If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. Comuníquese con SAMSUNG WORLDWIDE Si desea formular alguna pregunta o comentario en relación con los productos de Samsung, comuníquese con el centro de atención al cliente de SAMSUNG.
United States, for the warranty period originally specified, and to the Original Purchaser only. The above described warranty repairs must be performed by a SAMSUNG Authorized Service Center. Along with this Statement, the Original Limited Warranty Statement and a dated Bill of Sale as Proof of Purchase must be presented to the Service Center. Transportation to and from the Service Center is the responsibility of the purchaser.
Contents getting started List of Features ... 4 Accessories ... 4 Installing the LCD TV Stand ... 4 Viewing the Control Panel ... 5 Viewing the Remote Control ... 6 Connecting to an Antenna ... 7 Plug & Play (Initial Setup) ...
Excellent Digital Interface & Networking : With a built-in HD digital tuner, nonsubscription HD broadcasts can be viewed ■ without a cable box / STB (Set-Top-Box) satellite receiver. : Allows you to play music files, and pictures saved on a USB device. (P. 21) Media Play ■...
<ln19C450> ✎ Make sure to distinguish between the front and rear of the Stand when attaching it to the TV. ✎ Make sure that at least two persons lift and move the LCD TV. ✎ Lay the product down, with the screen facing up and fasten the screws. ✎...
Buttons used in the Channel list, Media Play menu, etc. Use these buttons in the Media Play and Anynet+ modes. (�: Controls recording on Samsung recorders with the Anynet+ feature) Installing batteries (Battery size: AAA) English Viewing the Remote Control MEDIA.P...
When the TV is initially powered on, basic settings proceed automatically. ✎ Connecting the power cord and antenna. Power Input When the TV is initially powered on, a sequence of on-screen prompts will assist in configuring basic settings. Press the POWERP button.
Using an hDMI / DVI Cable: hD connection (up to 1080p) We recommend using the HDMI connection for the best quality HD picture. Available devices: DVD, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver ✎ hDMI (DVI) In PC/DVI AUDIO In When using an HDMI/DVI cable connection, you must use the player, HD cable box, HD STB satellite receiver, cable box, or STB satellite receiver may require a DVI-HDMI (DVI...
Using an Optical (Digital) or Audio (Analog) Cable Connection Available devices: Digital Audio System, Amplifier, Home Theater ✎ DIgITAl AUDIO OUT (OPTICAl) When a Digital Audio System is connected to the of both the TV and the system. 5.1 CH (channel) audio is available when the TV is connected to an external device supporting 5.1 CH. When the receiver (home theater) is set to on, you can hear sound output from the TV’s optical jack.
Display Modes (D-sub and hDMI/DVI Input) Optimal resolution is 1360x768@60Hz. Mode Resolution horizontal Frequency (khz) 640 x 350 720 x 400 640 x 480 832 x 624 640 x 480 800 x 600 VESA DMT 1024 x 768 1280 x 720 1360 x 768 720 x 576 VESA CVT...
Basic Features How to Navigate Menus Before using the TV, follow the steps below to learn how to navigate the menu and select and adjust different functions. MEDIA.P MEnU button: Displays the main on-screen menu. 2 EnTERE / Direction button: Move the cursor and select an item.
Using Favorite Channels ¦ m → Channel → Channel list → EnTERE MEnU Add to Favorite / Delete from Favorite Set channels you watch frequently as Favorites. 1. Select a channel and press the button. 2. Add or delete a channel using the Add to Favorite or Delete from Favorite menu respectively.
Add / Delete : Delete or add a channel to display the ■ channels you want. ✎ nOTE All deleted channels will be shown on the Channels menu. A gray-colored channel indicates the channel has been deleted. Add menu only appears for deleted channels.
→ Picture → Advanced settings → MEnU EnTERE (available in standard / Movie mode) Compared to previous models, new Samsung TVs have a more precise picture. ✎ In PC mode, you can only make changes to and White Balance.
Picture Options MEnU m → Picture → Picture Options → EnTERE ✎ In PC mode, you can only make changes to the Tone and size. Picture Options Color Tone Size Digital Noise Filter HDMI Black Level POWER Film Mode U Move E Enter R Return Color Tone (Cool / normal / Warm1 / Warm2) ■...
Sound Menu Changing the Preset sound Mode ¦ m → sound → Mode → EnTERE MEnU Mode standard : Selects the normal sound ■ SLEEP mode. Music : Emphasizes music over voices. ■ Movie : Provides the best sound for ■...
sound Reset (Reset All / Reset sound Mode / Cancel) : Resets all sound settings to the factory Reset All ■ defaults. Reset sound Mode : Returns all sound values in the ■ currently selected mode to the default settings Setup Menu setting the Time ¦...
locking Programs ¦ m → setup → V-Chip → EnTERE MEnU V-Chip The V-Chip feature automatically locks out programs that are deemed inappropriate for children. The user must enter a PIN (personal identification number) before any of the V-Chip restrictions are set up or changed. ✎...
