- Page 1 OWNER’S MANUAL LED LCD MONITOR TV Please read this manual carefully before operating the your set and retain it for future reference. LED LCD MONITOR TV MODELS M1950D M2250D M2350D M2450D M2550D www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS CONTENTS ASSEMBLING AND PREPARING Unpacking Parts and buttons Lifting and moving the Monitor set Setting up the Monitor set - Attaching the Stand Base - Detaching the Stand Base and Body - Mounting on a table - Mounting on a wall - Tidying cables REMOTE CONTROL USING THE MONITOR SET Connecting to a PC - HDMI connection - DVI to HDMI connection - RGB connection Adjusting the screen - Selecting an image mode - Customizing image options - Customizing PC display options Adjusting the sound - Selecting an sound mode - Customizing sound options... - Page 3 ENTERTAINMENT Using integrated media features - Connecting USB storage devices - Browsing files - Viewing Photos - Listening to Music - Viewing Movies - DivX registration code - Deactivating the DivX feature CUSTOMIZING SETTINGS Accessing main menus Customizing settings - SETUP settings - PICTURE settings - AUDIO settings - TIME settings - OPTION settings - LOCK settings - INPUT settings - USB settings MAKING CONNECTIONS Connection overview Connecting to a HD receiver, DVD or VCR player - HDMI connection - DVI to HDMI connection...
-
Page 4: Assembling And Preparing
ASSEMBLING AND PREPARING ASSEMBLING AND PREPARING Unpacking Check your product box for the following items. If there are any missing accessories, contact the local dealer where you purchased your product. The illustrations in this manual may differ from the actual product and accessories. Remote control and Batteries CAUTION Do not use any pirated items to ensure the safety and product life span. Any damages or injuries by using pirated items are not covered by the warranty. NOTE The accessories supplied with your product may vary depending on the model. Product specifications or contents in this manual may be changed without prior notice due to upgrade of product functions. Power Cord AC-DC Adapter Cable Tie Stand Base CD (Owner's Manual) / RGB Cable Card... -
Page 5: Parts And Buttons
Parts and buttons PCMCIA Card Slot Remote Control Sensor Touch button INPUT Changes the input source. MENU Accesses the main menus, or saves your input and exits the menus. Selects the highlighted menu option or confirms an input. VOL Adjusts the volume level. Scrolls through the saved programmes. t PR s Turns the power on or off. / I All of the buttons are touch sensitive and can be operated through simple touch with your finger. NOTE You can set the Power indicator to on or off by selecting OPTION in the main menus. ASSEMBLING AND PREPARING Power Indicator Lighting On: Turned on Lighting Off: Turned off Touch Buttons Connection panel (See p.59) Description... -
Page 6: Lifting And Moving The Monitor Set
ASSEMBLING AND PREPARING Lifting and moving the Monitor set When moving or lifting the Monitor set, read the following to prevent the Monitor set from being scratched or damaged and for save transportation regardless of its type and size. CAUTION Avoid touching the screen at all times, as this may result in damage to the screen or some of the pixels used to create images. It is recommended to move the Monitor set in the box or packing material that the Monitor set originally came in. Before moving or lifting the Monitor set, disconnect the power cord and all cables. Hold the top and bottom of the Monitor set frame firmly. Make sure not to hold the transparent part, speaker, or speaker grill area. When holding the Monitor set, the screen should face away from you to prevent the screen from scratches. When transporting the Monitor set, do not expose the Monitor set to jolts or excessive vibration. When transporting the Monitor set, keep the Monitor set upright, never turn the Monitor set on its side, or tilt towards the left or right. Setting up the Monitor set Attaching the Stand Base Place the Monitor set with the screen side down on a flat and cushioned surface. -
Page 7: Mounting On A Table
Remove 2 screws and pull out the Stand Body from the Monitor set. Mounting on a table Lift and tilt the Monitor set into its upright position on a table. Leave a 10 cm (minimum) space from the wall for proper ventilation. 10 cm 10 cm Connect the AC-DC Adapter and Power Cord to a wall outlet. WARNING When you adjust the angle, do not hold the buttom of the Monitor set frame as shown on the following illustration, as may injure your fingers. CAUTION Disconnect the power cord first, and then move or install the Monitor set. Otherwise electric shock may occur. 10 cm NOTE 10 cm Tilt from +10 to -5 degrees up or down to adjust the angle of the Monitor set to suit your view. Front ASSEMBLING AND PREPARING Rear... -
Page 8: Mounting On A Wall
ASSEMBLING AND PREPARING Using the Kensington security system The Kensington security system connector is located at the back of the Monitor set. For more information of installation and using, refer to the manual supplied with the Kensington security system or visit http://www.kensington.com . Connect the Kensington security system cable between the Monitor set and a table. NOTE The Kensington security system is optional. You can obtain additional accessories from most electronics stores. Mounting on a wall For proper ventilation, allow a clearance of 10 cm on each side and from the wall. Detailed installation instructions are available from your dealer, see the optional Tilt Wall Mounting Bracket Installation and Setup Guide. 10 cm 10 cm 10 cm If you intend to mount the Monitor set to a wall, attach Wall mounting interface (optional parts) to the back of the set. When you install the Monitor set using the wall mounting interface (optional parts), attach it carefully so it will not drop. -
Page 9: Tidying Cables
M2250D M2350D VESA (A x B) 75 x 75 Standard screw Number of screws Wall mount RW120 bracket (optional) CAUTION Disconnect the power cord first, and then move or install the Monitor set. Otherwise electric shock may occur. If you install the Monitor set on a ceiling or slanted wall, it may fall and result in severe injury. Use an authorized LG wall mount and contact the local dealer or qualified personnel. D o not over tighten the screws as this may cause damage to the Monitor set and void your warranty. U se the screws and wall mounts that meet the VESA standard. Any damages or injuries by misuse or using an improper accessory are not covered by the warranty. NOTE Use the screws that are listed on the VESA standard screw specifications. The wall mount kit includes an installation manual and necessary parts. -
Page 10: Remote Control
REMOTE CONTROL REMOTE CONTROL The descriptions in this manual are based on the buttons of the remote control. Please read this manual carefully and use the Monitor set correctly. To replace batteries, open the battery cover, replace batteries (1.5 V AAA) matching and ends to the label inside the compartment, and close the battery cover. To remove the batteries, perform the installation actions in reverse. CAUTION Do not mix old and new batteries, as this may damage the remote control. Make sure to point the remote control to the remote control sensor on the Monitor set. (POWER) Turns the Monitor set on or off. ENERGY SAVING (See p.48) Adjusts the brightness of the screen to reduce energy consumption. TV/PC Selects TV or PC mode. LIST (See p.27) Displays the programme table. MARK Select the input to apply the Picture Wizard settings. Check and un-check programmes in the USB menu. Displays the selected favourite programme. (VOLUME) Adjusts the volume level. ENERGY TV / PC INPUT SAVING Q. - Page 11 MENU (See p.46) Accesses the main menus or saves your input and exit menus. Navigation buttons Scrolls through menus or options. Selects menus or options and confirms your input. BACK Allows the user to move return one step in an interactive application, EPG or other user interaction function. Teletext buttons (See p.64) These buttons are used for teletext. For further details, see the ‘Teletext’ section. USB Menu control buttons (See p.36) USB menu(Photo List and Music List or Movie List). ENERGY TV / PC INPUT SAVING Q. V IEW LIST MARK RATIO MUTE GUIDE Q.MENU...
