Summary of Contents for Samsung SGH-X630
- Page 1 SGH-X630 User’s Guide...
-
Page 2: Important Safety
Important safety precautions Failure to comply with the following precautions may be dangerous or illegal. Drive safely at all times Do not use a hand-held phone while driving. Park the vehicle first. Switch off the phone when refuelling Do not use the phone at a refuelling point (service station) or near fuels or chemicals. - Page 3 Keep the phone and all its parts, including accessories, out of the reach of small children. Accessories and batteries Use only Samsung-approved batteries and accessories, such as headsets and PC data cables. Use of any unauthorised accessories could damage you or your phone and may be dangerous.
-
Page 4: About This Guide
About this Guide This User’s Guide provides you with condensed information about how to use your phone. To quickly learn the basics for your phone, please refer to “Get started” and “Step outside the phone.” In this guide, the following instruction icons appear: Indicates that you need to pay careful attention to the subsequent... - Page 5 • Web browser Access the wireless web to get up-to-the-minute information and a wide variety of media content. • Get personal with photo caller ID See who’s calling you when their very own photo displays. • Name card Create name cards with your number and profile.
-
Page 6: Table Of Contents
Contents Unpack Make sure you have each item Your phone Keys, features, and locations Get started First steps to operating your phone Install and charge the phone ... 7 Power on or off... 8 Keys and display ... 9 Access menu functions ... 11 Customise your phone... - Page 7 Overview of menu functions To access Menu mode, press <Menu> in Idle mode. 1 Call log p. 28 1 Recent contacts p. 28 2 Missed calls p. 29 3 Dialled calls p. 29 4 Received calls p. 29 5 Delete all p.
-
Page 8: Unpack
You can obtain various accessories from your local Samsung dealer. The items supplied with your phone and the accessories available at your Samsung dealer may vary, depending on your country or service provider. Your phone Keys, features, and locations Earpiece... -
Page 9: Get Started
Get started First steps to operating your phone SIM card information When you subscribe to a cellular network, you receive a plug-in SIM (Subscriber Identity Module) card loaded with your subscription details, such as your PIN, and available optional services. Install and charge the phone Remove the Insert the SIM... -
Page 10: Power On Or Off
Get started When the phone is completely charged (the battery icon becomes still), unplug the adapter from the power outlet. Remove the adapter from the phone. Low battery indicator When the battery is low: • a warning tone sounds, • the low battery message displays, and •... -
Page 11: Keys And Display
Keys and display Keys Perform the function indicated on the bottom line of the display. In Idle mode, access your favourite menus directly. p. 66 In Menu mode, scroll through menu options. In Idle mode, launch the web browser. In Menu mode, select the highlighted menu option or confirm input. - Page 12 Get started Display Layout Menu Contacts Icons Received signal strength FM radio on Call in progress Out of your service area; you cannot make or receive calls Keypad Lock mode is active GPRS network Roaming network Call diverting feature active Icons display various icons.
-
Page 13: Access Menu Functions
Access menu functions The roles of the soft keys Use the soft keys vary depending on the function you are using. The bottom line of the display indicates their current role. Select Press the left soft key to select the highlighted option. -
Page 14: Customise Your Phone
Get started Customise your phone 1. In Idle mode, press Display <Menu> and select language Settings → Phone settings → Language. 2. Select a language. 1. In Idle mode, press Call ringtone <Menu> and select Settings → Sound settings → Incoming call →... - Page 15 You can set the Navigation Menu keys to function as shortcuts shortcuts to access your favourite menus. 1. In Idle mode, press <Menu> and select Settings → Phone settings → Shortcuts. 2. Select a key. 3. Select a menu to be assigned to the key.
