Summary of Contents for Westinghouse DVD Combo

  • Page 2: Table Of Contents

    IMPORTANT INFORMATION...2 1. WARNING...2 2. SAFETY GUIDELINES...3 3. IMPORTANT SAFETY INSTRUCTIONS...4 4. ANTENNA INSTALLATION SAFETY...6 5. CLEANING THE LCD TV...6 6. DISC...7 P R E PA R AT I O N ............9 1 .

  • Page 3: Important Information

    IMPORTANT INFORMATION 1. WARNING WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR MOISTURE. The lightning flash with arrow-head symbol, CAUTION within an quilateral triangle, is intended to alert the user to the presence of uninsulated RISK OF ELECTRIC SHOCK “dangerous voltage”...

  • Page 4: Safety Guidelines

    2. SAFETY GUIDELINES WARNING: This device must be operated with the original power supply. The power supply outlet should be located near the LCD TV and should be easily accessible. CAUTION: Always use the appropriate AC cord that is certifi ed for your specifi c country. Some examples are listed below: USA...UL Japan ...

  • Page 5: Important Safety Instructions

    IMPORTANT INFORMATION 3. IMPORTANT SAFETY INSTRUCTIONS Follow and obey all warnings and instructions marked on the LCD TV. For your safety, please read all the safety and operating instructions before you operate the LCD TV. Keep this user’s manual for future reference. (1) Read these instructions.
  • Page 6 ・Do not attempt repairs yourself. Your warranty does not cover repairs or attempted repairsb by anyone not authorized by Vivitek. ・If your LCD TV will not be used for a long period of time, unplug the LCD TV and remove the batteries from the remote control.

  • Page 7: Antenna Installation Safety

    IMPORTANT INFORMATION 4. ANTENNA INSTALLATION SAFETY •Outdoor Antenna Grounding If an outside antenna or cable system is connected to the LCD TV, be sure the antenna or cable system is grounded to prevent voltage surges and built-up static charges. Article 810 of the National Electrical Code, ANS/NFPA 70, provides information on proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

  • Page 8: Disc

    6. DISC 6-1 On handling discs • Be sure to hold the edge of disc. Do not touch the surface of the disc. • Do not attach paper or tape to discs. 6-2 On cleaning discs • Wipe the disc with a clean, dry cloth from the center outward toward the edges. •...
  • Page 9 IMPORTANT INFORMATION 6-5 Region management information The region number of this unit is 1. If region numbers, which stand for their playable area, are printed on your DVD video disc and you do not fi nd " 1 " or " ALL " , disc playback will not be allowed by the player.

  • Page 10: Preparation

    PREPARATION 1. PACKAGE CONTENTS 26"/32” LCD TV/DVD COMBINATION Remote Control x1 (with 2 pcs AAA batteries) User manual x1 Power cord x1 User manual Quick Connect Guide x1 Warranty card x1 Quick Connect Guide Warranty card...

  • Page 11: Tv Controls

    PREPARATION 2. TV CONTROLS 1. MENU Turn the Menu ON/OFF 2. VOL + / - Adjust (VOL + / -) sound volume or adjust a highlighted control while in the Adjust (CH + / -) channel when input is TV or adjust a highlight control while in the 3.

  • Page 12: Terminals

    3. TERMINALS PREPARATION 1. VGA Audio IN Connect to the Audio out (Green) from a computer. 2. VGA Using a 15-pin VGA cable, connect to a computer or other device with a VGA output. 3. YPbPr1 Input Connect an external video device with component output to these jacks.

  • Page 13: Remote Control

    PREPARATION 4. REMOTE CONTROL Remote Control 1.POWER Switch TV power On/Off. 2.Mute Mutes the sound. 3.DVD Eject Eject the DVD disc. 4.PC Select VGA source input. 5.DVD Select DVD source input. 6.TV Select TV (NTSC/ATSC) source input. HDMI Select HDMI 1/HDMI 2 source input. VIDEO Select Video/S-video input.
  • Page 14 PREPARATION Remote Control 16.Vol +/- Volume Up / Down adjustment. 17.Last CH Switch to previous channel. 18.Menu Display the menu screen. 19.▲/▼/◄/► Selects a desired item on the screen. 20.Enter Execute a command. 21.INFO Display the source and channel information. Guide Show program information of current channel.

