- Page 1 OWNER’S MANUAL BOTTOM FREEZER REFRIGERATOR Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. GF-5D712SL / GF-5D712BSL / GF-5L712PL www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS TABLE OF CONTENTS Adjusting the Refrigerator Shelves PRODUCT FEATURES - Detaching the Shelf - Refitting the Shelf - Using the Folding Shelf IMPORTANT SAFETY - When Closing the Door INSTRUCTIONS Big Fresh Zone - Removal of the Big Fresh Zone drawer - Refitting the Big Fresh Zone drawer COMPONENTS How to remove and refit the vegetable... -
Page 3: Product Features
PRODUCT FEATURES PRODUCT FEATURES * Depending on the model, some of the following functions may not be available. DOOR ALARM The Door Alarm function is designed to prevent refrigerator malfunctioning that could occur if a refrigerator door or freezer door remains open. If a refrigerator door or freezer door is left open for more than 60 seconds, a warning alarm sounds in 30 second intervals until it is closed. -
Page 4: Important Safety Instructions
iMPORTANT SAFETY iNSTRUCTiONS IMPORTANT SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others, or cause damage to the product. - Page 5 iMPORTANT SAFETY iNSTRUCTiONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following. This appliance is intended to be used in household and similar applications such as - staff kitchen areas, offices and other working environments;...
- Page 6 iMPORTANT SAFETY iNSTRUCTiONS READ ALL INSTRUCTIONS BEFORE USING THE APPLIANCE. To reduce the risk of fire, electric shock, or personal injury when using your product, basic safety precautions should be followed, including the following. CAUTiON Installation The refrigerator must be properly installed in accordance with the Installer Instructions that were taped to the front of the refrigerator.
-
Page 7: Components
COMPONENTS COMPONENTS Use this page to become more familiar with the parts and features of your refrigerator. Page references are included for your convenience. *The appearance and specifications of the actual product may differ depending on the model. Refrigerator Exterior (Applicable to some models only) LED Display Door in Door release Displays the refrigerator and... -
Page 8: Refrigerator Interior
COMPONENTS Refrigerator Interior (Applicable to some models only) Pure N Fresh Filter LED interior lamps The interior lamps light up Shelf the inside of the refrigerator. Dairy Product Bin Used to preserve dairy products. Fridge Basket Shelf Folding Shelf indoor ice Bin Door-in-Door Ice cubes are automatically produced. -
Page 9: Installation
iNSTALLATiON INSTALLATION Installation Overview Please read the following installation instructions first after purchasing this product or transporting it to another location. 1 Unpacking your 2 Choosing the proper refrigerator location 3 Connecting the 4 Leveling and Door water supply and Alignment water line... -
Page 10: Unpacking Your Refrigerator
iNSTALLATiON Unpacking Your Refrigerator Choosing the Proper Location Select a place where a water supply can WARNiNg be easily connected for the automatic icemaker. Use two or more people to move and install the refrigerator. Failure to do so can result in NOTE back or other injury. -
Page 11: Ambient Temperature
iNSTALLATiON How to Remove the Refrigerator Ambient Temperature Door Install this appliance in an indoor area where the temperature is between 13°C and 43°C. Removing the Left Refrigerator Door If the temperature around the appliance is too low or high, the cooling ability may be adversely affected. - Page 12 iNSTALLATiON Removing the Right Refrigerator Remove the cover and pull out the tube Door Disconnect all wire harnesses Remove the top hinge cover screw Lift the hook (not visible), located at the bottom of the front side of the cover with a flat-head screwdriver.
- Page 13 iNSTALLATiON NOTE Rotate the hinge lever clockwise. Lift the top hinge free of the hinge lever latch. Collet Tube insert Line Hinge Lever Latch 1) Gently insert the tube until only one line shows on the tube. CAUTiON When lifting the hinge free of the hinge (Correct) lever latch, be careful that the door does not fall forward.
- Page 14 iNSTALLATiON Assembling the Right Refrigerator Connect the wire harness Door Install the right-side door first. Make sure that the plastic sleeve is inserted in the bottom of the door. Lower the door onto the middle hinge pin as shown in the figure. Make sure that the door-switch located inside the cover is tightly connected.
- Page 15 iNSTALLATiON Assembling the Left Refrigerator Push the water supply tube into the hole Door on the top case and pull it through the backplate. Install the left refrigerator door after the right door is installed. Make sure that the plastic sleeve is inserted in the bottom of the door.
