Contents 1 Important Safety Notice 2 Your Clock Radio for iPhone/iPod Introduction What’s in the box Overview of the main unit 3 Get started Connect power Set time and date Turn on 4 Play Play from iPod/iPhone Play from an external device 5 Listen to radio Tune to a radio station Program radio stations automatically...
Page 3
Set the sleep timer Adjust display brightness 7 Adjust sound Adjust volume level Enhance bass 8 Product information Specifications 9 Troubleshooting...
1 Important Safety a Read these instructions. b Keep these instructions. c Heed all warnings. d Follow all instructions. e Do not use this apparatus near water. f Clean only with dry cloth. g Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions.
Page 5
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped. m Battery usage CAUTION – To prevent battery leakage which may result in bodily injury, property damage, or damage to the unit: •...
Notice Any changes or modifications made to this device that are not expressly approved by Philips Consumer Lifestyle may void the user’s authority to operate the equipment. This product complies with the radio interference requirements of the European Community. Your product is designed and manufactured with high quality materials and components, which can be recycled and reused.
Page 7
prevent negative consequences for the environmental and human health. Environmental information All unnecessary packaging has been omitted. We have tried to make the packaging easy to separate into three materials: cardboard (box), polystyrene foam (buffer) and polyethylene (bags, protective foam sheet.) Your system consists of materials which can be recycled and reused if disassembled by a specialized company.
2 Your Clock Radio for iPhone/iPod Congratulations on your purchase, and welcome to Philips! To fully benefit from the support that Philips offers, register your product at www.philips.com/welcome. Introduction With this unit, you can enjoy audio from the iPod, iPhone, other audio devices, or the radio.
Overview of the main unit Top View TUNING TUNING AL 1 AL 1 AL 2 AL 2 SLEEP SLEEP D O C K for D O C K for SOURCE SOURCE TUNING TUNING R E P E AT A L A R M R E P E AT A L A R M B R I G H T N E S S C O N T R O L B R I G H T N E S S C O N T R O L...
Page 10
• Skip to the previous/next audio file. • Search within an audio file. • Select a preset radio station. • Adjust time. e TUNING +/- • Tune to a radio station. • Adjust time. f VOL +/- • Adjust volume. •...
Page 11
OPEN OPEN 9V DC IN 9V DC IN MP3 LINK MP3 LINK FM AERIAL FM AERIAL m Backup battery compartment • Insert 2 pieces of AAA/R03/UM4, 1.5V batteries. n FM AERIAL • Improve FM reception. o MP3-LINK • Jack for an external audio device. p DC IN •...
Always follow the instructions in this chapter in sequence. If you contact Philips, you will be asked for the model and serial number of this apparatus. The model number and serial number are on the bottom of the apparatus. Write the numbers here: Model No.
Note • The voltage and power rating information is located on the bottom of the unit. Set time and date Dock the iPod/iPhone on the unit. Open the iPod/iPhone. » Time and date information on the iPod/iPhone transfers to the unit automatically. •...
Repeat steps 4-5 to set the minute, year, month, and day. Turn on Press POWER. » The unit switches to the last selected source. Switch to standby Press POWER again to switch the unit to standby mode. » The time and date (if set) appear on the display panel.
4 Play Play from iPod/iPhone You can enjoy audio from iPod/iPhone through this unit. Compatible iPod/iPhone Apple iPod and iPhone models with a 30-pin dock connector: • iPod classic, iPod touch, iPod nano, iPod 5th generation (video), iPod with color display, iPod mini. •...
• For certain iPod models, it may take up to a minute before the charging indication appears. Play from an external device You can also listen to an external audio device through this unit. Press SOURCE repeatedly to select AUX source. Connect the supplied MP3 link cable to: •...
5 Listen to radio Note • Only FM radio reception is available on this unit. Tune to a radio station • Position the antenna as far as possible from TV, VCR or other radiation source. Note • For optimal reception, fully extend and adjust the position of the antenna.
Program radio stations automatically You can program a maximum of 20 preset radio stations. In the tuner mode, press and hold DATE • AUTO TUNE/ TIME SET for more than 2 seconds to activate automatic program mode. » [AUTO] (auto) is displayed. »...
If you want to wake up to specific music track(s) on iPhone/iPod, after set iPhone/iPod playlist as the wake up source on the unit, you need to create a playlist called ‘PHILIPS’ via iTunes and copy the track(s) to this new ‘PHILIPS’ playlist.
Page 21
Activate and deactivate the alarm timer Press AL 1 or AL 2 repeatedly. » If the timer is activated, [ AL1] or [ AL2] is displayed. » If the timer is deactivated, before [AL1] or [AL2] disappears. Gentle wake Gentle wake function peacefully wakes you with gently ascending alarm volume.
View the alarm settings Press AL 1 or AL 2. Backup Battery Mode Under normal use, the unit should be powered through the AC adapter. If the AC adapter is disconnected, the unit will automatically switch to Backup Battery mode. Under Backup Battery mode: •...
Install backup batteries Caution • Risk of explosion! Keep batteries away from heat, sunshine or fire. Never discard batteries in fire. • Risk of product damage! When the apparatus is not used for long periods, remove the battery. Open the battery compartment on the back of the unit. Insert 2 x 1.5V R03/UM-4/AAA batteries with correct polarity.
Press SLEEP repeatedly until [OFF] displays. » disappears on the display. Adjust display brightness Press BRIGHTNESS/REP ALM repeatedly to select different levels of display brightness.
7 Adjust sound Adjust volume level During play, press VOL +/- to increase/decrease the volume level. Enhance bass During play, press DBB to turn on or off dynamic bass enhancement. » If DBB is activated, [DBB 1] is displayed. » If DBB is deactivated, [DBB 0] is displayed.
8 Product information Note • Product information is subject to change without prior notice. Specifications Amplifier Rated Output Power 2 x 2.5 W RMS Frequency Response 125 Hz - 16 kHz, ±3 dB Signal to Noise Ratio >55 dB MP3 link 500 mV RMS 10 kohm Tuner Tuning Range...
Page 27
General information AC power (power adaptor) AS190-090-AQ180; Input: 220 V, 50 Hz, 0.7 A; Class II; Output: 9.0 V 1.8 A Operation Power 10 W Consumption Standby Power Consumption < 1 W Dimensions 216.9 x105 x139.4 (mm) - Main Unit (W x H x D) Weight 0.75 kg - Main Unit...
If you encounter problems when using this apparatus, check the following points before requesting service. If the problem remains unsolved, go to the Philips web site (www.philips.com/welcome). When you contact Philips, ensure that the apparatus is nearby and the model number and serial number are available. No power •...
