Summary of Contents for Viking VRT530
- Page 1 Installation GUIDE 5 SERIES Built-in Gas Rangetops VRT530 VRT536 VRT548...
-
Page 2: Table Of Contents
Table of Contents Warnings & Important Safety Information ________________________________________________________________ 3 Dimensions ________________________________________________________________________________________ 4 Specifi cations _______________________________________________________________________________________ 5 Clearance Dimensions ________________________________________________________________________________ 6 Electrical & Gas Requirements _________________________________________________________________________ 8 General Information __________________________________________________________________________________ 9 Installation _________________________________________________________________________________________ 9 Final Preparation ___________________________________________________________________________________ 10 Performance Checklist _______________________________________________________________________________ 10 Service &... -
Page 3: Warnings & Important Safety Information
• The required use of a GFI is normally related to the location of a receptacle with respect to any signifi cant sources of water or moisture. • Viking Range, LLC will NOT warranty any problems resulting from GFI outlets which are not installed properly or do not meet the requirements below. -
Page 4: Dimensions
Dimensions 30” W. Gas Rangetop 36” W. Gas Rangetop - 7 / ( 7 5 - 7 / 8 ” ( 9 1 8 ” 48” W. Gas Rangetop - 7 / ( 1 2 8 ” 1 . 6 Side View 28-9/16”... -
Page 5: Specifi Cations
Specifi cations VRT5 Series Gas Rangetops Description 30” W. Models 36” W. Models 48” W. Models Overall width 29-7/8” (75.9 cm) 35-7/8” (91.1 cm) 47-7/8” (121.6 cm) Overall height To top of grate—9-1/4” (23.5 cm) (from bottom) To top of island trim—9-1/8” (23.2 cm) Additions to base To top of backguard—add 8”... -
Page 6: Clearance Dimensions
Clearance Dimensions •This rangetop may be installed directly adjacent to existing 36” (91.4 cm) high base cabinets. IMPORTANT: The top of the side trim MUST be 3/8” (.95 cm) above the adjacent base cabinet countertop. • The rangetop CANNOT be installed directly adjacent to sidewalls, tall cabinets, tall appliances, or other side vertical surfaces above 36”... - Page 7 Clearance dimensions The bottom of a standard hood should be 30” (76.2 cm) min. to 36” (91.4 cm) max. above the countertop. This would / C o typically result in the bottom of the hood being 66” (167.6 o s i cm) to 72”...
-
Page 8: Electrical & Gas Requirements
Electrical & Gas Requirements Electrical Requirements WARNING There is no connection necessary beyond plugging the unit into a polarized, grounded, 120 volt, 60 Hz, 15 amp circuit. The Electrical shock hazard minimum of 120 VAC is required for proper operation of gas To avoid the risk of electrical shock, personal ignition systems. -
Page 9: General Information
General Information READ AND FOLLOW ALL WARNING AND CAUTION INFORMATION WHEN WARNING INSTALLING THIS APPLIANCE. Moving hazard • All openings in the wall behind the appliance and in the fl oor under the To avoid risk of severe personal injury; appliance should be sealed. -
Page 10: Final Preparation
Final Preparation Some stainless steel parts may have a protective wrap, which must be peeled off . All stainless steel body parts should be wiped regularly with hot, soapy water at the end of each cooling period and with liquid cleaner designed for this material when soapy water will not do the job. -
Page 11: Service & Registration
Clearly describe the problem that you are having. If you are unable to obtain the name of an authorized service agency, or if you continue to have service problems, contact Viking Range, LLC at 1-888-845-4641, or write to: VIKING RANGE, LLC... - Page 12 Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 or visit our website at vikingrange.com 064096-000A EN (013018)
