- Page 1 Thor™ VM2CG Vehicle-Mount Computer Microsoft® Windows® Embedded CE 6 Operating System User's Guide...
- Page 2 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made. The information in this publication does not represent a commitment on the part of HII.
-
Page 3: Table Of Contents
Blue Key Orange Key 95-Key External Keyboard Keyboard Backlight USB Keyboard / Mouse Chapter 2 - Set Up A New Thor VM2CG Hardware Setup Software Setup Quick Mount Smart Dock Preparing the Dock Place the Thor VM2CG in the Dock... - Page 4 2-21 Connecting Bluetooth Devices 2-22 Taskbar Connection Indicator 2-22 Reboot 2-23 Warmboot 2-23 Restart 2-23 Cleaning the Touch Screen 2-24 Startup Help 2-25 Chapter 3 - Connecting Cables to the Thor VM2CG Connect External Keyboard Connect Cable - USB Client...
- Page 5 Thor VM2CG Screen Blanking 3-16 Screen Blanking Box 3-17 Screen Blanking with Switch 3-18 Fuse 3-19 Chapter 4 - Product Agency Compliance - Thor VM2CG Lithium Battery Safety Statement Vehicle Power Supply Connection Safety Statement Chapter 5 - Technical Assistance...
- Page 6 Rev. 01...
-
Page 7: Chapter 1 - Introduction
The dock provides conditioned input power for the Thor VM2CG. Peripheral connections are on the dock. The Thor VM2CG is designed to easily be removed from the dock with a latch on the lower rear of the Thor VM2CG housing. Since the dock remains attached to the vehicle, the Thor VM2CG computer can easily be moved from one vehicle equipped with a Quick Mount Smart Dock to another vehicle equipped with a Quick Mount Smart Dock. -
Page 8: Components
Rev. (a) Components Front View 1. Power Button 2. Speakers 3. Microphone... -
Page 9: Back View Quick Mount Smart Dock
7. Quick Release Handle (On Thor VM2CG) 8. Provision for Padlock (on Thor VM2CG) 9. Provision for Laptop Security Cable (on Thor VM2CG) 10. Power Switch (on Dock) 11. Power Connector (on Dock) 12. Fuse (on Dock) 13. SD Card Access Panel (On Thor VM2CG) 14. -
Page 10: Keyboard Options
Rev. (a) Keyboard Options The Thor VM2CG has an integrated keypad with five programmable keys and an available external keyboard. Integrated Keypad The integrated keypad contains five progammable keys, a blue modifier key and an orange modifier key. Press Orange plus P1-P5 to access P6-P10. -
Page 11: Orange Key
Rev. (a) Orange Key When the Orange LED is illuminated, the programmable keys provide the secondary function. Orange + P1 = P6 Orange + P2 = P7, etc. When the Orange modifier key is active, the LED located next to the key is illuminated. The modifier key remains active until: The Orange modifier key is pressed again, or A non-modifier key is pressed (i.e.: P1-P5), or The Blue modifier key is pressed. -
Page 12: 95-Key External Keyboard
95-Key External Keyboard The Thor VM2CG uses an optional rugged QWERTY 95 key keyboard, designed for ease of use with the Windows CE operating system. The keyboard connects directly to the D9 USB connector on the Thor VM2CG Quick Mount Smart Dock. -
Page 13: Chapter 2 - Set Up A New Thor Vm2Cg
Chapter 2 - Set Up A New Thor VM2CG This page lists a quick outline of the steps you might take when setting up a new Thor VM2CG. More instruction for each step is listed later in this guide. Please refer to the Thor VM2CG Reference Guide for additional information and instruction. -
Page 14: Quick Mount Smart Dock
The Thor VM2CG assembly consists of two parts, the Thor VM2CG computer and the Quick Mount Smart Dock. The Thor VM2CG contains an internal UPS battery that, once fully charged, powers the Thor VM2CG for a minimum of 30 minutes when the unit is not mounted in the dock. -
Page 15: Preparing The Dock
Rev. (a) Preparing the Dock 1. Attach RAM mount to vehicle (see Thor VM2CG Vehicle Mounting Reference Guide). Attach accessories to dock. 3. Attach power cable, 10-60VDC or 72-144VDC. 4. If the tethered I/O port cover is in place, lift the cover to expose the I/O port on the dock. The tether allows the cover to... -
Page 16: Place The Thor Vm2Cg In The Dock
1. Locate the notch on the upper rear of the Thor VM2CG (item A above). 2. Slide this notch over the top lip (C) of the Dock. Slide the Thor VM2CG from side to side on the Dock to make sure it fully engages on the lip of the Dock. -
Page 17: Backlights And Indicators