-
Page 16: Make/Answer Calls
Make/Answer calls 1. In Idle mode, enter an Make a call area code and phone number. 2. Press [ 3. To end the call, press 1. When the phone rings, Answer a call press [ 2. To end the call, press Press [ / ]. -
Page 17: Play Music
Use these methods: • Download from the wireless web p. 42 • Download from a computer using the optional Samsung PC Studio Samsung PC Studio User’s Guide • Receive via an active Bluetooth connection p. 72 1. In Idle mode, press <Menu>... -
Page 18: Listen To The Fm Radio
3. For Add files, press [ ] Create a to select the files you play list want and press (continued) <Select>. 4. Press <Back> to return to the music player screen. 1. From the music player Play music screen, press [ ]. files 2. -
Page 19: Browse The Web
1. From the station list on Store a radio the FM Radio screen, station press <Options> and select Add. 2. Enter the frequency of the station and press <Save>. 3. Select a location in which you want to store the station. -
Page 20: Use Phonebook
Step outside the phone Use Phonebook To the phone’s memory: Add a 1. In Idle mode, enter a contact phone number and press <Options>. 2. Select Save contact → Phone → a number type. 3. Specify contact information: First name, Last name, Mobile, Home, Office, Fax, Other, Email, Caller ID,... -
Page 21: Send Messages
Send messages 1. In Idle mode, press Send a text <Menu> and select message Messaging → Create (SMS) message → Text message. 2. Enter the message text. 3. Press <Options> and select Save and send or Send only. 4. Enter destination numbers. -
Page 22: View Messages
Step outside the phone View messages When a notification appears: View a text message 1. Press <View>. 2. Select the message from the Inbox. From the Inbox: 1. In Idle mode, press <Menu> and select Messaging → My messages → Inbox. 2. - Page 23 1. In Idle mode, press Search for <Menu> and select and pair with Settings → Bluetooth a Bluetooth → My devices → Search device for new devices. 2. Select a device. 3. Enter a Bluetooth PIN or the other device’s Bluetooth PIN, if it has one, and press <OK>.
-
Page 24: Enter Text
Enter text AB, T9, Number, and Symbol modes You can enter text for some features, such as messaging, Phonebook, or Calendar, using AB mode, T9 mode, Number mode, and Symbol mode. Changing the text input mode • Press and hold [ ] to switch between T9 mode ( ) and AB mode ( Depending on your country, you may... -
Page 25: Using T9 Mode
• Press the Navigation keys to move the cursor. • Press [C] to delete characters one by one. Press and hold [C] to clear the display. Using T9 mode T9 is a predictive text input mode that allows you to enter any character using single keystrokes. -
Page 26: Call Functions
Using Number mode Number mode enables you to enter numbers. Press the keys corresponding to the digits you want. Using Symbol mode Symbol mode enables you to insert symbols. display more symbols select a symbol clear the entered symbols insert the symbols Advanced calling features Making a call 1. -
Page 27: Answering A Call
Redialling recent numbers 1. In Idle mode, press [ ] to display the list of recent numbers. 2. Scroll to the number you want and press Making a call from Phonebook Once you have stored a number in Phonebook, you can dial the number by selecting it from Phonebook. -
Page 28: Using The Headset
Call functions Using the headset Use the headset to make or answer calls without holding the phone. Connect the headset to the jack on the right side of the phone. The button on the headset works as follows: Press redial the last call and hold the button twice. -
Page 29: Menu Functions
3. Press <Options> and select End held call to end the call on hold. 4. To end the current call, press [ Using the speakerphone feature Use your phone as a speaker phone to talk and listen with the phone a short distance away. -
Page 30: Menu Functions
• Join: set up a multi-party call by adding a caller on hold to a currently active call. You can include up to 5 people on a multi-party call. • Select one: select one of multi-party call participants. You can then use the following options: Private: have a private conversation with the selected participant. -
Page 31: Missed Calls
Using call log options While viewing call details, press <Options> to access the following options: • Call: edit the number and dial it. • Save contact: save the number to Phonebook. • Send message: send an SMS or MMS message to the selected number. •... -