-
Page 12: Using The Monitor Set
USING THE MONITOR SET USING THE MONITOR SET Connecting to a PC Your Monitor set supports the Plug & Play* feature and has the built-in speakers with Surround X that reproduces sound clearly with a rich bass. * Plug & Play: The function when a PC recognizes a connected device that users connect to a PC and turn on, without device configuration or user intervention. NOTE It is recommended to use the Monitor set with the HDMI connection for the best image quality. If you want to use an optional external speaker instead of the built-in speaker, set the Monitor set speaker feature to off (See p.52). HDMI connection Transmits the digital video and audio signals from your PC to the Monitor set. Connect the PC and the Monitor set with the HDMI cable as shown in the following illustrations. You should set PC as an input label to connect the PC to the Monitor set with an HDMI connection. To add an input label, see Adding an Input label on See p.30. HDMI OUT USB IN HDMI/DVI IN DC-IN COMPONENT IN... -
Page 13: Dvi To Hdmi Connection
DVI to HDMI connection Transmits the digital video signal from your PC to the Monitor set. Connect the PC and the Monitor set with the DVI to HDMI cable as shown the following illustrations. DVI OUT AUDIO OUT USB IN DC-IN COMPONENT IN HDMI/DVI IN VIDEO NOTE If you do not use an optional external speaker, connect the PC to the Monitor set with the supplied audio cable. Use a shielded signal interface cable, such as D-sub 15 pin signal cable and DVI to HDMI cable, with a ferrite core to maintain standard compliance for the product. If you want to use HDMI-PC mode, you must set the input label to PC mode. CAUTION Connect the signal input cable and tighten it by turning the screws clockwise. RGB connection Transmits the analog video signal from your PC to the Monitor set. Connect the PC and the Monitor set with the D-sub 15 pin cable as shown the following illustrations. -
Page 14: Adjusting The Screen
USING THE MONITOR SET Adjusting the screen Selecting an image mode Display images in its optimized settings by selecting one of the preset image modes. Press MENU to access the main menus. Press the Navigation buttons to scroll to PICTURE and press OK. Press the Navigation buttons to scroll to Picture Mode and press OK. Press the Navigation buttons to scroll to an image mode you want and press OK. Mode Description Vivid Adjusts the video image for the retail environment by enhancing the Contrast, Brightness, Colour, and Sharpness. Standard Adjusts the image for the normal environment. Cinema Optimizes the video image for the cinematic look and enjoy movies as if you are in a movie theater. Sport Optimizes the video image for high and dynamic actions by emphasizing primary Colours such as white, grass, or sky blue. -
Page 15: Customizing Pc Display Options
Customizing PC display options Customize options of each image mode for the best image quality. This function works in the following mode: RGB[PC] mode. Press MENU to access the main menus. Press the Navigation buttons to scroll to PICTURE and press OK. Press the Navigation buttons to scroll to Screen and press OK. Select and adjust following options, and then press OK. Option Description Resolution Selects a proper Resolution. Auto Sets to adjust the screen Position, Configure Size and Phase automatically. The displayed image may be unstable for a few seconds while the configuration is in progress. Position/ Adjusts the options when the Size/Phase image is not clear, especially when characters are shaky, after the auto configuration. Reset Restores the options to the default setting. When you are finished, press EXIT. When you return to the previous menu, press BACK. Adjusting the sound Selecting an sound mode Play the sound in its optimized settings by selecting one of the preset sound modes. -
Page 16: Watching Tv
WATCHING TV WATCHING TV Connecting an antenna or cable Connect an antenna, cable, or cable box to watch TV referring to the following. The illustrations may differ from the actual accessories and an RF cable is optional. Connecting an antenna or basic cable Connect the Monitor set to a wall antenna socket with an RF cable (75 ohm). Wall Antenna Socket NOTE Use a signal splitter to use more than 2 TVs. If the image quality is poor, install a signal amplifier properly to improve the image quality. If the image quality is poor with an antenna connected, aim the antenna to the proper direction. Visit http://AntennaWeb.org for more information about the antenna and cable connection. Connecting with a cable box Connect the Monitor set to a cable box and the cable box to a wall antenna socket with 2 RF cables (75 ohm). -
Page 17: Accessing The Tv For The First Time
Accessing the TV for the first time When you access the Monitor set for the first time, the initial setting screen appears. Select a language and customize the basic settings. Connect the power cord to a power outlet. Press on the Monitor set to turn the Monitor set on. The Power indicator lighting is turned on. NOTE When the Monitor set is in Power saving mode, the Power indicator lighting blinks. The initial setting screen appears if you access the TV for the first time. NOTE You can also switch the Monitor set from PC mode to TV mode, press TV/PC. You can also access Initial accessing OPTION in the main menus. If you do not operate the Monitor set within 40 seconds when the setting menu screen appears, the setting menus will disappear. Follow the on-screen instructions to customize your Monitor set according to your preferences. Language Mode Setting Country Auto Tuning NOTE To display images in the best quality for your home environment, select Home mode. -
Page 18: Watching Tv
WATCHING TV Watching TV Press on the Remote control or Monitor set to turn the Monitor set on. Press INPUT and select Antenna. Control the Monitor set using the following buttons and menus while you are watching TV. Button / Menu Description ) or Scrolls through the saved programmes PR ( Numbers Selects a programme by entering numbers Adjusts the volume level -) or MUTE Mutes all sounds PICTURE Selects one of the preset image modes (See p.48) AUDIO Selects one of the preset audio modes. (See p.52) RATIO Resizes an image (See p.28) To turn the Monitor set off, Press Remote control or on the Monitor set. Managing programmes Automatically setting up on the programmes... - Page 19 Only for Finland, Sweden, Denmark and Norway DVB-C Auto Tuning is a menu for users in countries that support DVB cable. If you want to select the Antenna Press MENU to access the main menus. Press the Navigation buttons to scroll to SETUP and press OK. Press the Navigation buttons to scroll to Auto Tuning and press OK. Press the Navigation buttons to scroll to Antenna and press OK. Select Start to start automatic tuning. The TV scans and saves available programmes automatically. When you are finished, press EXIT. When you return to the previous menu, press BACK. NOTE Use NUMBER buttons to input a 4-digit password in Lock System ‘On’. Automatic Numbering: Decide whether to use the programme numbers as sent by broadcasting stations for tuning. If you want to select the Cable Press MENU to access the main menus. Press the Navigation buttons to scroll to SETUP and press OK. Press the Navigation buttons to scroll to Auto Tuning and press OK. Press the Navigation buttons to scroll to Cable and press OK.
- Page 20 WATCHING TV Acquired certification SO: Sweden(Comhem), Denmark(YouSee, Stofa). If there are not any Service Operator that you want, select Other Operators. If you select "Other Operators", or the selected country supports "Other Operators" only, it may take some time to search all the channels, or it may not search some of the channels. If some of the channels do not appear, follow the steps below. 1. SETUP → Auto Tuning → Cable 2. Input additional values such as the frequency, symbol rate, modulation, and network ID (You can ask your cable service provider for the above information). The following values are needed in order to search all available programmes quickly and correctly. The commonly used values are provided as "default". However, for correct settings, please inquire of the cable service provider. When running Auto Tuning in DVB cable mode, selecting Full will search through all frequencies to find available channels. In the case when the programme is not searched by selecting the Default, perform the searching by selecting the Full. However, in the case when the programme is searched by selecting the Full, the Auto Tuning time can be taken too much. » Frequency: Enter a user-defined frequency range. »...