Change PIn : The Change PIN screen will appear. ■ Choose any 4 digits for your PIN and enter them. As soon as the 4 digits are entered, the Confirm new PIn screen appears. Re-enter the same 4 digits. When the Confirm screen disappears, your PIN has been memorized.
Yes: If the test pattern does not appear or there is noise in the test pattern, select Yes. There may be a problem with the TV. Contact Samsung’s Call Center for assistance (1-800-SAMSUNG). no: If the test pattern is properly displayed, select No.
TV’s USB port. USB (HDD) is not supported. Before connecting your device to the TV, please back up your files to prevent them from damage or loss of data. SAMSUNG is not responsible for any data file damage or data loss. Please connect directly to the Compatibility problem.
Page 22
MSC supports MP3 and JPEG files, and the PTP device supports JPEG files only. MTP (Media Transfer Protocol) is not supported. The playing duration of an mp3 file may be displayed as “00:00:00” if its playing time information is not found at the start of the file.
Page 23
Music Using the MP3 list Folder icon Photo Music list icon 307.2MB/973.7MB Move to the previous folder stage icon ✎ Press � or µ buttons to change pages. Photo Music ✎ The selected file is displayed on the top with its playing time. 1.
Page 24
setup Using the setup Menu : Select to control the slide show speed. You can slide show speed ■ select Fast, normal or slow. Background Music : Select to determine whether to play an MP3 file ■ during a slide show. You can select Music On or Music Off. Background Music setting : While a slide show is in progress, use ■...
Anynet+ is a function that enables you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. The Anynet+ system can be used only with Samsung devices that have the Anynet+ feature. To be sure your Samsung device has this feature, check if there is an Anynet+ logo on it.
Make sure to switch to an Anynet+ device by using the Device list. Recording ¦ You can make a recording of a TV Program using a Samsung recorder. 1. Select Recording. ✎ When there are more than two recording devices When multiple recording devices are connected, the recording devices are listed.
listening through a Receiver ¦ You can listen to sound through a receiver (i.e Home Theater) instead of the TV speaker. 1. Select Receiver and set to On. 2. Press the EXIT button to exit. ✎ If your receiver supports audio only, it may not appear in the device list. ✎...
Assembling the Blanking Bracket 1. Place the front of the TV onto a soft cloth or cushion on a table as in Figure 1. – Align the TV bottom along the table edge. 2. Press on the center of the TV back. Adjust the stand as in Figure 2 while pressing the button on the back of the stand. 3.
Page 29
Installing VEsA Compliant Mounting Devices (ln19C450) 1. Place the TV face down on a soft cloth or cushion on a table. 2. Adjust the stand, pressing the button on the back of the stand. 3. Align the mounting interface pad (not supplied) with the holes in the stand bottom and secure it with the four screws that come with the arm-type base, wall mount hanger or other bases (not supplied).
Page 30
Do not fasten the screws too strongly; this may damage the product or cause the product to fall, leading to personal injury. Samsung is not liable for these kinds of accidents. Samsung is not liable for product damage or personal injury when a non-VESA or non-specified wall mount is used or the consumer fails to follow the product installation instructions.
Untie the string before moving the TV. The Kensington Lock is not supplied by Samsung. It a device used to physically fix the system when using it in a public place. The appearance and locking method may differ from the illustration depending on the manufacturer. Refer to the manual provided with the Kensington Lock for additional information on proper use.
If the TV seems to have a problem, first try this list of possible problems and solutions. If none of these troubleshooting tips apply, visit samsung.com, then click on Support, or call Samsung customer service at 1-800-SAMSUNG. Issues Poor picture The TV image does not look as good as it did in the store.
Page 33
Issues solutions and Explanations No Picture, No Video The TV will not turn on. • • • The TV turns off automatically. • • • • There is no picture/video. • • • • • RF(Cable/Antenna) Connection The TV is not receiving all channels. •...
Explanations • Program the Cable/Sat remote control to operate the TV. Refer to the Cable/Sat user manual for SAMSUNG TV code. • Check the supported resolution of the TV and adjust the external device’s output resolution accordingly. Refer to resolution settings in this manual.
Display Resolution Environmental Considerations Operating Temperature Operating Humidity Storage Temperature Storage Humidity Model Name Screen Size (Diagonal) (18.5 inches measured diagonally) Sound Output Dimensions (WxDxH) Body With stand Weight Without Stand With Stand ✎ Design and specifications are subject to change without prior notice. ✎...
