OWNER'S MANUAL
WASHING
MACHINE
Before beginning installation, read these instructions carefully.
This will simplify installation and ensure that the product is
installed correctly and safely. Leave these instructions near the
product after installation for future reference.
EN ENGLISH
WFT1272DD
WFT1181DD
WFT9081DD
T2313SSAV
WFT1081DD
T2112SSAV
MFL67568772
Rev.04_052319
T2313NSAV
Copyright © 2017-2019 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG WFT1272DD
Summary of Contents for LG WFT1272DD
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. EN ENGLISH WFT1272DD WFT1181DD T2313NSAV WFT9081DD T2313SSAV WFT1081DD T2112SSAV www.lg.com MFL67568772 Rev.04_052319 Copyright © 2017-2019 LG Electronics Inc. All Rights Reserved.
-
Page 3: Table Of Contents
Washing Programme .................24 Option Programme ..................26 Manual Washing ..................28 Special Functions ..................29 SMART FUNCTIONS ............... 30 Using LG SmartThinQ Application .............30 Using Smart Diagnosis™ ................33 MAINTENANCE ............... 34 Cleaning Your Washing Machine ...............34 Cleaning the Water Inlet Filter ..............35 Cleaning the Drain Pump Filter (Optional) ..........35 Caution on Freezing During Winter ............36... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. This symbol is displayed to indicate matters and operations that can cause risk. - Page 5 Installation •Never attempt to operate the appliance if it is damaged, malfunctioning, partially disassembled, or has missing or broken parts, including a damaged cord or plug. •This appliance should only be transported by two or more people holding the appliance securely. •Tighten the drain hose to avoid separation.
- Page 6 •Improper connection of the equipment-grounding conductor can result in risk of electric shock. Check with a qualified electrician or service personnel if you are in doubt as to whether the appliance is properly grounded. •Do not modify the power cord provided with the appliance. Operation •Do not use a sharp object like drill or pin to press or separate an operation unit.
- Page 7 •In case of flood, disconnect the power plug and contact the LG Electronics customer information centre. •Do not use or store flammable or combustible substances (ether, benzene, alcohol, chemical, LPG, combustible spray, insecticide, air freshener, cosmetics, etc.) near the appliance.
- Page 8 •Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
- Page 9 Disposal •Before discarding an old appliance, unplug it. Cut off the cable directly behind the appliance to prevent misuse. •Dispose of all packaging materials (such as plastic bags and styrofoam) away from children. The packaging materials can cause suffocation. •Remove the door before disposing of or discarding this appliance to avoid the danger of children or small animals getting trapped inside.
-
Page 10: Installation
INSTALLATION Parts Door Tempered Glass Dispenser Drawer Bleach Dispenser Drum Leveling Feet Drain hose Water Supply Hose • Appearance and specifications may change without notice to improve the quality of the product. Accessories Tie strap (Optional) 2 water supply hoses Drain hose Anti-rat cover Screw for Anti-rat cover... -
Page 11: Specifications
Specifications Type 1 Model T2313NSAV T2313SSAV WFT1272DD Power Supply 220 V~, 50 Hz 230 V~, 50 Hz Size 590 mm (W) x 606 mm (D) x 990 mm (H) Product Weight 45 kg Allowable water 30 - 800 kPa pressure Max. -
Page 12: Installation Place Requirements
Installation Place • If it is impossible to avoid positioning the appliance next to a gas cooker or coal burning Requirements stove, an insulation (85x60 cm) covered with aluminum foil on the side facing the cooker or Location stove must be inserted between the two appliances. -
Page 13: Connecting The Supply Hose
Connecting the Supply Hose Connecting Hose to Water Tap • Before connecting the water supply hose to Connecting Screw-Type Hose to Tap the water tap, check the hose type and then with Thread choose the correct instruction. • The water supply hose supplied may vary Screw the hose connector onto the water from country to country. - Page 14 Push the adapter onto the end of the tap so Remove the guide plate if the tap is too that the rubber seal forms a watertight large to fit the adapter. connection. Tighten the four fixing screws. Guide plate Push the supply hose vertically upwards so Push the adapter onto the end of the tap so that the rubber seal within the hose can that the rubber seal forms a watertight...
