Summary of Contents for CDA CI230
-
Page 3: Table Of Contents
washing machine WARNINGS SPECIFICATIONS INSTALLATION AND ASSEMBLY USING THE APPLIANCE. PRACTICAL TIPS MAINTENANCE AND CLEANING SAFETY AND TROUBLESHOOTING ENVIRONMENTAL WARNINGS contents... -
Page 4: Warnings
warnings To avoid the risk of fire, electric shocks, injury or damage when using your washing machine, please take the following precautions: This washing machine comes with a manual that includes operating, maintenance and installation instructions. Please read all the instructions before using the washing machine. -
Page 5: Specifications
washing machine specifications Power cord Drain hose Control panel Detergent dispenser Stainless steel drum Hatch Accessible filter Adjustable feet ACCESSORIES Water inlet hose. -
Page 6: Installation And Assembly
washing machine installation and assembly UNPACKING AND UNBLOCKING THE WASHING MACHINE UNPACKING a Remove the base, corner protectors and top cover. UNBLOCKING a Remove the screws holding the plastic covers to the back of the washing machine. b Loosen and remove the 3 blocking screws. - Page 7 CONNECTION TO THE MAINS WATER SUPPLY AND DRAINAGE CONNECTION TO THE MAINS WATER SUPPLY The water supply hose is inside the drum: a Connect the bent end of the hose to the threaded inlet of the electrovalve located at the rear of the washing machine. b Connect the other end of the hose to the water intake.
- Page 8 LEVELLING THE WASHING MACHINE AND CONNECTING IT TO THE MAINS ELECTRICITY SUPPLY LEVELLING Use the adjustable feet to level the washing machine. This will reduce the noise level and prevent it from moving during use. Do not bring the feet too far out, you will achieve better stability.
- Page 9 PRE-CLEANING PRE-CLEANING When your washing machine has been correctly installed, we recommend that you pre-clean the machine. This is to check that the installation, the connections and the drainage are all correct, and to thoroughly clean the inside of the washing machine before any wash programmes are run (see the operating instructions on the following pages).
-
Page 10: Practical Tips
washing machine using the appliance and practical tips PREPARING GARMENTS FOR WASHING PREPARATION Before placing the clothes in the drum, make sure all the pockets are empty. Any small objects may block the drain pump. SORTING THE CLOTHES a Sort the clothes according to fabric and how they are made: We recommend using the delicate programmes for sensitive fabrics. - Page 11 USING DETERGENT AND ADDITIVES DETERGENT AND ADDITIVES a Your washing machine’s detergent dispenser has three compartments. b Put the detergent or additive into the detergent dispenser before starting the wash programme. c Liquid detergents may also be used in this washing machine. The level of liquid must never be higher than the MAX mark printed on the dispenser wall.
-
Page 12: Selecting The Wash Programme
SELECTING THE WASH PROGRAMME detergent dispenser The procedure for selecting the wash programme is as follows: a Activate the programme selector by pressing it to release it. b Select the wash programme by turning the programme selector dial (see programme table). The display on the control panel will light using the appliance and practical tips start/... - Page 13 When you select the programme, the following information will be displayed: 1 Wash programme phases: Prewash Wash Rinse Spin-drying and draining 2 Spin speed 3 Programme nº (for a few seconds) and then programme duration. 4 Additional functions Easy iron Extra rinse Intensive wash There are four types of programme:...
- Page 14 Recommended Programme temperature Normal cold Cold Quick 30ºC Normal 30ºC Normal 40ºC 5 (*) Normal 60ºC Normal 90ºC Prewash 60ºC Delicate cold Cold Delicate 30ºC — Delicate 40ºC — Delicate 60ºC — Wool 35ºC WOOL 35 Rinses Spin-drying Draining Programme for wash and energy consumption assessment in accordance with standard EN60456, press intensive wash button.
- Page 15 Max load Wash product of clothes compartment (Kg) NOTE: the KWh and litre consumptions and programme durations may vary depending on the type and amount of clothes, mains water pressure, etc. Programme description Normal wash, rinses, fabric conditioner if desired and long final spin SHORT wash, rinses, fabric conditioner if desired and long final spin...
-
Page 16: Spin Speed Selection
SPIN SPEED SELECTION SPIN-DRYING The wash options must always be selected after choosing the wash programme. Any programme change during selection cancels the previously selected options. a Spin speed selection and anti-crease button The selected programme has its own particular spin speed. b You can change it by repeatedly pressing the spin button. -
Page 17: Additional Functions
DELAY TIME SELECTION AND ADDITIONAL FUNCTIONS DELAY TIME Delay time selection button A delay of up to 24 hours can be selected. The delay must be selected after choosing the wash programme. To select the hours of delay, press the clock button. - Page 18 STARTING UP AND LOCK FUNCTION SELECTION STARTING UP Start/Stop button a To start up the washing machine you have to press the Start/Stop button. The minutes remaining until the end of washing and drying will appear on the display at all times. LOCK FUNCTION Lock function selection The lock function ensures that the programme...
- Page 19 Pressing the delay button during washing will have no effect on the washer. Pressing the Start/Stop button during the wash activates the PAUSE function. POWER CUTS...
-
Page 20: Maintenance And Cleaning
washing machine maintenance and cleaning MAINTENANCE After each wash, leave the door open for a while to allow the air to circulate freely inside the machine. From time to time, depending on the hardness of your water, it is recommendable to run a full wash cycle using a decalcifying product. - Page 21 CLEANING THE ACCESSIBLE FILTER AND THE OUTSIDE CLEANING THE FILTER Clean the accessible filter if the drain pump is blocked by any foreign objects. a Use a coin to turn the filter cap. b Pull out the filter cap. c Place a container under the drain pump filter to collect any water that comes out of it.
-
Page 22: Safety And Troubleshooting
If this is not the case, unplug the appliance and contact CDA CUSTOMER CARE. Do not open up the washing machine. It does not contain any fuses or... - Page 23 Why doesn’t the washing machine take in water? Why doesn’t the washing machine drain or spin-dry? Why doesn’t the washing machine spin-dry? Why can’t I see any water in the drum during the wash? safety and troubleshooting If no water is entering, F01 will appear on the display. Indicator F01, no water coming in, this may be due to a cut in the water supply, a tap turned off or a blocked water inlet filter.
- Page 24 This is why the hatch cannot be opened for 2 minutes. The washing machine can detect other indications. When this happens a number of other indicators appear on the display: F05, F06..., F10. If this happens, call CDA Customer Care.
-
Page 25: Environmental Warnings
eco-note INFORMATION FOR THE CORRECT DISPOSAL OF WASTE ELECTRICAL AND ELECTRONIC APPLIANCES When your appliance is of no further use, it should not be disposed of together with general domestic waste. It can be taken, free of charge, to a specific waste collection centre, run by your local authority, or dealers who provide this service. - Page 28 04/07 LJ6A030Q9...
