Gigabyte NVIDIA GV-N730D5-2GI User Manual

Graphics accelerator
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
®
NVIDIA
Graphics Accelerator
User's Manual
Rev. 105
Copyright
© 2012 GIGABYTE TECHNOLOGY CO., LTD
Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. ("GBT"). No part of this manual may be reproduced or trans-
mitted in any form without the expressed, written permission of GBT.
Trademarks
Third-party brands and names are the properties of their respective owners.
Notice
Please do not remove any labels on this graphics card. Doing so may void the warranty of this card.
Due to rapid change in technology, some of the speciÞ cations might be out of date before publication of this this
manual.The author assumes no responsibility for any errors or omissions that may appear in this document nor does
the author make a commitment to update the information contained herein.
Rovi Product Notice:
This product incorporates copyright protection technology that is protected by U.S. patents and other intellectual
property rights.Use of this copyright protection technology must be authorized by Rovi Corporation, and is intended
for home and other limited viewing uses only unless otherwise authorized by Rovi Corporation. Reverse engineering
or disassembly is prohibited.

Advertisement

Table of Contents
loading

Related Manuals for Gigabyte NVIDIA GV-N730D5-2GI

Summary of Contents for Gigabyte NVIDIA GV-N730D5-2GI

  • Page 1 User's Manual Rev. 105 Copyright © 2012 GIGABYTE TECHNOLOGY CO., LTD Copyright by GIGA-BYTE TECHNOLOGY CO., LTD. (“GBT”). No part of this manual may be reproduced or trans- mitted in any form without the expressed, written permission of GBT. Trademarks Third-party brands and names are the properties of their respective owners.

  • Page 2: Table Of Contents

    2. Hardware Installation ....................5 2.1. SLI Technology ......................5 3. Software Installation ....................7 3.1. Driver and Utility Installation ..................7 3.1.1. Driver Installation ......................7 3.1.2. GIGABYTE OC Guru II .....................9 3.2. Display Properties Pages ..................19 3.3. Accessing NVIDIA Control Panel ................20 4.

  • Page 3: Introduction

    1. Introduction 1.1. Minimum System Requirements • Hardware ® ® Intel Pentium 4 or AMD Athlon XP class 2GB system memory (4GB recommended) Optical drive for software installation (CD-ROM or DVD-ROM drive) • Operating System ® Windows ® Windows ® Windows Vista - 3 -...
  • Page 4 DO NOT APPLY POWER TO YOUR SYSTEM IF THE GRAPHICS CARD IS DAMAGED. In order to ensure that your graphics card can work correctly, please use offi cial GIGABYTE BIOS only. Using non-offi cial GIGABYTE BIOS might cause problem(s) on the graphics card. NVIDIA Series Graphics Accelerator...

  • Page 5: Hardware Installation

    2.1. Hardware Installation Now that you have prepared your computer, you are ready to install your graphics card. Step 1. Locate the PCI Express x16 slot. If necessary, remove the metal cover from this slot; then align your graphics card with the PCI Express x16 slot, and press it in Þ...
  • Page 6 ® How NVIDIA (Scalable Link Interface) technology works: If you are planning on using this graphics card as part of an SLI system, the following are required: - An SLI certiÞ ed motherboard with two/three PCIe x16 slots and correct chipset driver - An SLI bridge connector or 3-way SLI bridge connector In an SLI conÞ...

  • Page 7: Software Installation

    3. Software Installation Notice the following guidelines before installing the drivers: 1. First make sure your system has installed DirectX 9 or later version. 2. Make sure your system has installed the appropriate motherboard drivers (for the motherboard drivers, please contact the motherboard manufacturer.) Notice : The photos in this manual are for reference only and may not match what you exactly see on your screen 3.1.
  • Page 8 Step 3: Check the Express then click the NEXT button. Step 4: Check the Install NVIDIA Update then click the NEXT button. The system is installing the components. Step 5: Click the RESTART NOW button to restart the computer. Then the driver installation is completed. NVIDIA Series Graphics Accelerator - 8 -...

