- Page 1 OWNER’S MANUAL REFRIGERATOR- FREEZER Please read this owner's manual thoroughly before operating and keep it handy for reference at all times. www.lg.com...
-
Page 2: Table Of Contents
IMPORTANT SAFETY INFORMATION ....3 CONTENTS INSTALLATION ........... 11 INNER PARTS ............ 12 OPERATIONS ............. 13 Starting Before Setting The Temperature Door Alarm Self Test Controls For Refrigerator Compartment Fast Freezing Child Lock Controls For Freezer Compartment Ice Making Fresh Zone Vegetable Drawer Defrosting Deodorizer... -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION w WARNING w Keep ventilation openings, in the appliance enclosure or in the built-in structure, clear of obstruction. w Do not use mechanical devices or other means to accelerate the defrosting process, other than those recommended by the manufacturer. w Do not damage the refrigerant circuit. - Page 4 IMPORTANT SAFETY INFORMATION BASIC SAFETY PRECAUTIONS This guide contains many important safety messages. Always read and obey all safety messages. This is the safety alert symbol. It alerts you to safety messages that inform you of hazards that can kill or hurt you or others or cause damage to the product.
- Page 5 IMPORTANT SAFETY INFORMATION 1. When connecting the power Do not extend or modify the length of the Unplug the power plug when cleaning, power cord or power handling or replacing the interior lamp of the plug. refrigerator. It can cause electric shock •...
- Page 6 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not place heavy, or dangerous objects or Do not place a flower any containers containing vase, cup, cosmetics, fluids on top of the medicine or any container refrigerator. with water on the refrigerator.
- Page 7 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not use a hair dryer to dry the inside, or Avoid direct heat sources. light a candle to remove It may cause damage, malfunction, odor. and fire. It may cause explosion or fire.
- Page 8 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not allow any person except a qualified When any strange smell or smoke is engineer to disassemble, repair or alter the detected from the refrigerator, disconnect refrigerator. the power plug Service immediately and It may cause injury, center...
- Page 9 IMPORTANT SAFETY INFORMATION 2. When using the refrigerator Do not remove the cover Place all the internal shelving and parts in on the back. the right places before connecting the power. Don not use an Adapter. Never use lit candles or incense on the fridge, at risk of causing fire or product damage.
- Page 10 IMPORTANT SAFETY INFORMATION Do not put any living matter, animals, pets or Do not use carbonated water in the water children, in or on the tank. The gas refrigerator. pressure may cause leakage. Water Tank WARING : fill with potable water only. Do not use products such as abrasive Rinse out the water tank and ice making tray sponges, brushes or pads to clean the...
-
Page 11: Installation
THIS REFRIGERATOR IS MANUFACTURED WITH GREAT CARE, AND UTILIZES THE LATEST IN TECHNOLOGY. WE ARE CONFIDENT THAT YOU WILL BE FULLY SATISFIED WITH IT'S PERFORMANCE AND RELIABILITY. BEFORE YOU START YOUR REFRIGERATOR, PLEASE READ THIS BOOKLET CAREFULLY. IT PROVIDES EXACT INSTRUCTIONS FOR INSTALLATION, OPERATION AND MAINTENANCE, AND ALSO SUPPLIES SOME USEFUL HINTS. -
Page 12: Inner Parts
INNER PARTS FREEZER COMPARTMENT Lamp Shelf Freezer Freezer Temperature Door Rack Control Dial Twisting Ice Serve Type Ice Making Freezer Shelf Door Rack REFRIGERATOR COMPARTMENT Water Tank Fresh Zone Lamp Egg Tray Shelf Refrigerator Door Rack Vegetable Drawer Leveling Screw •... -
Page 13: Operations
OPERATIONS STARTING When your refrigerator is first installed, allow it 3 - 4 hours to stabilize at normal operating temperatures prior to filling it with fresh or frozen foods. If operation is interrupted, wait 5 minutes before restarting. BEFORE SETTING THE TEMPERATURE The temperature of the refrigerator is kept constant regardless of changes in room temperature. -
Page 14: Fast Freezing
OPERATIONS FAST FREEZING The FAST FREEZING feature operates ● when the refrigerator is first turned on. The compressor and circulating fan operate at maximum cooling capacity to quickly lower the refrigerator temperature. It shuts off automatically. If warm food is placed into the refrigerator, FAST FREEZING can be manually engaged with the button on ●... -
Page 15: Ice Making
OPERATIONS ICE MAKING Twisting Ice Serve Type To make ice cubes, fill the ice tray with water ● Ice Trays and insert in its position. Ice Cube Box To remove ice cubes, hold the lever of the tray ● and pull turn gently. Then, ice cubes drop in to the ice cube box. -
Page 16: Defrosting
OPERATIONS DEFROSTING Defrosting takes place automatically. ● The defrosted water flows down to the evaporating tray which located in ● the lower back side of the refrigerator and is evaporated automatically. DEODORIZER (OPTIONAL) Unpleasant odor of food in fresh food ●... -
Page 17: Water Dispenser
OPERATIONS WATER DISPENSER Only fill the water tank after it has been rinsed and installed into position. It should always ● be removed for cleaning. The water tank will leak when it contains water if it's valve is pushed, even if it is not fitted ●... -
Page 18: Suggestions On Food Storage
SUGGESTIONS ON FOOD STORAGE SUGGESTIONS ON FOOD STORAGE STORING FOOD Store fresh food in the refrigerator compartment. How food is frozen and thawed is an important ● factor in maintaining its freshness and flavor. Do not store food which goes bad easily at low temperatures, such as bananas, pineapples, and ●... -
Page 19: Cleaning
CLEANING It is important that your refrigerator be kept clean to w WARNING prevent undesirable odors. Spilled food should be wipe up immediately, since it may acidify and stain Always remove power cord from the wall outlet plastic surfaces if allowed to settle. prior to cleaning in the vicinity of electrical parts(lamps, switches, controls, etc.). - Page 20 CLEANING WATER DISPENSER Grille - Wipe with a wet cloth, and dry with a dry cloth. Water Tank - 1. It is not necessary to remove the tank to fill it with water. See page 17. NOTE Before closing door, close the water cap to prevent water ●...
-
Page 21: General Information
GENERAL INFORMATION VACATION TIME ANTI-CONDENSATION PIPE During average length vacations, you will probably The outside wall of the refrigerator cabinet may find it best to leave the refrigerator in operation. sometimes get warm, especially just after Place freezable items in freezer for longer life. installation. -
Page 22: Warning
w WARNING DO NOT USE AN EXTENSION CORD ABOUT GROUNDING (EARTHING) If possible, connect the refrigerator to its own In the event of an electric short circuit, grounding individual electrical outlet to prevent it and other (earthing) reduces the risk of electric shock by appliances or household lights from causing an providing an escape wire for the electric current. -
Page 23: Before Calling For Service
BEFORE CALLING FOR SERVICE SERVICE CALLS CAN OFTEN BE AVOIDED! IF YOU FEEL YOUR REFRIGERATOR IS NOT OPERATING PROPERLY, CHECK THESE POSSIBLE CAUSES FIRST : PROBLEM POSSIBLE CAUSES REFRIGERATOR DOES Has a house fuse blown or circuit breaker tripped? ● NOT OPERATE Has the power cord plug been removed or loosened from ●...
