Summary of Contents for Biostar P4SDP

  • Page 1 FCC Statement and Copyright This equipment has been tested and found to comply with the limits of a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 2: Table Of Contents

    Jumpers, Headers, Connectors & Slots ... 5 ESPAÑOL ... 10 Características del P4SDP... 10 Contenido del Paquete... 11 Disposición del P4SDP ... 11 Instalación de la CPU ... 12 Módulos DDR DIMM: DDR1-2 ... 13 Conectores, Cabezales, Puentes y Ranuras... 14 TROUBLE SHOOTING...
  • Page 3: English

    English P4SDP Features Use Sis 645DX/ Sis 962 Chipset, ITE IT8705, LAN Chip- VT6103 (optional). Contains on board I/O facilities, which include two serial ports, a parallel port, a PS/2 mouse port, a PS/2 keyboard port, audio ports, USB ports, a LAN port (optional) and a game port.
  • Page 4: Package Contents

    HDD Cable X 1, FDD Cable X 1, Fully Setup Driver CD X 1 Flash Memory Writer for BIOS update X 1 USB Cable X 2 (Optional) Rear I/O Panel for ATX Case X 1 (Optional) Layout of P4SDP JKBMS1 JUSBV2 &...
  • Page 5: Cpu Installation

    CPU Installation Pull the lever sideways away from the socket then raise the lever up to 90-degree angle. Locate Pin A in the socket and lock for the white dot or cut edge in the CPU. Match Pin A with the white dot/cut edge then insert the CPU.
  • Page 6: Ddr Dimm Modules: Ddr1-2

    DDR DIMM Modules: DDR1-2 DRAM Access Time: 2.5V Unbuffered DDR 200/266/333 MHz Type required. DRAM Type: 64MB/ 128MB/ 256MB/ 512MB/ 1GB DIMM Module (184 pin) DIMM Socket DDR Module Location DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * The list shown above for DRAM configuration is only for reference. How to install a DIMM Module 1.
  • Page 7: Jumpers, Headers, Connectors & Slots

    Peripheral Component Interconnect Slots: PCI1-5 This motherboard is equipped with 5 standard PCI slots. PCI stands for Peripheral Component Interconnect, and it is a bus standard for expansion cards, which has, supplanted the older ISA bus standard in most ports.
  • Page 8 Power Connectors: JATXPWR1/ JATXPWR2 JATXPWR2 (ATX 12V Power Connector) (ATX Main Power Connector) Wake On LAN Header: WOL1 Ground Wake up WOL1 Front USB Header: JUSB1/ JUSB2 Pin1,2 ==> +5V Pin3,4 ==> Data(-) Pin5,6 ==> Data(+) Pin7,8 ==> Ground JUSB1/2 Pin9 Pin10 ==>...
  • Page 9 5V/ 5VSB Selection for USB: JUSBV1/ 2 Pin 1-2 on ==> 5V Pin 2-3 on ==> 5V_SB JUSBV1/ 2 Front Panel Connector: JPANEL1 PWR_LED ON/OFF (+) (-) HLED ==> Speaker Conn. HLED ==> Hard Driver LED ==> Reset Button ==> Infrared Conn. ==>...
  • Page 10 Pin1 ==> Mic In Pin3 ==> Mic Power Pin5 ==> RT Line Out Pin7 ==> Reserved Pin9 ==> LFT Line Out Pin10 ==> LFT Line Out Pin11==> RT Line In Pin13 ==> LFT Line In Clear CMOS Jumper: JCMOS1 Pin 1-2 on ==> Normal Operation Pin 2-3 on ==>...
  • Page 11 Back Panel Connectors JKBMS1 JUSBLAN1 JPRNT1 JGAME1 PS/2 LAN(Optional) Mouse Parallel Game Port PS/2 Speaker Line In Mic COM1 COM2 Keyboard JCOM1 JCOM2...
  • Page 12: Español

    Español Características del P4SDP Usa Chipset SIS 645DX/ SIS 962, ITE IT8705, LAN Chip- VT6103 (opcional). Contiene facilidades I/O integrados en la placa madre en el que incluye dos puertos en serie, un puerto paralelo, un puerto para ratón PS/2, un puerto para teclado PS/2, puertos de audio, puertos USB, puerto LAN (opcional) y un puerto para juegos.
  • Page 13: Contenido Del Paquete

