  • Page 2 In the attached Warranty Booklet you will also find a description of the Services that Fiat offers to its customers, the Warranty Certificate and the detail of the terms and conditions for maintaining its validity.
  • Page 3 Owner Handbook. Alternatively, to access this information, go to the Internet website at http://aftersales.fiat.com/elum/. The eLUM website is free and conveniently allows you to browse the on-board handbooks of all other models of the Group, among many other things.

  • Page 4: Table Of Contents

    CONTENTS VEHICLE INTERIOR ....5 VERSIONS WITH MECHANICAL CHILD RESTRAINT KEY ..........11 SYSTEMS ........17 MANUAL CLIMATE PASSENGER'S FRONT DIGITAL REAR-VIEW CONTROL SYSTEM ....6 AIRBAG AND CHILD RESTRAINT MIRROR ........12 SYSTEMS ........17 AUTOMATIC CLIMATE ELECTRIC PARKING BRAKE CONTROL SYSTEM ....6 TPMS (Tyre Pressure (EPB) ........12 Monitoring System) ....19 3.5”...
  • Page 5 REFUELLING ......34 SUPPLEMENTS UCONNECT™ 5 ......35 RADIO ..........35 FLAT-BED TIPPER....MEDIA ..........35 CONTROLS ON THE STEERING WHEEL E BEHIND THE STEERING WHEEL .......36 SHUTTLE........ PAIRING A MOBILE PHONE ..36 UCONNECT™ ......37 DPF - FORCED GRAPHIC BUTTONS ON REGENERATION ....DISPLAY ........37 TOUCHSCREEN FUNCTION ..37 USB SOURCE ......38 APPLE CARPLAY AND...

  • Page 6: Vehicle Interior

    VEHICLE INTERIOR (E) DISPLAY AND TELEPHONE COMMANDS Scroll the display menu Open information screens and submenus OK Open screens and confirm the settings Accept incoming calls Voice commands Refuse/end incoming call F1A0720 CONTROLS BEHIND THE LEFT (G) Uconnect™ F1A0719 SIDE OF THE STEERING WHEEL (H) CLIMATE CONTROL SYSTEM - top/bottom button: search (A) LEFT STALK (External lights)

  • Page 7: Manual Climate Control System

    MANUAL CLIMATE AUTOMATIC 3.5” DISPLAY CONTROL SYSTEM CLIMATE CONTROL SYSTEM F1A0051 F1A0721 (A) Swivel ring for air mix temperature setting (red = hot, blue = cold) AUTO Activation/deactivation of (B) Fan activation/setting knob automatic climate control system (0 = off, 1-2-3 ventilation speed, Windscreen heating FRONT 4 = maximum speed)

  • Page 8: 7" Display

    Contact a Fiat Dealership assistance device indications (**) Repair immediately using the (G) Red symbols ANTI-INTRUSION WARNING dedicated “Fix & Go Automatic” kit and contact a Fiat Dealership as soon as possible HANDS NOT DETECTED ON STEERING WHEEL AIRBAG FAILURE (*)

  • Page 9: Amber Warning Lights/Symbols

    AMBER WARNING Warning Warning Meaning Meaning LIGHTS/SYMBOLS light light LOW ENGINE OIL ESC-ASR (*)/ TRACTION Warning PRESSURE Meaning PLUS (*)/ HILL HOLDER (*) light SYSTEM FAILURE ALTERNATOR FAILURE (*) HANDS NOT DETECTED ON ESC-ASR / TRACTION PLUS STEERING WHEEL SYSTEM DEACTIVATION INCOMPLETE DOOR/LOAD EOBD/INJECTION SYSTEM COMPARTMENT CLOSURE...
  • Page 10 CLEANING underway FAILURE (*) POSSIBLE ICE ON ROAD AUTOMATIC HIGH BEAM ENGINE OIL PRESSURE HEADLIGHTS FAILURE (*) SENSOR FAILURE FIAT CODE SYSTEM FAILURE (*) RAIN SENSOR FAILURE (*) HILL DESCENT CONTROL (where provided) DUSK SENSOR FAILURE (*) FUEL CUT-OFF SYSTEM...

  • Page 11: Green Warning Lights/Symbols

    GREEN WARNING Warning Warning Meaning Meaning LIGHTS/SYMBOLS light light SPEED LIMITER ON Warning Meaning SINGLE GEAR SHIFT INTELLIGENT SPEED light INDICATION (SHIFTING UP) ASSIST SYSTEM DIPPED BEAM ACTIVATION (where HEADLIGHTS / FOLLOW ME provided) HOME SINGLE GEAR SHIFT START&STOP SYSTEM INDICATION (SHIFTING MANUAL ACTIVATION / LANE CONTROL SYSTEM...