  • Page 15: Installation

    INSTALLATION 1. INSERT BATTERIES IN THE REMOTE CONTROL (1) Remove the battery cover. (2) Insert the batteries corresponding to the (+) and (−) marks on the battery compartment. (3) Re-attach the battery cover. CAUTION: (1) Only use AAA batteries. (2) Do not mix new and old batteries. This may result in cracking or leakage, which may pose a fi re risk or lead to personal injury.

  • Page 16: Antenna Connection

    2. ANTENNA CONNECTION 2-1 Outdoor Antenna Connection Cable TV lead-in VHF, UHF or VHF/UHF combination antenna 75 ohm coaxial cable (round) 300 ohm twin-lead (flat) Separate VHF/UHF Antenna VHF ANTENNA UHF ANTENNA 300 ohm twin-lead 300 ohm twin-lead 75 ohm coaxial cable ►Notice: F-type connector should be fi...

  • Page 17: External Device Connections

    INSTALLATION 3. EXTERNAL DEVICE CONNECTIONS You can enjoy picture and sound by connecting a DVD or video game system to the terminals located on the rear of the LCD TV set. When connecting an external device, turn off the power of the LCD TV set fi rst to prevent any possible damage.
  • Page 18 Audio/Video cable Video Audio (L) Audio (R) S-Video S-Video cable Home video game system Camcorder * If your external device has an S-video terminal, S-VIDEO connection is recommended. Antenna cable Cable system or antenna • For the cable, use a commercially available audio/video cable. •...

  • Page 19: Power Connection

    INSTALLATION 4. POWER CONNECTION Connect the power cord to the DVD combo LCD TV then to a proper AC outlet. IMPORTANT: The power input voltage is 120VAC, 60 Hz ONLY, Before beginning, make sure all devices are turned off. 5. INITIAL SETUP When you setup the LCD TV for the fi...
  • Page 20 INSTALLATION Setup Wizard (1) Press "▲ / ▼ " to select the language for menu and message showing on your TV, press Enter key to exit Setup Wizard menu. Press ENTER to access Time Zone settings. Press " " to select on your time zone. (3) Press ENTER to access Daylight Saving screen.
  • Page 21 INSTALLATION (4) Press ENTER to access RF Input Source screen. Press " " to select the source for your TV signal. ►Note: Select STD(Standard) for majority of cable systems. (5) Press ENTER to start the Channel Scan. Scanning channel searches available digital (HDTV) and analog (SDTV) channels of selected TV source, the numbers of available channels will show on the OSD menu.

  • Page 22: Basic Operation

    1.TURNING ON AND OFF THE POWER • Turning On the Power Press on the TV or on the remote control. ・POWER indicator (Blue): The TV is on. • Turning Off the Power Press on the TV or on the remote control. ・The TV enters standby mode and the image on the screen disappaers.

  • Page 23: Changing Channels

    BASIC OPERATION 3.CHANGING CHANNELS ・You can select channels using Channel Select Using Channel Select (0-9, • (DOT), ENT) • When selecting the channel using Channel Select, complete input of the channel number by holding down the button for the last digit for a moment. •To select a 1- or 2-digit channel number (e.g., Channel 5): Complete the following procedure within 4 seconds.

  • Page 24: Selecting Menu Items

    5.SELECTING MENU ITEMS The menus can be used to adjust the various settings of the LCD TV set. Select the desired menu item by following the steps below. ►NOTE: •The items displayed differ depending on the setting conditions. •The item selected is displayed in blue. •Last setting will be saved in memory.

  • Page 25: Menu Operation

    MENU OPERATION •Menu Setting screens For details of each menu item, refer to the page number indicated below. ►NOTE: •The illustrations and on-screen displays in this manual are for explanation purposes and may vary slightly from the actual appearance. •Depending on the setting condition, such source input , it may not be possible to adjust or set some items.

  • Page 26: Video

    1. VIDEO •You can adjust the Video to your preference with the following Video settings. 1.Press MENU on the remote control to display the menu screen. 2.Press ► / ▲ / ▼ to select the Video menu. 3.Press Enter to enter the Video meun list. 4.Press ▲...