-
Page 21: Manually Setting Up Programmes (In Digital Mode)
Manually setting up programmes (In digital mode) Manual Tuning lets you manually add a programme to your programme list. (For countries other than Finland, Sweden, Denmark and Norway & When selecting Antenna if Finland, Sweden, Denmark, Norway or “--”country is chosen) Press MENU to access the Main menus. Press the Navigation buttons to scroll to SETUP and press OK. Press the Navigation buttons to scroll to Manual Tuning and press OK. Press the Navigation buttons to scroll to DTV. Press the Navigation buttons or Number buttons to scroll Select the desired channel number, and then add programmes. -
Page 22: Manually Setting Up Programmes
WATCHING TV Manually setting up programmes (In analogue mode) Manual Tuning lets you manually tune and arrange the stations in whatever order you desire. Press MENU to access the main menus. Press the Navigation buttons to scroll to SETUP and press OK. Press the Navigation buttons to scroll to Manual Tuning and press OK. Press the Navigation buttons to scroll to TV and press OK. Press the Navigation buttons to scroll to System. Press the Navigation buttons to scroll to V/UHF or Cable. Press the Navigation buttons or Number buttons to scroll Select the desired channel number. Press the Navigation buttons to scroll to Commence searching. Press the Navigation buttons to scroll to Store and press OK When you are finished, press EXIT. When you return to the previous menu, press BACK. NOTE Use NUMBER buttons to input a 4-digit password in Lock System ‘On’. L: SECAM L/L (France) BG: PAL B/G, SECAM B/G (Europe / East Europe / Asia / New Zealand / M.East / Africa / Australia) I: PAL I/II (U.K. / Ireland / Hong Kong / South... -
Page 23: Cable Dtv Setting (In Cable Mode Only)
Cable DTV Setting (In Cable mode only) The range that a user can select from the Service Operator menu differs depending on number of Service Operator supported by each country, and if number of supported Service Operator for each country is 1, corresponding function becomes non- activation. After changing Service Operator, a warning window saying that channel map will be deleted when OK button is pressed or Close is selected, and a Auto-tuning pop-up window appears when 'YES' is selected. SETUP Move Auto Tuning Manual Tuning Programme Edit Software Update : On Diagnostics CI Information Cable DTV Setting Press MENU to access the Main menus. Press the Navigation buttons to scroll to SETUP and press OK. Press the Navigation buttons to scroll to Cable Setting and press OK. -
Page 24: In Dtv/Radio Mode
WATCHING TV In DTV/RADIO mode Skipping a programme number Press the navigation buttons, scroll to the programme number you wish to skip. Press the Blue button to skip the selected programme number. Press the Blue button again to release. NOTE The skipped programmes are shown in blue on the programme list and these programmes will not appear on the screen when changing programmes using P( buttons during watching TV. If you wish to watch a skipped programme, directly enter the programme number using number buttons or release it in the Programme Edit menu or EPG. In TV mode Deleting a programme Press the navigation buttons, scroll to the programme number you wish to delete. Press the Red button to delete the selected programme number. Press the Blue button to release. NOTE The selected programme is deleted, all the following programmes are shifted up one. Moving a programme Press the navigation buttons, scroll to the programme number you wish to move. -
Page 25: Software Update
Software Update Software Update means software can be downloaded through the digital terrestrial broadcasting system. Press MENU to access the main menus. Press the Navigation buttons to scroll to SETUP and press OK. Press the Navigation buttons to scroll to Software Update and press OK. Select On or Off. If you select On, a user confirm message box will be displayed to notify that new software is found. When you are finished, press EXIT. When you return to the previous menu, press BACK. When setting “Software Update” Occasionally, a transmission of updated digital software information will result in the following menu on the Monitor set screen. Software update is available. Would you like to download now? (approximately 30 Min ~ 2 hours) Your TV software is updated when you turn off the TV using the remote control or local key. -
Page 26: Diagnostics
WATCHING TV Diagnostics This function enables you to view information on the Manufacturer, Model/Type, Serial Number and Software Version. This displays the information and signal strength of the tuned *MUX. This displays the signal information and service name of the selected MUX. (*MUX: A higher directory of channels in digital broadcasting (a single MUX contains multiple channels.)) Press MENU to access the main menus. Press the Navigation buttons to scroll to SETUP and press OK. Press the Navigation buttons to scroll to Diagnostics and press OK. Display Manufacturer, Model / Type, Serial Number and Software Version. When you are finished, press EXIT. When you return to the previous menu, press BACK. CI [Common interface] Information This function enables you to watch some encrypted services (pay services). If you remove the CI Module, you cannot watch pay services. When the module is inserted into the CI slot, you can access the module menu. To purchase a module and smart card, contact your dealer. Do not repeatedly insert or remove a CI module from the Monitor set. This may cause a malfunction. When the Monitor set is turned on after inserting a CI Module, you may not have any sound output. This may be incompatible with the CI module and smart card. CI (Common Interface) functions may not be possible depending upon the country broadcasting circumstances. -
Page 27: Selecting The Programme List
Selecting the programme list You can check which programmes are stored in the memory by displaying the programme list. Displaying programme LIST Press LIST to access the Programme List. When you are finished, press MENU NOTE You may find some blue programmes. These have been set up to be skipped by auto programming or in the programme edit mode. Some programmes with the channel number shown in the programme LIST indicate there is no station name assigned. Selecting a programme in the programme list Press the Navigation buttons to programme. Switch to the chosen programme number and press OK. NOTE Press TV/RAD in Digital TV. will be switched between TV, DTV and Radio from the program you are currently watching.) Paging through a programme list Press the Navigation buttons to turn the pages. -
Page 28: Using Additional Options
WATCHING TV Using additional options Adjusting aspect ratio Resize the image to view the image at its optimal size by pressing RATIO while you are watching Monitor set. CAUTION If a fixed image displays on the screen for a long period of time, it will be imprinted and become a permanent disfigurement on the screen. This is “image burn” or “burn-in” and not covered by the warranty. If the aspect ratio is set to 4:3 for a long period of time, image burn may occur on the letterboxed area of the screen. NOTE You can also change the image size by accessing the quick menus or the main menus. - 16:9: The following selection will allow you to adjust the picture horizontally, in linear proportion, to fill the entire screen(useful for viewing 4:3 formatted DVDs). - Just Scan: Following Selection will lead to you view the picture of best quality without loss of original picture in high resolution image. Note: If there is noise in original Picture, You can see the noise at the edge. Just Scan - Original: When your Monitor set receives a wide screen signal it will automatically change to the picture format broadcast. Original - Full Wide: When Monitor set receives the wide screen signal,it will lead you to adjust the picture... - Page 29 - 4:3: The following selection will allow you to view a picture with an original 4:3 aspect ratio, gray bars will appear on both the left and right of the screen. - 14:9: You can view a picture format of 14:9 or a general Monitor set programme in the 14:9 mode. The 14:9 screen is viewed in the same way as in 4:3, but is magnified to the left and right. - Zoom: The following selection will allow you to view the picture without any alteration, while filling the entire screen. However, the top and bottom of the picture will be cropped. WATCHING TV - Cinema Zoom: Choose Cinema Zoom when you want to enlarge the picture in correct proportion. Note: When enlarging or reducing the picture, the image may become distorted. button: Adjust enlarge proportion of < or > Cinema Zoom. The adjustment range is 1 to button: Move the screen. NOTE You can only select 4:3, 16:9 (Wide), 14:9, Zoom/Cinema Zoom in Component mode. You can only select 4:3, Original, 16:9 (Wide), 14:9, Zoom/Cinema Zoom in HDMI mode.
-
Page 30: Using The Input List
WATCHING TV Using the input list Selecting an input source Press INPUT to access the input source list. - The connected device displays on each input source. Press the Navigation buttons to scroll to one of the input sources and press OK. Input source Description Antenna or Watch TV over the air, cable, and Cable digital cable broadcast View a PC display on the screen Watch the contents in a VCR or other external devices Component Watch the contents in a DVD or other external devices, or through a digital set-top box HDMI Watch contents in a PC, DVD or Digital settop box other high definition devices The connected input sources display in black and the disconnected input sources in grey. - If you add an input label to each input sources, you can easily identify a device connected to each input source. Adding an Input label Press MENU to access the main menus. -
Page 31: Language Selection (In Digital Mode Only)
NOTE If you do not finish the set-up Installation Guide by pressing BACK or if you time out on the OSD (On Screen Display) the installation menu will continuously appear until the set up is completed whenever the Monitor set is switched on. If you select the wrong local country, teletext may not appear correctly on the screen and some problems may occur during teletext operation. The CI (Common Interface) function may not be applied based on country broadcasting circumstances. DTV mode control buttons may not function based on country broadcasting circumstances. In country that Digital broadcasting regulation isn’t fixed, some DTV function may not work depending on digital broadcasting circumstances. The Country Setting "UK" should only be activated in UK. If the country setting is set to "--", European terrestrial/cable digital standard broadcasting programmes are available, but some DTV functions may not work properly. WATCHING TV Language selection (In digital mode only) The Audio function allows selection of a preferred language. If audio data in a selected language is not broadcast, the default language audio will be played. -
Page 32: Using The Lock Options
