G3500
GSM Mobile Phone
User Guide
Huawei Technologies Co., Ltd.

Advertisement

Table of Contents
loading

Related Manuals for Huawei G3500

Summary of Contents for Huawei G3500

  • Page 1 G3500 GSM Mobile Phone User Guide Huawei Technologies Co., Ltd.
  • Page 2 Thus the descriptions herein may not exactly match the product or its accessories you purchase. Huawei Technologies Co., Ltd reserves the right to change or modify any information or specifications contained in this manual without prior notice or obligation.

  • Page 3: Table Of Contents

    RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL. TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, IN NO CASE SHALL HUAWEI TECHNOLOGIES CO., LTD BE LIABLE FOR ANY SPECIAL, INCIDENTAL, INDIRECT, OR CONSEQUENTIAL DAMAGES, OR LOST PROFITS, BUSINESS, REVENUE, DATA, GOODWILL OR ANTICIPATED SAVINGS.
  • Page 4 4 Text Entry ..............7 Changing the Text Input Modes ........7 Entering English Letters ..........8 Entering Digits............8 Entering Symbols............8 5 Messaging..............9 Editing and Sending a Text Message......9 Editing and Sending a Multimedia Message....9 6 Contacts..............

  • Page 5: Getting To Know Your Phone

    1 Getting to Know Your Phone Your Phone The following figure shows the appearance of your phone and it is for your reference only. Earpiece Charger jack Screen Confirm key Left soft key Navigation keys Talk/Send key Right soft key Number keys End/Power key * key...

  • Page 6: Keys And Functions

    Keys and Functions Press To … … Make a call. Answer an incoming call. View All Calls in standby mode. Power on or power off the phone (by pressing and holding it for about 3s). End a call, or reject an incoming call. Return to standby mode.
  • Page 7 Press To … … Enter numbers, letters, and characters. Call the voice mail center in standby mode (by pressing and holding the 1 key). Speed-dial phone numbers in standby mode (by pressing and holding the 2–9 keys). Select a submenu item labeled with the corresponding number.

  • Page 8: Screen Icons

    Screen Icons Icon Indicates Signal strength. A new text message is received. The phone is roaming. The call forwarding function is enabled. The stopwatch function is enabled. The headset is being used. Missed call(s). An alarm is activated. The keypad is locked. Battery power level.

  • Page 9: Getting Started

    2 Getting Started Installing the SIM Card and Battery Ensure that the golden contact area on the SIM card is facing downward, and the beveled corner is properly aligned with the SIM card slot.

  • Page 10: Removing The Battery And Sim Card

    Removing the Battery and SIM Card...

  • Page 11: Charging The Battery

    Installing the micro SD card Charging the Battery Connect the charger to an AC power socket. Connect the charger to the charger jack on the phone. Wait until the battery is completely charged. During the charging, the charging icon is displayed in animation.

  • Page 12: Phone Lock

    Press (Select) or to display the selected menu. Press to select a submenu. Press (Select) or to display the menu. Press (Back) to return to the previous menu or exit the function menu. To return to standby mode, press Phone Lock The phone lock protects your phone from unauthorized use.

  • Page 13: Locking The Keypad

    Locking the Keypad Press and hold to lock the keypad. To unlock the keypad, press (Unlock) and in succession. If the Auto keypad lock function is enabled and the phone is idle for a preset period in standby mode, the keypad is locked automatically.

  • Page 14: Answering A Call

    Answering a Call When there is an incoming call, you can do as follows: Press to answer it. Press to reject it. Press (Mute) to mute the speaker, and then press (Reject) again to reject it. Press (Options) and select Answer to answer it. If the Any key function is enabled, you can press any key except to answer an incoming call.

  • Page 15: Entering English Letters

    Entering English Letters In "ABC" or "abc" input mode, you can press a key labeled with the desired letter once to enter the first letter on the key, twice to enter the second letter on the key, and so on. In "eZi ABC", "eZi Abc"...

  • Page 16: Messaging

    5 Messaging Editing and Sending a Text Message Select Menu > Messages > SMS > Write message. Edit the text message. Press (Options) and select Done. Press (Select) to select from the following options: Send only: to enter the phone number or select the recipient from the contact list.

