Thank you for purchasing the Yamaha SILENT Cello™. In order to obtain the
maximum performance and enjoyment from your SILENT Cello™, we urge you
to read this Owner's Manual thoroughly before using the instrument. Please
keep this Owner's Manual in a safe place for later reference.
Precautions ................................................................... 3
Main Unit/Accessories ................................................. 4
Nomenclature ............................................................... 5
Set up ............................................................................ 8
■ Tuning and Changing the Strings ............................................. 8
■ About the Chest Support . ....................................................... 10
■ About the End Pin . .................................................................. 10
Power Supply ...............................................................11
■ Using Batteries .........................................................................11
■ Supplying AC Power . ................................................................11
Specifications ............................................................. 12
SVC110
Owner's Manual
Contents
™
1
Advertisement
Table of Contents
Related Manuals for Yamaha SILENT Cello SVC-110SK
Summary of Contents for Yamaha SILENT Cello SVC-110SK
-
Page 1: Table Of Contents
™ SVC110 Owner’s Manual Thank you for purchasing the Yamaha SILENT Cello™. In order to obtain the maximum performance and enjoyment from your SILENT Cello™, we urge you to read this Owner’s Manual thoroughly before using the instrument. Please keep this Owner’s Manual in a safe place for later reference. - Page 2 FCC INFORMATION (U.S.A.) 1. IMPORTANT NOTICE: DO NOT MODIFY THIS of other electronic devices. Compliance with FCC regulations does not guarantee that interference will not occur in all installations. If UNIT! this product is found to be the source of interference, which can be de- This product, when installed as indicated in the instructions con- termined by turning the unit “OFF” and “ON”, please try to eliminate tained in this manual, meets FCC requirements. Modifications not the problem by using one of the following measures: expressly approved by Yamaha may void your authority, granted by the FCC, to use the product. Relocate either this product or the device that is being affected by the interference. 2. IMPORTANT: When connecting this product to accessories and/ or another product use only high-quality shielded cables. Cable/s Utilize power outlets that are on different branch (circuit breaker or fuse) circuits or install AC line filter/s. supplied with this product MUST be used. Follow all installation instructions. Failure to follow instructions could void your FCC In the case of radio or TV interference, relocate/reorient the antenna. authorization to use this product in the USA. If the antenna lead-in is 300 ohm ribbon lead, change the lead-in to 3. NOTE: co-axial type cable. This product has been tested and found to comply with the requirements listed in FCC Regulations, Part 15 for Class “B” digital If these corrective measures do not produce satisfactory results, devices. Compliance with these requirements provides a reason-...
-
Page 3: Precautions
• Unplug the AC power adaptor during electric storms. • Avoid plugging the AC power adaptor into the same AC outlet as appliances with high power consumption, such as electric heaters or ovens. Also avoid using multi-plug adaptors since these can result in reduced sound quality and possible damage. ■ Turn Power OFF When Making Connections • To avoid damage to the SILENT Cello™ and other devices to which it is connected (a sound system, for example), turn the power switches of all related devices OFF prior to connecting or disconnecting audio cables. ■ Handling and Transport • Never apply excessive force to the controls, connectors or other parts. • Always unplug cables by gripping the plug firmly, not by pulling on the cable. • Disconnect all cables before moving the unit. • Physical shocks caused by dropping, bumping, or placing heavy objects on the unit can result in scratches and more serious damage. ■ Cleaning • Clean the body and control panel with a dry soft cloth. • A slightly damp cloth may be used to remove stubborn grime and dirt. • Never use cleaners such as alcohol or thinner. ■ Electrical Interference • This unit contains digital circuitry and may cause interference if placed too close to radio or televi- sion receivers. If this occurs, move it further away from the affected equipment. Yamaha is not responsible for damage caused by improper handling or operation. -
Page 4: Main Unit/Accessories
Main Unit/Accessories After opening the packaging, please check that all the parts listed below are included. SVC110 • Cello x 1 • Soft case x 1 • Bridge x 1 • Chest support x 1 • Stereo headphones x 1 • Audio cable x 1 (For connection of AUX IN jack) * Power Adaptor (sold separately): Yamaha PA-3C (for use in Japan), PA-130 (for use internationally) * To play SVC110, you will need 2 SUM-3 (AA) size batteries. -
Page 5: Nomenclature
Nomenclature ● Front Tuning peg Neck Fingerboard 4th string (C) 2nd string (D) 3rd string (G) 1st string (A) Body Frame Bridge seat Bridge Adjuster Tailpiece Saddle Tail nylon End pin End pin stopper... - Page 6 ● Rear Stereo headphones * Supplied headphones or any other type PHONES jack VOLUME Lamp POWER switch REVERB switch REV. ON/ON/OFF RM (ROOM) HL1 (HALL 1) HL2 (HALL 2) DC-IN 9-12V jack (+ –) (Power adaptor connector) Cord hook Wrap the Power Adaptor’s cord around the cord hook (prevents cord from being unplugged). Battery cover Power adaptor (Option) Electric outlet...