WATCHING TV Audio Language OSD Information Display Status Not Available MPEG Audio Dolby Digital Audio Audio for “Visual Impaired” Audio for “Hearing Impaired” Dolby Digital Plus Audio AAC Audio Subtitle Language Selection When two or more subtitle languages are broadcast, you can select the subtitle language with the SUBTITLE button on the remote control. Press the Navigation buttons to select a subtitle language. Subtitle Language OSD Information Display Status Not Available Teletext Subtitle Subtitle for “Hard of Hearing” The audio/subtitles can be displayed in a simpler form with 1 to 3 characters broadcast by the service provider. When you select supplementary Audio (Audio for “Visual/Hearing Impaired”) the TV may output a part of the Main audio. Using the Lock options Locking the buttons on the Monitor set. -
Page 33: Parental Control (In Digital Mode Only)
Parental control (In digital mode only) This function operates according to information from the broadcasting station. Therefore if the signal has incorrect information, this function does not operate. A password is required to gain access to this menu. This set is programmed to remember which option it was last set to even if you switch the set off. Prevents children from watching certain adult’s TV programmes, according to the ratings limit set. Enter a password to watch a blocked programme. Blocking Off : Permits all Blocking Off : Permits all programmes programmes 10 and above 10 and above 11 and above 11 and above 12 and above 12 and above 13 and above... -
Page 34: Epg (Electronic Programme Guide) (In Digital Mode)
EPG (ELECTRONIC PROGRAMME GUIDE) (IN DIGITAL MODE) EPG (ELECTRONIC PROGRAMME GUIDE) (IN DIGITAL MODE) Using Electronic Programme Guide This system has an Electronic Programme Guide (EPG) to help your navigation through all the possible viewing options. The EPG supplies information such as programme listings, start and end times for all available services. In addition, detailed information about the programme is often available in the EPG (the availability and amount of these programme details will vary, depending on the particular broadcaster). This function can be used only when the EPG information is broadcast by broadcasting companies. The EPG displays the programme details for next 8 days. Press INFO to shows the present screen information. Icon Description Displayed with a DTV Programme. Displayed with a Radio Programme. Displayed with a MHEG Programme. Displayed with a AAC Programme. -
Page 35: Button Function In 8 Day Guide Mode
Button Function in 8 Day Guide Mode Button Description RED Button Change EPG mode. GREEN Enter Date setting mode. Button YELLOW Enter Timer Record/Remind setting Button mode. BLUE Button Enter Timer Record/Remind list mode. The EPG will disappear after moving to a selected program. Select NOW or NEXT Programme. Select the Broadcast Programme. Page Up/Down. PAGE ( , ) GUIDE Switch off EPG. BACK EXIT TV/RAD Select TV or RADIO Programme. INFO Detail information on or off This displays the 8 Day Guide mode for the programme in the Favourite List. -
Page 36: Entertainment
ENTERTAINMENT ENTERTAINMENT Using integrated media features Connecting USB storage devices Connect USB storage devices such as a USB flash memory, external hard drive, or MP3 player to the Monitor set and use multimedia features (“Browsing files” See p.37). Connect a USB flash memory or USB memory card reader to the Monitor set as shown on the following illustration. The USB screen appears. USB IN HDMI/DVI IN DC-IN COMPONENT IN VIDEO To disconnect a USB storage device, make sure to end the connection properly to prevent damages to the Monitor set or files. Press Q.MENU to access the quick menus. Press the Navigation buttons to scroll to USB Device and press OK. Disconnect the USB storage device only when the message says that it is safe to remove. CAUTION Do not turn the Monitor set off or remove a USB storage device while the USB storage device is connected to the Monitor set, as this could result in loss of files or damage to the USB storage device. Back up your files saved on a USB storage device frequently, as you may lose or damage the files and this may be not... -
Page 37: Browsing Files
If the USB HDD does not have an external power source, the USB device may not be detected. So be sure to connect the external power source. - Please use a power adaptor for an external power source. We do not guarantee an USB cable for an external power source. Data in a USB storage device cannot be deleted in the NTFS file system. If your USB memory device has multiple partitions or if you use a USB multi-card reader, you can use up to 4 partitions or USB memory devices. Only the FAT, FAT16, FAT32 file system supports the delete function. If a USB memory device is connected to a USB multi-card reader, its volume data may not be detected. If the USB memory device does not work properly, disconnect and reconnect it. How fast a USB memory device is detected differs from device to device. If the USB is connected in Standby Mode, specific hard disk will automatically be loaded when the Monitor set is turned on. The recommended capacity is 1 TB or less for a USB external hard disk and 32 GB or less for USB memory. Any device with more than the recommended capacity may not work properly. If a USB external hard disk with a “Energy Saving” function does not work, turn the hard disk off and on again to make it work properly. USB storage devices below USB 2.0 are supported as well. But they may not work properly in the movie list. When a broken file is played in the USB storage, the Monitor set may turn off or work abnormally. ENTERTAINMENT Browsing files Access the Photo, Music or Movie lists and... -
Page 38: Viewing Photos
ENTERTAINMENT Press the Navigation buttons to browse files. The highlighted file will display in the preview window. Photo List Page 1/1 No Marked Up Folder Drive 1 SG kim 002 10/01/2010 SG kim 004 10/01/2010 SG kim 006 10/01/2010 0 folder(s), 0 file(s) Up Folder Navigation Popup Menu Page Change Description Current page number/total number of pages The number of selected files File and Folder name Preview window File size, information. - Page 39 Using photo options Use the following options while viewing photos. ꔗ 1/17 ꔃ Slideshow Delete Option Q.MENU Options Number of selected photos Option Description Slideshow Starts or stops a slideshow with selected photos. If there are no selected photos, all photos saved in the current folder display during a slideshow. To set a slideshow speed, select Option. Turns the background music on or off. To set the background music folder, select Option. Rotates photos clockwise (90°, 180°, (Rotate) 270°, 360°). NOTE The supported photo size is limited. You cannot rotate a photo if the resolution of the rotated width is larger than the supported resolution size. Delete Deletes a photo. Option Slide Speed: Selects a slideshow speed (Fast, Medium, Slow).
-
Page 40: Listening To Music
ENTERTAINMENT Listening to Music Press the Navigation buttons to scroll to USB and press OK. Press the Navigation buttons to scroll to Music List and press OK. Select Drive1 to access the connected USB storage device. Press the Navigation buttons to scroll to a folder you want and press OK. Press the Navigation buttons to scroll to a file you want and press OK. A pop-up window will appears. Music List No Marked Page 2/3 Music Title SG 001 Up Folder SG 001.mp3 SG 002.mp3 SG 003.mp3 1 folder(s), 3 file(s) Up Folder Navigation Popup Menu Page Change Play music by using the following menus. - Page 41 Using the Music List function, play Press Q. MENU to access the Pop-Up menus. Press the Navigation buttons to scroll to Set Audio Play Set Audio and Press OK. Choose Options. Set Audio Play. Set Audio. ꕉ Previous When you select the Set Audio Play. Press the Navigation buttons to show the Set Audio Play. Press the Navigation buttons to make appropriate adjustments. NOTE When “Off” is selected in Repeat menu, replay will stop once the last file in the list finishes playing. But, when “ ꕙ ” button is pressed while the last fine in the list is in the middle of replay and “Repeat” is in “Off” position, the first file in the list will be play. When you select the Set Audio. Press the Navigation buttons to to show the Sound Mode, Auto Volume, Clear Voice II, Balance.
-
Page 42: Viewing Movies
ENTERTAINMENT Viewing Movies Play video files on the Monitor set. Your Monitor set displays all of the video files saved in a USB storage device. Movie (*.dat / *.mpg / *.mpeg / *.ts / *.trp / *.tp / *.vob/ *.mp4 / *.mkv / *.avi / *.divx) supporting file. Video format: DivX3.11, DivX4.12, DivX5. x, DivX6, Xvid1.00, Xvid1.01, Xvid1.02, Xvid1.03, Xvid 1.10- beta-1/beta-2, Mpeg-1, Mpeg-2, Mpeg-4, H.264/AVC Audio format: Dolby Digital, AAC, Mpeg, MP3, LPCM, HE-AAC Bit rate: within 32 kbps to 320 kbps (MP3) Subtitle format: *.smi / *.srt / *.sub (Micro DVD, SubViewer1.0/2.0) / *.ass / *.ssa / *.txt (TM Player) / *.psb (Power Divx). Some user-created subtitles may not work properly. Some special characters are not supported in subtitles. HTML tags are not supported in subtitles. Subtitles in languages other than the supported languages are not available. Time information in an external subtitle file should be arranged in ascending order to be played. The screen may suffer temporary interruptions (image stoppage, faster playback, etc.) when the audio language is changed. A damaged movie file may not be played correctly, or some player functions may not be usable. Movie files produced with some encoders may not be played correctly. If the video and audio structure of recorded file is not interleaved, either video or audio is outputted. - Page 43 avi: Dolby Digital, HE-AAC, AAC, MPEG, MP3, LPCM mkv: Dolby Digital, HE-AAC, AAC, MPEG, MP3, LPCM divx: Dolby Digital,HE-AAC,AAC,MPEG, MP3,LPCM Max Resolution 1920 x 1080 @ 30p Press the Navigation buttons to scroll to USB and press OK. Press the Navigation buttons to scroll to Movie List and press OK. Select Drive1 to access the connected USB storage device. Press the Navigation buttons to scroll to a folder you want and press OK. Press the Navigation buttons to scroll to a file you want and press OK. A pop-up window will appears. Movie List Page 2/3 No Marked Moive Title SG 001.avi Up Folder SG 001.avi SG 002.avi SG 003.avi 640x480, 720KB Up Folder...
- Page 44 ENTERTAINMENT When you select the Set Video Play. Menu Description Picture Selects your desired picture format during Size movie play Audio Changes the Language Group of the Language audio/subtitle during movie play. Subtitle Language Sync Adjusts the time synchronisation of the subtitle from -10 secs to +10 secs by steps of 0.5 secs during movie play. Position Changes the position of the subtitle either up or down during movie play. Size Selects your desired Subtitle size during movie play. Press the Navigation button to show the Picture Size, Audio Language or Subtitle Language. Press the Navigation button to make appropriate adjustments. Subtitle Support Language Language Latin1 English, Spanish, French, German,...