The display backlight is controlled by power management. When the user activity timer expires, the display backlight is turned off. Different timeouts can be set for when the Thor VM2CG is operating in the following power configuration modes: AC/DC Mode... -
Page 18: Led Functions
Rev. (a) LED Functions System LEDs Connection LEDs Blue LED Orange LED Programmable LED... -
Page 19: System Leds
Rev. (a) System LEDs 1. SYS (System Status) LED 2. UPS (Uninterruptible Power Supply) LED 3. SSD (Solid State Drive) LED SYS (System Status) LED LED Behavior System State Solid Green On but Backlight Off On but Display Off Green blinking very slowly External power present Suspend (1/2 sec. -
Page 20: Ups Status Led
Rev. (a) UPS Status LED The color of the UPS LED identifies the charge level and the behavior of the LED identifies the charging state. Charge Level LED Color Status Green Fully charged (>90%) Less than fully charged, but more than 2 minutes runtime remaining, Out of charging temperature range, Amber... -
Page 21: Connection Leds
Rev. (a) Connection LEDs 1. WWAN LED 2. WiFi LED 3. Bluetooth LED WWAN LED LED Behavior Status Solid Green Indicates a WWAN connection to a network. Indicates no WWAN connection. WiFi LED LED Behavior Status Solid Green Indicates a connection with an IP address to an Access Point Indicates no connection to an Access Point. -
Page 22: Keyboard Leds
Rev. (a) Keyboard LEDs The keyboard LEDs are located near the specified key. Blue LED LED Behavior Status Indicates the Blue modifier key is active. Blue modifier mode is invoked for the next keypress. Pressing the Blue key a second time exits this modifier mode and turns off the LED. -
Page 23: Power Up
Power Up If a USB drive, such as a thumb drive is attached to the Thor VM2CG, the device attempts to boot from the USB drive and cannot. Please remove the USB drive and power up the Thor VM2CG again. -
Page 24: Tapping The Touch Screen With A Stylus
Rev. (a) Tapping the Touch Screen with a Stylus Note: Always use the point of the stylus for tapping or making strokes on the touch screen. Never use an actual pen, pencil, or sharp/abrasive object to write on the touch screen. Hold the stylus as if it were a pen or pencil. -
Page 25: Set Power Scheme Timers
Shutdown orderly shutdown. UPS Power Scheme This power scheme is automatically selected any time the Thor VM2CG is operating from UPS power. This scheme overrides any user selected power configuration mode. Switch state to User Idle Default is After 30 seconds... -
Page 26: Ignition Control Power Scheme, Ignition Off
System Idle timer has expired. When the User Idle timer is set to “Never”, the power scheme timers never place the Thor VM2CG in User Idle, System Idle, Suspend or Shutdown modes (even when the Thor VM2CG is idle). -
Page 27: Adjust Speaker Volume
You can also select / deselect sounds for key clicks and screen taps and whether each is loud or soft. As the volume scrollbar is moved between Loud and Soft, the Thor VM2CG emits a tone each time the volume increases or decreases in decibel range. -
Page 28: Set Date And Time Zone
Tap Start > Settings > Control Panel > Date/Time icon or tap the Date/Time in the taskbar. Set Date, Time, Time Zone, and assign a Daylight Savings location on the Thor VM2CG after a warm boot or anytime. There is very little functional change from standard desktop PC Date/Time Properties options. Adjust the settings and tap the OK button or the Apply button to save changes to the registry. -
Page 29: Touch Screen
Follow the instructions on the screen. Tap the OK button when complete, if necessary. Apply the Touch Screen Protective Film The Thor VM2CG touch screen protective film is shipped in packs of 10. The protective film is flexible and treated with an anti- glare coating on the outer surface. -
Page 30: Removal
2. Pull the release tab to separate the protective backing from the rear of the protective film. Avoid touching the rear side of the protective film while removing the liner. 3. Place the rear side of the protective film against the Thor VM2CG display, roughly centering the protective film over the display. -
Page 31: Using The Input Panel / Virtual Keyboard
