- Page 1 OWNER’S MANUAL AIR CONDITIONER Please read this manual carefully before operating your set and retain it for future reference. TYPE : WALL MOUNTED www.lg.com P/NO : MFL42132808...
-
Page 2: Table Of Contents
Room Air Conditioner Ownerʼs Manual TABLE OF CONTENTS FOR YOUR RECORDS A. Safety Precautions ......3 B. Electrical Safety........6 Write the model and serial numbers here: Temporary Use of an Adapter ....6 Model # Temporary Use of an Extension Cord ...6 Serial # Symbols used in this Manual....6 You can find them on a label on the side of each unit. -
Page 3: Safety Precautions
Safety Precautions Safety Precautions To prevent injury to the user or other people and property damage, the following instructions must be followed. n Incorrect operation due to ignoring instruction will cause harm or damage. The seriousness is classified by the following indications. This symbol indicates the possibility of death or serious injury. - Page 4 Safety Precautions Indoor/outdoor wiring connections must Safely dispose off the packing materials. Make sure to check that the power cable be secured tightly and the cable should Like screws, nails, batteries, broken plug is not dirty, loose or broken and be routed properly so that there is no things etc after installation or svc and then only insert the plug completely.
- Page 5 Safety Precautions Do not use the product for special purposes, Do not block the inlet or outlet of air flow. Use a soft cloth to clean. Do not use such as preserving foods, works of art, etc. It harsh detergents, solvents or splashing is a consumer air conditioner, not a precision water etc .
-
Page 6: Electrical Safety
Electrical Safety Electrical Safety • This appliance must be properly grounded. To minimize the risk of electric shock, you must alway plug into a grounded oulet. • Do not cut or remove the grounding prong from the power plug. • Attaching the adapter ground terminal to the wall receptacle cover screw does not ground the appliance unless the cover screw is metal and not insulated, and the wall receptacle is grounded through the house wiring. -
Page 7: Product Introduction
Product Introduction Product Introduction Here is a brief introduction of the indoor and outdoor units. Please see the information specific to your indoor unit type. Indoor Units Standard Split Type Display panel LED indicators Air inlet Grille tab Plasma filter (Optional) Front grille ON/OFF button Air filter... -
Page 8: Operation Indication Lamps
Product Introduction Art Cool Deluxe(Type 1) Art Cool Deluxe(Type 2) Display panel LED indicators Display panel LCD indicators Air inlet Air inlet Air filter Plasma filter Plasma filter Air filter Air discharge Air discharge Front panel Power cord Signal receiver Front panel ON/OFF button Power cord... -
Page 9: Operating Instructions
Operating Instructions Operating Instructions How to insert the Batteries 1. Remove the battery cover by pulling it according to the arrow direction. 2. Insert new batteries making sure that the (+) and (-) of battery are installed correctly. 3. Reattach the cover by sliding it back into position. NOTE 1. -
Page 10: Remote Control Operation
Operating Instructions Remote Control Operation The remote control transmits the signals to the system. 1. OPERATION DISPLAY Displays the operation conditions. 2. CHAOS SWING BUTTON Used to stop or start louver movement and set the desired up/down airflow direction 3. OPERATION MODE SELECTION BUTTON Used to select the operation mode. -
Page 11: Operation Mode
Operating Instructions Operation Mode Cooling Operation Healthy Dehumidification Operation Mode This mode dehumidifies without overcooling. Press the START/STOP BUTTON to turn the unit on. The unit will respond with a beep. Select Cooling Operation. Press the Operation Mode Selection Button. Each time the button is pressed, the operation mode is shifted in the arrow direction. - Page 12 Operating Instructions Heating Operation(Heat pump model only) Press the Start/Stop button. The unit will respond with a beep. To select Heating Operation, press the Operation Mode Selection button. Each time the button is pressed, the operation mode is shifted in the direction of the arrow. TEMP.
- Page 13 Operating Instructions Jet Cool Operation Press the Start/Stop button. The unit will respond with a beep. Press the Jet Cool button to operate the speed cooling mode and the unit will operate in super high fan speed TEMP. on cooling mode for 30 minutes. TIME To cancel the Jet Cool mode, press the Jet Cool button again or the fan speed button or the room temperature...
- Page 14 Operating Instructions Vertical Airflow Direction Control The up/down airflow (Vertical Airflow) can be adjusted NOTICE by using the remote control. If you press the CHAOS swing button, the horizontal airflow direction is changed automatically based on the CHAOS algorithm to distribute the air in the room evenly and at the same time to make the human body feel most comfortable, as if enjoying a natural breeze.
-
Page 15: Maintenance And Service
Maintenance and Service Maintenance and Service Before performing any maintenance, turn off the main power to the system, disconnect the circuit breaker and unplug the power cord. Indoor Unit Clean the unit with a soft dry cloth. Do not use bleach or abrasives. Never use any of these •... - Page 16 Maintenance and Service 3. Deluxe (Type 1): Open the upside of the panel and lift it up as shown. The hooks of the panel will come off. Remove the air filters. Then pull out the plasma filter Plasma filter Front panel Panel hook After cleaning and drying well reinstall the filters in their original position.
-
Page 17: Outdoor Unit
Maintenance and Service Type 2: Pull the front panel from both sides as shown. Then pull the filter tab slightly forward to remove the filter. After removing the air filter remove the plasma and triple deodorizer filter by slightly pulling forward. Deodorizer�... -
Page 18: Troubleshooting Tips! Save Time And Money
Maintenance and Service Troubleshooting Tips! Save time and money! The air conditioner may be operating abnormally when: Problem Possible Causes What To Do n The air conditioner is • Make sure the air conditioner plug is unplugged. pushed completely into the outlet. n The fuse is blown/circuit •... - Page 21 ° à ≤ G Ÿ ù ‘ d « ¬ ´ G E L ƒ d ∏ ô F § ◊ É ≈ G Y ∏ Ö c « d ∏ Î ´ : G d æ ƒ www.lg.com P/NO : MFL42132808...