  • Page 17: Contacts

    Press (Options) and select Done. Press （Done）and select Send. Contact your service provider for the availability of the Multimedia Messaging Service (MMS) and how to subscribe this service. Open multimedia messages with caution. Objects in multimedia messages may contain hazards that can damage your phone, such as malicious software.

  • Page 19: Multimedia

    7 Multimedia Camera Press in standby mode, or select Menu > Multimedia > Camera. Press (Options), and then select to view the photo album or set relevant parameters. Press to take a photo. Press (Continue) to save the photo; press (Delete) to delete the photo.

  • Page 20: Fm Radio

    Audio player Select Menu > Multimedia > Audio player. Select audio file. Press (Options) and select Play. You can do as follows when the audio is being played: Press to adjust the volume. Press to pause/continue. Press (Stop) to stop playing the audio. FM Radio The headset cable can be used as an antenna.

  • Page 21: Sound Recorder

    Press (Options) and select Channel list, Manual input, Preset auto search, settings, Record, Append or File list. Sound Recorder Select Menu > Multimedia > Sound recorder. Press (Options) and select Record. During the recording process, press pause/continue. Press (Stop) to stop recording.

  • Page 22: Connectivity

    8 Connectivity You can access WAP sites and use WAP-based services on your phone. To access the WAP sites through your phone, you need to subscribe the corresponding service from the service provider and set the relevant parameters on your phone. For details about the service and the charges, contact your service provider.
  • Page 23 Press (Options) and select Done. The browser will display the corresponding WAP page.

  • Page 24: Warnings And Precautions

    9 Warnings and Precautions This section contains important information pertaining to the operating instructions of your device. It also contains information about how to use the mobile safely. Read this information carefully before using your device. Electronic Device Power off your device if using the device is prohibited. Do not use the device when it causes danger or interference with electronic devices.
  • Page 25 stations. Comply with restrictions on the use of radio equipment in fuel depots, storage, and distribution areas, and chemical plants. Also, adhere to restrictions in areas where blasting operations are in progress. Before using the device, watch out for areas that have potentially explosive atmosphere that are often, but not always, clearly marked.
  • Page 26 Operating Environment Do not use or charge the device in dusty, damp or dirty places or places with magnetic fields. Otherwise, the circuit may not function properly. The device complies with the RF specifications when the device is used near your ear or at[0] a distance of 1.5 cm from your body.
  • Page 27 your ears like ringing or if you hear muffled speech, get your hearing checked. If you continue to use high volume, your hearing will soon get affected. Hearing experts offer the following suggestions to protect your hearing: Reduce the time you use the receiver, earbuds, headphones, speakerphone, or earpieces at high volume.
  • Page 28 Battery and Charger The battery can be charged and discharged hundreds of times before it eventually wears out. When the standby time and talk time are shorter than normal, replace the battery. Use the AC power supply defined in the specifications of the charger.
  • Page 29 Clearing and Maintenance The device, battery, and charger are not water-resistant Keep them dry. Protect the device, battery and charger from water or vapor. Do not touch the device and charger with a wet hand. Otherwise, it may lead to short-circuit or malfunction of the device and electric shock to the user.
  • Page 30 Do not dismantle the device or accessories. Otherwise, manufacturer is not liable to pay for damages as the device and accessories are not covered by warranty. Emergency Call You can use your device for emergency calls in the service area. The connection, however, cannot be guaranteed in all conditions.
  • Page 31 below the value. This is because the device is designed to use the minimum power required to reach the network. Before a device model is available for sale to the public, it must be tested and certified by the Federal Communications Commission (FCC), ensuring that it does not exceed the limit established by the government-adopted requirement for safe exposure.
  • Page 32 interference received, including interference that may cause undesired operation. These limits are designed to provide reasonable protection against harmful interference in a residential installation. The operation is subject to the condition that this device does not cause harmful interface. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
  • Page 33 RF exposure warning: The equipment complies with FCC RF exposure limits set forth for an uncontrolled environment. The equipment must not be co-located or operating in conjunction with any other antenna or transmitter. Max. SAR Measurement: Head SAR: 1.220 W/kg Body SAR: 1.370 W/kg...
  • Page 34 Version: V100R001_01 NO.: 6010144...