    Cable HDD X 1, Cable FDD X 1, Completo Setup Driver CD X 1 Memoria Flash Writer para actualización del BIOS X 1 Cable USB X 2 (Opcional) Panel trasero I/O para caja ATX X 1 (Opcional) Disposición del P4SDP JKBMS1 Teclado JUSBV2 &...
  • Page 14: Instalación De La Cpu

    Instalación de la CPU Tire de la palanca del lado del zócalo, luego levante la palanca hasta un ángulo de 90 grados. Sitúe el contacto A del zócalo y busque el punto blanco o corte el borde en la CPU. Empareje el contacto A con el punto blanco/ corte del borde, luego inserte la CPU.
  • Page 15: Módulos Ddr Dimm: Ddr1-2

    Módulos DDR DIMM: DDR1-2 DRAM Tiempo de Acceso: 2.5V Unbuffered DDR 200/266/333 MHz Tipo requerido. DRAM Tipo: 64MB/ 128MB/ 256MB/ 512MB/ 1GB Módulo DIMM (184 Contactos) Localización del Zócalo Módulo DDR DIMM DDR 1 64MB/128MB/256MB/512MB/1GB DDR 2 64MB/128MB/256MB/512MB/1GB * La lista de arriba para la configuarción DRAM es solamente para referencia.
  • Page 16: Conectores, Cabezales, Puentes Y Ranuras

    Conectores, Cabezales, Puentes y Ranuras Conectores del Disco Duro: IDE1/ IDE2 La placa madre tiene un controlador de 32-bit PCI IDE que proporciona Modo PIO 0~4, Bus Master, y funcionalida Ultra DMA / 33/ 66/ 100. Tiene dos conectores HDD IDE1 (primario) y IDE2 (secundario). El conector IDE puede conectar a un master y un drive esclavo, así...
  • Page 17 Conectores de Encendido: JATXPWR1/ JATXPWR2 JATXPWR2 (ATX 12V Conector de Corriente) (ATX Conector de Corriente Principal) Cabezal Wake On LAN: WOL1 Tierra Wake up WOL1 Cabezal Frontal USB: JUSB1/ JUSB2 Contacto1,2 ==> +5V Contacto3,4 ==> Dato(-) Contacto5,6 ==> Dato(+) Contacto7,8 ==> Tierra JUSB1/2 Contacto9 Contacto10 ==>...
  • Page 18 Conector del Panel Frontal: JPANEL1 PWR_LED (+) (-) HLED ==> Conector de Altavoz HLED ==> LED del Disco Duro ==> Boton de Reinicio ==> Conector Infrarojo ==> Boton de Suspension PWR_LED ==> Corriente LED ON/ OFF ==> Boton de Encendido Subsistema de Audio: JAUDIO1/ JCDIN1 JAUDIO1 JAUDIO1...
  • Page 19 Pin1 ==> Entrada del Mic Pin3 ==> Corriente del Mic Pin5 ==> RT Salida de Linea Pin7 ==> Reservado Pin9 ==> LFT Salida de Linea Pin11 ==> RT Entrada de Linea Pin12 ==> RT Entrada de Linea Pin13 ==> LFT Entrada de Linea Pin14 ==> LFT Entrada de Linea Puente de Borrar CMOS: JCMOS1 Contacto 1-2 on ==>...
  • Page 20 Conectores del Panel Trasero JKBMS1 JUSBLAN1 JPRNT1 LAN(Opcional) Raton PS/2 Paralelo Teclado COM1 PS/2 JCOM1 JGAME1 Puerto de Juego Salida del Entrada Entrada de COM2 Altavoz de Linea JCOM2...
  • Page 21: Trouble Shooting

    Trouble Shooting PROBABLE No power to the system at all Power light don’t illuminate, fan inside power supply does not turn on. Indicator light on keyboard does not turn on PROBABLE System inoperative. Keyboard lights are on, power indicator lights are lit, hard drive is spinning.
  • Page 22: Solución De Problemas

    Solución de Problemas CAUSA PROBABLE No hay corriente en el sistema. La luz de corriente no ilumina, ventilador dentro de la fuente de alimentación apagada. Indicador de luz del teclado apagado. CAUSA PROBABLE Sistema inoperativo. Luz del teclado encendido, luz de indicador de corriente iluminado, disco rígido está...