-
Page 15: Installing The Drain Hose
Installing the Drain Hose Connecting Hose to Appliance Attach the hot water line to the hot water inlet Before connecting the drain hose, check your on the back of the washing machine. Attach the drain hose model and choose the correct cold water line to the cold water inlet on the instruction. - Page 16 Non-pump Model Positioning the Drain Hose • The length of the drain hose should not Push the elbow hose toward the body of the exceed 3 m. washing machine. • Do not place the drain hose on a threshhold of 6 cm or more. max.
-
Page 17: Leveling The Appliance
Leveling the Appliance Assembling the Anti-Rat Cover (Optional) If the floor is uneven, turn the adjustable feet as required (Do not insert pieces of wood etc. Insert the Anti-Rat cover to the assembling hole under the feet). Make sure that all four feet are from the front or back of the washing machine. -
Page 18: Operation
OPERATION Using the Appliance Choose the desired wash programme. • Press the Program button repeatedly until Before the first wash, select a washing the desired programme is selected. programme (Normal, add a half load of detergent), allow the washing machine to wash without clothing. -
Page 19: Sorting Laundry
Sorting Laundry Caring before loading. • Combine large and small items in a load. Look for a care label on your clothes. Load large items first. • This will tell you about the fabric content • Large items should not be more than half of your garment and how it should be the total wash load. -
Page 20: Adding Cleaning Products
Adding Cleaning Products • Dilute liquid detergent with water and pour into the drum, start the cycle. Detergent Dosage • Using liquid detergent without diluting, or leaving laundry for a long time after pouring • Detergent should be used according to the diluted liquid detergent into the drum might instruction of the detergent manufacturer and cause damage, bleaching or discoloration of... - Page 21 Adding Fabric Softener Adding Liquid Bleach • Do not exceed the maximum fill line. • Check clothing care label for special Overfilling can cause early dispensing of the instructions and separate the laundry to be fabric softener, which may stain clothes. Close bleached.
-
Page 22: Control Panel
Control Panel For Steam Models Power Button Program Button • Press the Power button to turn the • Programmes are available according to washing machine on. laundry type. • The power goes off automatically about 30 • Lamp will light up to indicate the selected seconds after the wash is finished. - Page 23 For Non-Steam Models Power Button Program Button • Press the Power button to turn the • Programmes are available according to washing machine on. laundry type. • The power goes off automatically about 30 • Lamp will light up to indicate the selected seconds after the wash is finished.
-
Page 24: Washing Programme
Washing Programme Allergy Care (for steam models) This programme is a powerful, high temperature Wash cycles are designed for the best wash programme designed specifically to reduce performance for each type of load. Select the certain allergens. programme that best matches the load contents for maximum wash performance and fabric •... - Page 25 Delicates Duvet Use this programme to wash delicate fabrics Use this programme to wash a blanket or such as lingerie and woolens. Before washing, bedclothes with hand wash sign. check the care label for the washing • Cashmere bedclothes, acrylic blanket, mixed instructions.
-
Page 26: Option Programme
Option Programme Rinse • Press the Rinse button to change the number Water Level of rinses. • Press the Water Level button to adjust water level. Intensive Rinse • It can be changed during operation. • Use Intensive Rinse to remove detergents more effectively. - Page 27 Steam (for steam models) Soak • Press the Steam button to use steam. • Soak can be selected to wash heavily soiled laundry by soaking in water for some time to • Steam is automatically selected under the remove dirt and grime. Allergy Care programme.