-
Page 16: How To Remove The Freezer Door
iNSTALLATiON How to Remove the Freezer Height Adjustment Door (TURN OFF THE MAIN Leveling the doors may not be possible when POWER. Same procedure for the floor is not leveled, or is of weak or poor construction. The refrigerator is heavy and left and right doors) should be installed on a rigid and solid surface. -
Page 17: If The Heights Of The Freezer Doors Are
iNSTALLATiON If the heights of the Freezer doors Method 2, only allows a maximum of 3mm of adjustment) are different (1) Use the wider side of the number Method 1 is recommended. spanner to turn locking nut ( For freezer doors, use spanner clockwise to unscrew the locking nut. -
Page 18: Connecting The Water Line
iNSTALLATiON Connecting the Water Line Plug in the refrigerator Arrange the coil of tubing so that it does not vibrate against the back of the refrigerator or Before You Begin against the wall. Push the refrigerator back to the wall. This water line installation is not covered by the refrigerator warranty. -
Page 19: How To Use
HOW TO USE HOW TO USE Before use Clean the refrigerator. Clean your refrigerator thoroughly and wipe off all dust that may have accumulated during shipping. CAUTiON Do not scratch the refrigerator with a sharp object or use a detergent that contains alcohol, a flammable liquid or an abrasive when removing any tape or adhesive from the refrigerator,. -
Page 20: Control Panel
HOW TO USE Control Panel (Applicable to some models only) Control Panel Features Fridge Temperature Express Freeze Indicates the set target temperature of the This function increases both ice making and refrigerator compartment in Celsius (°C). freezing capabilities. The recommended Fridge set temperature in When you touch the Express Freeze button, normal ambient conditions and loads is 3°C ~ 4°C. - Page 21 HOW TO USE Ice On/Off Lock Press the Ice On/Off button for 3 seconds to turn The Lock function disables every other button the icemaker On/Off. on the display. When power is initially connected to the refrigerator, the Lock function is off. Light If you want to activate the Lock function to lock...
-
Page 22: In-Door Ice Bin
HOW TO USE In-Door Ice Bin * Depending on the model, some of the To remove the in-door ice bin, grip the following functions may not be available. front handle, slightly lift the lower part, and slowly pull out the bin as shown. CAUTiON Keep hands and tools out of the ice compartment door and dispenser chute. -
Page 23: Automatic Icemaker
HOW TO USE Automatic Icemaker WARNiNg Personal Injury Hazard * Depending on the model, some of the DO NOT place fingers or hands on the following functions may not be available. automatic ice making mechanism while the refrigerator is plugged in. Ice is made in the automatic icemaker and sent to the dispenser. - Page 24 HOW TO USE Automatic Icemaker When You Should Turn the Icemaker Off (continued) When the water supply will be shut off for several hours. CAUTiON When the ice bin is removed for more The first ice and water dispensed may than one or two minutes.
-
Page 25: Ice And Water Dispenser
HOW TO USE Ice and Water Dispenser NOTE If discolored ice is dispensed, check * Depending on the model, some of the the water filter and water supply. If the following functions may not be available. problem continues, contact a qualified service center. -
Page 26: Storing Food
HOW TO USE Storing Food Food Preservation Location (Applicable to some models only) Each compartment inside the refrigerator is designed to store different types of food. Store your food in the optimal space to enjoy the freshest taste. Fridge Basket Store beverages, water, etc. - Page 27 HOW TO USE Food Preservation Location (Applicable to some models only) (continued) Dairy Product Bin Store diary foods such as butter, cheese, etc. Folding Shelf Fold this shelf to store large-sized containers or food. Door-In-Door Store frequently-taken out foods such as beverages, snacks, etc. Extra Space Preserve small foods such as eggs, ham, etc.
-
Page 28: Food Storage Tips
HOW TO USE Storing Frozen Food Food Storage Tips * The following tips may not be applicable NOTE depending on the model. Check a freezer food guide or a reliable cookbook for further information about preparing Wrap or store food in the refrigerator in airtight food for freezing or food storage times. -
Page 29: Adjusting The Refrigerator Shelves
HOW TO USE Storing Frozen Food (continued) Adjusting the Refrigerator Shelves Packaging The shelves in your refrigerator are adjustable Successful freezing depends on correct to meet your individual storage needs. Your packaging. When you close and seal the model may have either glass or wire shelves. package, it must not allow air or moisture in or out. -
Page 30: Using The Folding Shelf
HOW TO USE Using the Folding Shelf When Closing the Door You can store taller items, such as containers or bottles, by simply pushing the front half of the shelf underneath the back half of the shelf. Pull the front of the shelf firmly toward you to return to a full shelf. -
Page 31: Big Fresh Zone
HOW TO USE Big Fresh Zone Refitting the Big Fresh Zone drawer Removal of the Big Fresh Zone drawer. Insert the left and right roller of the drawer into the guides whilst the draw is slightly lifted at the front. and push it in gently Pull the drawer back to the end of its while lowering it at the same time. -
Page 32: How To Remove And Refit The Vegetable Box
HOW TO USE How to remove and refit the How to refit vegetable box vegetable box Lift the vegetable box drawer assembly on How to remove the vegetable box to an angle and place it into the refrigerator compartment ready for fitting. While the refrigerator doors are wide open, take out all the shelves from the refrigerator compartment. -
Page 33: Extra Space (Multi Collection Corner)