  • Page 27: Preset Mode

    MENU OPERATION 1-1 Preset Mode: Upon the watching program, you can select an appropriate video setting with the preset mode. Selected Item Movie Sports Game Enhanced User 1-2 Video Settings: The Video Settings sub-menu allows adjustments to display settings such as brightness, contrast, saturation, hue, sharpness and backlight level.
  • Page 28 1-3 Screen Size: The Screen Size sub-menu option adjusts the manner in which source signal formats are displayed on the screen. 1-4 Color Temp Selected Item Cool Neutral Warm User MENU OPERATION *You can also use on your remote control for this function. Description White with bluish tone Neutral white...
  • Page 29 MENU OPERATION 1-5 VGA Setting: Adjust VGA Setting of your TV (Horizontal, Vertical, Phase, Auto Sync). ►Note: •Make sure to select the input signal from the following PC Compatibility Chart before a PC. Selected Item Move the image Horizontal position Horizontal to the left.

  • Page 30: Audio

    MENU OPERATION 1-6 Video Reset : Reset all Video sub-menu options to the factory defaults. 2. AUDIO 2-1 Bass, Treble & Balance: Use ▲ / ▼ / ◄ / ► to select or adjust your favorite bass, treble and balance settings.

  • Page 31: Analog Preference

    MENU OPERATION 2-2 Optical out (SPDIF): Select the audio format for Optical Out (AC3, PCM). Selected Item Select surround audio format Select stereo audio format ►Note: •Optical Out (SPDIF) is only available for DVD or when receiving digital broadcasting. 2-3 Analog Preference: The Analog Preference sub-menu sets the audio output to the desired listening preference.
  • Page 32 2-4 Digital Preference: Select the digital Broadcasting preferred language (English, French, Spanish). Selected Item English Set Digital Broadcasting preferred language to English French Set Digital Broadcasting preferred language to French Spanish Set Digital Broadcasting preferred language to Spanish ►Note: •Digital Preference is only available when receiving digital broadcasting. 2-5 TV Speaker The TV Speaker sub-menu sets the speaker output preference.

  • Page 33: Audio Only

    MENU OPERATION 2-6 Audio Only. Audio Only is a listening mode by turning off the LCD backlight and allowing the current input’s audio to remain “on” for listening. You can enable Audio Only mode from OSD menu. On: enable Audio Only mode. When Audio Only is on, LED light shows blue.

  • Page 34: Channels

    3. CHANNELS 3-1 Channel List The Channel List sub-menu defi nes which channels are available for viewing when utilizing the analog/digital tuner. Selected Item Check All Select all channels from Master Channel List Uncheck All Unselect all channels from Master Channel List Analog Only Select all analog channels from Master Channel List Digital Only...
  • Page 35 MENU OPERATION 3-2 Favorites The Favorites sub-menu adds or subtracts channels from the favorite channels list. Channels added to the list can be accessed by pressing the FAV A,FAV B or FAV C button on the remote control instead of directly entering the channel number.

  • Page 36: Scan Channels

    MENU OPERATION 3-3 Scan Channels The Scan Channels sub-menu automatically scans for available channels based upon the source input selected. If scanning for OTA (over the air) channels, select Antenna as the input source. If scanning for Cable channels, select Cable as the input source After selecting the input source, activate the Scan button to initiate scanning or cancel the scan function by selecting Stop Scan.
  • Page 37 MENU OPERATION 3-4 Find Channel The Find Channel sub-menu allows for manual addition of user specifi ed channels. 3-5 Edit Channel Name The Channel Name Edit sub-menu allows for modification of the friendly name of any channel within the channels list. To modify a channel name, select the Channel Name Edit sub-menu, scroll through the list of available channels and press the ENTER button to modify the desired channel name.

  • Page 38: Locks

    MENU OPERATION 4. LOCKS The Locks menu provides the ability to set ratings that block programming that may be inappropriate for the viewing audience such as programs and movies that contain violence, adult language or nudity. A personal identifi cation number (PIN) will need to be created the fi rst time the Locks menu is accessed. Enter the new PIN using the remote control, then confi...

  • Page 39: Rating Locks

    MENU OPERATION 4-1 Rating Locks The Ratings Locks sub-menu blocks programming based upon the TV or Movie rating for the country specifi ed. ►Note: The Ratings Locks are only valid for the North American market. ►Note: The Ratings Locks menu is only applicable when the input source is the TV tuner. USA TV Ratings as determined by the FCC.
  • Page 40 Canadian (French) ratings as defi ned by the Regie du Cinema. Canadian (English) ratings as defi ned by the Regie du Cinema. Block Unrated Shows Selected Item MENU OPERATION General programming, suitable for all audiences 8 ans+ Children eight years and older 13 ans+ Viewers 13 years and older 16 ans+...

