LG 47WV30-BAA Owner's Manual

Signage display
Hide thumbs Also See for 47WV30-BAA:
Table of Contents

Advertisement

Quick Links

OWNER'S MANUAL
SIGNAGE DISPLAY
Please read this manual carefully before operating the your set and
retain it for future reference.
SIGNAGE DISPLAY MODELS
47WV30
www.lg.com

Advertisement

Table of Contents
loading

Related Manuals for LG 47WV30-BAA

Summary of Contents for LG 47WV30-BAA

  • Page 1 OWNER’S MANUAL SIGNAGE DISPLAY Please read this manual carefully before operating the your set and retain it for future reference. SIGNAGE DISPLAY MODELS 47WV30 www.lg.com...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CONTENTS ASSEMBLING AND PREPAR- Unpacking Parts To install in a Portrait Layout Remove L-brackets before Installation Moving Handles - Moving the device in a vertical position - Moving the device in a horizontal posi- tion STORAGE METHOD FOR PANEL PRO- TECTION - Correct Method - Incorrect Method...
  • Page 3 Connecting to the LAN - LAN connection Daisy Chain Monitors - RGB Cable - DVI Cable TROUBLESHOOTING General SPECIFICATIONS RS-232 CONTROL LICENSE NOTE The following three phenomena may occur due to the characteristics of the Super Narrow Bezel LCD. They are not related to the display's performance. 1.

  • Page 4: Assembling And Preparing

    ASSEMBLING AND PREPARING ASSEMBLING AND PREPARING Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories.

  • Page 5: Parts

    Parts RS-232C DVI OUT (CONTROL) DVI IN RGB OUT AUDIO /DVI (RGB/DVI) RGB IN REMOTE CONTROL IN Connection panel (See p.50 to p.51) ASSEMBLING AND PREPARING SPEAKER AUDIO (8 ) COMPONENT IN...

  • Page 6: To Install In A Portrait Layout

    ASSEMBLING AND PREPARING To install in a Portrait Layout When installing in a Portrait Layout, rotate the monitor clockwise 90 degrees (when facing the screen). Remove L-brackets before Installation Remove the L-brackets from each corner of the monitor before installing it. NOTE Keep the removed L-brackets and use them when moving the monitor later.

  • Page 7: Moving Handles

    Moving Handles Moving the device in a vertical position Hold the vertical handles on the left and right sides or the left and right handles on the back of the display. Vertical handle on the side CAUTION Be careful not to directly touch the panel or expose it to shock when moving the monitor. Hold the monitor with the handles as the corners of the front panel are sharp, which may cause an injury.

  • Page 8: Storage Method For Panel Protection

    ASSEMBLING AND PREPARING STORAGE METHOD FOR PANEL PROTECTION Correct Method Panel If the product needs to be set upright, hold both sides of the product, and tilt backward carefully for. Do not let the panel not to touch the floor. Panel Cushion When laying down the product, lay a cushion on a...

  • Page 9: Installing On A Wall

    If you install the Monitor set on a ceiling or slanted wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. Do not over tighten the screws as this may cause damage to the Monitor set and void your warranty.

  • Page 10: External Equipment Setup

    ASSEMBLING AND PREPARING EXTERNAL EQUIPMENT SETUP IR RECEIVER This allows a remote control sensor to be placed in a custom location. Then that display can control other displays via an RS-232 cable. Refer to page 19 for more information. AUDIO (RGB/DVI) REMOTE CONTROL IN...

  • Page 11: Tiling Displays

    Tiling Displays How to Join Sets - Installing Set 1 *Example of 2 x 2 tiling * The numbers assigned in this example (#1, #2, #3, #4) are used to demonstrate the installation procedure to ensure it is easy to follow. These numbers have nothing to do with the Set ID that is used to operate the remote control.

  • Page 12: How To Join Sets - Installing Set 2

    ASSEMBLING AND PREPARING How to Join Sets - Installing Set 2 Join Set 2 to Set 1 using the guide brackets on the top side of Set 1 and mount the two sets to the wall mount plate or the wall. Remove the guide brackets after mounting the sets.

  • Page 13: How To Join Sets - Installing Set 3

    How to Join Sets - Installing Set 3 Fix the guide brackets to Set 3 following the steps above, and loosely mount the set to the wall mount plate or the wall. <Joined Sets 1 and 2> Minimize the space between the sides of the sets using the U-shaped fixture. When the sets are joined with the minimum amount of space between them, firmly mount them to the wall mount plate or the wall.