HOW TO USE Extra Space (Multi collection Dairy Corner corner) You can store dairy products such as butter, Store small foods like eggs, ham, cheese, etc. cheese etc. If you close the refrigerator door with the dairy corner left open, the refrigerator door may not close properly. -
Page 34: Door-In-Door Shelf Disassembly
HOW TO USE Door-In-Door Shelf Disassembly Remove screws on both sides of magic (Applicable to some models only) space cover. Raise magicspace cover up and take it out. Hold the bottom of lower basket and raise it up to take it out. Hold the bottom of daily basket and raise it up to take it out. -
Page 35: Adjustable Moving Basket
HOW TO USE Adjustable Moving Basket Freezer Drawer Use the compartment for packed frozen foods It can be moved up and down as necessary, and and frequently-accessed foods. used conveniently. Use the bottom compartment for frozen foods. To move the Adjustable Moving Basket up or (Dried fish &... -
Page 36: Refitting The Freezer Drawer
HOW TO USE Freezer/Fridge basket Refitting the Freezer Drawer You can store small packaged frozen food Insert both rollers into the guides with (Freezer basket), small packaged refrigerated the front of the drawer slightly raised and food or beverages (Fridge basket) such as milk, gently push in. -
Page 37: Maintenance
MAiNTENANCE MAINTENANCE Cleaning Both the refrigerator and freezer sections defrost automatically; however, clean both sections about once a month to prevent odors. Wipe up spills immediately. Always unplug the refrigeration before cleaning. General Cleaning Tips WARNiNg Unplug refrigerator or disconnect power. Use non-flammable cleaner. -
Page 38: Replacing The Pure N Fresh Filter
MAiNTENANCE Replacing the Pure N Fresh Inside Walls (allow freezer to warm filter up so the cloth will not stick) To help remove odors, you can wash the inside of the refrigerator with a mixture of baking It is recommended that you replace the Pure N soda and warm water. -
Page 39: Replacing The Water Filter
MAiNTENANCE Replacing the Water Filter NOTE Replace with a new water filter. This refrigerator does not require a filter Insert the new filter into the filter head and bypass plug when the filter is not in place. rotate it clockwise until the arrow on the new filter lines up with the arrow on the filter head. -
Page 40: Smart Diagnosis
Press and hold the Freezer Only use the Smart Diagnosis feature when Temperature button for three instructed to do so by the LG call center agent. seconds while continuing The transmission sounds that you will hear are to hold your phone to the normal and sound similar to a fax machine. -
Page 41: Troubleshooting
TROUBLESHOOTiNg TROUBLESHOOTING Review the Troubleshooting section before calling for service; doing so will save you both time and money. Problem Possible Causes Solutions Refrigerator and The refrigerator display control Cancel the OFF mode so that the unit Freezer section is set to OFF (some models). commences operation. - Page 42 TROUBLESHOOTiNg Problem Possible Causes Solutions Refrigerator or Refrigerator was recently It may take up to 24 hours for each compartment Freezer section is installed. to reach the desired temperature. too warm. Air vents are blocked. Rearrange items to allow air to flow throughout the compartment.
- Page 43 TROUBLESHOOTiNg Problem Possible Causes Solutions Interior moisture Doors are opened often or for When the doors are opened often or for long buildup. long periods of time. periods of time, warm, humid air enters the compartment. This raises the temperature and moisture level within the compartment.
- Page 44 TROUBLESHOOTiNg Problem Possible Causes Solutions Frost or ice Condensation from food with a This is normal for food items with a high water crystals on frozen high water content has frozen content. food (inside of inside of the food package. sealed package).
- Page 45 TROUBLESHOOTiNg Problem Possible Causes Solutions Pulsating or Your refrigerator is designed Normal Operation High-Pitched to run more efficiently to keep Sound your food items at the desired temperature. The high efficiency compressor may cause your new refrigerator to run longer than your old one, but it is still more energy efficient than previous models.
- Page 46 TROUBLESHOOTiNg Problem Possible Causes Solutions Icemaker is not Demand exceeds ice storage The icemaker will produce approximately 50~80 making enough capacity. cubes in a 24 hour period. ice. House water supply is not Connect the refrigerator to a cold water supply connected, valve is not turned with adequate pressure and turn the water on fully, or valve is clogged.
- Page 47 TROUBLESHOOTiNg Problem Possible Causes Solutions Icemaker is not Doors are opened often or for If the doors of the unit are opened often, ambient making enough long periods of time. air will warm the refrigerator which will prevent ice (continued). the unit from maintaining the set temperature.
- Page 48 TROUBLESHOOTiNg Problem Possible Causes Solutions Not dispensing Doors are not closed Ice will not dispense if any of the refrigerator ice. completely. doors are left open. Infrequent use of the dispenser. Infrequent use of the ice dispenser will cause the cubes to stick together over time, which will prevent them from properly dispensing.
- Page 49 TROUBLESHOOTiNg Problem Possible Causes Solutions Not dispensing New installation or water line Dispense 2.5 gallons of water (flush for water. recently connected. approximately 5 minutes) to remove trapped air and contaminants from the system. Do not dispense the entire 2.5 gallon amount continuously.
- Page 50 TROUBLESHOOTiNg Problem Possible Causes Solutions Ice has bad taste Water supply contains minerals A water filter may need to be installed to or odor. such as sulfur. eliminate taste and odor problems. NOTE: In some cases, a filter may not help. It may not be possible to remove all minerals / odor / taste in all water supplies.
