Specification
Power supply
Antenna
Host Interface
Standard Compliance
Frequency Range
Modulation
Receiver Sensitivity
Transfer rate (standard)
*
Output Power
Security
* Transfer rate are theoretical values; however, actual communication rate will
vary according to communication environment or connected equipment.
105mA
DC 3.3V ,
Tx 1, Rx 1
USB 2.0 + GPIO x1
Bluetooth 3.0
2.4 GHz (2.40GHz-2.4835GHz)
・GFSK
・Pi/4 QPSK
・8DPSK
-88 dBm(typ.) GFSK, 0.1%BER
-85 dBm(typ.) for pi/4-DQPSK, 0.01%BER
3.0Mbps(MAX, Theoretical Value)
Class 1, 8
dBm typical
BT E0/AES/SAFER+