  • Page 14: How To Join Sets - Installing Set 4

    ASSEMBLING AND PREPARING How to Join Sets - Installing Set 4 Loosely mount Set 4 to the wall mount plate or the wall and minimize the space between the sets using the U-shaped fixtures. When Set 4 is firmly mounted to the wall, remove the U-shaped fixtures. Remove the guide brackets.

  • Page 15: Inserting The Cable Holder

    ASSEMBLING AND PREPARING Inserting the Cable Holder As illustrated, insert two cable holders into the holes at the bottom rear of the set to organize the cable bundles. As illustrated, screw the power cable holder into the hole on the bottom rear of the set to hold the power cables together.

  • Page 16: Remote Control

    REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the Monitor set correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching label inside the compartment, and close the battery cover.
  • Page 17 MENU(See p.41) Selects a menu. Clears all on-screen displays and returns to Set viewing from any menu. Up/Down/Left/Right Allows you to navigate the on-screen menus and adjust the system settings to your preference. Accepts your selection or displays the current mode. BACK Allows the user to move back one step in an interactive...

  • Page 18: Displaying The Device Name Connected To An Input Port

    REMOTE CONTROL PQRS WXYZ 1/a/A CLEAR - * # MARK Displaying the device name connected to an input port BRIGHT NESS MUTE Display which devices are connected to which external input ports. AUTO S.MENU MENU Access the Input list screen and press the blue (input label) button on the remote control.

  • Page 19: Picture Id

    Picture ID Picture ID is used to change the settings of a specific display using a single IR receiver for multi-vision. The set receiving the IR signal communicates with another set via an RS232 connection. Each set is identified by a Set ID. If you assign the Picture ID using the remote control, only displays with the same Picture ID and Set ID can be controlled remotely.

  • Page 20: Using The Monitor Set

    USING THE MONITOR SET USING THE MONITOR SET Connecting to a PC NOTE It is recommended to you use an HDMI connection for the best image quality. CAUTION Connect the signal input cable and tighten it by turning the screws clockwise.

  • Page 21: Dvi To Dvi Connection

    DVI to DVI connection Transmits the digital video signal from your PC to the Monitor set. Connect the PC and the Monitor set with the DVI to DVI cable as shown the following illustrations. DVI IN AUDIO (RGB/DVI) NOTE If you do not use an optional external speaker, connect the PC to the Monitor set with audio cable.

  • Page 22: Audio Connection

    USING THE MONITOR SET Audio connection Transmits the audio signals from your PC to the Monitor set. Connect the PC and the Monitor set with the Audio cable as shown in the following illustrations. You should set PC as an input label to connect the PC to the Monitor set with an Audio connection.

  • Page 23: Adjusting The Screen

    Adjusting the screen Selecting an image mode Display images using optimized settings by selecting one of the preset image modes. Press MENU to access the main menus. Press the Navigation buttons to scroll to PICTURE and press OK. Press the Navigation buttons to scroll to Picture Mode and press OK.

  • Page 24: Customizing Pc Display Options

    USING THE MONITOR SET Advanced Customizes the advanced options. Control See more information about advanced options See p.43. Picture Restores the options to the default Reset setting. When you are finished, press EXIT. When you return to the previous menu, press BACK.

  • Page 25: Customizing Sound Options

    OK. Select and adjust following options, and then press OK. Option Description Infinite LG's Infinity Sound option provides Sound 5.1 channel stereo sound from two speakers. Treble Controls the dominant sounds in the output. When you turn up the treble, it will increase the output to the higher frequency range.
  • Page 26 USING THE MONITOR SET - 16:9: The following selection will allow you to adjust the picture horizontally, in linear proportion, to fill the entire screen(useful for viewing 4:3 formatted DVDs). Just Scan: Following Selection will lead to you view the picture of best quality without loss of original picture in high resolution image.

  • Page 27: Entertainment

    ENTERTAINMENT Connecting to a wired network (Depending on model) Connect the display to a local area network (LAN) via the LAN port as shown on the following illustra- tion and set up the network settings. 47WV30 only supports wired network connection. After making a physical connection, a small number of home networks may require the display network settings to be adjusted.

  • Page 28: Network Status

    (ISP), the number of devices that can receive internet service may be limited by the applicable terms of service. For details, contact your ISP. LG is not responsible for any malfunction of the display and/or the internet connection feature due to communication errors/malfunctions as- sociated with your internet connection, or other connected equipment.

