- Page 1 OWNER’S MANUAL MICROWAVE OVEN Please read this owner’s manual thoroughly before operating. MS408 (optional, please check model specification) www.lg.com MFL40257837...
-
Page 3: Microwave Cooking
CONTENTS CONTENTS How the Microwave Function Works Microwaves are a form of energy similar to radio, IMPORTANT SAFETY INSTRUCTIONS television waves, and ordinary daylight. Normally, microwaves spread outwards as they travel through the BEFORE USE This oven, however, has a magnetron that is designed Unpacking &... -
Page 4: Important Safety Instructions
IMPORTANT SAFETY INSTRUCTIONS IMPORTANT SAFETY INSTRUCTIONS Please keep for future reference. Read and follow all instructions before using your oven to prevent the risk of f electric shock, personal injury, or damage when using the oven. This guide does not cover all possible conditions that may occur. - Page 5 IMPORTANT SAFETY INSTRUCTIONS t is hazardous for anyone other than a competent person to carry out any service or repair operation that involves the removal of a cover which gives protection against exposure to microwave energy. 10 W hen the appliance is operated in the combination mode, children should only use the oven under adult supervision due to the temperatures generated.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS 10 D o not use recycled paper products. 11 D o not rinse the tray and rack by placing it in water just after cooking. This may cause breakage or damage. Improper use could result in damage to your oven. 12 B e certain to place the oven so the front of the door is 8 cm or more behind the edge of the surface on which it is placed, to avoid accidental tipping of the appliance.
- Page 7 IMPORTANT SAFETY INSTRUCTIONS As the colours of the wires in the mains lead of this appliance may not correspond with the coloured markings identifying the terminals in your plug proceed as follows: The wire which is colored BLUE must be connected to the terminal which is marked with the letter N or Colored BLACK.
-
Page 8: Before Use
BEFORE USE beFore use unpacking & Installing By following the basic steps on these two pages you will be able to quickly check that your oven is operating correctly. Please pay particular attention to the guidelines on where to install your oven. When unpacking your oven make sure you remove all accessories and packing materials. - Page 9 BEFORE USE Press the STOP/CLEAR button, and press the START/QUICK START button one time to set 30 seconds of cooking time. The DISPLAY will count down from 30 seconds. When it reaches 0 it will sound BEEPS. Open the oven door and test the temperature of the water.
-
Page 10: Microwave - Safe Utensils
BEFORE USE Microwave-safe utensils never use metal or metal trimmed utensils in using microwave function Microwaves cannot penetrate metal. They will bounce off any metal object in the oven and cause arcing, an alarming phenomenon that resembles lightning. Most heat resistant non metallic cooking utensils are safe for use in your oven. -
Page 11: Control Panel
BEFORE USE Control panel part SENSOR COOK Sensor Cook allows you to cook most of your favorite food by selecting the food type and the weight of the food. See page 14 "Sensor Cook" SENSOR REHEAT See page 18 “Sensor Reheat” AL MENU See page 19 “Global Menu”... -
Page 12: Setting Clock
BEFORE USE SETTING CLOCK To adjust the (ex. Corned Beef 1.2 kg) cooking time for a longer time, When your oven is plugged in for the first time or or for a shorter time when power resumes after a power interruption, the numbers in the display reset to "0". -
Page 13: How To Use
HOW TO USE HoW to use MICROWAVE POWER LEVEL CHART TIMED COOKING (manual cooking) Power Level This function allows you to cook food for a desired time. There are 10 power levels available. * Boiling water. The example below shows how to set 80% power * Browning ground beef. -
Page 14: Child Lock
HOW TO USE CHILD LOCK Categories: Sensor Reheat This is a unique safety feature that prevents Sensor Cook unwanted oven operations. Once the CHILD LOCK is set, no cooking can take place. For most Sensor Cooking programs, a chart with specific food examples and cooking instructions is provided in the next few pages. - Page 15 HOW TO USE SENSOR COOK MENU INSTRUCTIONS - VEGETABLE Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature S-F1 Jacket Potato 1 - 4 pieces Room Wash & pat potatoes dry with paper towel. Pierce 1 piece = 3 each potato 3 times with a fork.
- Page 16 HOW TO USE SENSOR COOK MENU INSTRUCTIONS - RICE / PASTA Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature S-P1 White Rice - 2 cups Rice : Room 3 - 5 Rice 1 cup cups 2 cups Water : Room Tap water cups 2 cups...
- Page 17 HOW TO USE SENSOR COOK MENU INSTRUCTIONS - DESSERT Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature S-d1 Cake 1 packet Room Prepare the cake following the microwave instructions on the side of the packet, ignoring the Packet cooking instructions.
-
Page 18: Sensor Reheat Menu Instructions
HOW TO USE SENSOR REHEAT This feature allows you to reheat precooked To reheat DINNER PLATE room-temperature or refrigerated foods without selecting cooking times and power levels. This feature has 6 categories : dinner plate, rice, soup, 1. Press ECO ON / STOP. casserole, risotto and pizza. -
Page 19: Global Menu
HOW TO USE SENSOR REHEAT MENU INSTRUCTIONS Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature Sr 5 Risotto 1- 4 cups Room Place the cooked risotto into a microwave- safe, heatproof dish.Cover with a lid or double layer of plastic wrap loosely.After reheating stir well before serving. -
Page 20: Global Menu Instructions
HOW TO USE GLOBAL MENU INSTRUCTIONS Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature Ac-1 Corned Beef 1.0 - 2.0 kg Refrigerated Corned beef 1 kg 1. 5 kg 2 kg 15 - 20 Warm water 3 cups 4 cups 6 cups Brown sugar... - Page 21 HOW TO USE GLOBAL MENU INSTRUCTIONS Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature Ac-2 Seasoned Meat 1.0 - 2.0 kg Refrigerated Apricot Lamb 15 - 20 Loin of forequarter lamb (deboned) 1 packet dried apricots 250 ml apricot nectar 1 tbs cornflour Unroll meat.
