- Page 1 5”B&W Rear View Safety System Instruction Manual English Version 1.0 MODEL: RV453 www.lorexcctv.com © Copyright 2007 LOREX Technology Inc.
- Page 2 Thank you for purchasing the Lorex 5” Black & White Rear View Safety System. This system helps to prevent backing-up and parking accidents by allowing you to view or check on the traffic behind your vehicle, or when rounding corners (blind spot prevention).
- Page 3 4. Keep enough space around the unit for ventilation. Slots and openings in the storage cabinet should not be blocked 5. During lightning storms, or when the unit is not used for a long time, disconnect the power supply, antenna, and cables to protect the unit from electrical surge LOREX TECHNOLOGY INC. http://www.lorexcctv.com...
-
Page 4: Table Of Contents
Operating Instructions ................11 System Specifications - Appendix #1 ............12 Camera Specifications - Appendix #2 ............. 13 Lorex CVA453 Accessory Cables - Appendix #3........14 RV453 FEATURES • Automatic activation of camera when gear is shifted into reverse. • Built-in 2 Camera input. -
Page 5: Getting Started
Getting Started Getting Started The RV453 Rearview System comes with the following components: 5” B&W CRT Monitor 1/3” CCD Weatherproof Camera Power cable and Harness 65’ (2 Piece) Camera Ex- tension Cable Mounting Hardware and Brackets Sunshade for Monitor for Monitor and Camera CHECK YOUR PACKAGE TO CONFIRM THAT YOU HAVE RECEIVED THE COMPLETE SYSTEM, INCLUDING ALL COMPONENTS SHOWN ABOVE. -
Page 6: Rv453 - Front
RV453 - Front RV453 - Front 1. POWER SWITCH - Turns the monitor ON/OFF: • Press the power switch to turn the monitor ON. The green LED indicator will illuminate. • Press the power switch again to turn the monitor OFF (STANDBY MODE).The green LED indicator will extinguish. -
Page 7: Rv453 - Back
RV453 - Back RV453 - Back 1. CAMERA 1 / CAMERA 2 INPUTS - Allows 2 Cameras (4-Pin) to connect to the system. • Connect the provided camera to the first channel (C1). • An additional camera can be connected to C2 (not included). -
Page 8: Camera Installation
Camera Installation Camera Installation 1. Connect the 1.8 M cable from the camera to the short 5M piece of the 20M (15M + 5 M) 2-piece extension cable provided. 2. Connect the other end of the 5M cable to the 15M piece, which connects to CAM 1 or CAM 2 on the back of the monitor Mounting the Cameras and Cables 1. -
Page 9: Camera Overview
Camera Overview Camera Overview Monitor Overview... -
Page 10: Monitor Installation
Monitor Installation Monitor Installation 1. Determine the location to mount the monitor. Install the monitor mounting bracket by placing the screw into the center hole. Rotate and adjust the bracket by turning it left and right for the best placement. Screw in the slide holes on the bracket and tighten the screws. 2. -
Page 11: Full Connection Diagram
Full Connection Diagram Full Connection Diagram 1. Connect the RED wire to the (12V – 32V DC) power terminal, which powers the system when the ignition key is turned on the vehicle. 2. Connect the BLACK wire to a metal portion of the vehicle or the negative battery post. 3. -
Page 12: System Specifications - Appendix #1
System Specifications - Appendix #1 System Specifications - Appendix #1 Picture Tube Black and White 7” Picture (measured diagonally) ° Deflection angle Picture Image Factory preset to reverse image Picture Resolution 600 TV Lines Power Connector Red: Positive 12V~32V Input Brown: Reverse Gear 12V ~ 32V input Black: Ground White: Dimmer... -
Page 13: Camera Specifications - Appendix #2
70mm (W) x 50mm (H) x 50mm (D) Weight 0.75 lbs / 0.34 kg As our products are subject to continuous improvement, LOREX Technology Inc. and its subsidiaries reserve the right to modify product design, specifications and prices, without notice and without incurring any obligation. E&OE... -
Page 14: Lorex Cva453 Accessory Cables - Appendix #3
Lorex CVA453 Accessory Cables - Appendix #3 Lorex CVA453 Accessory Cables - Appendix #3 Additional adapter cables are available for backward compatibility between the Lorex 452 Series and the Sentinel CCTV 452 Series Rear view systems. Adaptor Cable #1 - CA452 (Camera... - Page 15 It’s all on the web Product Information Specification Sheets User Manuals Software Upgrades Quick Start Guides Firmware Upgrades VISIT www.lorexcctv.com wwwlorexcctv.com Lorex Technology Inc.
