- Page 1 All manuals and user guides at all-guides.com e-HyperRim ALU series indoor bicycle trainer instructions manual - 1 -...
- Page 2 All manuals and user guides at all-guides.com SCHEMATIC HF-2 Screw-M SR-13 SR-12 HF-4 ER-16 ER-1 ER-10 SR-12 ER-7 M8-3 ER-8 ER-2 SR-5 Screw-L ER-12 SR-7 ER-17 SR-8 ER-14 ER-18 ER-11 ER-13 Screw-S Screw w/ washer ER-9 ER-15 ER-6 Screw-M <Remote Version> F-1 : Coupling (Right) ER-1 :...
-
Page 3: Important Notes
• The trainer is manufactured to precise standards. You may not disassemble or rebuild it. • "Magturbo" and “RDA” are the trademarks of Minoura Co.,Ltd. and may not be copied. • "Magturbo" and “RDA” are the trademarks of Minoura Co.,Ltd. and may not be copied. - Page 4 All manuals and user guides at all-guides.com HOW TO SETUP YOUR E-HYPER-RIM ALU TRAINER <Required Tools: M5 hex wrench> Open the frame support leg fully and place it on the flat and level floor. Install the Mag resistance unit on the left side slot and the assistant roller on the right side slot beside the trainer pillar by the supplied M6x12 bolts.
- Page 5 The right side coupling has a black plastic skewer nut protector (called a “Grommet”). This is to protect your skewer from damage during use. Minoura cannot guarantee compatibility with all makes and models of skewer, however when using your own skewer please use the supplied grommet.
- Page 6 All manuals and user guides at all-guides.com HOW TO INSTALL THE REMOTE LEVER You can install the remote lever on anywhere the diameter is between 22.2mm (7/8”) and 31.8mm (1-1/4”) like as on the handlebar. Fully loosen the knob bolt on the plastic holder until it stops then push down the bolt to open the holder. (see Fig.
- Page 7 This work requieres high skill for disassembling and assembling the Mag unit. If you don’t have confidence, please ask to the Minoura dealer where you purchased the trainer. The instructions manual will come with the replacement V-belt kit, also you can download it from our web site (http://www.minoura.jp).
- Page 8 Fax +81-584-27-7505 / E-mail: minoura@minoura.jp http://www.minoura.jp MINOURA NORTH AMERICAN WARRANTY CENTER MINOURA NORTH AMERICAN WARRANTY CENTER MINOURA NORTH AMERICAN WARRANTY CENTER (for North American residents only) MINOURA NORTH AMERICAN WARRANTY CENTER MINOURA NORTH AMERICAN WARRANTY CENTER (for North American residents only)
