OWNER'S MANUAL
WASHING
MACHINE
Before beginning installation, read these instructions
carefully. This will simplify installation and ensure that the
product is installed correctly and safely. Leave these
instructions near the product after installation for future
reference.
EN ENGLISH
F4V310*N* F4V309*N* F4V308*N*
MFL71438443
Rev.02_061220
Copyright © 2020 LG Electronics Inc. All Rights Reserved.
www.lg.com
Advertisement
Table of Contents
Related Manuals for LG F4V310 N Series
Summary of Contents for LG F4V310 N Series
- Page 1 This will simplify installation and ensure that the product is installed correctly and safely. Leave these instructions near the product after installation for future reference. EN ENGLISH F4V310*N* F4V309*N* F4V308*N* www.lg.com MFL71438443 Rev.02_061220 Copyright © 2020 LG Electronics Inc. All Rights Reserved.
-
Page 2: Table Of Contents
Adding Detergents and Softeners ..............21 Control Panel ....................24 Programme Table ....................27 Extra Options and Functions ................32 SMART FUNCTIONS LG ThinQ Application ..................35 Smart Diagnosis ....................35 MAINTENANCE Cleaning After Every Wash................37 Cleaning the Appliance Periodically & Performing an Emergency Water Evacuation......................38 TROUBLESHOOTING Before Calling for Service................41... - Page 3 APPENDIX Product Fiche....................49...
-
Page 4: Safety Instructions
SAFETY INSTRUCTIONS SAFETY INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE USE The following safety guidelines are intended to prevent unforeseen risks or damage from unsafe or incorrect operation of the appliance. The guidelines are separated into ‘WARNING’ and ‘CAUTION’ as described below. Safety Messages This symbol is displayed to indicate matters and operations that can cause risk. - Page 5 SAFETY INSTRUCTIONS • Children of less than 3 years should be kept away unless continuously supervised. • If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. •...
- Page 6 SAFETY INSTRUCTIONS • Do not modify the power plug provided with the appliance. If it does not fit the power outlet, have a proper outlet installed by a qualified electrician. • This appliance is equipped with a power cord having an equipment- earthing / grounding conductor (earthing pin) and a grounding power plug.
- Page 7 • Do not touch the door during a high temperature programme. • In case of a water leak from the appliance or flood, disconnect the power plug and contact the LG Electronics customer information centre. • Turn off water taps to relieve pressure on hoses and valves and to minimize leakage if a break or rupture should occur.
- Page 8 • Only qualified service personnel from LG Electronics service centre should disassemble, repair, or modify the appliance. Contact an LG Electronics customer information centre if you move and install the appliance in a different location.
-
Page 9: Caring For The Environment
• You can take your appliance either to the shop where you purchased the product, or contact your local government waste office for details of your nearest authorised WEEE collection point. For the most up to date information for your country, please see www.lg.com/global/recycling. -
Page 10: Installation Parts And Specifications
INSTALLATION INSTALLATION Parts and Specifications NOTE • Appearance and specifications may change without notice to improve the quality of the appliance. Front View Rear View a Control Panel a Power Plug b Detergent Dispenser Drawer b Transit Bolts c Drum c Drain Hose d Door e Cover Cap... - Page 11 INSTALLATION Accessories *1: The included accessories vary depending on the model you purchased. Cold Supply Hose Anti–slip Sheets*1 Spanner Elbow Bracket for Securing Drain Hose Caps for Covering Transit Bolt Tie Strap Holes Specifications Model F4V310*N* F4V309*N* F4V308*N* Power Supply 220‒240 V~, 50 Hz Product Weight 66 kg...
-
Page 12: Installation Place Requirements
INSTALLATION Installation Place or floor moldings that may increase the required clearances. Requirements Before installing the appliance, check the following information to make sure that the appliance should be installed in a correct place. Installation Location • This appliance must be installed on firm flooring to minimize vibration during the spin cycle. - Page 13 • Power outlet must be within 1 meter of either side of the appliance. NOTE WARNING • You can purchase rubber cups (part No. 4620ER4002B) from the LG service • Repairs to the appliance must only be centre. carried out by qualified personnel. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning.
-
Page 14: Unpacking The Appliance
INSTALLATION Unpacking the fully loosen all transit bolts by turning them counterclockwise. Appliance Lifting the Appliance Off the Foam Base * This feature may vary depending on the model purchased. After removing the carton and shipping material, lift the appliance off the foam base. -
Page 15: Levelling The Appliance
• Do not install the washing machine on diagonally, adjust the feet again. a plinth, stand or elevated surface unless it is manufactured by LG • Check whether the appliance is Electronics for use with this model. perfectly level after installation. -
Page 16: Connecting The Water Supply Hose
NOTE excessive vibration. Incorrect levelling • Additional anti-slip sheets are available may cause malfunction through noise at LG Electronics service centre. and vibration. If this occurs, install the anti-slip sheets under the levelling feet and adjust the level. Clean the floor to attach the anti-slip Connecting the Water sheets. - Page 17 INSTALLATION • No further backflow protection NOTE required for connection to the water inlet. • After connecting the water inlet hose to the water tap, turn on the water tap to flush out foreign substances (dirt, sand, sawdust, and etc.) in the water Checking the Rubber Seal lines.