  • Page 12: Grey Warning Lights/ Symbols

    Warning 2) 3) 4) 5) WARNING Meaning light Starting the engine (with the electronic key battery flat): place the rounded "DRIVE MODE” FUNCTION 1) Do not place the keys of the vehicle in edge of the electronic key (the side (versions with automatic the wireless charging compartment(M) transmission)

  • Page 13: Digital Rear-View

    DIGITAL REAR-VIEW The combination of a digital rear-view ATTENTION mirror and rear camera with dynamic MIRROR guidelines (where provided) makes 2) Always remove the key and lock the it possible to visually check the area vehicle when leaving it. behind the vehicle in order to perform manoeuvres more safely.

  • Page 14: Automatic Transmission

    AUTOMATIC To shift the gear lever from P to any EXTERNAL LIGHTS other position, with the ignition device TRANSMISSION on MAR, press the brake pedal and 6) 7) the button on the lever. The gear lever can be shifted freely from R to N or D, while the button on the lever must be pressed with the engine idling to shift from R to P.

  • Page 15: Auto Function (Dusk Sensor)

    DAYTIME RUNNING LIGHTS (DRL) (“Daytime Running Lights”) Starting device in MAR position and stalk ring (A) in fig. 12, or AUTO fig. 13, or fig. 14 (where provided). FRONT/REAR FOG LIGHTS Use button (A) fig. 15: F1A0609 F1A0689  first press: front fog lights and side lights switch on if the dipped beam AUTO FUNCTION (Dusk PARKING LIGHTS...

  • Page 16: High Beam Headlights

    Move the left stalk to the stable The vehicle is equipped with on- board assistance functions designed position: Contact a Fiat Dealership to have the to provide support in the event of an  upwards: activates right direction headlights’ direction checked and accident and/or emergency (HELP).
  • Page 17 Uconnect™ system. Contact unavailable (see the “Settings” chapter vehicles. a Fiat Dealership as soon as of the Uconnect™ system in the The HELP function is activated with: possible Owner Handbook for more details).

  • Page 18: Child Restraint Systems

    CHILD RESTRAINT SYSTEMS 8) 9) 10) 11) 12) 13) 14) 15) 16) 17) 18) 19) For optimal protection in the event of an impact, all occupants must be seated and wearing adequate restraint systems, including newborn and other children! This prescription is compulsory in all EC countries F0T0950 F1A0647...
  • Page 19 It is 17) Fiat Professional recommends fitting important to check the dedicated LED 13) Always make sure that the diagonal the child restraint system according to...

  • Page 20: Tpms (Tyre Pressure Monitoring System)

    TPMS (Tyre The TPMS continues to advise ATTENTION the driver of the low tyre pressure Pressure condition until this is corrected; the Monitoring System) 20) The TPMS is optimised for the warning continues until the pressure original tyres and wheels provided. corresponds or exceeds the pressure 20) 21) 22) 23) 24) 25) 26) 27) 28) TPMS pressures and alerts have been...

  • Page 21: Driving Tips

     indicate that the vehicle has DRIVING TIPS 25) The system only warns that the tyre broken down using the devices pressure is low: it is not able to inflate In daily use, the consumption of an required by the law in the current them.
  • Page 22  position the jack at the lifting  alert anybody nearby that the support nearest the wheel to be vehicle is about to be raised. They replaced, at the points shown must stay clear and not touch the in fig. 19. For short wheelbase vehicle it until it has been lowered versions with retractable again...
  • Page 23 36) 37) F1A0174  with the tools assembled, undo F1A0634 F1A0171 the bolts fig. 25 fully and remove  proceed by lifting the vehicle the wheel After lifting the vehicle:  for all versions, reach through the rear right wheel arch to turn the screw (A) fig. 22 on the spare wheel retaining device using the wrench supplied, assembled...
  • Page 24  assemble the tools to tighten the  tighten the knob onto the screw to For vehicles with alloy rims, proceed bolts fully, passing alternately from as follows: secure the bracket fig. 27 one bolt to the diagonally opposite  carry out the operations described above for changing the wheel, until ...
  • Page 25 39) 40) 32) Use the jack only to replace wheels on the vehicle with which it is supplied or on other vehicles of the same model. ATTENTION Never use the jack for other purposes, such as lifting other vehicle models. Never use the jack to carry out repairs 29) Use your hazard warning lights, under the vehicle.

  • Page 26: Fix & Go Automatic Quick Tyre Repair Kit

     a spray can (A) of sealant, FIX & GO 38) At the end of the operation of raising/ complete with transparent filler AUTOMATIC QUICK locking the spare wheel, after having hose (E); black pressure top- checked the correct positioning of the TYRE REPAIR KIT up hose (C);...
  • Page 27  insert the sealant cartridge (A) into  operate the compressor by Stop safely, engage the parking the corresponding compressor pressing the ON/OFF button brake and top up the pressure to compartment (F) and press it (ON position) fig. 30. When the prescribed value using the black down hard until you feel the the pressure gauge (B) reads...

