IDENTIFICATION RECORD

DATA LABEL

Every generator set has a DATA LABEL that contains important
information pertinent to the generator. The data label, which can be
found attached to the generator's lower connection box, lists the
unit's serial number and its rated voltage, amps, wattage capacity,
phase, frequency, rpm, power factor, production date, etc.
GENERATOR SET DATA
MODEL
RATED KVA
RATED KW
RATED VOLTAGE
POWER FACTOR
ENGINE RPM
ALTERNATOR SUBTRANSIENT REACTANCE
ALTERNATOR TRANSIENT REACTANCE
CLASS ROTOR STATOR WINDING INSULATION AT 25°C AMBIENT
GENERAC POWER SYSTEMS, INC.
WAUKESHA, WI
For actual information related to this particular model, please
refer to the Manual Drawing Listing located at the end of this
manual, or to the data label affixed to the unit.
Stationary Emergency Generator Model and Serial
Number
This number is the key to numerous engineering and manufactur-
ing details pertaining to your unit. Always supply this number
when requesting service, ordering parts or seeking information.
General Information
MADE IN USA
SERIAL
PHASE
RATED AMPS
HERTZ ALT RPM
PRODUCTION DATE
NOTE:
Identification Code
Use this code to obtain important information about the generator.
For example, if the code is:
M — Designates generators capable of paralleling. NOTE:
Only 100kW and 150kW, 6.8L units are currently avail-
M Q T 1 0
able for this configuration.
QT — Quiet Test Generator Series
100 — kw Rating
5.4 — Engine Size in Liters
A — Voltage Code: A = 120/240, Single-phase; G =
120/208, Three-phase; K = 277/480, Three-phase; J
= 120/240, Three-phase;
L = 346/600, Three-phase
N — Fuel: N = Natural Gas; V = Vapor Propane
S — Enclosure Material: A = Aluminum; S = Steel
(Corrosion Resistant Aluminum Enclosure Material,
Steel is Standard)
N — Emission Equipment: N = No Equipment; Y =
Catalytic Converter and Air/Fuel Ratio Controller
A — Industrial Dealer Product
Voltage Codes
The identification code letter following the unit's engine size is the
generator's "voltage code."
Groups and Assembly Numbers
The manual drawing listing lists the groups and corresponding
assembly numbers for each unit. The assembly numbers refer to
exploded view drawing numbers that are applicable to the specific
generator model. These drawings are located in the back half of
this manual.
2-1
0 5 4 A N S N A
