Important Notice
User Manual
Startup manual gives you infor-
mation of installation, prepara-
tion of the main unit and basic
operation.
Copyright© 1999
CAT EYE Co., Ltd.
3
MSC2DxUE-000703
INTRODUCTION
Thank you very much for purchasing the CAT EYE MSC-2Dx. The MSC-2Dx is a multi sports
computer that combines the functions of a wireless heart rate monitor and a wired
Cyclocomputer. Our race proven Cyclocomputer technology and the double pulse heartrate
system enables you to monitor, track and record your training and racing like never before.
The recorded data can be downloaded to a PC by using the optional download unit.
Please read this manual to gain a thorough understanding of the product and how it works.
Please keep this manual in a safe place.
If this manual is damaged or lost, contact our offices, your local dealer or www.cateye.com.
Important
• Always follow the warnings that are marked with
• No part of this manual may be reproduced or transmitted without the prior written permis-
sion of Cat Eye Co., Ltd.
• The contents and illustrations in this manual are subject to change without notice.
• If there should be any errors or inaccuracies in this manual, please contact Cat Eye at
www.cateye.com.
Warning!!!.
* Windows is a registered trademark of Microsoft Corporation.
E
1
MSC-2Dx