-
Page 45: Divx Registration Code
DivX registration code Check and register the DivX registration code of your Monitor set so that you can rent or purchase the latest movies at www.divx.com/vod . To play a rented or purchased DivX file, the file’s registration code should be same with your Monitor set’s DivX registration code. Press MENU to access the USB menus. Press the Navigation button to scroll to DivX Reg. Code and press OK. View the registration code of your Monitor set. DivX(R) Video On Demand Your registration Code is: xxxxxxxxxx To learn more visit www.divx.com/vod. Close ABOUT DIVX VIDEO: DivX® is a digital video format created by DivX, Inc. This is an official DivX Certified device that plays DivX video. Visit www.divx.com for more information and software tools to convert your files into DivX video. ABOUT DIVX VIDEO-ON-DEMAND: This DivX Certified® device must be registered in order to play DivX Video-on-Demand (VOD) content. To generate the registration code, locate the DivX VOD section in the device setup menu. Go to vod.divx.com with this code to complete the... -
Page 46: Customizing Settings
CUSTOMIZING SETTINGS CUSTOMIZING SETTINGS Accessing main menus Press MENU to access the main menus. Press the Navigation buttons to scroll to one of the following menus and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. When you are finished, press EXIT. When you return to the previous menu, press BACK. PICTURE (See p.48) Adjusts the image size, quality, or effect SETUP (See p.47) Sets up and edit programmes SETUP OPTION (See p.56) Customizes the general settings OPTION LOCK (See p.57) Locks or unlocks channels and programs AUDIO (See p.52) Adjusts the sound quality, effect, or volume level PICTURE AUDIO TIME LOCK INPUT INPUT (See p.58) Views the input sources with their labels... -
Page 47: Customizing Settings
Customizing settings SETUP settings Press MENU to access the main menus. Press the Navigation buttons to scroll to SETUP and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available Programme settings are described in the following: Setting Auto Tuning Tunes and stores all available programmes through antennas or cable inputs (See p.18). Manual Tuning Tunes and stores the programmes you want manually (See p.21 to 22). Programme Edit Adds or deletes pregrammes on the programme (See p.23). Software Update This automatically updates your monitor's software. (See p.25). Diagnostics This shows you the manufacturer, model or type number, serial number and software information. (See p.26). CI information Enables you to watch some encrypted services (pay services) (See p.26). Cable DTV Setting You can run the service operator or the programme auto update. (Only in countries where DBV-C (In Cable Mode is supported). (See p.23). Only) CUSTOMIZING SETTINGS SETUP Auto Tuning... -
Page 48: Picture Settings
CUSTOMIZING SETTINGS PICTURE settings Press MENU to access the main menus. Press the Navigation buttons to scroll to PICTURE and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available picture settings are described in the following: Setting Aspect Ratio Changes the image size to view images at its optimal size (See p.28). Picture Wizard Adjusts the image quality and calibrates the screen by following the on-screen instructions. The customized options will be saved as Expert1 in the picture modes. Picture Wizard Dynamic Contrast Colour Gain NOTE If you use Picture Energy Saving Sets to automatically adjust the screen brightness corresponding to the surroundings. Option The backlight is off. Minimum/ Selects the brightness level of the backlight. Medium/ Maximum Screen off The screen turns off in 3 seconds. PICTURE Aspect Ratio : 16:9 Picture Wizard ꕊ... - Page 49 Setting Picture Mode Selects one of the preset image or customizes options in each mode for the best Monitor set screen performance. You are also able to customize advanced options of each mode. The available preset picture modes vary depending on the Monitor set . Mode Vivid Adjusts the video image for the retail environment by enhancing the contrast, brightness, Colour, and sharpness. Standard Adjusts the image for the normal environment. Cinema Optimizes the video image for a cinematic look to enjoy movies as if you are in a movie theater. Sport Optimizes the video image for high and dynamic actions by emphasizing primary Colours such as white, grass, or sky blue. Game Optimizes the video image for a fast gaming screen such as PCs or games. Expert1/2 Adjusts the detailed video image settings for video experts as well as general viewers. SCREEN Customizes the PC display options in RGB mode. (In RGB-PC Option Mode Only) Resolution Selects a proper resolution. See "Specification" See p.71 for the recommended resolution for each model. Auto Configure Sets to adjust the screen position, clock, and phase automatically. The displayed image may be unstable for a few seconds while the configuration is in progress. Position/Size/ Adjusts the options when the picture is not clear, especially when characters are Phase shaky, after the auto configuration.
- Page 50 CUSTOMIZING SETTINGS Basic image options Setting Backlight A djusts the brightness of the screen by controlling the LCD backlight. If you decrease the brightness level, the screen becomes darker and the power consumption will be reduced without any video signal loss. Contrast Increases or decreases the gradient of the video signal. You may use Contrast when the bright part of the picture is saturated. Brightness Adjusts the base level of the signal in the picture. You may use Brightness when the dark part of the picture is saturated. Sharpness Adjusts the level of crispness in the edges between the light and dark areas of the picture. The lower the level, the softer the image. Colour Adjusts intensity of all Colours. Tint Adjusts the balance between red and green levels. Colour Temperature Set to warm to enhance hotter colours such as red, or set to cool to make picture bluish. Advanced Control Customizes the advanced options. Reset Restores the options to the default setting. NOTE You cannot adjust colour and tint in the RGB-PC / HDMI-PC mode. When the Expert 1/2 is selected, you can select Backlight, Contrast, Brightness, H Sharpness, V Sharpness, Colour or Tint . Advanced image options Setting Dynamic Contrast...
- Page 51 Setting Colour Temperature This is the function to adjust the overall colour of the screen to the feeling you want. (Medium/Warm/Cool) y A » Method: 2 Points » Pattern: Inner, Outer » Red/Green/Blue Contrast, Red/Green/Blue Brightness : » The adjustment range is -50 to +50. y B » Method: 10 point IRE » Pattern: Inner / Outer » IRE (Institute of Radio Engineers) is the unit to display the size of the video signal and can be set among 10, 20, 30 to 100. You can adjust Red, Green or Blue according to each setting. » Red/Green/Blue: The adjustment range is -50 to +50. Colour Management As the tool used by the experts to make adjustments by using the test patterns, this does not System affect other colours but can be used to selectively adjust the 6 colour areas (Red/Green/Blue/ Cyan/ Magenta/Yellow). Colour difference may not be distinctive even when you make the adjustments for the general video. Adjusts Red/Green/Blue/Yellow/Cyan/Magenta. » Red/Green/Blue/Yellow/Cyan/Magenta Colour: The adjustment range is -30 to +30. » Red/Green/Blue/Yellow/Cyan/Magenta Tint: The adjustment range is -30 to +30. This feature is disable in RGB-PC and HDMI (PC) mode. CUSTOMIZING SETTINGS Description...
-
Page 52: Audio Settings
CUSTOMIZING SETTINGS AUDIO settings Press MENU to access the main menus. Press the Navigation buttons to scroll to AUDIO and press Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available audio options are described in the following: Setting Auto Volume Activates the Auto Volume feature to keep the volume level consistent whenever you change programmes. The volume level may not be consistent due to different signal conditions of broadcasting stations. Clear Voice ll By differentiating the human sound range from others, it helps users listen to human voices better. Balance Adjusts balance between the left and right speakers according to your room environment. Sound Mode Selects one of the preset sound modes or customize each option in each mode. Mode Standard Music Cinema Sport Game NOTE I f sound quality or volume is not at the level you want, it is recommended to use a separate home theater system or amplifier to cope with different user environments. Option Surround X Treble Bass Reset... - Page 53 Setting Digital Audio Out This function allows you to select your preferred Digital Audio Output. When Dolby Digital is available, selecting Auto in the Digital Audio Out menu will set SPDIF(Sony Philips Digital InterFace) output to Dolby Digital. If Auto is selected in the digital audio out menu when Dolby Digital is not available, SPDIF output will be PCM(Pulse-code modulation). Even if both Dolby Digital and Audio language have been set in a channel which broadcast Dolby Digital Audio, only Dolby Digital will be played. NOTE There is a possibility that when HDMI mode, some DVD players do not make SPDIF sound. At that time, set the output of the digital audio of the DVD player to PCM. (In HDMI, Dolby Digital Plus is not supported). Mode Auto (Speaker On) Auto (Speaker Off) TV Speaker Turns on the internal speaker of the Monitor set when using an external Hi-Fi or SRS system. You can use the TV speaker as an audio output device even if there is no video input. DTV Audio Setting When different audio types exist in an input signal, this function allows you to select the audio type (In Digital Mode you want. Only) NOTE y Auto: Automatically outputs in the order HE - AAC ꔃ Dolby Digital ꔃ MPEG. y HE - AAC, Dolby Digital, MPEG: Allows users to select the audio type they want. »...
