LK - 135
LK - 136
USER'S GUIDE
Please keep all information for future reference.
Safety Precautions
Before trying to use the Digital Keyboard, be sure to read the separate "Safety Precautions".
GUÍA DEL USUARIO
Guarde toda la información para futuras consultas.
Precauciones de seguridad
Antes de intentar usar el teclado digital, asegúrese de leer las "Precauciones de seguridad" separadas.
About Music Score data
You can use a computer to download music score data from the CASIO Website. For more information, visit the
URL below.
http://world.casio.com/
Acerca de los datos de partituras
Puede utilizar un ordenador (computadora) para descargar los datos de partituras desde el sitio web de CASIO.
Para obtener más información, visite la siguiente URL.
http://world.casio.com/
LK135-ES-1A
EN/ES
Advertisement
Table of Contents
Related Manuals for Casio LK-136
Summary of Contents for Casio LK-136
- Page 1 Antes de intentar usar el teclado digital, asegúrese de leer las “Precauciones de seguridad” separadas. About Music Score data You can use a computer to download music score data from the CASIO Website. For more information, visit the URL below.
- Page 2 ●Any reproduction of the contents of this manual, either in part or its entirety, is prohibited. Except for your own, personal use, any other use of the contents of this manual without the consent of CASIO is prohibited under copyright laws.
-
Page 3: Table Of Contents
Operating Precautions ..... EN-21 Included Accessories Separately Available Accessories ●Music Stand • You can get information about accessories that are separately for this product from the CASIO ●Leaflets • Safety Precautions catalog available from your retailer, and from the • Other (Warranty, etc.) CASIO website at the following URL. -
Page 4: General Guide
General Guide • Illustrations in this User’s Guide show the LK-135. The following explains the meaning of the $ symbol that appears on the product console and with the key names below. $ : Indicates a function that is enabled by holding down the button for some time. - Page 5 General Guide 1 P(Power) button ☞EN-8 bl TEMPO button ☞EN-11, 13 2 VOLUME buttons ☞EN-8 bm FUNCTION button ☞EN-4 3 kPAUSE, SYNCHRO/FILL-IN button ☞EN-12, 17 bn EASY MODE button ☞EN-14 4 PLAY/STOP, START/STOP button ☞EN-12, 13, 15 bo LESSON LITE button ☞EN-14 5 PART SELECT, ACCOMP, $CHORDS button bp Speakers ☞EN-13, 15, 16...
-
Page 6: Timeout
General Guide Timeout • Negative values cannot be input using the number buttons. If you do not perform any operation for a while configuring Use [+] (increase) and [–] (decrease) instead. settings, the display will return to the previous screen automatically. - Page 7 General Guide bm key Parameter Display Description presses Dance Music DM Tempo Specifies whether or not the performance tempo changes to the value that is Tempo Setting preset for each pattern. on: When the pattern is switched, the performance tempo changes to the tempo suggested for the selected pattern.
- Page 8 General Guide bm key Parameter Display Description presses LCD Contrast Contrast Adjusts display contrast. 1 to 12: A larger value makes the display contrast darker. Auto Power Off Setting that controls whether or not the Digital Keyboard turns off automatically after a period of non-use.
-
Page 9: Getting Ready To Play
Using Batteries Getting Ready to Play Preparing the Music Stand • Be sure to turn off power before loading batteries. • It is up to you to prepare six commercially available AA-size batteries. Do not use oxyride batteries or any other nickel based batteries. -
Page 10: Playing The Digital Keyboard
Playing the Digital Keyboard Using Headphones Using headphones cuts off output from the built-in speakers, Turning on Power and Playing which means you can practice playing even late at night without disturbing others. • Be sure to turn down the volume level before connecting Press 1P (Power). -
Page 11: Controlling The Keyboard Sounds
Controlling the Keyboard Sounds Select from a variety of musical instrument sounds To select an instrument for playing Press 6 TONE. Use 9 (10-key) to select the tone number you want. The corresponding tone number and tone name will appear on the screen. •... -
Page 12: Playing In The Dance Music Mode
Playing in the Dance Music Mode Dance Music Mode In the Dance Music Mode, you can combine and play multiple type of pattern phrases, and apply effects to songs that are playing, in order to enjoy dance music. Pattern phrases of each part can be combined, making it possible to enjoy dance music like a DJ. Entering the Dance Music Mode (page EN-11) changes the functions of the keyboard keys as shown below. -
Page 13: Using The Dance Music Mode
Playing in the Dance Music Mode Track reset switch Changing the Tempo Pressing this key while playback is in progress returns Press the bl TEMPO button. playback to the beginning of the currently playing phrase. This displays current tempo value along with the text “TEMPO”. -
Page 14: Dance Music Mode Settings
Playing Built-in Songs Dance Music Mode Settings With this Digital Keyboard, built-in music data is referred to Dance Music Volume (DM Vol.) Setting as “songs”. You can play back songs for your listening pleasure, or for play-along practice. See “Using the FUNCTION Button (bm)” (page EN-4). Dance Music Sync Type (DM Sync) Setting •... - Page 15 Playing Built-in Songs Changing Playback Speed (Tempo) Turning Off the Part of One Hand for Practice (Part Select) Press the bl TEMPO button. You can turn off the right hand part or the left hand part of a This displays current tempo value along with the text song during playback and practice playing the along with the “TEMPO”.
