- Page 1 SP1090 Cordless 900MHZ Speaker System User’s Manual Please read before using the equipment...
- Page 2 INTRODUCTION This 900 MHz wireless speaker system uses latest wireless technology that enables you to enjoy music and TV sound anywhere inside or outside your home. You can simply connect the system to any audio source such as Radio, TV, VCR, Hi-Fi and CD/MP3/VCD/DVD player.
-
Page 3: Component Identification
COMPONENT IDENTIFICATION TRANSMITTER Antenna Power on indicator (Blue) SPEAKER RECEIVERS... -
Page 4: Remote Control
REMOTE CONTROL INSTALLATION TRANSMITTER 1. Insert the antenna tube into the antenna wire. 2. Connect the supplied AC/DC power adaptor to an electrical wall outlet. 3. Plug the AC/DC power adaptor in the DC jack located on the rear of the transmitter. - Page 5 SPEAKER RECEIVERS 1. Insert 6 pieces ‘C’ size ALKALINE battery into the battery compartment with correct polarity at the bottom of the speakers (batteries not included in the package) or connect the 12V power adaptor to the DC input jack on the bottom of each speaker, then plug it to the wall AC outlet.
-
Page 6: Remote Control Unit
REMOTE CONTROL UNIT 1. Remove the battery cover at the rear of the remote control unit and insert 2 pieces “AAA” size battery provided into the battery compartment with the correct polarity. 2. Place back the cover and close the battery compartment. OPERATION 1. - Page 7 b) Whenever you find frequency jam, move your channel switch from one channel to the other channel (there are two channels for selection) on the transmitter, and then press the “AUTO-TUNE” button again. 5. You should now be able to place the speakers freely from room to room without disruption.
- Page 8 no/weak operation input signal from audio source for 4 minutes. In other words, if the signal comes back, the transmitter will work again automatically. b) Press the ON/OFF button to turn off the speaker and the LED light goes off, or simply press the ON/OFF button on the remote control unit. If you use the remote control unit to turn off the speaker, the speaker will be at stand-by mode for 5 minutes and the LED will be changed from blue to green.
-
Page 9: Technical Specifications
TECHNICAL SPECIFICATIONS Transmission Mode UHF MONO Carrier Frequency 900 MHz Operation Voltage Transmitter, DC 12.5V 150mA Speaker, 6 X ‘C’ size Alkaline batteries or DC 12V 1.7A adaptor Remote Control Unit, 2 X ‘AAA’ size batteries Frequency Response 40Hz – 12KHz Distortion 1.5% S/N Ratio...