  • Page 9: Gigabyte Oc Guru Ii

    3.1.2. GIGABYTE OC Guru II Step 1: Click the GIGABYTE OC Guru II item. Step 2: Choose the language for the installation and click the OK button. Step 3: Step 4: Choose the Typical and click the Next button Click the Finish button. Then the installation of the GIGABYTE OC Guru II is completed.
  • Page 10 OC GURU II: Profi les Users have 5 ProÞ les, 1/ 2/ 3/ 4/ 5 , to set different proÞ les. By clicking 1/ 2/ 3/ 4/ 5, users can switch around these proÞ les This page indicates where users can set up MONITORING GPU CLOCK MEMORY CLOCK FAN MINIMUM VOLTAGE POWER TARGET OSD ONLINE SUPPORT.
  • Page 11 MONITORING: Show real time GPU Clock/MEMORY Clock Click MORE to MONITORING PANEL MONITORING PANEL: Function: Monitoring Panel Settings. Function: Start recording. Function: Stop recording. - 11 - Software Installation...
  • Page 12 Monitoring panel settings: Function: Show the chosen items on the MONITORING PANEL. Function: Set up a folder to save the recorded fi les. Function: Return to MONITORING Page. Function: Save the settings. Function: Restore the default setup. NVIDIA Series Graphics Accelerator - 12 -...
  • Page 13 GPU CLOCK Under nVIDIA new structure, there are BASE and BOOST CLOCK under GPU Clock. BASE CLOCK is the combination of DEFAULT BASEC LOCK and OFFSET. BOOST CLOCK is the combination of DEFAULT BOOST CLOCK and OFFSET. Under most cases, BASE CLOCK is smaller/ equal to BOOST CLOCK. When changing DEFAULT CLOCK, represents PLUS and represents MINUS.
  • Page 14 Show real time fan speed and fan mode SPEED: shows real time fan speed, it will show 0% if using a passive graphics card. MODE: shows Auto mode or Manual mode, users can set up in SETTINGS SETTINGS: AUTO mode, fans will be controlled automatically. MANUAL mode, users can adjust fan behavior by adjusting the blue point on the fan graph.
  • Page 15 MINIMUM VOLTAGE Show and set up MINIMUM VOLTAGE When changing MINIMUM VOLTAGE, represents PLUS and represents MINUS. Users can enter numbers directly to change MINIMUM VOLTAGE. POWER TARGET Show and set up POWER TARGET When changing POWER TARGET, represents PLUS and represents MINUS.
  • Page 16 OSD settings: Function: Return to SETTINGS Page. Function: Set up where OSD will show during games through clicking on one of the 9 squares. Function: Setup a shortcut key for SOFTWARE On-Screen Display (OSD). Function: Setup shortcut keys and a folder to save screenshots. The settings can be adjusted by clicking on or by dragging the scrollbar.
  • Page 17 ONLINE SUPPORT Click to enter ONLINE SUPPORT ONLINE SUPPORT: 1.Update BIOS: The BIOS version of your VGA is shown in the page. By clicking the item while you are connected to the internet, the software detects if there is an updated BIOS version available. You can download the up- dated BIOS version and it installs automatically.
  • Page 18 GIGABYTE product page. 5.CONTECT US When you are connected to the internet, clicking the item will link to the offi cial GIGABYTE CONTECT US page. 6.FAQ When you are connected to the internet, clicking the item will link to the offi...

  • Page 19: Display Properties

    3.2. Display Properties Pages Display Settings (Resolutions and Color Quality for Windows) To access Display Settings page, right-click on desktop and select Personalize, then the Personalization win- dows will show up. Select Display Settings to adjust the screen resolution and color quality settings. You can move the slider to change the resolution.

  • Page 20: Accessing Nvidia Control Panel

    3.3. Accessing NVIDIA Control Panel After installation of the display driver, right-click on the desktop and select NVIDIA Control Panel. The NVIDIA Control Panel is used to conÞ gure all your graphics card settings. Right-click on the desktop and select NVIDIA Control Panel. In the NVIDIA Control Panel, select a category to alter speciÞ...
  • Page 21 3D Settings Tasks in the 3D Settings pages allow you to do the following: • Change the image and rendering settings of your 3D applications and games that utilize Direct3D and OpenGL technology. • Override the shipped clocked frequencies of your GPU and GPU memory to increase your GPU perfor- mance.
  • Page 22 Display A variety of display features enable you to further manipulate and conÞ gure your display settings to optimize the use of your displays. Tasks in the Display pages allow you to do the following: • Move CRT screen position •...
  • Page 23 Adjust Desktop Color Settings Use this page to set the contrast, sharpness, and color depth (Digital Vibrance) of the images on your desktop. These changes will not affect any video playback. To change video color set- tings, go to Adjust Video Color Settings under the Video and TV section from the Start page.
  • Page 24 Adjust Desktop Size and Position You can adjust desktop size and position for your displays. Set Up Multiple Displays NVIDIA nView technology enables you to view your desktop in one of several multi-display modes to make the best use of the displays (monitors) that are connected to your computer.
  • Page 25 (1) The same on both display (Clone) Clone mode indicates that both displays in the display pair show images of the same desktop. Clone Mode (2) Confi gured independently from each other (Dualview) Dualview mode indicates that both displays in the display pair function as one virtual desktop.
  • Page 26 Stereoscopic 3D Tasks in the Stereoscopic 3D pages allow you to do the following: • Set up stereoscopic 3D • View compatibility with games Set Up Stereoscopic 3D You can enable stereoscopic 3D, set depth, and set your 3D displays and 3D glasses. (To en- able stereoscopic 3D function, you will need 3D displays and glasses.
  • Page 27 Video & Television Video and television features are similar to those for analog for optimal viewing. Tasks in the Video & Televi- sion pages allow you to do the following: • Adjust your television picture quality and video color settings for the best possible viewing in its environment.

  • Page 28: Troubleshooting Tips

    4. Troubleshooting Tips The following troubleshooting tips may help if you experience problems. Contact your dealer or GI- GABYTE for more advanced troubleshooting information. Check that the card is seated properly in the PCI Express x16 slot. Ensure that the display cable is securely fastened to the card's display connector. Make sure that the monitor and computer are plugged in and receiving power.

  • Page 29: Appendix

    "end of life" product. Restriction of Hazardous Substances (RoHS) Directive Statement GIGABYTE products have not intended to add and safe from hazardous substances (Cd, Pb, Hg, Cr+6, PBDE and PBB). The parts and components have been carefully selected to meet RoHS requirement.
  • Page 30 Finally, we suggest that you practice other environmentally friendly actions by understanding and using the energy-saving features of this product (where applicable), recycling the inner and outer packaging (including shipping containers) this product was delivered in, and by disposing of or recycling used batteries properly. With your help, we can reduce the amount of natural resources needed to produce electrical and electronic equipment, minimize the use of landÞ...
  • Page 31 - 31 - Appendix...
  • Page 32 NVIDIA Series Graphics Accelerator - 32 -...
  • Page 33 - 33 - Appendix...
  • Page 34 NVIDIA Series Graphics Accelerator - 34 -...