  • Page 29: Connecting Usb Storage Devices

    Connecting USB storage de- vices Connect USB storage devices such as a USB flash memory, external hard drive to the display and use multimedia features (See "Browsing files" on page 30). Connect a USB flash memory or USB memory card reader to the Display as shown on the follow- ing illustration.

  • Page 30: Browsing Files

    ENTERTAINMENT If the USB HDD does not have an external power source, the USB device may not be detected. So be sure to connect the external power source. - Please use a power adaptor for an external power source. We do not guarantee an USB cable for an external power source.

  • Page 31: Viewing Movies

    Supported file format Type Supported file format Movie DAT,MPG,MPEG,VOB,AVI,DIVX,MP4,MKV, TS,TRP,TP,ASF,WMV,FLV) Movie(*.mpg/*.mpeg/*dat/*.ts/*.trp/*.tp/*. vob/*.mp4/*.mov/*.mkv/*.divx/*.avi/*.asf/*. wmv/*.flv/*.avi(motion-jpeg)/*. mp4(motion-jpeg)/*.mkv(motion-jpeg))sup- porting file Video format : DivX3.11, DivX4.12, DivX5.x, DivX6, Xvid1.00, Xvid1.01, Xvid1.02, Xvid1.03, Xvid1.10 beta-1/beta-2, Mpeg-1, Mpeg-2, Mpeg-4, H.264/AVC, VC1, JPEG, Sorenson H.263 Audio format : Dolby Digital, AAC, Mpeg, MP3, LPCM, HE-AAC, ADPCM, WMA Bit rate : within 32 kbps to 320 kbps(MP3)
  • Page 32 ENTERTAINMENT Page 1/1 Movie List Drive1 USB External Move Change Numbers Mark Mode To Photo list Page 1/1 Movie List Mark Mode Drive1 USB External 051. Apple_ ... 02:30:25 Move View Play Marked Mark All Unmark All Exit Mark Mode Menu Description Play Marked...
  • Page 33 Tips for using playing video files Some user-created subtitles may not work properly. Some special characters are not supported in subtitles. HTML tags are not supported in subtitles. Subtitles in languages other than the sup- ported languages are not available. The screen may suffer temporary interrup- tions (image stoppage, faster playback, etc.) when the audio language is changed.
  • Page 34 MAINTENANCE When you select the Set Video Play,, Press the Navigation buttons to scroll to show the Picture Size, Audio Language, Subtitle Language or Repeat. Press the Navigation buttons to scroll to make appropriate adjustments. Menu Description Picture Size Selects your desired picture format during movie play.

  • Page 35: Viewing Photos

    When you select the Set Video,, Press the Navigation buttons to scroll to make appropriate adjustments. When you select the Set Audio,, Press the Navigation buttons to scroll to show the Sound Mode, Clear Voice II or Balance. Press the Navigation buttons to scroll to make appropriate adjustments.
  • Page 36 MAINTENANCE Using photo options Use the following options while viewing photos. 01_a.jpg 2008/12/10 1920 x 1080 479 KB ◄ ◄ ► 2/13 Q.MENU Slideshow Option ■ ► Options Number of selected photos Option Description Slideshow Starts or stops a slideshow with selected photos.

  • Page 37: Listening To Music

    When you select the Set Photo View, Press the Navigation buttons to scroll to select Slide Speed or BGM.. Press the Navigation buttons to scroll to make appropriate adjustments. Video, When you select the Press the Navigation buttons to scroll to make appropriate adjustments.
  • Page 38 MAINTENANCE Control playback by using the following buttons. Music List 3 file(s) Marked Drive1 ► 004. - B04.mp3 005. - B05.mp3 006. - B06.mp3 007. - B07.mp3 00:00 00:00 00:00 00:00 ◄► 005. - B05.mp3 ► 02:30 / 03:25 ■ ►...

  • Page 39: Divx Registration Code

    Music options Press MENU to access the Pop-Up menus. Press the Navigation buttons to scroll to Set Au- dio Play. or Set Audio. and press OK. NOTE Option values changed in Movie List Photo List Music not affect Option value changed in Photo List sic List are changed likewise in...
  • Page 40 MAINTENANCE Deactivating the DivX feature Deactivate all of the devices through the web server and block devices from activating. Delete the existing authentication information to receive a new DivX user authentication for the dis- play. Once this function is executed, a DivX user authentication is required again to see DivX DRM files.