Rev. (a) Using the Input Panel / Virtual Keyboard The virtual keyboard is always available when needed e.g., text entry. Place the cursor in the text entry field and, using the stylus: Tap the Shift key to type one capital letter. Tap the CAPS key to type all capital letters. -
Page 32: Setup Terminal Emulation Parameters
Rev. (a) Setup Terminal Emulation Parameters Before you make a host connection, you will, at a minimum, need to know: the alias name or IP address (Host Address) and the port number (Telnet Port) of the host system to properly set up your host session. 1. -
Page 33: Using The Applock Switchpad
Click the switchpad icon in the taskbar. A checkmark on the switchpad menu indicates applications currently active or available for Launching by the Thor VM2CG user. When Keyboard, on the Switchpad Menu, is selected, the default input method (Input Panel, Transcriber, or custom input method) is activated. -
Page 34: Connecting Bluetooth Devices
The system administrator has also assigned a Computer Friendly Name using EZPair for the Thor VM2CG. To connect Bluetooth devices, the Thor VM2CG should be as close as possible and in direct line of sight (distances up to 32.8 feet or 10 meters) with the targeted Bluetooth device during the discovery and pairing process. -
Page 35: Reboot
Using the Start menu, select Start > Run and type WARMBOOT in the text box. Press Enter. The Thor VM2CG immediately warmboots. The WARMBOOT text command is not case-sensitive. Use the P1 + P5 + Orange keypress sequence to reboot the Thor VM2CG. The keys may be pressed in sequence; they do not need to be held down simultaneously. -
Page 36: Cleaning The Touch Screen
Rev. (a) Cleaning the Touch Screen Note: These instructions are for components made of glass. If there is a removable protective film sheet on the display, remove the film sheet before cleaning the screen. Keep fingers and rough or sharp objects away from the bar code reader scanning aperture and the mobile device touch screen. If the glass becomes soiled or smudged, clean only with a standard household cleaner such as Windex®... -
Page 37: Startup Help
There may be slight delays while the wireless client connects to the network, authorization Thor VM2CG seems to lockup for voice-enabled applications complete, and Bluetooth relationships establish or re-estab- as soon as it is rebooted. lish. When an application begins, the Thor VM2CG is ready for use. 2-25... - Page 38 Rev. 01 2-26...
-
Page 39: Chapter 3 - Connecting Cables To The Thor Vm2Cg
Chapter 3 - Connecting Cables to the Thor VM2CG Connect External Keyboard The Thor VM2CG supports an optional external 95-key USB keyboard. The external keyboard has a D9 connector to connect to the USB port on the Thor VM2CG Quick Mount Smart Dock. -
Page 40: Connect Cable - Usb Client
Rev. (a) Connect Cable - USB Client USB-C Cable Assembly 1. D9 Connector 2. USB Client Connector (for connecting to a USB host) 3. USB Host Connector (for connecting to a USB device) 1. Seat the cable end connector (connector 1) firmly over the USB Cable Connector on the Quick Mount Smart Dock. 2. -
Page 41: Connect Cable - Serial
1. The scanner cable is attached to either the COM1 or COM2 port on the Quick Mount Smart Dock. 2. Connect the serial cable for the scanner as directed above. 3. When the Thor VM2CG is powered on, it provides power to the serial scanner. -
Page 42: Connecting The Headset Cable
2. Tighten the thumbscrews in a clockwise direction. Do not over tighten. 3. Slide the cable ends together until they click shut. Do not twist or bend the connectors. The Thor VM2CG internal microphone and speakers are automatically disabled when the headset is connected. -
Page 43: Adjust Headset / Microphone And Secure Cable
The headset consists of an earpiece, a microphone, a clothing clip and a cable. The headset attaches to the audio cable end of the voice cable which attaches to the Thor VM2CG. Align the audio connector and the headset quick connect cable end. Firmly push the cable ends together until they click and lock in place. -
Page 44: Connecting An Ac/Dc Power Supply
15 Amp overcurrent protection (10 Amp for 230V circuits). 1. Turn the Thor VM2CG off. 2. Connect the detachable cordset provided by Honeywell (US only, all others must provide their own cable) to the external power supply (IEC 320 connector). -
Page 45: Connecting Vehicle Power