-
Page 18: Installing The Drain Hose
INSTALLATION Installing the Drain • When installing the drain hose to a sink, secure it tightly with string. Hose Installing the Drain Hose with the Elbow Bracket The drain hose should not be placed higher than 100 cm above the floor. Water in the appliance may not drain or may drain slowly. -
Page 19: Operation Operation Overview
OPERATION OPERATION Operation Overview • Remove items from the flexible door seal gasket to prevent clothing and door seal damage. Using the Appliance Before the first wash, select the Cotton wash programme and add a half amount of the detergent. Start the appliance without clothes. -
Page 20: Preparing The Wash Load
OPERATION Checking the Clothes Care Label appliance will shut off and all settings will be lost. The symbols tell you about the fabric content of your garment and how it End of cycle. should be washed. • When the cycle is finished, a melody Symbols on the Care Labels will sound. -
Page 21: Adding Detergents And Softeners
OPERATION keys can damage both your appliance • Do not use liquid detergent if you are and clothes. using the Delay End function, or if you have selected Pre Wash option, as the liquid will dispense immediately and may harden in the drawer or the tub. •... - Page 22 OPERATION Using the Dispenser Either powdered or liquid fabric softener may be used. To add detergent dosage to the • Pour fabric softer to the maximum fill dispenser: line. Pouring excessive fabric softener over the maximum fill line can cause it Open the dispenser drawer.
- Page 23 OPERATION Adding Detergent Tablets Detergent tablets can also be used when washing. Open the door and put detergent tablets into the drum before loading the clothes. Load the clothes into the drum and close the door. NOTE • Do not put tablets into the dispenser. Adding Water Softener A water softener, such as anti-limescale can be used to cut down on the use of...
-
Page 24: Control Panel
OPERATION Control Panel The actual control panel may differ from model to model. Control Panel Features Description Power On/Off Button • Press this button to turn the washing machine on. Programme Knob • Programmes are available according to the clothes type. •... - Page 25 OPERATION Description Display • The display shows the settings, estimated remaining time, options, and status messages. When the appliance is turned on, the default settings in the display will illuminate. • While the load weight is sensed automatically, the display on the control panel blinks.
- Page 26 OPERATION Description Estimated Time Remaining • When a washing programme is selected, the default time for that programme is displayed. This time will change as options are selected. • If the display shows , then the time will be displayed after the load sensing has detected the load size.
-
Page 27: Programme Table
OPERATION Programme Table Washing Programme Cotton 40 °C (Cold to 95 °C) Max. Load: Rating Description Washes normally soiled clothes by combining various drum motions. • Pressing the Start/Pause button without selecting a programme will cause the Cotton programme to begin immediately, using the default settings. - Page 28 OPERATION Delicates 20 °C (Cold to 40 °C) Max. Load 3 kg Description Washes machine-washable lingerie, sheer and lacy clothes. Hand/Wool 30 °C (Cold to 40 °C) Max. Load 2 kg Description Washes hand-washable and machine-washable delicate clothes such as washable wool, lingerie, dresses etc. •...
- Page 29 OPERATION • Select the proper wash temperature and spin speed for the desired programmes. • Actual water temperature may differ from the declared cycle temperature. • Neutral detergent is recommended. Extra Options *1:This option is automatically inserted in the programme and can not be deselected. NOTE •...
- Page 30 OPERATION Selectable Maximum Spin Speed Spin Speed Programme Default Available Cotton 1400 rpm Eco 40-60 1400 rpm Mixed Fabric 1000 rpm Easy Care 1400 rpm Silent Wash 800 rpm Up to 1000 rpm Hygiene 1400 rpm Baby Care 1000 rpm Up to 1000 rpm Delicates 800 rpm...
- Page 31 OPERATION Consumption Data of Standard Programme F4V310*N* Residual Program Temp. Duration Energy Load (kg) Water (L) moisture (°C) (h:mm) (kWh) 10.5 4:52 0.670 Eco 40-60 5.25 4:18 0.630 Intensive 5.25 4:08 0.560 F4V309*N* Residual Program Temp. Duration Energy Load (kg) Water (L) moisture (°C)
-
Page 32: Extra Options And Functions
OPERATION Extra Options and Intensive This function is used to wash normal and Functions heavily soiled clothes. • Press the Intensive button. You can use the extra options and functions to customize the programmes. Follow the next steps to customise a Customising a Washing washing programme: Programme... - Page 33 OPERATION If this occurs, press Power button Close the door and press the Start/ twice to cycle the machine off and back Pause button. NOTE • For safety reasons, the door remains locked when the water level or Using Basic Options temperature inside of the drum is high.