Page 32: Call Cost
Menu functions Call cost (Menu 1.7) This network feature displays the cost of calls. This menu is available only if supported by your SIM card. Note that this is not intended to be used for billing purposes. • Last call cost: check the cost of your last call. -
Page 33: Add New Contact
Using Phonebook options While viewing contact details, press <Options> to access the following options: • Edit: edit contact information. • Send message: send an SMS or MMS message to the selected number. • Copy to: copy the contact to the phone’s memory or to the SIM card. -
Page 34: Group
Menu functions Group (Menu 2.3) Use this menu to organise your contacts in caller groups. Creating a caller group 1. Press <Options> and select Add. 2. Enter a name for the group. 3. Select the caller ID line and set an image. -
Page 35: My Namecard
• View: check the name and number assigned to a key. • Change: assign a different number to a key. • Remove: clear the speed dial setting for a key. Dialling speed dial numbers In Idle mode, press and hold the appropriate key. -
Page 36: Service Number
Use the following methods to save music files to your phone’s memory: • Download from the wireless web • Download from a computer using the optional Samsung PC Studio PC Studio User’s Guide • Receive via an active Bluetooth connection p. 74 Downloaded or received files are stored in the Music folder. - Page 37 Creating the play list 1. From the music player screen, press <Options> and select Add to playlist → Add all or Add files. 2. For Add files, press [ ] to select the files to be added and press <Select>. 3.
-
Page 38: Fm Radio
Menu functions Shuffle: set the music player to play tracks in random order. Visualisation: change the playback animation. Skin: select a skin type. Volume: select a volume level. • Details: access the file properties. Accessing the play list From the music player screen, press [Up]. Press <Options>... -
Page 39: Voice Recorder
1. Connect the headset to the phone and press [ ] to turn on the radio. 2. Press <Options> and select Add. 3. Enter the frequency of the station and press <Save>. 4. Select a location in which you want to store the station. -
Page 40: Java World
Menu functions 3. Press <Stop> or [Down] to end recording. The voice memo is saved automatically. Reviewing the voice memo After recording a voice memo, press [ ] to review the voice memo. During playback, use the following keys: Function Pauses or resumes playback. -
Page 41: World Clock
• Delete: delete the selected application or all applications, except for the standard games. • Details: access the application properties. • Upgrade: upgrade the application to the latest version. • Protection: lock the application to protect it from being deleted, or unlock the application. -
Page 42: Alarm
Menu functions 2. Press [ ] to select the time zones you want. 3. Press <Save>. Alarm (Menu 3.6) Use this menu to set alarms. The alert type for a normal alarm corresponds to the call alert type settings. A wake-up alarm is not affected by your sound settings. -
Page 43: Convertor
• Press <.()> to insert a decimal point or bracket. • Press [ ] or [ ] to move the cursor. 2. Press one of the Navigation keys to access the math function you want. 3. Enter the second number. 4. -
Page 44: Stopwatch
Menu functions Stopwatch (Menu 3.0) Use this menu to measure elapsed time. The maximum time is 10 hours. 1. Press [ ] to start the stopwatch. 2. Press [ ] to check an interval. You can repeat this step for a total of 4 intervals. SIM AT (Menu 3.*) This menu is available if you use a SIM AT... -
Page 45: Bookmarks
Press select a browser [ ], or press item <Options> and choose Select. return to the [C], or press previous page <Options> and select Back. Using page options From any web page, press <Menu> to access the following options: • Bookmarks: bookmark the current page or access the bookmark list. -
Page 46: Http
Menu functions Accessing a bookmarked page Selecting a bookmark item launches the web browser and accesses the associated web page. Using bookmark options After saving an item, press <Options> to access the following options: • Go to URL: access the bookmarked web page. - Page 47 Creating and sending an SMS message 1. Enter your message and press [ ]. • The maximum number of characters allowed in a message varies by service provider. If your message exceeds the maximum number of characters, the phone will split the message. •...