Correct electrical polarity is required for safe and proper installation. See the figures below for additional wire color- coding specifics. The Thor VM2CG DC input wires (Red DC+ and Black DC-) and the Blue ignition input wire are galvanically isolated. The Green ground input is used for electrostatic discharge (ESD) protection. -
Page 46: Connect Vehicle 10-60Vdc
Rev. (a) Connect Vehicle 10-60VDC 1. The Thor VM2CG must not be mounted in the Quick Mount Smart Dock. The power switch on the Dock must be turned Off. The power cable must be UNPLUGGED from the Dock. 2. While observing the fuse requirements specified above, connect the power cable as close as possible to the actual battery terminals of the vehicle (if using unswitched power). -
Page 47: Ignition Control
Thor VM2CG ignition signal wire can be connected (less than 1mA over input voltage range) to the switched circuit to allow the Thor VM2CG to power on when the vehicle is switched on. When the vehicle is switched off, more aggressive power management settings are enabled to preserve the vehicle battery charge. -
Page 48: Auto-On Control
On position. The Ignition wire is not used and should be left disconnected. 1. Existing Circuitry on Vehicle 2. Forklift Battery 9. Thor VM2CG Computer in Quick Mount Smart Dock 3. Main Switch 10. COM1 or COM2 Connector on Dock 4. -
Page 49: Manual Control
1. Existing Circuitry on Vehicle 8. Blue Wire (not connected) 2. Forklift Battery 9. Thor VM2CG Computer in Quick Mount Smart Dock 3. Main Switch 10. COM1 or COM2 Connector on Dock 4. 10A Slow blow Fuse close to power source 11. -
Page 50: Vx6 / Vx7 Adapter Cable
VX6 / VX7 Adapter Cable An adapter cable is available to attach the Thor VM2CG to a vehicle previously equipped with a VX6/VX7 DC power cable. The adapter cable has a 5-pin connector to match with the VX6/VX7 power supply cable on one end and a 6-pin connector to match to the Thor VM2CG on the other. -
Page 51: Vehicle 72-144Vdc Power Connection
Rev. (a) Vehicle 72-144VDC Power Connection This option requires DC/DC external power supply Part no. VX89303PWRSPLY. Caution: For installation by trained service personnel only. Caution: For proper and safe installation, the input power cable must be connected to a fused circuit on the vehicle. This fused circuit requires a 10 Amp maximum time delay (slow blow) high interrupting rating fuse. -
Page 52: Connect Vehicle 72-144Vdc
Green ground input is used for electrostatic discharge (ESD) protection. Connect Vehicle 72-144VDC 1. The Thor VM2CG must not be mounted in the Quick Mount Smart Dock. The power switch on the Dock must be turned Off. The power cable must be UNPLUGGED from the Dock. -
Page 53: Wiring Diagram
Once installation is complete, remember to start the Thor VM2CG and configure the Auto-On behavior. Please see the Thor VM2CG Reference Guide for details: Start > Settings > Control Panel > Options > Misc tab. -
Page 54: Thor Vm2Cg Screen Blanking
COM port on the Thor VM2CG. A user-supplied cable can also be used. Please refer to the Thor VM2CG Reference Guide for specifications on building a serial cable for the screen blanking feature and Screen Control (in the Windows Control Panel) to configure the Thor VM2CG for screen blanking. -
Page 55: Screen Blanking Box
Rev. (a) Screen Blanking Box Screen Blanking Box Connection Terminal Input from vehicle motion sensing circuitry. 12-xxV Please refer to label on Screen Blanking Box for allowable voltage input range. DC - These two terminals are for a user provided serial cable. The cable must be constructed so that Pin 7 (RTS) connects to switched side of the connection and Pin 8 (CTS) connects to the other terminal. -
Page 56: Screen Blanking With Switch
Rev. (a) Screen Blanking with Switch In applications where it is impractical to use the screen blanking box due to vehicle voltage or lack of a motion sensing signal, screen blanking can be controlled via a user supplied switch or relay that provides an electrical conductive connection on vehicle motion. -
Page 57: Fuse
Fuse The Thor VM2CG uses an 8A time delay (slow blow), fuse that is externally accessible and user replaceable. The fuse is located on the back of the Quick Mount Smart Dock. The fuse is accessed by unscrewing the cap as indicated below. - Page 58 Rev. 01 3-20...
