can select the fan speed in three steps – low, medium and high. Each time the button is pressed, the fan speed mode is shifted.
- Page 12 Temperature Setting/Room Temperature Checking...
- Page 13 Timer...
- Page 14 Care and Care and maintenance maintenance Caution: Before performing any maintenance, turn off the main power to the system. Indoor Unit q Never use any of the followings: Grille, Case, and Remote Control q Turn the system off before cleaning. To clean, •...
- Page 15 Outdoor Unit The heat exchanger coils and panel vents of the outdoor unit should be checked regularly. If clogged with dirt or soot, the heat exchanger and panel vents may be professionally steam cleaned. Note: Dirty or clogged coils will reduce the operating efficiency of the system and cause higher operating costs.
- Page 16 When the air conditioner is not going to be used for a long time. When the air conditioner is to When it is not going to be used for be used again. a long time. Operate the air conditioner on Air circulation n Check that the air inlet and outlet of the mode (Refer to page 15) for 2 to 3 hours.
- Page 17 Self-diagnosis Function...
- Page 18 Error Diagnosis ERROR CODE DIAGNOSIS DESCRIPTION Recover after 5 seconds of operation when respective CH-01 Check room thermistor thermistor healthy CH-02 Check pipe thermistor (CN-Pipe/In) Recover after 3 seconds of operation when respective thermistor healthy CH-03 Check Wired Remote Connection Check wired remote cable for cut/loose contact.
- Page 19 Troubleshooting Before you call for service... Tips Troubleshooting Tips! Save time and money! Check the following points before requesting repairs or service..If the malfunction persist, please contact your dealer. Case Explanation Have you made a mistake in timer operation? The air conditioner does not operate.
- Page 20 Wide LCD Wired Remote Controller (Optional)
