Thank you for purchasing this Panasonic product.
Before operating this unit, please read these instructions completely.
Before using this product, please pay particular attention to the "Safety precautions"
section (Pages 2 and 3) for safe use.
Please ensure the date and name of store of purchase are stamped in warranty card and
keep it stored together with these operating instructions in a safe place for future reference.
AUS/NZ
Operating Instructions
Refrigerator (For Household Use)
Contents
Safety Precautions ......................................................2
Installation ....................................................................4
Parts Identifi cation ......................................................6
Operation
To use all features .......................................................7
Control Panel ...................................................... 7
ECONAVI Operation ........................................... 8
Quick Freezing .................................................... 8
Food Stored ........................................................ 9
Refrigerator Compartment ................................ 10
Prime Fresh ....................................................... 10
Freezer Compartment ........................................11
Cleaning, removing and re-installing .......................12
Cleaning ............................................................ 12
Troubleshooting .........................................................15
Specifi cations ............................................................16
NR-CY54B
Model No.
Printed in Thailand
AK-177500
T0917-0
09-2017
Advertisement
Table of Contents
Related Manuals for Panasonic ECONAVI NR-CY54BGSAU
Summary of Contents for Panasonic ECONAVI NR-CY54BGSAU
-
Page 1: Table Of Contents
Cleaning ............12 Troubleshooting ............15 Specifi cations ............16 Thank you for purchasing this Panasonic product. Before operating this unit, please read these instructions completely. Before using this product, please pay particular attention to the “Safety precautions” section (Pages 2 and 3) for safe use. -
Page 2: Introduction
Introduction Safety Precautions WARNING CAUTION This expression presumes possibility of a death This expression presumes possibility of personal or serious injury. injury or property damage. Do not Make sure you do this Do not take apart iso-butane Risk of fi re / fl ammable materials WARNING For power plug and cord... - Page 3 Introduction CAUTION WARNING When installing... When storing food... ● Do not install the product in locations ● Do not freeze glass bottles, that there is a risk of injury. exposed to water. (If the liquid in a glass bottle ● Provide a grounding connection or install a is frozen and broken, you ground-fault interrupter when the product is may be injured.)
-
Page 4: Installation
Installation Installation Before using for product. Is the refrigerator installed in the following locations? ●Locations subject to heat and direct sunlight (The cooling power will be reduced and electricity wasted.) ●Poorly ventilated locations with high humidity (Rust will be caused.) ●Locations where the surface is unstable and slanted On carpet, mats, or vinyl fl... - Page 5 Installation Requests and notices Do not peel the seal on the back. Otherwise, the cooling performance may deteriorate. If you have peeled it, then cut a cloth packing tape into a square and paste it Seal onto the refrigerator. Do not open/close the doors during the interior cooling process.
-
Page 6: Parts Identifi Cation
Installation Operation Parts Identifi cation NR-CY54B REFRIGERATOR LED lamp COMPARTMENT Small tempered glass tray Egg tray Egg shelf Egg tray Large tempered glass tray Door gasket Free rack PC Tempered glass tray crisper Bottle shelf Door gasket Vegetable Case Freezing Case Bottle shelf Prime fresh case Ice twister... -
Page 7: To Use All Features
Installation Operation To use all features Control Panel Temperature setting and a guide of temperature The temperature can be adjusted for Min-Max levels. Button Fridge Prime Fresh Freezer Temperature setting Approximately -1 °C ~ 3 °C Chill Higher than “Med” Higher than “Med”... -
Page 8: Econavi Operation
Operation ECONAVI Operation The refrigerator detects the opening and closing of the refrigerator door and the brightness around the refrigerator to automatically control operation to ensure maximum energy saving.* ECONAVI operates only when the temperature setting is “Med” for both the freezer and refrigerator compartments. -
Page 9: Food Stored
Operation Food Stored In order to preserve food quality for long time, please store it in the right place. When storing food... ●Foodstuff such as vegetable, fruits and fresh Refrigerator food should be wrapped or pack in box compartment before freezing and refrigerating. -
Page 10: Refrigerator Compartment
Operation Refrigerator Compartment The position of the second tray from the top can be changed. (1) Lift up the back of the tray and pull it (2) Insert the tray in the desired position by forward. Once the protrusions of the tray reversing the steps. -
Page 11: Freezer Compartment
Operation Freezer Compartment Approx. -20 °C ~ -18 °C ● A lot of frozen food and cooked meal can be stored. Requests ● For the upper case of the freezer, put your food within the height of the case. Freezing Case (Upper) ●... -
Page 12: Appendix
Introduction Appendix Cleaning, removing and re-installing Before cleaning or conducting maintenance, be absolutely sure to disconnect the power plug from the power outlet. Do not connect or disconnect the power plug with wet hands. When the plug is disconnected, leave it for 10 minutes before plugging again. If not, the compressor may not work. - Page 13 Appendix Trays Once every 3 months Removing Attaching Lift up the back of the tray and pull it Push the tray until it reached the end forward. Once the protrusions of the lock. tray are unhooked from the rails, tilt the tray and remove it.
- Page 14 Introduction Appendix Bottom freezer case (Freezer compartment) Pull the freezer draw out towards yourself. Lift both sides of the bottom freezer case and move upward. Lift up the drawer slightly and pull towards yourself until it reaches the stoppers. 2 2 2 ●The contact sections of the drawer rails have been coated with lubricant.
-
Page 15: Troubleshooting
Appendix Troubleshooting In these cases? Check here. ● Check that the plug and wall socket are in good condition. The refrigerator does not ● Check if there is any problem with the mains fuse or house wiring. operate. ● Check by unplugging for 10 minutes and plugging back in. ●... -
Page 16: Specifi Cations
89 / 196 n i l n i l Rated Voltage (V) Refer to the rating label put at the door or the back of the Rated Frequency (Hz) cabinet. Panasonic Corporation Website: http://www.panasonic.com © Panasonic Appliances (Thailand) Co., Ltd. 2017...