  • Page 28: Procedure For Restoring The Pressure

     only use original cartridges, which Fix&Go kit package label. Carefully read can be purchased from the Fiat the cartridge label before use and avoid improper use. The kit should be used by Dealership WARNING adults and cannot be used by children.

  • Page 29: Fuses

    F53 - 7.5A - Instrument panel (C) = fuse with damaged filament Heated seat, Windscreen wiper motor (+battery) For fuse replacement, contact a Fiat F33 - 7.5A - Battery monitoring sensor F94 - Not used Dealership. for Start&Stop versions (+battery) F34 - 7.5A - Minibus interior lights...

  • Page 30: Engine Compartment Fusebox

    ENGINE COMPARTMENT F06 - 40A/60A - Engine cooling fan WIRED MODULE FUSEBOX high speed F07 - 40A/50A - Engine cooling fan low speed F08 - 40A - Passenger compartment fan (+key) F09 - 15A - Rear power socket (+battery) F10 - 15A - Horn F14 - 15A - Power socket (+battery) F1A0458-1 F15 - 15A - Cigarette lighter (+battery)

  • Page 31: Optional Wired Module

    OPTIONAL WIRED RIGHT CENTRAL PILLAR F61 - Vacant MODULE OPTIONAL FUSEBOX F62 - Vacant F63 - 10A - Passenger additional heater command F64 - Vacant F65 - 30A - Passenger additional heater fan F1A0455-1 F61 - 30A - Webasto control unit F62 - 20A - Passenger compartment electric fan with Webasto F63 - 20A - Tow Hook Socket...
  • Page 32 46) If the replaced fuse blows again, contact a Fiat Dealership. 47) Contact Fiat Dealership if a safety system (airbags, brakes), engine system (engine, gearbox) or steering system general protection fuse blows. 48) For fuse replacement, contact a Fiat...

  • Page 33: Scheduled Servicing

    SCHEDULED SERVICING SERVICE SCHEDULE Thousands of miles Thousands of kilometres Years ● ● ● ● ● Check battery state of charge and possibly recharge Check tyre condition/wear and adjust pressure, if necessary; check the expiry date of the ● ● ●...
  • Page 34 Thousands of miles Thousands of kilometres Years Replace toothed timing drive belt ● ● ● ● ● Replace air cleaner cartridge (2) Change engine oil and replace oil filter Change the brake fluid ● ● ● ● ● Replace the passenger compartment filter Replace TBM battery (where provided) Only use the fluids shown in the “Refuelling”...

  • Page 35: Refuelling

    REFUELLING 2.2 120 HP -140 HP -160 HP -180 HP Prescribed fuels and original H3-Power with AdBlue® lubricants Network Tempo Libero Fuel tank (litres): 90 (*) 75 (**) Diesel for motor vehicles (EN590 Specification) Including a reserve of (litres): 10 / 12 UREA tank (where provided) approx.

  • Page 36: Uconnect™ 5

    UCONNECT™ 5  Brief button press: Activation/deactivation of Play (playback) / Pause function Radio source: Select the radio station stored under "Preset 3" Media source: Select the next track  Brief button press:  Long button press: Radio source: Select the radio Radio source: Store the radio station station stored under "Preset 1"...

  • Page 37: Controls On The Steering

    BROWSE After the "Pair new phone" pairing ENTER procedure is selected, a pop-up Rejection of incoming call screen indicating the device name and  Brief button press: Ending of call in progress a random 4-digit PIN will appear on Confirmation of the option displayed the display.

  • Page 38: Uconnect

    UCONNECT™ TOUCHSCREEN Home: Show the main FUNCTION screen GRAPHIC BUTTONS ON The system uses the touchscreen Media: Access Media mode DISPLAY features; to interact with the various to select available sources, (A) fig. 39 (10” version), fig. 40 (7” functions, press the graphic buttons folder tracks and interaction version).

  • Page 39: Usb Source

    Press your finger on the chosen field WARNING The ‘‘double telephone’’ NOTE Customisation is only active or button to select the field or perform feature is not available while using the when the vehicle is stationary. If an the function associated with the telephone in CarPlay or Android Auto attempt is made to customise with button.

  • Page 40: Wheels

    3000 PTT with oversized tyres, except certifications and open source lists PANORAMA: 4.0/4.0 available for in-vehicle components use the following link: 3300 PTT / 3500 PTT with Oversize http://aftersales.fiat.com/elum/ tyres: 4.1/4.5 Winter and All-Seasons tyres: 4.1/4.5 CONNECTED PANORAMA with oversized tyres: SERVICES 4.1/4.5...
  • Page 41 FCA Italy S.p.A. – MOPAR – Technical Service Operation Via Adige 7, 10040 Rivalta di Torino (TO) – Italy Print n. 603.85.473 - 11/2021 - 2 Edition...