  • Page 41: Channel Locks

    MENU OPERATION 4-2 Channel Locks The Channel Locks sub-menu provides individual channel blocking regardless of any ratings lock in place. 4-3 Front Panel Lock This important feature is for use in an environment where the display’s owner does not want the conditions of the display changed.You can enable or disable it from OSD menu.

  • Page 42: Dvd Locks

    4-5 DVD Locks Set restriction of DVD programs with Rating Locks. Selected Item View All No Lock. Kid Safe Just release the content appropriate for children under 12 No Adult Just lock the content appropriate for adult. 4-6 Reset Locks Reset all channel and rating locks to the factory defaults.

  • Page 43: Settings

    MENU OPERATION 5. SETTINGS 5-1 Menu Language The Menu Language sub-menu toggles the default language for the on-screen display menus. 5-2 Date & Time Set the current time and date. 1.Press ► to set the current time and date on TV.
  • Page 44 MENU OPERATION 2. Press ▲ to select “Auto-Update Time”. 3.Press ENTER to cancel the check. Note:When you check the “Auto-Update Time”, you cannot adjust the date and time. 4. Press ▲ to select “Today’s Date”. 5. Press ENTER to adjust the “Today’s Date”. 6.
  • Page 45 MENU OPERATION 16. Press▼ to select “Time Zone”. 17. Press ENTER to list to Time Zone. 18. Press ▲ or ▼ to select the Time Zone you stay. 19. Press ENTER to exit. 20. Press▼ to select “Daylight Savings Observed”. 21.

  • Page 46: Weekly Timers

    5-3 Weekly Timers This function allows you to set the TV to turn on and off at scheduled time. You can set two different timers. MENU OPERATION 1.Press ▲ to choose Timer. 2.Press ENTER to select “Timer 1” or “Timer 2”. 3.Press ▼...

  • Page 47: Closed Captions

    MENU OPERATION 5-4 Sleep Timer This function allows you to set the sleep time to automatically turn off the TV. Selected item 15 minutes 30 minutes 45 minutes 60 minutes 90 minutes 5-5 Closed Captions Closed Captions provide on-screen text in conjunction with the audio program for those who are deaf or hard of hearing.
  • Page 48 MENU OPERATION 5-5-2 Basic Selection The Basic Selection sub-menu confi gures the video frame fi eld setting for closed captioning content. Most closed caption content can be found within CC1. 5-5-3 Advanced Selection The Advanced Selection sub-menu provides enhanced closed caption options for the CC experience. ►Note: •Advanced Selection is only available when receiving digital broadcasting.

  • Page 49: Input Labels

    MENU OPERATION 5-5-5 Caption preference The Caption Preference sub-menu sets the default caption. If Automatic, the caption is determined by the broadcast. 5-5-6 Reset CC Reset all Closed Caption settings to the factory defaults. 5-6 Input labels The Input Labels sub-menu allows for modifi cation of the friendly name for the input port list. To modify an input port label, select the Input Labels sub-menu, scroll through the list of available inputs, choose one of the pre- selected input port descriptions or create a custom label.

  • Page 50: Power Management

    5-7 Autosource If the "Autosource" is ON. once you plug in or power on a new source, the TV will detect it and automatically switch to the new input. 5-8 Power Management The Power Management sub-menu confi gures the power state of the LCD-TV when turned off. Selected Item Normal The TV into a low power standby state.
  • Page 51 MENU OPERATION 5-10 Power LED Set LED indicator on bezel to On or OFF 5-11 DVD Restoration DVD Restoration Mode is a functional setting that restores the anamorphic DVD to its original intended viewing mode. This is done by determining the fl ag setting and adjusting Standard Aspect Mode accordingly. When the fl...

  • Page 52: System Info

    MENU OPERATION 5-12 System Info The System Info sub-menu provides detailed information about the LCD-TV and its operating status. Information provided includes the system fi rmware version as well as the current input source and signal types being decoded. 5-13 Reset All Reset all settings back to factory defaults.

  • Page 53: Advanced

    MENU OPERATION 6.ADVANCED You can adjust the video to your preference with the following settings. 6-1 Cinemotion Detect a fi lm-based source (originally encoded at 24 frames/second) and then recreate each still fi lm frame to cinematic picture quality (ON, OFF). Selected Item Description Set Cinemotion to ON...

