2
Remove the two screws on the top of the
unit.
3
Remove the mounting sleeve with the sup-
plied disassembly tools.
4
Ensure that car dashboard opening is within
these measurements.
5
Install the sleeve into the dashboard and
bend the tabs outward to fix the sleeve.
6
Place the supplied rubber cushion over the
end of the mounting bolt.
7
Slide the unit into the dashboard until you
hear a click sound.
8
Reconnect the negative terminal of the car
battery.
Attach the front panel 6
1
Attach the trim plate to the main unit.
2
Insert the right side of the panel in the
chassis until it is correctly engaged.
3
Push the left side of the panel and point the
left hole at the left pillar.
4
Release the panel to engage the left side.
5
Push the front side of the panel backward to
the main unit a "click" is heard.
Turn on
1
Press
to turn on the unit.
•
To turn off the unit, press
for 3 sec-
onds.
Set clock
1
Press MENU repeatedly until [TIME FOR-
MAT] (time format)displays.
2
Use rotary encoder knob to toggle the set-
tings:
•
[TIME FORMAT 12H]
•
[TIME FORMAT 24H]
3
Press
or
repeatedly until [CLOCK SET]
(clock set) displays.
Hour digits blinks
»
4
Set hour with rotary encoder knob.
5
Press OK/MUTE to confirm.
Minute digits blinks
»
6
Set minute with rotary encoder knob.
7
Press
to confirm clock set and exit the
menu.
Listen to radio
1
Press SOURCE repeatedly to select [Radio].
2
Press
or
to select band: [FM1], [FM2],
[FM3], [AM1], or [AM2] .
3
Press
or
to tune to a radio station
manually.
The radio station is broadcast.
»
Play with RDS
The RDS (Radio Data System) function operates
only in areas with FM stations broadcasting RDS
signals. If you tune to an RDS station, an RDS icon
and information about the presenter, station or
program is displayed.
Turn on RDS
Note
By default, the RDS function is off.
•
•
To adjust the RDS function, the unit
must be
under Radio playback mode.
1
Press MENU for 3 seconds.
2
Rotate encoder knob to select [RDS ON]:
•
To turn off the RDS function, repeat
steps above and choose [RDS OFF].