-
Page 59: Chapter 4 - Product Agency Compliance - Thor Vm2Cg
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. Consult the dealer or an experienced radio/TV technician for help. Notice Changes or modifications made to this equipment not expressly approved by Honeywell may void the FCC authorization to operate this equipment. EMC Directive Requirements This is a Class B product. - Page 60 Li-Ion Battery When disposing of the Thor VM2CG UPS battery, the following precautions should be observed: The battery should be disposed of properly. The battery should not be disassembled or crushed. The battery should not be heated above 212°F (100°C) or incinerated.
- Page 61 Rev. (a) Waste Electrical and Electronic Equipment (WEEE) Important: This symbol is placed on the product to remind users to dispose of Waste Electrical and Electronic Equipment (WEEE) appropriately, per Directive 2002-96-EC. In most areas, this product can be recycled, reclaimed and re- used when properly discarded.
- Page 62 Rev. (a) R&TTE Directive Requirements This device bearing the CE marking is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC. This device complies with the following harmonized European Standards: Health: EN63211:2008 Safety: EN60950-1:2006 + A1:2010 + A11:2009 + A12:2011 EMC: EN301 489-1 V1.9.2:2011, EN301 489-17 V2.1.1:2009 Radio: EN300 328 V1.7.1:2006 The following CE marking is valid for EU harmonized telecommunications products.
-
Page 63: Lithium Battery Safety Statement
Rev. (a) Lithium Battery Safety Statement Caution: Lithium battery inside. Danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type recommended by battery manufacturer. (US) Attention: Contient une pile de lithium. Risque d’explosion dans le cas où la pile ne serait pas correctement remplacée. Remplacer uniquement avec une pile semblable ou equivalente au type de pile recommandé... - Page 64 Rev. (a) Lithium Battery Safety Statement, continued Legend: Chinese – CN; Danish – DK; Dutch – NL; English – US; Finnish – FI; French- - FR; German – DE; Greek – GR; Italian – IT; Japanese – JP; Korean – KR; Norwegian – NO; Portuguese – PT; Spanish – ES; Swedish – SE; Turkish – TR.
-
Page 65: Vehicle Power Supply Connection Safety Statement
Rev. (a) Vehicle Power Supply Connection Safety Statement Vehicle Power Supply Connection: If the supply connection is made directly to the battery, a 10A slow-blow fuse should be installed in the positive lead within 5 inches (12.7 cm.) of the battery positive (+) terminal. (US) Raccordement de l’alimentation du véhicule Si l’alimentation est raccordée directement à... - Page 66 Rev. 01...
-
Page 67: Chapter 5 - Technical Assistance
Limited Warranty Honeywell International Inc. ("HII") warrants its products to be free from defects in materials and workmanship and to conform to HII’s published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any HII product which is (i) improperly installed or used;... - Page 68 The duration of the limited warranty for the Thor VM2CG is 1 year. The duration of the limited warranty for the Thor VM2CG Quick Mount Smart Dock is 1 year. The duration of the limited warranty for the Thor VM2CG Vehicle Mount Assembly is 1 year.
- Page 69 Rev. (a)
- Page 70 Honeywell Scanning & Mobility 9680 Old Bailes Road Fort Mill, SC 29707 www.honeywellaidc.com E-EQ-VM2CEOGWW Rev (a) 1/13...