- Page 48 Menu functions 2. Enter the message subject and press [ ]. 3. Select the Image and video line. 4. Select Add image or Add video and add an image or a video clip. • The maximum size allowed for a message can differ, depending on your service provider.
-
Page 49: My Messages
• Attach: attach a Phonebook entry as a name card or calender data as a data format attachment. • Change image/Change video/Change sound: replace an added item. • Clear subject/Clear message: clear the subject or text of the message. • Remove media/Remove sound/ Remove: remove an added item. - Page 50 Menu functions SMS messages • Reply via: reply to the sender via SMS or MMS. • Forward: forward the message to other people. • Delete: delete the message. • Move to phone/Move to SIM: move the message between the SIM card and the phone’s memory.
- Page 51 Push messages • Go to URL: connect to the URL specified in the message. • Delete: delete the message. • Copy entry: extract URLs, e-mail addresses, or phone numbers from the message. • Protection: lock the message to protect it from being deleted, or unlock the message.
-
Page 52: Templates
Menu functions • Protection: lock the message to protect it from being deleted, or unlock the message. • Details: access the message properties. Sent messages (Menu 5.2.4) This folder stores messages that you have sent. While viewing a message, press <Options> to access the following options: •... -
Page 53: Delete All
Using template options From the template list, press <Options> to access the following options: • Edit: edit the selected template. • Send message: create and send a new message. • Delete: delete the selected template. • Add new: add a new template. Delete all (Menu 5.4) Use this menu to delete messages in each... - Page 54 Menu functions Bearer selection: select either GSM or GPRS preferred, depending on your network. • Block number: store the phone numbers from which you want to reject messages. • Current profile: select an SMS setting profile. • Profile settings: set the properties of each profile.
- Page 55 Reject unknown senders: reject messages from unknown senders. Allow adverts: accept advertisements. Allow information: accept information messages. Allow reports: set the network to inform the sender when a message has been delivered to you. Recep. in home network: determine if your phone retrieves new messages automatically when you are in your home service area.
-
Page 56: Memory Status
Menu functions Memory status (Menu 5.6) Use this menu to view the amount of memory currently in use in each message folder. File manager (Menu 6) The File manager menu allows you to access image, video, and sound files stored in the phone’s memory. -
Page 57: Videos
• Delete: delete the file. • Rename: change the file name. • Move to Favourite images: move the file to the Favourite images folder. • Move to Downloaded images: move the file to the Downloaded images folder. • Move to Photos: move the file to the Photos folder. -
Page 58: Music
Menu functions • Move to Downloaded videos: move the file to the Downloaded videos folder. • Move to Video clips: move the file to the Video clips folder. • Bluetooth visibility: share the file or all files with other Bluetooth devices. •... -
Page 59: Other Files
• Bluetooth visibility: share the file or all files with other Bluetooth devices. • Protection: lock the file to protect it from being deleted, or unlock the file. • Details: access the file properties. Other files (Menu 6.5) Files that you have received but which are not supported by your phone are stored in this folder. - Page 60 Menu functions Entering a schedule item 1. Select a date on the calendar. 2. Press <Options> and select Create → Schedule. 3. Enter information or change the settings: • Subject: enter a title for the item. • Details: enter item details. •...
-
Page 61: Consulting The Calendar
4. Press <Save> to save the anniversary. Entering a memo 1. Select a date on the calendar. 2. Press <Options> and select Create → Memo. 3. Enter a memo and press <Save>. Entering a To do item 1. Select a date on the calendar. 2. - Page 62 Menu functions Using calendar options On the calendar, press <Options> to access the following options: • View mode: change the view mode of the calendar. next section • Create: add a new item. • Go to: enter the specific date you want to access.