  • Page 41: Customizing Settings

    CUSTOMIZING SETTINGS Accessing main menus Press MENU to access the main menus. Press the Navigation buttons to scroll to one of the following menus and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. When you are finished, press EXIT.

  • Page 42: Picture Settings

    CUSTOMIZING SETTINGS PICTURE settings Press MENU to access the main menus. Press the Navigation buttons to scroll to press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT.
  • Page 43 Basic image options Setting Backlight Adjusts the brightness of the screen by controlling the LCD backlight. If you decrease the brightness level, the screen becomes darker and the power consumption will be reduced without any video signal loss. Contrast Increases or decreases the gradient of the video signal. You may use bright part of the picture is saturated.

  • Page 44: Audio Settings

    Select this option to enjoy sublime sound. Select this option to watch sports broadcasting. To enjoy dynamic sound when playing a game. LG's Infinity Sound option provides 5.1 channel stereo sound from two speakers. Controls the dominant sounds in the output. When you turn up the treble, it will increase the output to the higher frequency range.

  • Page 45: Time Settings

    TIME settings Press MENU to access the main menus. Press the Navigation buttons to scroll to Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT.

  • Page 46: Option Settings

    CUSTOMIZING SETTINGS OPTION settings Press MENU to access the main menus. Press the Navigation buttons to scroll to Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT.
  • Page 47 Setting Tile Mode Setting Tile Mode Auto Config. Position Size Natural Reset Setting Mode Hysterisis Set Temperature Current Temperature NOTE We recommend that you use the Auto mode to prevent any malfunctions resulting from incorrect fan settings. Product/Service This option shows information about the set. Info.

  • Page 48: Network Settings

    CUSTOMIZING SETTINGS NETWORK settings Press MENU to access the main menus. Press the Navigation buttons to scroll to press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT.

  • Page 49: Making Connections

    MAKING CONNECTIONS Connect various external devices to the ports on the Monitor set’s back panel. Find an external device you want to connect to your Monitor set shown in the following illustration. Check the connection type of the external device. Go to the appropriate illustration and check the connection details.

  • Page 50: Connecting To A Hd Receiver, Dvd Or Vcr Player

    MAKING CONNECTIONS Connecting to a HD receiver, DVD or VCR player Connect a HD receiver, DVD, or VCR player to the Monitor set and select an appropriate input mode. HDMI connection Transmits the digital video and audio signals from an external device to the Monitor set. Connect the external device and the Monitor set with the HDMI cable as shown on the following illustration.

  • Page 51: Av Connection

    AV connection Transmits the analog video and audio signals from an external device to the Monitor set. Connect the external device and the Monitor set with a component video cable and composite audio cable as shown on the following illustration. (not included) AUDIO (RGB/DVI)

  • Page 52: Daisy Chain Monitors

    MAKING CONNECTIONS Daisy Chain Monitors Use this function to share the RGB video signal with other monitors without having to use a separate signal splitter box. • To use different products connected to each other Connect one end of the signal input cable (15-pin D-Sub Signal Cable) to the RGB OUT connector of product 1 and connect the other end to the RGB IN connector of other products RGB Cable...

  • Page 53: Troubleshooting

    TROUBLESHOOTING General No image is displayed Problem Is the product power cord connected? Does the 'Invalid Format' message appear? Does the 'No Signal' message appear? NOTE Vertical frequency: To enable the user to watch the product display, screen image should be changed tens of times every second like a fluorescent lamp.
  • Page 54 TROUBLESHOOTING The screen image looks abnormal. Problem Is the screen position wrong? Do thin lines appear on the background screen? Horizontal noise appears or the characters look blurred. The screen is displayed abnormally. After-image appears on the product. Problem After-image appears when the product is turned off.

  • Page 55: Specifications

    SPECIFICATIONS LCD Panel Screen Type Pixel Pitch Video Signal Max. Resolution Recommended Resolution Horizontal Frequency Vertical Frequency Synchronization Type Input Connector Power Rated Voltage Power Consumption Dimensions (Width x Height x Depth) / Weight 1047 mm x 592 mm x 91.1 mm / 29 kg Environmental Operating Temperature conditions...
  • Page 56 SPECIFICATIONS PC supported mode Horizontal Resolution Frequency(kHz) 720 x 400 31.468 31.469 640 x 480 37.879 800 x 600 49.725 832 x 624 48.363 1024 x 768 44.772 1280 x 720 47.72 1360 x 768 47.71 1366 x 768 63.981 1280 x 1024 1 to 9: RGB Mode * : HDMI/DVI mode...