- Page 54 CUSTOMIZING SETTINGS Stereo/Dual Reception (In Analogue Mode Only) When a programme is selected, the sound information for the station appears with the programme number and station name. Press Q. MENU and press the Navigation to access the AUDIO and press OK. Press the Navigation button to scroll to sound output Broadcast On Screen Display Mono MONO Stereo STEREO Dual DUAL I , DUAL II , DUAL I + II Mono sound selection If the stereo signal is weak in stereo reception, you can switch to mono. In mono reception, the clarity of sound is improved. Language selection for dual language broadcast a programme can be received in two languages (dual language), you can switch to DUAL I, DUAL II or DUAL I + II. DUAL I Sends the primary broadcast language to the loudspeakers. DUAL I I Sends the secondary broadcast language to the loudspeakers.
-
Page 55: Time Settings
TIME settings Press MENU to access the main menus. Press the Navigation buttons to scroll to TIME and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available time settings are described in the following: Setting Clock Sets the time, date, time zone, and daylight-saving time feature. The time will be set automatically according to a digital channel signal which includes time information provided by the broadcasting station. If not, set the time and date manually. NOTE If you turn the power off by disconnecting the power cord, the current time setting will be reset. Off Time/On Time Sets the time to turn on or off the Monitor set automatically. To use this function, you should set the current time and date in the Clock menu. NOTE I f you do not press any button within 2 hours after the Monitor set turns on by the On Time feature, the Monitor set enters the Standby mode automatically. I f you set the On Time feature and turn the Monitor set off by pressing Main power switch, the On Time feature will not work. To activate the On Time feature, the Monitor set must be in Standby mode. I f you set both Off Time and On Time features to the same time, the Off Time function overrides the On Time feature, when the Monitor set is on. Sleep Timer Sets the length of time until the Monitor set to turns off. When you turn the Monitor set off and turn it on again, the Sleep Timer will be set to off. CUSTOMIZING SETTINGS TIME Clock Off Time... -
Page 56: Option Settings
CUSTOMIZING SETTINGS OPTION settings Press MENU to access the main menus. Press the Navigation buttons to scroll to OPTION and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available option settings are described in the following: Setting Language Selects a language for the display or audio (See p.31). Disabled This function is for the blind, and provides explanatory audio describing the current situation in a Assistance TV programme in addition to the basic audio. Data Service This function allow users to choose between MHEG (Digital Teletext) and Teletext if both exist at (only in Ireland.) the same time.(See p.64 to 66) Country Selects a desired country.(See p.30) Input Label Selects a label for an input source to identify a device connected to each input source. NOTE If you want to use HDMI-PC mode, you must set the input label to PC mode. Set ID Adds an ID to the connected devices.(See p.80) Power Indicator Sets to turn on or off the Power indicator on the Monitor set. Demo Mode Display the slide show to explain the various logo of this Monitor set. -
Page 57: Lock Settings
LOCK settings Press MENU to access the main menus. Press the Navigation buttons to scroll to LOCK and press Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available lock settings are described in the following: Setting Set Password Changes the 4-digit password. The default password is ‘0’, ‘0’, ‘0’, When France is selected for Country, the default password is not ‘0’, ‘0’, ‘0’, ‘0’ but ‘1’,’2’,’3’,’4’. NOTE If you forget the password, press '0' '3' '2' Lock System Activates or deactivates the lock system Rating Block Programme Parental Guidance Input Block Key Lock The Monitor set can be set so that the remote control is required to control it. This feature can be used to prevent unauthorized viewing. NOTE In Key Lock ‘On’, if the Monitor set is turned off, press the INPUT, P the Monitor set or POWER, INPUT, P control then the set will be turned on. -
Page 58: Input Settings
CUSTOMIZING SETTINGS INPUT settings Press MENU to access the main menus. Press the Navigation buttons to scroll to INPUT and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available input settings are described in the following: Setting Antenna Select it when watching the DTV/TV.(See p.16). Select it when watching the VCR or external equipment.(See p.62). Component Select it when using the DVD or the Digital set-top box depends on connector.(See p.61). Select it when using PC depends on connector.(See p.12). HDMI Select it when using DVD, PC or Digital set-top box depend on connector.(See p.12 or 61). USB settings Press MENU to access the main menus. Press the Navigation buttons to scroll to USB and press OK. Press the Navigation buttons to scroll to the setting or option you want and press OK. - To return to the previous level, press BACK. When you are finished, press EXIT. When you return to the previous menu, press BACK. The available usb settings are described in the following: Setting Photo List You can view photo files on USB storage device. (See p.38) Music List You can play music files on USB storage device. (See p.40) Movie List You can play movie files on a USB storage device. (See p.42) Divx Reg. -
Page 59: Making Connections
MAKING CONNECTIONS Connect various external devices to the Monitor set and switch input modes to select an external device. For more information about an external device’s connection, refer to the manual supplied with each device. Available external devices are: HD receivers, DVD players, VCRs, audio systems, USB storage devices, PC, camcorders or cameras, gaming devices, and other external devices. NOTE If you record a TV program on a DVD recorder or VCR, make sure to connect the Monitor set signal input cable to the Monitor set through a DVD recorder or VCR. For more information about recording, refer to the manual supplied with the connected device. The external device connection may differ from the model. Connect external devices to the Monitor set by referring to the following table. Connection overview Connection type HDMI (highly recommended) Component Optical audio Analog audio Video Digital Analog MAKING CONNECTIONS Audio Digital Analog... - Page 60 MAKING CONNECTIONS Connect various external devices to the ports on the Monitor set’s back panel. Find an external device you want to connect to your Monitor set shown on the following illustration. Check the connection type of the external device. Go to the appropriate illustration and check the connection details. HD Receiver HDMI – See p.61 DVI – See p.61 Component – See p.61 Speaker Digital optical audio – See p.62 Headphone – See p.63 HDMI – See p.12 DVI – See p.13 RGB – See p.13 NOTE If you connect a gaming device to the Monitor set, use the cable supplied with the gaming device.
-
Page 61: Connecting To A Hd Receiver, Dvd Or Vcr Player
Connecting to a HD receiver, DVD or VCR player Connect a HD receiver, DVD, or VCR player to the Monitor set and select an appropriate input mode. HDMI connection Transmits the digital video and audio signals from an external device to the Monitor set. Connect the external device and the Monitor set with the HDMI cable as shown on the following illustration. HDMI OUT USB IN HDMI/DVI IN DC-IN COMPONENT IN VIDEO NOTE Use a High Speed HDMI™ Cable. High Speed HDMI™ Cables are tested to carry an HD signal up to 1080p and higher. DVI to HDMI connection Transmits the digital video signal from an external device to the Monitor set. Connect the external device and the Monitor set with the DVI-HDMI cable as shown in the following illustration. To transmit an audio signal, connect an optional audio cable. -
Page 62: Euro Scart Connection
MAKING CONNECTIONS Euro Scart connection Transmits the video and audio signals from an external device to the Monitor set. Connect the external device and the Monitor set with the Euro Scart cable as shown on the following illustration. To display images by using progressive scan, make sure to use the Euro Scart cable. USB IN HDMI/DVI IN DC-IN COMPONENT IN VIDEO AUDIO/ VIDEO Connecting to an audio system Use an optional external audio system instead of the built-in speaker. NOTE If you use an external audio device instead of the built-in speaker, set the TV speaker feature to off (See p.52). Digital optical audio connection ANTENNA/ CABLE IN AUDIO Transmits the digital audio signal from the Monitor set to an external device. Connect the external device and the Monitor set with the optical audio... -
Page 63: Headphone Connection
Headphone connection Transmits the headphone signal from the Monitor set to an external device. Connect the external device and the Monitor set with the headphone as shown on the following illustration. USB IN HDMI/DVI IN DC-IN COMPONENT IN VIDEO Connecting to a USB Connect a USB storage device such as s USB flash memory, external hard drive, MP3 player or a USB memory card reader to the Monitor set and access the USB menu to use various multimedia files. "Connecting USB storage p.36 and “Browsing ANTENNA/ CABLE IN AUDIO HDMI/DVI IN DC-IN MAKING CONNECTIONS devices" on See files” on See p.37 USB IN COMPONENT IN ANTENNA/ CABLE IN VIDEO... -
Page 64: Teletext
