- Page 1 Test Report No.: GETEC-E3-07-016 FCC Class B Certification APPENDIX H : USER’S MANUAL EUT Type: 20.1” LCD Monitor FCC ID: BEJL206WDQ...
- Page 2 User’s Guide L206WD ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for future reference. ee the label attached on the product and give the information to your dealer when you ask for service.
-
Page 3: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential electrical shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 4 Important Precaautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
-
Page 5: Connecting The Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Connecting the stand base or Removing the stand base Place the monitor with its front facing downward on a cushion or soft cloth. Rotate the Stand Body as shown in figure Assemble the Stand Base(Front, Rear) into the Stand Body in the correct direction. -
Page 6: Disassembling The Stand
Connecting the Display Disassembling the stand Put a cushion or soft cloth on aflat Place the monitor face Down on surface. the cushion or soft cloth. Pushing Latch inside, Take the stand base from stand body. Important This illustration depicts the general model of connection. Your monitor may differ from the items shown in the picture. -
Page 7: Positioning Your Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -3˚~17˚... -
Page 8: Using The Pivot Function
Connecting the Display Using the Pivot function Lift the monitor to its highest height to utilize the Pivot function. . Landscape & Portrait : You can rotate the panel 90 clockwise. Please be cautious and avoid contact between the monitor head and the Stand Base when rotating the screen to access the Pivot function. -
Page 9: Using The Computer
Connecting the Display Using the Computer Make sure to turn off the computer and product. Connect the cable as below sketch map form Connect DVI Cable Connect Dsub Cable (PC) Connect Dsub Cable (Mac) Analog signal Digital signal Power Cord D-sub1 D-sub2 Wall-outlet type... -
Page 10: Control Panel Functions
Control Panel Functions Front Panel Controls SOURCE Button Use this button to make D-Sub, DVI, USB connector active. The default setting is D-Sub. Use this button to enter or exit the On Screen Display. MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. - Page 11 Control Panel Functions Use these buttons to select or adjust functions in the On Buttons Screen Display. For more information, refer to page A15. Use this button to enter a selection in the On Screen AUTO/SET Display. Button AUTO IMAGE ADJUSTMENT When adjusting your display settings, always press the AUTO/SET button before entering the On Screen Display(OSD).
-
Page 12: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD. - Page 13 On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub-menu Reference BRIGHTNESS PICTURE To adjust the brightness, contrast and gamma of CONTRAST the screen GAMMA sRGB To customize the color COLOR PRESET 6500K...
-
Page 14: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. Press the MENU Button, then the main menu of the OSD appears. - Page 15 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description PICTURE To adjust the brightness of the screen. BRIGHTNESS P I C T U R E To adjust the contrast of the screen. CONTRAST Set your own gamma value. : -50/0/50 GAMMA On the monitor, high gamma values display whitish images and low gamma...
- Page 16 On Screen Display(OSD) Selection and Adjustment Main menu Sub menu Description TRACKING CLOCK To minimize any vertical bars or stripes visible on the screen background. T R A C K I N G The horizontal screen size will also change. To adjust the focus of the display.
-
Page 17: Flatron F-Engine
On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you touch the button on the front of the monitor. Menu Name Icons Sub-menu Name FLATRON F-ENGINE Screen when applied Screen when not applied When you execute F-ENGINE, two tones will appear on the screen as shown. -
Page 18: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the • Check and see if the power cord is connected display connected? properly to the power outlet. Is the power on and the •... -
Page 19: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is • Press the AUTO/SET button to automatically incorrect. adjust your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. -
Page 20: Have You Installed The Display Driver
Troubleshooting Display image is incorrect The screen color is • Check if the signal cable is properly connected mono or abnormal. and use a screwdriver to fasten if necessary. • Make sure the video card is properly inserted in the slot. •... -
Page 21: Specifications
Specifications Display 20.1 inches (51.133 cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating 20.1 inches viewable 0.258*0.258 mm pixel pitch Horizontal Freq. Analog : 30 - 83 kHz (Automatic) Sync Input Digital : 30 - 83 kHz (Automatic) Vertical Freq. 56 - 75 Hz (Automatic) Input Form Separate TTL, Positive/Negative... - Page 22 Specifications Stand Base Attached ( ), Detached ( O ) Wall-outlet type or PC-outlet type Power cord NOTE Information in this document is subject to change without notice.
-
Page 23: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 720 x 400 31.468 640 x 480 31.469 640 x 480 37.500 800 x 600 37.879 800 x 600 46.875 1024 x 768 48.363 1024 x 768 60.123 1152 x 864 67.500... -
Page 24: Installing The Wall Mount Plate
Installing the Wall mount plate This monitor satisfies the specifications of the Wall mount plate or the interchange device. Place the monitor with its front facing downward on a soft cloth. Separate the stand using a screwdriver as shown in the picture. Install the Wall mount plate. - Page 25 Digitally yours...
-
Page 26: Regulatory Information
Regulatory information Regulatory information... -
Page 27: Fcc Compliance Statement
Regulatory Information cont. respecte toutes les exigences du Règlement sur le FCC Compliance Statement matériel brouilleur du Canada. This equipment has been tested and found to comply NOTICE within the limits of a Class B digital device pursuant to Part The regulations are applied only to the products with the 15 of the FCC Rules. - Page 28 Regulatory Information cont. computer and/or display, after a certain period of inactivity, Why do we have environmentally labelled computers? In many countries, environmental labelling has become an shall reduce its power consumption to a lower level, in one established method for encouraging the adaptation of or more stages.
- Page 29 Regulatory Information cont. relevant bio-accumulative TCO’95 requirement permits Monitor Disposal the inclusion of lead, as no replacement has yet been WARNING developed. If you need to dispose of a monitor, ask a qualified service representative for the proper procedure. Improper disposal could Cadmium is present in rechargeable batteries and in the result in personal injury from implosion.
- Page 30 Regulatory Information cont. Approval requirements cover a wide range of issues: ecology, ergonomics, emission of electrical and TCO’99 requires that plastic components weighing more magnetical fields, energy consumption and electrical than 25 grams shall not contain flame retardants with safety. organically bound bromine or chlorine.
- Page 31 The product must be prepared for recycling and the If you want to find out more information about our recycling manufacturer must have a certified environmental program, please contact your local LG vendor or a management system such as EMAS or ISO 14 001 corporate representative of LG.