- Page 22 HOW TO USE GLOBAL MENU INSTRUCTIONS Standing Time Weight Initial Menu Code Instructions (minutes) Limit Temperature Ac-6 Fish Fillets 0.2 - 0.6 kg Refrigerated Place each fish fillet onto a square of baking paper, 2 - 3 tuck the tail end under. Drizzle with fresh lemon or fresh lime juice and season with salt and pepper.
- Page 23 HOW TO USE GLOBAL MENU INSTRUCTIONS Weight Initial Code Menu Instructions Limit Temperature Fc-1 Ratatouille 1.5kg Room Ingredients 1 onion, cut into chunks 1 eggplant, cut into chunks 1 zucchini, cut into chunks 1 colored sweet pepper, cut into chunks 3 tomatoes, chopped 1 tablespoon tomato paste 2 garlic cloves, crushed...
- Page 24 HOW TO USE GLOBAL MENU INSTRUCTIONS Weight Initial Code Menu Instructions Utensil Limit Temperature Fc-4 Spinach ream 1.2kg Room Ingredients Microwave-safe bowl 600g vegetable purée 1 ½ cups chicken stock 2 tablespoons all-purpose flour 2 tablespoons butter 1 cup cream Nutmeg, salt and pepper to taste 1.
- Page 25 HOW TO USE GLOBAL MENU INSTRUCTIONS Weight Initial Menu Code Instructions Limit Temperature Ic-1 Spaghetti 1.0kg Room Ingredients for bolognaise sauce olognaise 1 tablespoon olive oil 1 onion, chopped 1 garlic clove, crushed 400g ground beef 100g tomato paste 2 chopped tomatoes 1 tablespoon dried greens Salt and pepper to taste Ingredients for pasta...
- Page 26 HOW TO USE GLOBAL MENU INSTRUCTIONS Weight Initial Code Menu Instructions Limit Temperature Ic-4 Stuffed epper 1.5kg Room Ingredients 4 colored sweet peppers 2 canned tuna 2 piece dry black bread, chopped 1 garlic clove, crushed 100g parmesan cheese Salt and pepper to taste 200g tomato puree 1.
- Page 27 HOW TO USE GLOBAL MENU INSTRUCTIONS Weight Initial Code Menu Instructions Limit Temperature Dolma 1.0kg Room Ingredients 1 pot of grapes leaves 200g cooked rice 500g ground beef 1 onion, chopped Salt and pepper to taste ½ cup water ½ cup sour cream 1.
-
Page 28: Melt Table
HOW TO USE MELT SOFTEN The oven uses low power to melt foods (butter, The oven uses low power to soften foods (butter, ice chocolate, marshmallows and cheese). See the cream, cream cheese, and frozen juice) following table. See the following table. Example : To Melt 227g Chocolate. -
Page 29: Quick Defrost Menu Instructions
HOW TO USE QUICK DEFROST The Quick Defrost feature provides you with Example: To defrost 0.5 kg meat. the express defrosting method for 500g of frozen minced meat. If more than 500g is 1. Press ECO ON / STOP. required to be defrosted, this should be done separately in weights of 500gms for each cycle. -
Page 30: Auto Defrost Menu Instructions
HOW TO USE Example: To defrost 1.2 kg of Minced Meat, AUTO DEFROST select Meat menu, enter the weight, and press START Seven defrost sequences are preset in the oven. The defrost feature provides you with the best defrosting method for frozen foods. The cooking 1. - Page 31 HOW TO USE AUTO DEFROST MENU INSTRUCTIONS Standing Time Weight Initial Code Menu Instructions (minutes) Limit Temperature d EF2 Steak / Chops 0.1- 1.5kg Frozen Remove the meat completely from it’s wrapping. 5 - 30 Using thin strips of foil, shield the fatty areas with the foil, making sure the foil is secure.
-
Page 32: Food Characteristics & Microwave Cooking
FOOD CHARACTERISTICS & MICROWAVE COOKING FooD CHaraCteriStiCS & MiCrowave CooKing Keeping an eye on things The recipes in the book have been formulated with great care, but your success in preparing them depends on how much attention you pay to the food as it cooks. Always watch your food while it cooks. Your microwave function is equipped with a light that turns on automatically when the oven is in operation so that you can see inside and check the progress of your food. - Page 33 FOOD CHARACTERISTICS & MICROWAVE COOKING FooD CHaraCteriStiCS & MiCrowave CooKing Browning Meats and poultry that are cooked fifteen minutes or longer will brown lightly in their own fat. Foods that are cooked for a shorter period of time may be brushed with a browning sauce such as worcestershire sauce, soy sauce or barbecue sauce to achieve an appetizing colour.
-
Page 34: To Clean Your Oven
FOOD CHARACTERISTICS & MICROWAVE COOKING / QUESTIONS & ANSWERS to Clean Your oven Keep the inside of the oven clean Food spatters or spilled liquids stick to oven walls and between the seal and door surfaces. It is best to wipe up spillovers with a damp cloth right away. -
Page 35: Technical Specifications
TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS MS408 Power Input 230 V ~ 240V/50 Hz Microwave Output Power. 1100 Watt (IEC60705 rating standard) Microwave Frequency 2450 MHz Oven Cavity Dimension 398 mm(W) X 265 mm(H) X 402 mm(D) Outside Dimension 556 mm(W) X 320 mm(H) X 440 mm(D) MS408 Net Weight 17.1 Kg... - Page 36 LGEAP Printed in China...