-
Page 63: Camera
Camera (Menu 8) You can use the camera module embedded in your phone to take photos and record videos. To access this menu, press <Menu> in Idle mode and select Camera, or press and hold • Do not take photos of people without their permission. - Page 64 Menu functions • Shooting mode: take a photo in the following modes: Single shot: take a photo in normal mode. You can select whether or not the camera automatically saves a photo. Multi-shot: take a series of action stills. You can select the number of photos the camera will take and the shooting speed.
-
Page 65: Recording A Video
Function Changes the image quality. Changes the shooting mode. Changes the colour tone or applies a special effect. Selects a decorative frame. Sets the timer. Goes to the Photos folder. Changes the preview screen. Using photo options After saving a photo, press <Options> to access the following options: •... - Page 66 Menu functions 5. To Press play back the video [ ]. clip access video options <Options>. delete the video clip [C] and then <Yes>. return to Record <Preview>. mode Using camera options in Record mode In Record mode, press < following options: •...
-
Page 67: Settings
Function Changes the frame size. Changes the colour tone or applies a special effect. Mutes or unmutes audio. Sets the timer. Goes to the Video clips folder. Changes the preview screen. Using video options After saving a video clip, press <Options> to access the following options: •... -
Page 68: Phone Settings
Menu functions • Time format: select a time format. • Set date: enter the current date. • Calendar starting day: set which day of the week the calendar starts with. Phone settings (Menu 9.2) Many different features of your phone’s system can be customised to suit your preferences. -
Page 69: Display Settings
Volume key (Menu 9.2.5) Use this menu to set whether the phone mutes the call ringer or rejects a call if you press and hold [ / ] when a call comes in. Extra settings (Menu 9.2.6) You can turn the automatic redialling or answering feature on or off. -
Page 70: Sound Settings
Menu functions • Main display normal: select the length of time the backlight stays on. • Main display dim: select the length of time the display stays on in Dim mode after the backlight turns off. After a specified time, the display turns off. Dialling display (Menu 9.3.5) Use this menu to select a font colour for the... -
Page 71: Network Services
Silent mode (Menu 9.4.5) Use this menu to set how the phone acts to alert you to a specific event while in Silent mode. Extra tones (Menu 9.4.6) Use this menu to customise additional tones for the phone. • Minute minder: set the phone to beep every minute during an outgoing call to keep you informed of the length of your call. -
Page 72: Call Waiting
Menu functions 5. Enter the number to which calls are to be diverted. 6. If you selected No reply, move to the Seconds line and select the length of time the network delays before diverting a call. 7. Press <Select>. Call barring (Menu 9.5.2) This network service allows you to restrict... - Page 73 Network selection (Menu 9.5.4) This network service allows you to either automatically or manually select the network to be used while roaming outside of your home area. You can select a network other than your home network only if there is a valid roaming agreement between the two.
-
Page 74: Bluetooth
Menu functions Bluetooth (Menu 9.6) Using the Bluetooth feature, you can connect the phone wirelessly to other Bluetooth devices and exchange data with them, talk hands-free, or control the phone remotely. Bluetooth technology allows free wireless connections between all Bluetooth-compliant devices within a range of 10 metres. - Page 75 2. Select Search for new devices. After searching, a list of devices to which you can connect displays. The following icons indicate the type of device: • Mobile phone • • Computer • • Unknown • device The colour of the icon indicates the status of the the device: •...
-
Page 76: Security
Menu functions Sending data via Bluetooth 1. Activate the Bluetooth feature. 2. Select the application in which the item you want to send is stored. 3. Scroll to the item you want and press <Options>. 4. Select Send via → Bluetooth. 5. -
Page 77: Connection Settings
Phone lock (Menu 9.7.3) Use this menu to lock the phone from unauthorised use. When this feature is enabled, you must enter a 4- to 8-digit phone password each time the phone is switched on. The password is preset to 00000000. To change the password, use the Change password menu. - Page 78 Menu functions Your phone is set up by default for connecting to the network. If you change the settings without first checking with your service provider, the web browser and MMS features may not work properly. Creating a profile 1. Press <New>. If a profile has already been saved, press <Options>...
