FOR YOUR RECORDS. . .
DATE PURCHASED ____________________________________
DEALER __________________________________________________
SERIAL # _____________________________________________
* NOTE: Please complete and return your warranty card within ten (10) days.
"It delivered room-shaking bass and dramatically demonstrated the
effectiveness of a single subwoofer placed to one side of the room."
- Julian Hirsh
Stereo Review, January 1997
"In general, the Velodyne could play slightly louder, and often
cleaner, than the Sunfire."
-D.B. Keele, Jr.
Audio/June 1998
"How do they get this kind of bass out of such a tiny box? Deep, tight,
tuneful and loud enough to rattle pictures on the wall--this is serious
subwoofing."
-Robert Deutsch
Stereophile Guide to Home Theater/September 1998
Velodyne Acoustics, Inc.
345 Digital Drive
Morgan Hill, CA 95037
408.465.2800 voice
408.779.9227 fax
Web Site: www.velodyne.com
E-mail: techhelp@velodyne.com
Printed on recycled paper
63-SPL81012 Rev B 08/02
SPL-800
SPL-1000
and
SPL-1200
Owner's Manual
Audio/Video Subwoofer System
Advertisement
Table of Contents
Related Manuals for Velodyne SPL-1200
Summary of Contents for Velodyne SPL-1200
- Page 1 "How do they get this kind of bass out of such a tiny box? Deep, tight, tuneful and loud enough to rattle pictures on the wall--this is serious subwoofing." -Robert Deutsch Stereophile Guide to Home Theater/September 1998 Velodyne Acoustics, Inc. 345 Digital Drive Morgan Hill, CA 95037 408.465.2800 voice 408.779.9227 fax Web Site: www.velodyne.com...
-
Page 2: Important Safety Instructions
Voice Coil Inputs Outputs Magnetically Shielded Warranty (parts/labor) Weight (approx.) Thank you for purchasing a Velodyne! SPL-800 SPL-1000 SPL-1200 10.5" x 10.25" x 12.75" x 12.25" x 14.75" x 14.5" x 12" 13.75" 15.75" 28Hz - 120Hz 24Hz - 120Hz 22Hz - 120Hz <5% (typical) - Page 3 Vorsicht: Zur Vermeidung von Gefahr durch elektrischen Schlag, Deckel (oder Rückwand) nicht abnehmen. Produkt enthält keine Anwenderteile. Reparatur und Wartung nur von qualifiziertem Fachpersonal vornehmen lassen. Das Blitzsymbol dient als Hinweis auf unisolierte „gefährliche Spannungen“ innerhalb des Gehäuses, deren Werte eine Berührungsgefahr für den Menschen darstellen können. Das Symbol mit dem Ausrufungszeichen dient als Hinweis auf wichtige, in den Unterlagen des Subwoofers enthaltene Bedienungs- und Wartungsvorschriften.
-
Page 4: Importantes Consignes De Securite
IMPORTANTES CONSIGNES DE SECURITE ATTENTION Risque d’électrocution Ne pas ouvrir Attention: Afin d’éviter tout risque d’électrocution, ne pas enlever le boitier (ou partie arrière de l’enceinte). Aucune pièce ne doit être manipulée par l’utilisateur. Pour tout entretien, vous référer à un personnel de service qualifié. -
Page 5: Speaker-Level Connection
Speaker-level Connection Figures 2 shows an easy way to connect your Velodyne subwoofer directly to your receiver or integrated amplifier, if it lacks line-level outputs. You may also connect your satellites directly to your receiver or amplifier along with the subwoofer. Your receiver or amplifier will not notice the additional load of the suboofer due to the high input impedance. -
Page 6: Product Features
12" (9.7" piston diameter) subwoofer with 3" voice coil and 162 ounce magnet/346 ounce motor structure • Built-in 1500 watts Dynamic/750 watts RMS high efficiency class D amplifier (SPL-1000 and SPL-1200); 1200 watts Dynamic/600 watts RMS (SPL-800) • Adjustable (40 to 120Hz) low-pass crossover (defeatable) •... -
Page 7: Line-Level Connection
The SPL-1000 and SPL-1200 are magnetically shielded to reduce the amount of stray magnetic energy emitted from the speaker's motor structure. - Page 8 signal processor, line-level crossover, or receiver with pre-amp level outputs. The SPEAKER LEVEL jacks connect directly to the speaker outputs of any amplifier, integrated amplifier, or receiver. Your amplifier section will notice no additional loading effects when you use these inputs due to their very high impedance.
