- Page 1 Test Report No.: GETEC-E3-05-041 FCC Class B Certification APPENDIX H : USER’S MANUAL EUT Type: 20” LCD Monitor FCC ID: BEJL20NU...
- Page 2 User’s Guide L20NP ake sure to read the Important Precautions before using the product. Keep the User's Guide(CD) in an accessible place for furture reference. ee the label attached on the product and quote this information to your dealer when you require service.
-
Page 3: Regulatory Information
Regulatory Information FCC Compliance Statement CE Conformity Notice (for Europe) This equipment has been tested and found to comply within Products with the “CE” Marking comply with the EMC the limits of a Class B digital device pursuant to Part 15 of Directive(89/336/EEC) and LOW VOLTAGE Directive the FCC Rules. - Page 4 Regulatory Information cont. scheme, which provides for international environmental Lead can be found in picture tubes, display screens, solder, labelling of personal computers. The labelling scheme was and capacitors. Lead damages the nervous system and in developed as a joint effort by the TCO (The Swedish higher doses causes lead poisoning.
- Page 5 Regulatory Information cont. TCO99 The energy requirements include a demand that the computer and/or display, after a certain period of inactivity, shall reduce its power consumption to a lower level in one or more stages. The length of time to reactivate the computer shall be reasonable for Congratulations! the user.
-
Page 6: Important Precautions
Important Precautions This unit has been engineered and manufactured to ensure your personal safety, however improper use may result in potential e shock or fire hazards. In order to allow the proper operation of all safeguards incorporated in this display, observe the following basic rules for its installation, use, and servicing. - Page 7 Important Precautions On Installation Do not allow anything to rest upon or roll over the power cord, and do not place the display where the power cord is subject to damage. Do not use this display near water such as near a bathtub, washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool.
-
Page 8: Connecting The Display
Connecting the Display Before setting up the monitor, ensure that the power to the monitor, the computer system, and other attached devices is turned off. Positioning your display Adjust the position of the panel in various ways for maximum comfort. Tilt Range : -5˚~30˚... -
Page 9: Using The Computer
Connecting the Display Using the Computer Place the monitor in a convenient, well-ventilated location near your computer. To adjust height of your monitor, unlock the stand lock on top of the stand. Connect the signal cable. When attached, tighten the thumbscrews to secure the connection. - Page 10 Connecting the Display To arrange cables in order Press the push button, and pull the stand cover down to separate it from the stand. Stand cover Push button PUSH PUSH After connecting cables, put the stand cover correctly into the holes on the stand.
-
Page 11: Control Panel Functions
Control Panel Functions Front Panel Controls Control Function Power Button Use this button to turn the display on or off. This Indicator lights up green when the display Power Indicator operates normally(On Mode). If the display is in Sleep Mode (Energy Saving), this indicator color changes to amber. - Page 12 Control Panel Functions Control Function Use this button to enter or exit the On Screen Display. MENU Button OSD LOCKED/UNLOCKED This function allows you to lock the current control settings, so that they cannot be inadvertently changed. Press and hold the MENU button for 5 seconds. The message "OSD LOCKED"...
-
Page 13: On Screen Display (Osd) Control Adjustment
On Screen Display (OSD) Control Adjustment Screen Adjustment Making adjustments to the image size, position and operating parameters of the display is quick and easy with the On Screen Display Control system. A short example is given below to familiarize you with the use of the controls. The following section is an outline of the available adjustments and selections you can make using the OSD. - Page 14 On Screen Display(OSD) Selection and Adjustment The following table indicates all the On Screen Display control, adjustment, and setting menus. Main menu Sub-menu Reference BRIGHTNESS To adjust the brightness, PICTURE contrast and gamma of the CONTRAST screen GAMMA PRESET 6500K To customize the color of COLOR 9300K...
-
Page 15: On Screen Display(Osd) Selection And Adjustment
On Screen Display(OSD) Selection and Adjustment You were introduced to the procedure of selecting and adjusting an item using the OSD system. Listed below are the icons, icon names, and icon descriptions of the all items shown on the Menu. NOTE OSD (On Screen Display) menu languages on the monitor may differ from the manual. -
Page 16: To Improve The Clarity And Stability Of The Screen
On Screen Display(OSD) Selection and Adjustment To improve the clarity and stability of the screen OSD Adjust Description T R A C K I N G To minimize any vertical bars or CLOCK stripes visible on the screen background.The horizontal screen size will also change. -
Page 17: Flatron F-Engine
On Screen Display(OSD) Selection and Adjustment The OSD screen will appear when you touch the (-) button on the right side of the monitor. Menu Name Icons Sub-menu Name FLATRON F-ENGINE Screen when applied Screen when not applied When you execute F-ENGINE, two tones will appear on the screen as shown. -
Page 18: Troubleshooting
Troubleshooting Check the following before calling for service. No image appears No image appears Is the power cord of the Check and see if the power cord is connected display connected? properly to the power outlet. Is the power indicator Press the Power button. -
Page 19: Display Image Is Incorrect
Troubleshooting Display image is incorrect Display Position is Press the AUTO button to automatically adjust incorrect. your display image to the ideal setting. If the results are unsatisfactory, adjust the image position using the H position and V position icon in the on screen display. Check Control Panel -->... -
Page 20: Have You Installed The Display Driver
Troubleshooting Have you installed the display driver? Have you installed the Be sure to install the display driver from the display driver? display driver CD (or diskette) that comes with your display. Or, you can also download the driver from our web site: http://www.lge.com. Do you see an Make sure to check if the video card supports "Unrecognized monitor,... -
Page 21: Specifications
Specifications Display 20.1 inches (51.0cm) Flat Panel Active matrix-TFT LCD Anti-Glare coating 20.1 inches viewable 0.255mm pixel pitch Horizontal Freq. Analog : 28 - 83kHz (Automatic) Sync Input Digital : 28 - 83kHz (Automatic) Vertical Freq. 56 - 85Hz (Automatic) Input Form Separate TTL, Positive/Negative Composite TTL Positive/Negative... - Page 22 Specifications Attached( ), Detached ( O ) Tilt/Swivel Stand Attached( ), Detached ( O ) Signal cable Wall-outlet type or PC-outlet type Power cord NOTE Information in this document is subject to change without notice.
-
Page 23: Preset Modes (Resolution)
Specifications Preset Modes (Resolution) Display Modes (Resolution) Horizontal Freq. (kHz) Vertical Freq. (Hz) 31.47 640 x 350 31.47 640 x 480 37.50 640 x 480 43.27 640 x 480 31.47 720 x 400 37.88 800 x 600 46.88 800 x 600 53.67 800 x 600 49.72... - Page 24 Specifications This monitor meets VESA-compliant mounting interface pad specifications. VESA wall mounting Connected to another object (stand type and wall- mounted type. This monitor accepts a VESA- compliant mounting interface pad.- optional) For further information, refer to the VESA Wall Mounting Instruction Guide.
