- Page 1 HI9813-51 & HI9813-61 Portable pH / EC / TDS / Temperature Meters...
- Page 2 All rights are reserved. Reproduction in whole or in part is prohibited without the written consent of the copyright owner, Hanna Instruments Inc., Woonsocket, Rhode Island, 02895, USA.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1. Preliminary Examination ............4 2. General Description ..............4 3. Functional Description & LCD Display ........5 4. Specifications ................. 7 5. General Operations ..............9 5.1. Battery Replacement ............ 9 5.2. Connecting the Electrode ..........9 5.3. -
Page 4: Preliminary Examination
Each instrument is delivered in a rugged carrying case and supplied with: • HI1285-51 pH / EC / TDS / Temperature combination probe with DIN connector with 1 m (3.3’) cable (HI9813-51) • HI1285-61 pH / EC / TDS / Temperature combination probe with CAL Check™... -
Page 5: Functional Description & Lcd Display
3. FUNCTIONAL DESCRIPTION & LCD DISPLAY HI9813-51 Dip probe in calibration solution and turn the knob to match the solution value for current temperature HI9813-51 On/Off mS/cm °C 1. 8-pin DIN connector socket 2. Battery-level indicator 3. LCD display 4. On-screen calibration knob indicator 5. - Page 6 HI9813-61 Dip probe in Dip probe in CAL - CHECK calibration solution and solution and turn press the knob to match the solution value HI9813-61 On/Off mS/cm Check °C 1. 8-pin DIN connector socket 2. Battery-level indicator 3. LCD display 4.
-
Page 7: Specifications
(based on 442 curve for natural water) Temperature Range* 0.0 to 70.0 °C Resolution 0.1 °C Accuracy ±0.5 °C HI1285-51 HI9813-51 Probe (included) HI1285-61 HI9813-61 Battery life Approximately 150 hours of continuous use Auto shut-off After 8 minutes of non-use Battery type... - Page 8 Probe Reference Single, Ag/AgCl Junction Cloth Electrolyte Max. Pressure 0.1 bar pH: 0 to 13 Range EC: 0 to 6 mS/cm Temperature: 0 to 50°C (32 to 122°F) Tip Shape Spheric, Ø 8.0 mm (0.31”) Glass Type LT (low temperature) Temperature Sensor Yes Amplifier Body Material...
-
Page 9: General Operations
5. GENERAL OPERATIONS 5.1. BATTERY REPLACEMENT To replace the batteries, follow the next steps: • Turn OFF the instrument. • Remove the three screws on the back of the instrument to open the battery compartment. • Remove the old battery. •... -
Page 10: Calibration
6. CALIBRATION 6.1. pH For high accuracy, frequent calibrations are recommended. Additionally, the pH range should be recalibrated: • Whenever the electrode is replaced. • At least once a month. • After testing aggressive chemicals. • If HI9813-61 does not pass CAL Check test Preparation Recommended pH calibration standard buffers: pH 4.01, 6.86 (NIST), 7.01, 9.18 (NIST), 10.01. -
Page 11: Ec / Tds
6. Rotate the EC/TDS calibration knob until reading is displayed at 25 °C. EC/TDS Conversion Factor HI9813-51 HI9813-61 have a variable TDS conversion factor, automatically adjusted from 0.56 to 0.78 based on actual EC readings (based on 442 curve for natural water). -
Page 12: Measurement
7. MEASUREMENT 7.1. pH • Immerse the probe tip 4 cm (1 1/2”) into the sample. • Press pH key to select pH measurement mode. • Stir briefly and wait a few minutes for the measurement to stabilize. Screens from DY9812 Measured pH value is displayed on the screen. -
Page 13: Temperature
7.3. TEMPERATURE • Immerse the tip of the probe 4 cm (1 1/2”) into the sample. • Press the °C (Temperature) key. • Stir briefly and wait a few minutes for the measurement to stabilize. 9813V3 received from Mech. Read value is displayed on the LCD. Dip probe in - CHECK solution and... -
Page 14: Ph Values At Various Temperatures
pH VALUES AT VARIOUS TEMPERATURES 8. pH VALUES AT VARIOUS TEMPERATURES Temp pH Values °C °F 4.01 6.86 7.01 9.18 10.01 4.01 6.98 7.13 9.46 10.32 4.00 6.95 7.10 9.39 10.24 4.00 6.92 7.07 9.33 10.18 4.00 6.90 7.05 9.27 10.12 4.00 6.88... -
Page 15: Probe Maintenance
9. PROBE MAINTENANCE Periodic Maintenance Proper care and maintenance is essential for accurate readings. Cleaning, calibrating, and appropriate storage extends the life of the probe. • Inspect connector for corrosion and replace probe if necessary. • Inspect probe and cable for cracks or points of broken insulation. If any present, replace the probe. - Page 16 CAL Check™ & Cleaning (HI9813-61) To check meter’s calibration status: 1. Rinse the probe with water 2. Immerse the tip of the probe 4 cm (1 1/2”) into HI50021 calibration check solution. Note: A reading around pH 4.01 indicates that the probe is broken and requires replacement.
-
Page 17: Accessories
10. ACCESSORIES Ordering information Product description Probes Combination, amplified pH / EC / TDS/temperature probe HI1285-51 with built-in temperature sensor, 8-pin DIN connector and 1 m (3.3’) cable Combination, amplified pH / EC / TDS / temperature probe HI1285-61 with built-in temperature sensor, with CAL Check™... -
Page 18: Certification
Damage due to accidents, misuse, tampering, or lack of prescribed maintenance is not covered. ® If service is required, contact your local Hanna Instruments office. If under warranty, report the model number, date of purchase, serial number (engraved on the bottom of the meter), and the nature of the problem. - Page 19 ® Hanna Instruments reserves the right to modify the design, construction or appearance of its products without advance notice.
- Page 20 World Headquarters Hanna Instruments Inc. Highland Industrial Park 584 Park East Drive Woonsocket, RI 02895 USA www.hannainst.com MAN9813-61 Printed in ROMANIA...