-
Page 28: Manual Washing
Manual Washing When you need a Rinse/Spin, Spin, Rinse, or Wash cycle only, these can be set manually. Rinse, Spin Spin only Rinse only Wash only Press the Power button. Press the Rinse Press the Spin Press the Rinse Press the Wash button. -
Page 29: Special Functions
Special Functions Child Lock Use this option to disable the controls. This feature can prevent children from changing programmes or operating the appliance. Locking the Control Panel Press and hold the Rinse button for 3 seconds. ' ' and the remaining time are alternatively shown on the display while they are locked. -
Page 30: Smart Functions
• For appliances with the logo • LG SmartThinQ is not responsible for any Check the distance between the appliance network connection problems or any faults, and the wireless router (Wi-Fi network). - Page 31 Installing LG SmartThinQ NOTE • If you change your wireless router, Internet Search for the LG SmartThinQ application from service provider, or password, delete the the Google Play Store or Apple App Store on a registered appliance from the LG SmartThinQ smart phone.
- Page 32 (such as • Once the Remote Start mode is enabled, you the cost of media, shipping, and handling) upon can start a cycle from the LG Smart ThinQ email request to opensource@lge.com. This smartphone application. If the cycle is not...
-
Page 33: Using Smart Diagnosis
Customer Information Centre transmitted for analysis. Use this function if you need an accurate diagnosis by an LG Electronics customer NOTE information center when the appliance • The Smart Diagnosis™ function depends on malfunctions or fails. -
Page 34: Maintenance
MAINTENANCE Tub Clean WARNING • Unplug the washing machine before cleaning Tub Clean is a special cycle to clean the inside to avoid the risk of electric shock. Failure to of the washing machine. Perform this cycle follow this warning may result in serious injury, regularly. -
Page 35: Cleaning The Water Inlet Filter
Cleaning the Water Inlet Filter Cleaning the Drain Pump Filter (Optional) • Turn off the supply taps to the machine if the washing machine is to be left for any length of • The drain filter collects threads and small time (e.g. -
Page 36: Caution On Freezing During Winter
Caution on Freezing During Winter • When frozen, the product does not operate normally. Make sure to install the product where it will not freeze during winter. • In case the product must be installed outside on a porch or in other outdoor conditions, make sure to check the following. -
Page 37: Troubleshooting
TROUBLESHOOTING The appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following before you call for service: Diagnosing Problems Symptoms Reason... - Page 38 Symptoms Reason Solution • Dispenser compartment is overfilled causing bleach or softener to dispense Bleach or softener dispensed immediately. ALWAYS measure bleach to too soon. prevent overfilling. • Close the dispenser drawer slowly. Bleach or softener was added • Always use the dispensers to ensure that Staining directly to the wash load in laundry products are properly dispensed...
- Page 39 Symptoms Reason Solution Control panel has powered • This is normal. Press the Power button off due to inactivity. to turn the washing machine on. Washing machine is • Make sure cord is plugged securely into unplugged. a working outlet. Water supply is turned off.
- Page 40 Symptoms Reason Solution • Make sure the inlet filters on the fill Filter clogged. valves are not clogged. • Check that supply hoses are not kinked Supply hoses may be kinked. or clogged. Washing machine not filling properly • Make sure that both hot and cold water Insufficient water supply.
- Page 41 • Find the Wi-Fi network connected to your that you are trying to connect smartphone and remove it, then register to is incorrect. your appliance on LG SmartThinQ. • Turn off the Mobile data of your Mobile data for your smartphone and register the appliance smartphone is turned on.
-
Page 42: Error Messages
Error Messages Symptoms Reason Solution • Close the door completely. If the The door is not closed properly. error code is not released, call for service. • Check nothing is caught under the door, including shipping materials or lothing. Door lock switch error. •... - Page 43 Symptoms Reason Solution • The automatic attempt to rebalance UE rebalancing operation is not the load was not successful. The successful. cycle has been paused to allow the load to be manually adjusted. • Add more items to allow the washing The load is too small.
-
Page 44: Warranty
• Costs associated with removal of your Product from your home for repairs. • The removal and reinstallation of the Product if it is installed in an inaccessible location or is not installed in accordance with published installation instructions, including LG’s owner’s and installation manuals. - Page 45 Memo...
