- Page 1 Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Asus ROG GM501GS EI003T cerca il tuo prodotto tra le migliori offerte di Notebook E13603 First Edition / February 2018 G Series GAMING NOTEBOOK PC...
-
Page 2: Top View
Top View NOTE: • The keyboard’s layout may vary per region or country. The Notebook view may also vary in appearance depending on the Notebook PC model. • Closing the lid when the system is under high load forces your Notebook PC to go into sleep mode to prevent overheating. Array microphones Camera indicator Camera Display panel Status indicators Air vents Power button Airplane mode indicator Numeric keypad Keyboard Touchpad Capital lock indicator Notebook PC User Guide... -
Page 3: Getting Started
I/O ports and slots USB 3.1 Gen 2 port Power (DC) input port USB 3.1 Gen 2 Type-C™/Thunderbolt 3 HDMI port combo port Security slot USB 3.1 Gen 2 port with USB Charger+ Headphone/Headset/Microphone jack Getting started 1. Charge your Notebook PC A. Connect the DC power connector into your Notebook PC’s power (DC) input port. B. Plug the AC power adapter into a 100V~240V power source. NOTE: The power adapter may vary in appearance, depending on models and your region. Charge the Notebook PC for 3 hours before using it in battery mode for the first time. 2. Lift to open the display panel 3. - Page 4 Maintaining your Notebook PC Removing the bottom cover for cleaning WARNING! Turn off your Notebook PC and disconnect all connected peripherals before removing the bottom cover. Do not turn on your Notebook PC before reattaching the bottom cover. Remove the screws from the Notebook PC’s bottom cover. Lift your display panel half-open and position your Notebook PC as shown below. Face the bottom cover and firmly hold both sides of your Notebook PC. Notebook PC User Guide...
- Page 5 Use your thumbs to slightly slide the bottom cover upwards and firmly press on the top corners until the bottom part pops open. Pull out the bottom cover and remove it completely from your Notebook PC. Notebook PC User Guide...
- Page 6 To reattach the bottom cover: Align and hook the bottom cover to your Notebook PC as shown below. Adjust the bottom cover to ensure the clips are inserted in place. Close your display panel. Notebook PC User Guide...
- Page 7 Secure the bottom cover using the screws you removed earlier. Notebook PC User Guide...
- Page 8 • When using your Notebook PC on power adapter mode, the socket outlet must be near to the unit and easily accessible. • Locate the input/output rating label on your Notebook PC and ensure that it matches the input/output rating information on your power adapter. Some Notebook PC models may have multiple rating output currents based on the available SKU. • Power adapter information: - Input voltage: 100-240Vac - Input frequency: 50-60Hz - Rating output current: 9.23A (180W) / 11.8A (230W) - Rating output voltage: 19.5V WARNING! Read the following precautions for your Notebook PC’s battery: • Only ASUS-authorized technicians should • Never attempt to short-circuit your remove the battery inside the device Notebook PC’s battery. (for non-removable battery only). • Never attempt to disassemble and • The battery used in this device may present reassemble the battery a risk of fire or chemical burn if removed or (for non-removable battery only). disassembled. • Discontinue usage if leakage is found. • Follow the warning labels for your personal • This battery and its components must be...