  • Page 57: Rs-232 Control

    RS-232 CONTROL You can control several products at a time by connecting them to a single PC. In the Option menu, Set ID must be between 1 and 225 without being duplicated. Connecting the cable Connect the RS-232C cable as shown in the picture. The RS-232C protocol is used for communication between the PC and product.

  • Page 58: Command Reference List

    RS-232 CONTROL Command Reference List 01. Power 02. Input Select 03. Aspect Ratio 04. Volume Mute 05. Volume Control 06. Contrast 07. Brightness 08. Color 09. Tint 10. Sharpness 11. OSD Select 12. Treble 13. Bass 14. Balance 15. Color Temperature 16.

  • Page 59: Transmission / Receiving Protocol

    Transmission / Receiving Protocol 39. Serial No. Check 40. S/W Version 41. Tile Matrix 42. Tile ID Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1]: First command to control the set. [Command 2]: Second Command to control the set. [Set ID]: Set ID wants to communicate with the set. Command for test is 00. [DATA]: Information passed to the set.
  • Page 60 RS-232 CONTROL Transmission / Receiving Protocol 01. Power (Command : k a) To control Power On / Off of the display. Transmission [k][a][ ][Set ID][ ][Data][Cr] Data 00 : Power Off 01 : Power On Acknowledgement [a][ ][Set ID][ ][OK/NG][Data][x] * In a like manner, if other functions transmit ‘FF’...
  • Page 61 07. Brightness (Command: k h) To adjust screen brightness. You can also adjust contrast in the PICTURE menu. Transmission [k][h][ ][Set ID][ ][Data][Cr] Data 00 to 64: Brightness 0 to 100 Acknowledgement [h][ ][Set ID][ ][OK/NG][Data][x] 08. Color (Command: k i) To adjust screen color.
  • Page 62 RS-232 CONTROL 15. Color Temperature (Command: x u) To adjust color temperature. You can also adjust color temperature in the Picture menu. Transmission [x][u][ ][Set ID][ ][Data][Cr] Data 00 to 64: Warm 50 to Cool 50 Acknowledgement [u][ ][Set ID][ ][OK/NG][Data][x] 16.
  • Page 63 23. Tile H Size (Command: d g) To set the Horizontal size. Transmission [d][g][ ][Set ID][ ][Data][Cr] Data 00 to 64: Min to Max Acknowledgement [g][ ][Set ID][ ][OK/NG][Data][x] 24. Natural Mode (in Tile Mode) (Comman : d j) To assign the Tile Natural mode for Tiling function. Transmission [d][j][ ][Set ID][ ][Data][Cr] Data 00: Off...
  • Page 64 RS-232 CONTROL 31. Language (Command: f i) To set language for OSD. Transmission [f][i][ ][Set ID][ ][Data][Cr] Data 00: Korean 01: Chinese 02: Japanese 03: English 04: French 05: German 06: Italian 07: Portuguese 08: Spanish(EU) 09: Russian Acknowledgement [i][ ][Set ID][ ][OK/NG][Data][x] 32.
  • Page 65 37. FAN Fault Check (Command: d w) To set Fan control on/off. * This function only works in Tile Off mode. Transmission [d][w][ ][Set ID][ ][Data][Cr] Data FF: Data should be always ff in hexadecimal. Acknowledgement [w][ ][Set ID][ ][OK/NG][Data][x] Data 00: Abnormal State 01: Normal State 38.
  • Page 66 RS-232 CONTROL IR CODE (Hex) Function POWER MONITOR ON MONITOR OFF Evergy Saving INPUT Number 0 Number 1 Number 2 Number 3 Number 4 Number 5 Number 6 Number 7 Number 8 Number 9 VOL+ VOL- BRIGHTNESS BRIGHTNESS ARC (MARK) MUTE MENU AUTO...

  • Page 67: License

    LICENSE A different license is supported depending on the model. Visit www.lg.com for more information on the license. HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC. ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, LLC, a subsidiary of Rovi Corporation.
  • Page 68 Make sure to read the Safety Precautions before using the product. Keep the Owner's Manual(CD) in an accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET. Record it below should you ever need service.