-
Page 16: Using Built-In Songs To Master Keyboard Play
Using Built-in Songs to Lesson Lite Master Keyboard Play Select the song you want to practice (page EN-12). The methods you can use for practice with this Digital Keyboard are described below. Press bo LESSON LITE. ● Easy Mode Play notes on the keyboard in accordance with the Press keyboard keys as they light. -
Page 17: Using Auto Accompaniment
Using Auto Accompaniment Playing All Parts With Auto Accompaniment, simply select an accompaniment Auto Accompaniment with Chords pattern. Each time you play a chord with your left hand the appropriate accompaniment will play automatically. It’s like Playing a chord with your left hand automatically adds bass having a personal backup group along with you wherever and harmony accompaniment parts to the currently selected you go. - Page 18 Using Auto Accompaniment ■ CASIO CHORD Selecting a Chord Input Mode With CASIO CHORD, you can use simplified fingerings to You can select from among the following five chord input play the four types of chords described below. modes. Chord Type •...
-
Page 19: Using Auto Accompaniment Effectively
Connecting External Devices Using Auto Accompaniment Effectively Connecting to Audio Equipment Varying Play during a Performance You can connect the digital piano to a commercially available stereo system or amplifier, or to a recording device. You can insert Auto Accompaniment fill-ins (variations) to make your performances more interesting and lively. -
Page 20: Reference
Reference Troubleshooting Symptom Action Included Accessories I can’t find something that should be here. Carefully check inside all of the packing materials. Power Requirements Power will not turned on. • Check the AC adaptor or make sure that the batteries are facing correctly (page EN-7). -
Page 21: Returning The Digital Keyboard To Its Factory Default Settings
Reference Symptom Action The volume or tone setting I made has changed. • Adjust the main volume setting (page EN-8). • Turn power off and then back on to initialize all Digital Keyboard settings (page EN-8). • Replace the batteries with new ones or switch over to AC adaptor power (page EN-7). -
Page 22: Specifications
Reference Specifications Model LK-135/LK-136 Keyboard 61 keys Key Lighting Maximum number of keys simultaneously lit: 4 Maximum Polyphony 32 notes Tones Preset Tones Effects Dance Music effects Song Bank Preset Songs Easy Mode Lesson Parts Left hand, right hand, both hands... -
Page 23: Operating Precautions
Reference Operating Precautions Be sure to read and observe the following operating precautions. ■ Location Avoid the following locations for this product. • Areas exposed to direct sunlight and high humidity • Areas subjected to temperature extremes • Near a radio, TV, video deck, or tuner The above devices will not cause malfunction of the product, but interference from the product can cause audio or video interference of a nearby device. -
Page 24: Appendix
Appendix/Apéndice Tone List/Lista de tonos Tone Name/ Tone Name/ No./Nº No./Nº Nombre del tono Nombre del tono PIANO/E.PIANO PIPE GRAND PIANO PICCOLO BRIGHT PIANO FLUTE HONKY-TONK RECORDER ELEC.GRAND PIANO BOTTLE BLOW ELEC.PIANO 1 WHISTLE ELEC.PIANO 2 OCARINA 60’S E.PIANO SYNTH-LEAD CHORUS E.PIANO SQUARE LEAD HARPSICHORD... -
Page 25: Drum Assignment List
Appendix/Apéndice Drum Assignment List/Lista de asignación de batería Key/ Note No./ DRUMS SET NAME Clave Nº de nota STANDARD SET DANCE SET BRUSH SET INDIAN SET C -1 E -1 F -1 A -1 B -1 C ... -
Page 26: Rhythm List
Appendix/Apéndice Rhythm List/Lista de ritmos Rhythm name/ Rhythm name/ No./Nº No./Nº Nombre del ritmo Nombre del ritmo 8 BEAT QAWWALI STRAIGHT 8 BEAT KERALA 8 BEAT RAJASTHANI 16 BEAT AMERICAN 16 BEAT COUNTRY BALLAD 16 BEAT SHUFFLE 1 BLUEGRASS 16 BEAT SHUFFLE 2 DIXIE BALLAD TEX-MEX... -
Page 27: Song List
Appendix/Apéndice Song List/Lista de canciones No./ No./ Title/Título Title/Título Nº Nº WORLD 061 MINUET IN G MAJOR 001 TWINKLE TWINKLE LITTLE STAR 062 MUSETTE IN D MAJOR 002 LIGHTLY ROW 063 GAVOTTE (GOSSEC) 003 LONG LONG AGO 064 ARABESQUE (BURGMÜLLER) 004 ON TOP OF OLD SMOKEY 065 CHOPSTICKS 005 SAKURA SAKURA... -
Page 28: Dance Music Mode List
Appendix/Apéndice Dance Music Mode List/ Lista de modos de música de danza No./Nº Title/Título ELECTRO DANCE 1 ELECTRO DANCE 2 ELECTRO DANCE 3 BIG BEAT TECHNO 1 BIG BEAT TECHNO 2 SPEED SHUFFLE 1 SPEED SHUFFLE 2 POP TRANCE 1 POP TRANCE 2 SLOW SOUL 1 DIGITAL SHUFFLE 1... -
Page 29: Fingering Guide
Appendix/Apéndice *1 With Fingered 2, interpreted as Am7. Fingering Guide/ *2 With Fingered 2, interpreted as Am7 b Guía de digitación *3 Inverted form not supported in some cases. *1 Con Fingered 2, se interpreta como Am7. *2 Con Fingered 2, se interpreta como Am7 b Fingered 1, Fingered 2 Chords/ Acordes Fingered 1, Fingered 2 *3 En algunos casos no se puede usar la forma invertida. - Page 30 Appendix/Apéndice...
- Page 31 This recycle mark indicates that the packaging conforms to the environmental protection legislation in Germany. Esta marca de reciclaje indica que el empaquetado se ajusta a la legislación de protección ambiental en Alemania. MA1608-A Printed in China...