-
Page 79: Solve Problems
• Delete: delete the profile. • Add new connection: add a new profile. Reset settings (Menu 9.9) Use this menu to reset the phone’s settings you have changed. 1. Press [ ] to select the setting categories to be reset. 2. - Page 80 Solve problems “Enter PUK” • The PIN code has been entered incorrectly three times, and the phone is now blocked. Enter the PUK supplied by your service provider. “No service,” “Network failure,” or “Not done” displays • The network connection has been lost. You may be in a weak signal area.
-
Page 81: Health And Safety Information
The model and serial numbers of your phone • Your warranty details • A clear description of the problem Then contact your local dealer or Samsung after-sales service. Health and safety information SAR certification information This phone meets European Union (EU) requirements concerning exposure to radio waves. -
Page 82: Precautions When Using Batteries
Health and safety information The highest SAR value for this model phone was 0.515 W/kg. SAR tests are conducted using standard operating positions with the phone transmitting at its highest certified power level in all tested frequency bands. Although the SAR is determined at the highest certified power level, the actual SAR level of the phone while operating can be well below the maximum value. -
Page 83: Road Safety
• Use only Samsung-approved batteries, and recharge your battery only with Samsung-approved chargers. Disconnect the charger from the power source when it is not in use. Do not leave the battery connected to a charger for more than a week, since overcharging may shorten its life. -
Page 84: Operating Environment
Health and safety information Operating environment Remember to follow any special regulations in force in the area you are in, and always switch off your phone whenever it is forbidden to use it, or when it may cause interference or danger. When connecting the phone or any accessory to another device, read its user’s guide for detailed safety instructions. -
Page 85: Potentially Explosive Environments
Other medical devices If you use any other personal medical devices, consult the manufacturer of your device to determine if it is adequately shielded from external RF energy. Your physician may be able to assist you in obtaining this information. Switch off your phone in health care facilities when regulations posted in these areas instruct you to do so. -
Page 86: Emergency Calls
Health and safety information Emergency calls This phone, like any wireless phone, operates using radio signals, wireless, and landline networks as well as user- programmed functions, which cannot guarantee connection in all conditions. Therefore, you should never rely solely on any wireless phone for essential communications like medical emergencies. -
Page 87: Care And Maintenance
• Failure to observe these instructions may lead to the suspension or denial of telephone services to the offender, or legal action, or both. Care and maintenance Your phone is a product of superior design and craftsmanship and should be treated with care. - Page 88 Health and safety information • When the phone or battery gets wet, the label indicating water damage inside the phone changes colour. In this case, phone repairs are no longer guaranteed by the manufacturer's warranty, even if the warranty for your phone has not expired.
-
Page 89: Index
Index AB mode, text input • 22 Alarm • 40 Answering call • 25 second call • 26 Anykey answer • 67 Auto redial • 67 Background image • 67 Backlight time, set • 67 Barring, calls • 70 Battery charging •... -
Page 90: Card
Index Games • 38 Greeting message • 66 Health and safety • 79 Holding, call • 26 Icons, description • 10 Images, downloaded • 54 Inbox, messages • 47 International calls • 24 Internet • 42 Java applications • 34 Key tones selecting •... - Page 91 Problems, solve • 77 Push messages • 49, 53 Radio • 36 Received calls • 29 Received messages • 47 Recording videos • 63 voice memos • 37 Redialling automatically • 67 manually • 25 Resetting phone • 77 Ringer incoming calls •...
- Page 92 2006. 05. 12 (place and date of issue) * It is not the address of Samsung Service Centre. For the address or the phone number of Samsung Service Centre, see the warranty card or contact the retailer where you purchased your phone.
- Page 93 some of the descriptions in this guide may not match your phone exactly. * Depending on your country, your phone and accessories may appear different from the illustrations in this guide. World Wide Web http://www.samsungmobile.com Printed in Korea Code No.:GH68-09948A English (EU).