TELETEXT TELETEXT This feature is not available in all countries. Teletext is a free service broadcast by most TV stations which gives up-to-the-minute information on news, weather, television programmes, share prices and many other topics. The teletext decoder of this TV can support the SIMPLE, TOP and FASTEXT systems. SIMPLE (standard teletext) consists of a number of pages which are selected by directly entering the corresponding page number. TOP and FASTEXT are more modern methods allowing quick and easy selection of teletext information. ENERGY TV / PC INPUT SAVING Q. V IEW LIST MARK RATIO MUTE GUIDE MENU Q.MENU INFO EXIT Auto Config. Switch On/Off Press the TEXT button to switch to teletext. The initial page or last page appears on the screen. Two page numbers, TV station name, date and time are displayed on the screen headline. The first page number indicates your selection, while the second shows the current page displayed. -
Page 65: Fastext
Fastext The teletext pages are colour coded along the bottom of the screen and are selected by pressing the corresponding coloured button. Page selection Press the T.OPT button and then use the Navigation button to select menu. Display the index page. You can select the pages which are colour coded along the bottom line with corresponding coloured buttons. AS with SIMPLE teletext mode, you can select a page by entering its three digit page number with the NUMBER buttons in FASTEXT mode. The P or v button can be used to select the preceding or following page. Special Teletext Function Text Option Index Time Hold Reveal Update Close Index Select the each index page. TELETEXT Time When viewing a TV programme, select this menu to display the time at the top right hand corner of the screen. In the teletext mode, press this button to select a sub page number. The sub page number is displayed at the bottom of the screen. To hold or change the sub page, press the RED buttons/GREEN buttons, < > or NUMBER buttons. -
Page 66: Digital Teletext
DIGITAL TELETEXT DIGITAL TELETEXT This function works in UK, Ireland only. The TV gives you access to digital teletext which is greatly improved in various aspects such as text, graphics etc. This digital teletext can access special digital teletext services and specific services which broadcast digital teletext. You should select off in the subtitle language menu to display teletext by pressing the SUBTITLE button. Teletext within digital service Press the numeric or P or button to select a digital service which broadcasts digital teletext. Follow the indications on digital teletext and move onto the next step by pressing TEXT, OK, Navigation button, Red button, Green button, Yellow button, Blue button or Number buttons and etc. To change digital teletext service, select a different service by the numeric or P or button. -
Page 67: Maintenance
MAINTENANCE Clean your Monitor set regularly to keep the best performance and to extend the product lifespan. CAUTION Make sure to turn the power off and disconnect the power cord and all other cables first. When the Monitor set is left unattended and unused for a long time, disconnect the power cord from the wall outlet to prevent possible damage from lightning or power surges. Screen and frame To remove dust, wipe the surface with a dry and soft cloth. To remove major dirt, wipe the surface with a soft cloth dampened in clean water or a diluted mild detergent. Then wipe immediately with a clean and dry cloth. CAUTION Do not push, rub, or hit the surface with your fingernail or a sharp object, as this may result in scratches on the screen and image distortions. Do not use any chemicals, such as waxes, benzene, alcohol, thinners, insecticides, air fresheners, lubricants, as these may damage the screen’s finish and cause discolorations. MAINTENANCE Cabinet and stand To remove dust, wipe the cabinet with a dry and soft cloth. To remove major dirt, wipe the cabinet with a soft cloth dampened in a clean water or water containing a small amount of mild detergent. CAUTION Do not spray liquid onto the surface. If water enters the Monitor set, it may result in fire, electric shock, or malfunction. -
Page 68: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING General The operation does not work normally. Problem The remote control doesn’t work Power is suddenly turned off The video function does not work. Problem No picture & No sound Picture appears slowly after switching on No Colour, poor colour, or poor picture Horizontal / vertical bars or picture shaking Poor reception on some channels Lines or streaks in pictures Resolution y Check to see if there is any object between the product and the remote control causing obstruction. Ensure you are pointing the remote control y Ensure that the batteries are installed with correct polarity ( to , to ). y Ensure that the correct remote operating mode is set: TV, VCR, etc. y Install new batteries. -
Page 69: Pc Mode
Problem No picture when connecting HDMI The audio function does not work. Problem Picture OK & No sound No output from one of the speakers Unusual sound from inside the product No sound when connecting HDMI or USB There is a problem with PICTURE settings. Problem When the user changes the Monitor set picture settings, the automatically converts back to the initial settings after a certain period of time. PC mode No image is displayed. Problem Power is on, power indictor is blue but the screen appears extremely dark. Does the ‘Invalid format’ message appear? Does the ‘Check signal cable’... - Page 70 Colour. Do back spots appear on the screen? The screen image looks abnormal. Problem Is the screen position wrong? Do thin lines appear on the background screen? Horizontal noise appears or the characters look blurred. Resolution y Install the product driver, which is provided with the product, or download it from the web site. (http://www.lg.com) y See if the plug & play function is supported by referring to the video card user’s guide. Resolution y If you use a fixed image for a long time, the pixels may be damaged quickly. Use the screen saver function. Resolution y Set screen Colour resolution to more than 24 bits (true Colour) Select control Pane → Display → Settings → Colour Table menu in Windows. y Check the connection status of the signal cable. y Several pixels (red, green, white or black Colour) may appear on the screen, which can be attributable to the unique characteristics of the LCD panel. It is not a malfunction of the LCD.
-
Page 71: Specifications
SPECIFICATIONS M1950D LCD Panel Screen Type Pixel Pitch Video Signal Max. Resolution Recommended Resolution 1360 x 768 @ 60 Hz Horizontal Frequency Vertical Frequency Synchronization Type Input Connector Power Rated Voltage Power Consumption AC/DC Adapter Tilt Tilt Range Dimensions (Width x Height x Depth) Weight Environmental Operating Temperature conditions Operating Humidity Storage Temperature Storage Humidity Product specifications shown above may be changed without prior notice due to upgrade of product functions. 470.1 mm Wide (18.51 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 470.1 mm 0.3 mm (H) x 0.3 mm (V) 1360 x 768 @ 60 Hz 30 kHz to 61 kHz 56 Hz to 75 Hz Separate Sync, Digital TV, D-Sub Analog, SCART, PC Audio In, Component, HDMI 19 V 2.0 A On Mode : 30 W (typ.) Off Mode 0.5 W... - Page 72 SPECIFICATIONS M2250D LCD Panel Screen Type Pixel Pitch Video Signal Max. Resolution Recommended Resolution 1920 × 1080 @ 60 Hz Horizontal Frequency Vertical Frequency Synchronization Type Input Connector Power Rated Voltage Power Consumption AC/DC Adapter Tilt Tilt Range Dimensions (Width x Height x Depth) Weight Environmental Operating Temperature conditions Operating Humidity Storage Temperature Storage Humidity Product specifications shown above may be changed without prior notice due to upgrade of product functions. 546.86 mm Wide (21.53 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 546.86 mm 0.248 mm (H) x 0.248 mm (V) 1920 × 1080 @ 60 Hz 30 kHz to 83 kHz 56 Hz to 75 Hz Separate Sync, Digital TV, D-Sub Analog, SCART, PC Audio In, Component, HDMI 19 V 2.2 A On Mode : 35 W (typ.) Off Mode 0.5 W...
- Page 73 M2350D LCD Panel Screen Type Pixel Pitch Video Signal Max. Resolution Recommended Resolution 1920 × 1080 @ 60 Hz Horizontal Frequency Vertical Frequency Synchronization Type Input Connector Power Rated Voltage Power Consumption AC/DC Adapter Tilt Tilt Range Dimensions (Width x Height x Depth) Weight Environmental Operating Temperature conditions Operating Humidity Storage Temperature Storage Humidity Product specifications shown above may be changed without prior notice due to upgrade of product functions. 584.2 mm Wide (23 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 584.2 mm 0.265 mm (H) x 0.265 mm (V) 1920 × 1080 @ 60 Hz 30 kHz to 83 kHz 56 Hz to 75 Hz Separate Sync, Digital TV, D-Sub Analog, SCART, PC Audio In, Component, HDMI 19 V 2.4 A On Mode : 40 W (typ.) Off Mode 0.5 W Manufacturer: LITE-ON, Model PA-1650-68...
- Page 74 SPECIFICATIONS M2450D LCD Panel Screen Type Pixel Pitch Video Signal Max. Resolution Recommended Resolution 1920 × 1080 @ 60 Hz Horizontal Frequency Vertical Frequency Synchronization Type Input Connector Power Rated Voltage Power Consumption AC/DC Adapter Tilt Tilt Range Dimensions (Width x Height x Depth) Weight Environmental Operating Temperature conditions Operating Humidity Storage Temperature Storage Humidity Product specifications shown above may be changed without prior notice due to upgrade of product functions. 609.7 mm Wide (24 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 609.7 mm 0.276 mm (H) x 0.276 mm (V) 1920 × 1080 @ 60 Hz 30 kHz to 83 kHz 56 Hz to 75 Hz Separate Sync, Digital TV, D-Sub Analog, SCART, PC Audio In, Component, HDMI 19 V 2.4 A On Mode : 40 W (typ.) Off Mode 0.5 W...
