Alfa Network ADS-R02 Specifications

ADS-R02
Support NAT For IP Sharing and
4-Port 100Mbps Base-T Fast Ethernet Switch
The Router is a broadband router with LAN and WAN port. It is a special product for SOHO users to access Internet
via a broadband connection. It needs only one ISP account for the whole LAN users to access Internet
simultaneously, and equipped with a 10Mbps Ethernet WAN port to connect an ADSL or cable modem. The
Broadband Router allows you to connect your office to Internet with cost effective way. It comes with a web based
configuration server, making installation simple and easy.
FEATURES
Connects to a broadband Modem or an Ethernet Backbone
Share a single IP account within your entire network via NAT routing way
Remote management with Telnet or Web browser interface
Build-in server:
-DHCP server automatically assigns IP address for local computers
-http daemon for Web browser management
-telnet daemon for on-line management
-TFTP server to upgrade the firmware of router and configuration file to be backup and restore
Virtual server mapping provides secure server for Internet access
A nature Firewall and secure gateway by Network Address Translation Protocol
Equipped with a 4-port EtherFast Switch
Fully compatible with all of platforms (Windows 95/98/2000/Me/NT4.0/NT5.0, UNIX, OS/2, Apple MAC)
Free running with Netscape, Mosaic, Internet Explorer, Telnet, and any Internet application
Easy installation and friendly Web-based interface
Support one console port to configure the system by terminal program via RS-232 cable