-
Page 9: Avis Concernant Les Batteries Remplaçables
Avis concernant les batteries remplaçables • La batterie de l’appareil peut présenter un • La batterie et ses composants doivent risque d’incendie ou de brûlure si celle-ci est être recyclés de façon appropriée. retirée ou désassemblée. Copyright Information You acknowledge that all rights of this Manual remain with ASUS. Any and all rights, including without limitation, in the Manual or website, are and shall remain the exclusive property of ASUS and/or its licensors. Nothing in this Manual intends to transfer any such rights, or to vest any such rights to you. ASUS PROVIDES THIS MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND. SPECIFICATIONS AND INFORMATION CONTAINED IN THIS MANUAL ARE FURNISHED FOR INFORMATIONAL USE ONLY, AND ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE, AND SHOULD NOT BE CONSTRUED AS A COMMITMENT BY ASUS. Copyright © 2018 ASUSTeK COMPUTER INC. All Rights Reserved. Limitation of Liability Circumstances may arise where because of a default on ASUS’ part or other liability, you are entitled to recover damages from ASUS. In each such instance, regardless of the basis on which you are entitled to claim damages from ASUS, ASUS is liable for no more than damages for bodily injury (including death) and damage to real property and tangible personal property; or any other actual and direct damages resulted from omission or failure of performing legal duties under this Warranty Statement, up to the listed contract price of each product. ASUS will only be responsible for or indemnify you for loss, damages or claims based in contract, tort or infringement under this Warranty Statement. -
Page 10: Asus Recycling/Takeback Services
ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials. Please go to http://csr.asus.com/english/Takeback.htm for detailed recycling information in different regions. FCC Radio Frequency (RF) Exposure Caution Statement WARNING! Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. “The manufacture declares that this device is limited to Channels 1 through 11 in the 2.4GHz frequency by specified firmware controlled in the USA. ” This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. To maintain compliance with FCC RF exposure compliance requirements, please avoid direct contact to the transmitting antenna during transmitting. End users must follow the specific operating instructions for satisfying RF exposure compliance. UL Safety Notices • DO NOT use the Notebook PC near water, for example, near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet basement or near a swimming pool. • DO NOT use the Notebook PC during an electrical storm. There may be a remote risk of electric shock from lightning. • DO NOT use the Notebook PC in the vicinity of a gas leak. • DO NOT dispose the Notebook PC battery pack in a fire, as they may explode. Check with local codes for possible special disposal instructions to reduce the risk of injury to persons due to fire or explosion. -
Page 11: Global Environmental Regulation Compliance And Declaration
Global Environmental Regulation Compliance and Declaration ASUS follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASUS product is in line with global environmental regulations. In addition, ASUS disclose the relevant information based on regulation requirements. Please refer to http://csr.asus.com/english/Compliance.htm for information disclosure based on regulation requirements ASUS is complied with: Japan JIS-C-0950 Material Declarations, EU REACH SVHC, Korea RoHS. Regional notice for Singapore This ASUS product complies with IMDA Standards. Complies with IMDA Standards DB103778 Regional notice for California WARNING Cancer and Reproductive Harm - www.P65Warnings.ca.gov Notebook PC User Guide... -
Page 12: Coating Notice
Coating Notice IMPORTANT! To provide electrical insulation and maintain electrical safety, a coating is applied to insulate the device except on the areas where the I/O ports are located. Power Safety Requirement Products with electrical current ratings up to 6A and weighing more than 3Kg must use approved power cords greater than or equal to: H05VV-F, 3G, 0.75mm or H05VV-F, 2G, 0.75mm REACH Complying with the REACH (Registration, Evaluation, Authorization, and Restriction of Chemicals) regulatory framework, we publish the chemical substances in our products at ASUS REACH website at http://csr.asus.com/english/REACH.htm. Notebook PC User Guide... -
Page 13: Prevention Of Hearing Loss
Prevention of Hearing Loss To prevent possible hearing damage, do not listen at high volume levels for long periods. Simplified EU Declaration of Conformity ASUSTek Computer Inc. hereby declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 2014/53/EU. Full text of EU declaration of conformity is available at https://www.asus.com/support/. The WiFi operating in the band 5150-5350 MHz shall be restricted to indoor use for countries listed in the table below: Notebook PC User Guide... -
Page 14: Red Rf Output Table
RED RF Output table Intel 9560 Function Frequency Maximum Output Power (EIRP) 2413 - 2471 MHz 17.41 dBm 5150 - 5350 MHz 17.49 dBm WiFi 5470 - 5725 MHz 15.46 dBm 5725 - 5850 MHz 4.46 dBm Bluetooth 2413 - 2471 MHz 11.2 dBm Intel 9260 Function Frequency Maximum Output Power (EIRP) 2413 - 2471 MHz 17.41 dBm 5150 - 5350 MHz 17.28 dBm WiFi 5470 - 5725 MHz 15.46 dBm 5725 - 5850 MHz 4.3 dBm Bluetooth 2413 - 2471 MHz... -
Page 15: Federal Communications Commission Interference Statement
• Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced radio/TV technician for help. FCC COMPLIANCE INFROMATION Per FCC Part 2 Section 2.1077 Asus Computer International Responsible Party: Address: 800 Corporate Way, Fremont CA 94539. Phone/Fax No: (510)739-3777/(510)608-4555 hereby declares that the product Product Name :... - Page 16 15060-0JC00000 Notebook PC User Guide...
- Page 17 GM501G 使用机种 15060-0JC00000 ASUS料号 1506-174J000 PEGA料号 E13603 GM501G User's 品名规格 Manual-LC//V1.0 封面封底128G铜版纸+封面封底哑油 材质 内页80G模造纸 封底封面满版4C内BK 颜色 骑马钉 加工方式 4+12P 页数 成品 105*148 mm (±2mm) 尺寸 箱 出货方式...
