- Page 1 Air conditioner User manual AM***NN1DCH Thank you for purchasing this Samsung air conditioner. Before operating this unit, please read this user manual carefully and retain it for future reference.
-
Page 2: Table Of Contents
Contents Safety Information Safety Information At a Glance Indoor Unit Overview Main parts Operation Features Cleaning and Maintenance Cleaning and Maintaining English... -
Page 3: Safety Information
If you have any questions, call your nearest contact centre or find help and information online at www.samsung.com. WARNING Hazards or unsafe practices that may result in severe personal injury or death. - Page 4 Safety Information Safety Information The installation of this appliance must be performed by a qualified technician or service company. Failing to do so may result in electric shock, fire, explosion, problems with the product, or injury. Install a switch and circuit breaker dedicated to the air conditioner. Failing to do so may result in electric shock or fire.
- Page 5 When installing the outdoor unit, make sure to connect the drain hose so that draining is performed correctly. The water generated during the heating operation in the outdoor unit may overflow and result in property damage. In particular, in winter, if a block of ice falls, it may result in injury, death or property damage.
- Page 6 Safety Information Safety Information In the event of a gas leak (such as propane gas, LP gas, etc.), ventilate immediately without touching the power line. Do not touch the appliance or power line. Do not use a ventilating fan. A spark may result in an explosion or fire. To reinstall the air conditioner, please contact your nearest service centre.
- Page 7 Do not insert your fingers or foreign substances into the air inlet/outlet of the air conditioner. Take special care that children do not injure themselves by inserting their fingers into the product. Do not strike or pull the air conditioner with excessive force. This may result in fire, injury, or problems with the product.
- Page 8 Safety Information Safety Information Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may result in electric shock, fire, problems with the product, or injury. Do not operate the appliance with wet hands.
- Page 9 FOR CLEANING WARNING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner, alcohol or acetone to clean the appliance. This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, unplug the air conditioner from the wall socket and wait until the fan stops.
-
Page 10: At A Glance
Indoor Unit Overview Indoor Unit Overview Main parts The indoor unit and its display may look slightly different from the illustration shown below, depending on the model and the panel type. PC1NWFMAN 01 Display Indication Function Operation indicator Heating and cooling model: Operation(Blue) / Defrost(Yellow) Cooling only model: Operation indicator... - Page 11 PC1NUSMAN / PC1NUPMAN 01 Display Indication Function Remote control sensor Operation indicator Heating and cooling model: Operation(Blue) / Defrost(Yellow) Cooling only model: Operation indicator Timer indicator 02 Air flow blade Fan indicator 03 Panel 04 Air intake Filter cleaning indicator English...
-
Page 12: Operation Features
Operation Features Operation Features Operating temperature and humidity When using the air conditioner follow the operating temperature and humidity ranges. Mode Outdoor temperature Indoor temperature Indoor humidity Cool mode 18°C to 32°C (64°F to 90°F) 80% or less Depending on the outdoor Heat mode 30°C (86°F) or less unit specifications... -
Page 13: Cleaning And Maintenance
Cleaning and Maintaining Before cleaning the indoor unit, be sure to turn off the auxiliary power switch. Cleaning the indoor unit exterior Wipe the surface of the indoor unit with a tepid damp cloth. Remove the dust accumulated in the narrow gaps of the product with a soft brush. - Page 14 Cleaning and Maintaining Cleaning the air filter CAUTION Before cleaning the indoor unit, be sure to turn off the auxiliary power switch. Be sure to hold the grille with a hand to prevent dropping from the opening of the front grille. NOTE When removing the grill completely, unhook the safety hooks on both sides of the grill.
- Page 15 PC1NUPMAN Insert a driver at the marked points and open the front grille. Press the Push signs on the air filter. Grab the handle of the air filter and pull it out from the indoor unit. English...
- Page 16 Cleaning and Maintaining 2 Cleaning the air filter Clean the air filter with a vacuum cleaner or soft brush. If dust is too heavy, then rinse it with running water and dry it in a ventilated area. CAUTION Do not scrub the air filter with a brush or other cleaning utensil.
- Page 17 4 Resetting the air filter After cleaning and reassembling the air filter, be sure to reset the filter-cleaning reminder as follows: Indoor unit with the wired remote control: Press the Filter Reset button. Indoor unit with the wireless remote control: Press the Options Filter Reset...
- Page 18 Cleaning and Maintaining Periodical maintenance Requires qualified Unit Maintenance item Interval technicians Clean the air filter. At least once a month Clean the condensate drain pan. Once a year Required Indoor Clean up the heat exchange. Once a year Required unit Clean the condensate drain pipe.
- Page 19 Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expense. Problem Solution The air conditioner Because of the protective mechanism, the appliance does not start does not operate operating immediately to keep the unit from overloading. The air immediately after it conditioner will start in 3 minutes.
- Page 20 Cleaning and Maintaining Problem Solution The wired remote Check whether the indicator is displayed at the bottom right of the control does not remote control display. In this case, turn off both the air conditioner and operate. the auxiliary power switch, and then contact a service centre. The air conditioner is not turned on or Check whether the wired remote control is set for group control.
- Page 21 Problem Solution Close the windows and doors to maximize the cooling and heating efficiencies. If the Cool mode is stopped and then started immediately, cool air comes out after about 3 minutes to protect the compressor of the outdoor unit. The air is not cool or warm enough.