- Page 75 M2550D LCD Panel Screen Type Pixel Pitch Video Signal Max. Resolution Recommended Resolution 1920 × 1080 @ 60 Hz Horizontal Frequency Vertical Frequency Synchronization Type Input Connector Power Rated Voltage Power Consumption AC/DC Adapter Tilt Tilt Range Dimensions (Width x Height x Depth) Weight Environmental Operating Temperature conditions Operating Humidity Storage Temperature Storage Humidity Product specifications shown above may be changed without prior notice due to upgrade of product functions. 634.4 mm Wide (25 inch) TFT (Thin Film Transistor) LCD (Liquid Crystal Display) Panel. Visible diagonal size : 634.4 mm 0.288 mm (H) x 0.288 mm (V) 1920 × 1080 @ 60 Hz 30 kHz to 83 kHz 56 Hz to 75 Hz Separate Sync, Digital TV, D-Sub Analog, SCART, PC Audio In, Component, HDMI 19 V 2.8 A On Mode : 50 W (typ.) Off Mode 0.5 W Manufacturer: LITE-ON, Model PA-1650-68...
- Page 76 SPECIFICATIONS RGB (PC) supported mode M1950D Resolution Horizontal Frequency(kHz) 640 x 480 31.469 640 x 480 37.500 800 x 600 37.879 800 x 600 46.875 1024 x 768 48.363 1024 x 768 60.023 1280 x 768 47.776 1280 x 800 49.306 1360 x 768 47.712 M2250D M2350D M2450D Horizontal Resolution Frequency(kHz) 720 x 400 31.468 640 x 480 31.469 640 x 480 37.500 800 x 600 37.879 800 x 600 46.875...
- Page 77 HDMI (DTV) supported mode Horizontal Vertical Resolution Frequency(kHz) Frequency(Hz) 720 x 480 31.469 59.940 31.500 60.000 720 x 576 31.250 50.000 1280 x 720 37.500 50.000 1280 x 720 44.960 59.940 45.000 60.000 1920 x 1080 33.720 59.940 33.750 60.000 1920 x 1080 28.125 50.000 1920 x 1080 27.000 24.000 1920 x 1080 33.750 30.000 1920 x 1080 56.250 50.000 1920 x 1080...
-
Page 78: Ir Codes
IR CODES IR CODES This feature is not available for all models. Code (Hexa) Energy Saving ( ꕊ ) (POWER) TV / PC INPUT RATIO TV/RAD Q.MENU MENU GUIDE Up ( ꕌ ) Down ( ꕍ ) Left (<) Right (>) OK( ꔉ ) BACK( ꕉ ) EXIT INFO ( + ) ( - ) FAV ( MARK ) MUTE P ( ꕌ ) P ( ꕍ... -
Page 79: External Control Device Setup
EXTERNAL CONTROL DEVICE SETUP RS-232C Setup Connect the RS-232C (serial port) input jack to an external control device (such as a computer or an A/V control system) to control the product’s functions externally. Connect the serial port of the control device to the RS-232C jack on the product back panel. RS-232C IN (CONTROL & SERVICE) NOTE RS-232C on this unit is intended to be used with third party RS-232C control hardware and software. The instructions below are provided to help with programming software or to test functionality using telenet software. RS-232C connection cables are not supplied with the product. EXTERNAL CONTROL DEVICE SETUP Type of connector; D-Sub 9-Pin Male RS-232C IN (CONTROL & SERVICE) Pin name No connection RXD (Receive data) -
Page 80: Rs-232C Configurations
EXTERNAL CONTROL DEVICE SETUP RS-232C configurations 7-Wire Configuration (Serial female-female NULL modem cable) D-Sub 9 D-Sub 9 3-Wire Configurations(Not standard) D-Sub 9 D-Sub 9 Set ID Set ID number. "Real Data OPTION Menu Language Audio Language Subtitle Language : English Disabled Assistance Data Service Country Input Label Set ID Power Indacator Demo Mode Mode Setting Factory Reset... -
Page 81: Communication Parameters
Communication Parameters Baud rate: 9600 bps (UART) Data length: 8 bits Parity : None Stop bit: 1 bit Communication code: ASCII code Use a crossed (reverse) cable. Command reference list COMMAND1 COMMAND2 01. Power 02. Aspect Ratio 03. Screen Mute 04. Volume Mute 05. Volume Control 06. Contrast 07. Brightness 08. Colour 09. Tint 10. Sharpness 11. OSD Select 12. Remote control lock mode 13. Treble 14. Bass 15. Balance 16. Colour Temperature 17. Energy Saving 18. Auto Configuration 19. Tune Command 20. Programme... -
Page 82: Transmission / Receiving Protocol
EXTERNAL CONTROL DEVICE SETUP Transmission / Receiving protocol Transmission [Command1][Command2][ ][Set ID][ ][Data][Cr] [Command 1] : First command to control the set.(j, k, m or x) [Command 2] : Second command to control the set. [Set ID] : You can adjust the set ID to choose desired monitor ID number in option menu. Adjustment range is 1 to 99. When selecting Set ID ‘0’, every connected set is controlled. Set ID is indicated as decimal (1 to 99) on menu and as Hexa decimal (0x0 to 0x63) on transmission/ receiving protocol. * [DATA] : To transmit command data. Transmit ‘FF’ data to read status of command. * [Cr] : Carriage Return ASCII code ‘0 x 0D’ * [ ] : ASCII code ‘space (0 x 20)’ OK Acknowledgement [Command2][ ][Set ID][ ][OK][Data][x] The set transmits ACK (acknowledgement) based on this format when receiving normal data. At this time, if the data is data read mode, it indicates present status data. If the data is data write mode, it returns the data of the PC computer. - Page 83 04. Volume Mute (Command: k e) To control volume mute on/off. You can also adjust mute using the MUTE button on remote control. Transmission [k][e][ ][Set ID][ ][Data][Cr] Data 00 : Volume mute on (Volume off) 01 : Volume mute off (Volume on) Ack [e][ ][Set ID][ ][OK/NG][Data][x] 05. Volume Control (Command: k f) To adjust volume. You can also adjust volume with the VOLUME buttons on remote control. Transmission [k][f][ ][Set ID][ ][Data][Cr] Data Min : 00 to Max : 64 * Refer to ‘Real data mapping ’. See p.84 Acknowledgement [f][ ][Set ID][ ][OK/NG][Data][x] 06. Contrast (Command: k g) To adjust screen contrast. You can also adjust contrast in the PICTURE menu. Transmission [k][g][ ][Set ID][ ][Data][Cr] Data Min : 00 to Max : 64 * Refer to ‘Real data mapping ’. See p.84 Acknowledgement [g][ ][Set ID][ ][OK/NG][Data][x] 07. Brightness (Command: k h) To adjust screen brightness.
- Page 84 EXTERNAL CONTROL DEVICE SETUP 14. Bass (Command: k s) To adjust bass. You can also adjust bass in the AUDIO menu. Transmission [k][s][ ][Set ID][ ][Data][Cr] Data Min : 00 to Max : 64 * Refer to ‘Real data mapping ’. See p.84 Acknowledgement [s][ ][Set ID][ ][OK/NG][Data][x] 15. Balance (Command: k t) To adjust balance. You can also adjust balance in the AUDIO menu. Transmission [k][t][ ][Set ID][ ][Data][Cr] Data Min : 00 to Max : 64 * Refer to ‘Real data mapping ’. See p.84 Acknowledgement [t][ ][Set ID][ ][OK/NG][Data][x] 16. Colour Temperature (Command: x u) To adjust colour temperature. You can also adjust Colour. Temperature in the PICTURE menu. Transmission [x][u][ ][Set ID][ ][Data][Cr] Data Min : 00 to Max : 64 * Refer to ‘Real data mapping ’. See p.84 Acknowledgement [u][ ][Set ID][ ][OK/NG][Data][x] 17. Energy Saving (Command: j q) To reduce the power consumption of the Monitor Set.
- Page 85 21. Key(Command: m c) To send IR remote key code. Transmission [m][c][ ][Set ID][ ][Data][Cr] Data Min : 00 to Max : 64 * Data Key cod - See p.78 Acknowledgement [c][ ][Set ID][ ][OK/NG][Data][x] 22. Back Light (Command: m g) To Control the back light. Transmission [m][g][ ][Set ID][ ][Data][Cr] Data : data Min: 00 to Max: 64 Acknowledgement [g][ ][Set ID][ ][OK/NG][Data][x] 23. Input select (Command: x b) (Main Picture Input) To select input source for main picture. Transmission [x][b][ ][Set ID][ ][Data][Cr] Data Structure Data 00: DTV 40: Component 10: Analogue 60: RGB 20: AV 90: HDMI Acknowledgement [b][ ][Set ID][ ][OK/NG][Data][x] EXTERNAL CONTROL DEVICE SETUP...
- Page 86 UK Only...
- Page 88 Make sure to read the Safety Precautions before using the product. Keep the Owner’s Manual (CD) in an accessible place for future reference. The model and serial number of the SET is located on the back and one side of the SET. Record it below should you ever need service.