  • Page 54: Noise Reduction

    6-2 3D Comb Filter Select 3D comb fi lter to Off,Low,Medium,High. 6-3 Deinterlaced Select image display to Progressive or Interlace (ON, OFF). 6-4 Noise Reduction Reduce noise from TV screen.(Off,Low,Medium,High ). MENU OPERATION Selected Item Description Set 3D Comb Filter to Off Set 3D Comb Filter to Low level Medium Set 3D Comb Filter to Medium level...
  • Page 55 MENU OPERATION 6-5 Brightness Selected Item Brightness 6-6 Contrast Selected Item Contrast 6-7 Saturation Selected Item Saturation 6-8 Hue Selected Item 6-9 Sharpness Selected Item Sharpness 6-10 Backlight Selected Item Backlight 6-11 User Color Temp ◄button For less brightness ◄button For less contrast ◄button For less color intensity...

  • Page 56: Guide

    MENU OPERATION 6-12 Reset Advanced Reset Advanced Settings to factory preset values. 7.GUIDE The Guide menu displays program information for the current channel such as signal strength, audio/video signal type, channel number, V-Chip support, closed captioning status and program title. ►Note: The Guide menu is only applicable when viewing digital television through the TV tuner.

  • Page 57: Play Disc

    PLAYING A DISC 1.PLAYBACK PROCEDURE (1) Press POWER on the unit or on the remote control to turn on the unit. ・Every time you press POWER, the TV/DVD will starts from previous mode. (2) Press DVD on the remote control to select DVD mode. ・The DVD startup screen will appear on the screen.

  • Page 58: Special Playback

    2.SPECIAL PLAYBACK (1).Fast Forward Playback Press ► ► during normal playback. Each press of ► ► will increase the speed of the search (x 2), (x 4), (x 8), (x 20). To resume normal playback, press ► to play. (2).Fast Reverse Press◄...

  • Page 59: Dvd Settings

    PLAYING A DISC 3.DVD SETTINGS Under DVD source, press Setup on remote control if you want to change the default DVD settings. Selected item Down Mix Select DVD Down Mix to Stereo or LT/RT. Repeat Press ENTER repeatedly to set “Chapter”, “Title”, “All” or “OFF”. ON: 1.Skip the meun screen to playback.It will be convenient for Demo Mode OFF: Turn off “Demo Mode”...

  • Page 60: Mp3/Wma/Jpeg Cd Playback

    This TV/DVD can playback the MP3/WMA/JPEG-data which has been recorded on CD-R or CD-RW. To produce the MP3/WMA/JPEG-data, you need a Windows-PC with CD-R/RW drive and a MP3/WMA/JPEG-encoding Software (not supplied). The Apple-HFS-System cannot be played. ►Note: This TV/DVD requires discs/recordings to meet certain technical standards in order to achieve optimal playback quality.

  • Page 61: Mp3/Mwa Cd Playback

    MP3/WMA/JPEG CD Playback Standard, sampling frequency, and the bit rate: MP3 CD MPEG-1 Audio 32kHz, 44.1kHz, 48kHz 32kbps ~ 320 kbps (constant bit rate or variable bit rate) The recommend recording setting for a high-quality sound is 44.1kHz of sampling frequency and 128kbps of constant bit rate.

  • Page 62: Specifications

    Model Name Type Panel Color Viewing Angles Input Signal Video/Audio Output Signal TV Compatibility The best TVs use the best technology: ATI inside your TV for The Ultimate Visual Experience™. Video Engine Your new Westinghouse TV is powered by ATI’s Xilleon™ image processing chip for the true high defi...
  • Page 63 SPECIFICATIONS Model Name Type Panel Color Viewing Angles Input Signal Video/Audio Output Signal TV Compatibility The best TVs use the best technology: ATI inside your TV for The Ultimate Visual Experience™. Video Engine Your new Westinghouse TV is powered by ATI’s Xilleon™ image processing chip for the true high defi...

  • Page 64: Troubleshooting

    •Power is ON but No Screen Image ・Make sure the video cable connected to the DVD combo LCD TV is tightly secured to the video output port on the back of the computer. If the other end of the video cable is not attached properly to the DVD combo LCD TV, secure it tightly.

  • Page 65: Appendix

    APPENDIX APPENDIX A: Remove the base To lay the front bezel down on a soft and clear area, and please be sure that there is no any foreign object Remove the four screws as shown in thefollowing illustration. ►Note: ・Be sure to turn off the LCD TV and disconnect all cables before detaching the base. ・The LCD TV has VESAÒ...