- Page 7 Rotate the VOLUME dial to the desired playing with the AUX. VOL control. level. ■ LINE OUT jack ■ Reverb Function The LINE OUT jack, located on the rear of The SILENT Cello™ incorporates Yamaha’s the instrument, delivers the stereo signal of the DSP reverb technology. Play while trying out SILENT Cello™ to external audio equipment. the three types of reverb. Using an optional stereo phone plug cable (or monaural phone plug cable) to connect the Slide the POWER switch to the REV. ON posi-...
-
Page 8: Set Up
Set up ■ Tuning and Changing the Strings The SILENT Cello™ is shipped from the factory with the 1st string 4th string bridge unfitted. First, set up the bridge and then proceed Slit with tuning. Logo As the strings get old, sound quality will gradually decrease, imprint and it will become difficult to tune the instrument. Change the strings as soon as you think they are getting old. [Looking from the tailpiece] Bridge seat • The end of the strings are sharp and can cut fingers. Use caution when changing strings. •... - Page 9 • If the adjuster is too loose, Make sure that the Tail Nylon is correctly Caution Caution positioned on top of the Saddle. it could produce noise while playing. Saddle Don’t loosen too much. Tail nylon • When the instrument is not being used, loosen the strings until the pitch drops a whole tone. •...
-
Page 10: About The Chest Support
■ About the Chest Support Back of SILENT Cello™ The chest support is used to rest the cello against your body. As shown in the illustration, insert the pins Pins on the chest support into the attaching holes located on the back of the instrument. Chest support ■ About the End Pin Loosen the end pin stopper, extend the end pin to a comfortable length for playing and firmly tighten the end pin stopper. A rubber foot is attached to the tip of the End Pin end pin. Removing the rubber foot exposes Stopper the pointed end pin that can be used on appropriate surfaces. End Pin • The end pin is pointed. Please be careful when Rubber Foot using the exposed end pin. -
Page 11: Power Supply
• To prevent possible damage to the unit due to battery leakage and unnecessary power drain, remove the batteries from the unit when it is not going to be used for an extended period of time. ■ Supplying AC Power Power Adaptor (sold separately): Yamaha PA-3C (for use in Japan), PA-130 (for use internationally) Plug the adaptor’s DC output cable into the SILENT Cello™ DC IN 9-12V jack located on the back of the instrument, making sure the plug is firmly inserted into the jack. -
Page 12: Specifications
Specifications Neck Maple Body Spruce/Maple Fingerboard/Tuning Pegs Ebony Bridge Maple (Aubert) Frame Plywood Tail Piece Adjuster 4 pieces (Wittner) Strings Ball-end type (Helicore) Sensor Piezo pick-up Connectors/Controls • Headphone Output • AUX IN (w/Volume Control) • LINE OUT • Volume • Reverb Switch (RM/HL1/HL2) • POWER Switch (OFF/ON/REV. ON) Power • SUM-3 size battery x 2 2.5 W (with the PA-3C), Power Consumption 1.0 W (with the PA-130, PA-130A, B) Using Manganese batteries Battery Life (Continuous Use) • Without Reverb (POWER Switch “ON”) approximately 10 hours • With Reverb (POWER Switch “REV. ON”) approximately 3 hours Using Alkaline batteries • Without Reverb (POWER Switch “ON”) - Page 13 〒 静岡県浜松市中区中沢町 430-8650 10-1 WG80460 1502 R3 Printed in Japan...