- Page 34 OPERATION changing cycles or operating the appliance. NOTE • Once this function is set, all buttons are locked except the Power button. • When the controls are locked, the remaining time are alternatively shown on the display during the wash while this function is engaged.
-
Page 35: Smart Functions
LG ThinQ Application • The feature may be subject to change without prior notice and may have a different form depending on where The LG ThinQ application allows you to you are located. communicate with the appliance using a smartphone. - Page 36 SMART FUNCTIONS After the data transfer is complete, the diagnosis will be displayed in the application. NOTE • For best results, do not move the smartphone while the tones are being transmitted.
-
Page 37: Maintenance
MAINTENANCE MAINTENANCE WARNING • Unplug the appliance before cleaning to avoid the risk of electric shock. Failure to follow this warning may result in serious injury, fire, electric shock, or death. • Never use harsh chemicals, abrasive cleaners, or solvents to clean the appliance. They may damage the finish. -
Page 38: Evacuation
MAINTENANCE Cleaning the Appliance Press the Start/Pause button to start. Periodically & Performing an Leave the door open to dry the inside of the appliance completely. Emergency Water • When the inside of the appliance is Evacuation not dried completely, it may cause a bad smell or mildew. - Page 39 MAINTENANCE Remove the water inlet filter with water and then proceed to remove small pliers and then clean the filter any debris or objects from the filter. using a medium bristle tooth brush. After cleaning the drain pump filter, carefully reinsert the filter and screw Cleaning the Drain Pump Filter the drain cap back in clockwise and Performing an Emergency...
- Page 40 MAINTENANCE • Then gently pull the drawer outward while pressing hard the disengage button. Remove the build-up of detergent and softener. • Rinse the drawer and the components of the drawer with warm water to remove the build-up from detergent and softener. Use only water to clean the dispenser drawer.
-
Page 41: Troubleshooting
Your appliance is equipped with an automatic error-monitoring system to detect and diagnose problems at an early stage. If the appliance does not function properly or does not function at all, check the following tables before calling to LG Electronics service centre. - Page 42 • Check and clean the drain filter. Door sensor malfunctions. dE dE1 dEz dE4 • Please call LG service centre. You can find your local LG DOOR ERROR service centre phone number in the warranty card. This is a control error.
- Page 43 TROUBLESHOOTING Symptoms Possible Cause & Solution Is supply/drain hose or drain pump frozen? • Supply warm water into the drum in order to unfreeze the FROZEN FAILURE drain hose and the drain pump. Cover the supply hose with wet and warm towel. Water leaks.
- Page 44 TROUBLESHOOTING Symptoms Possible Cause & Solution Vibrating noise Package materials are not removed. • Remove package materials. The clothes may be unevenly distributed in the drum. • Pause the programme and redistribute the clothes after the door unlocks. Not all levelling feet are resting firmly and evenly on the floor.
- Page 45 TROUBLESHOOTING Symptoms Possible Cause & Solution Appliance does Control panel has powered off due to inactivity. not operate. • This is normal. Press the Power button to turn the appliance on. Appliance is unplugged. • Make sure that the cord is plugged securely into a working outlet.
- Page 46 TROUBLESHOOTING Symptoms Possible Cause & Solution Door does not The door cannot be opened for safety reasons once the open. appliance starts. • This is normal. You can safely open the door after turns off. Appliance is not Inlet filter clogged. filling properly.
- Page 47 TROUBLESHOOTING Symptoms Possible Cause & Solution Cycle end is Unbalance is detected or suds removing programme is delayed • This is normal. The time remaining shown on the display is only an estimated duration. Actual time may vary. Performance Symptoms Possible Cause &...
- Page 48 TROUBLESHOOTING Symptoms Possible Cause & Solution Wrinkling Appliance is not unloaded promptly. • Always remove items from the appliance as soon as the programme is complete. Appliance is overloaded. • The appliance can be fully loaded, but the drum should not be tightly packed with items.
- Page 49 APPENDIX APPENDIX Product Fiche Commission Delegated Regulation (EU) No 1061/2010 Asterisk(s) means model variant and can be varied (0-9) or (A-Z). F4V310*N* F4V309*N* F4V308*N* Rated capacity 10.5 kg 9 kg 8 kg Energy efficiency class on a scale from D A+++ A+++ A+++...
- Page 50 APPENDIX F4V310*N* F4V309*N* F4V308*N* Programme time of the standard programme • The standard 60 °C cotton programme at full load (min.) • The standard 60 °C cotton programme at partial load (min.) • The standard 40 °C cotton programme at partial load (min.) •...
- Page 51 Memo...
- Page 52 ＠ Life ' s Good...
