Single Outlet Remote Power Switch - Setup Guide (EZ-62B)
Overview:
The ezOutlet3 (EZ-62B) is the latest of the ezOutlet family for remote network
management. Functions include:
● Auto-Reset upon loss of Internet or LAN device
● Remote control to turn power to the outlet on/ off or reset. This can be done
through the ezDevice application or through your Cloud4UIS account on any
computer with an Internet connection
● Schedule outlets to be turned on/ off or reset at specified Day(s)/ Time(s)
● Manage multiple devices from the same Cloud4UIS account (including EZ-22B,
UIS-522B, and UIS-622B
● Device 'owner' can share device(s) with
other Cloud4UIS users OR transfer device
ownership to other Cloud4UIS users
● Add device via the serial number when not
connected to the same LAN
Locating your Device ID & Serial Number:
Both the Device ID and Serial Number can be found
on the bottom of your EZ-62B.
LED Indicators:
LED
Internet
Internet connection
(IN)
normal
Cloud
Cloud Link normal
Link
(CL)
Auto
Auto Reset Is
Reset
enabled
(AR)
Output
Outlet is ON
ON
Device not yet added/
linked to cloud account
OFF
No Internet
N/A
Outlet is OFF
BLINKING
N/A
No Cloud Connection
Manual Control is
enabled
Outlet is Resetting
Advertisement
Related Manuals for 5Gstore EZ-62B
Summary of Contents for 5Gstore EZ-62B
- Page 1 Single Outlet Remote Power Switch - Setup Guide (EZ-62B) Overview: The ezOutlet3 (EZ-62B) is the latest of the ezOutlet family for remote network management. Functions include: ● Auto-Reset upon loss of Internet or LAN device ● Remote control to turn power to the outlet on/ off or reset. This can be done...
-
Page 2: Setting Up Your Device
Setting up your Device 1. Connect an Ethernet cable from LAN port on your router to the EZ-62B. 2. Connect the power plug from the EZ-62B to a wall outlet. Once the system boots up, the Output and Internet LEDs will turn ON. - Page 3 Local Web Administration page ● Each EZ-62B can only be added to an account once . If you need to change that, you will need to remove the device from your account first and then another user...
- Page 4 Section 1: Configuration via ezDevice mobile application: 1. Open the ezDevice app and log in 2. Select your EZ-62B from the Device List 3. The next screen will display a Menu 4. Select the menu option you need to configure 5.
- Page 5 3. Settings a. Outlet mode : Select between Auto Reset OR Manual Control i. Auto Reset : The EZ-62B will Ping a specific address or the default website addresses and when pings fail, power to the outlet will be reset ii.
- Page 6 3. Schedule : Set up to 6 schedules. If you want the outlet to be turned OFF at one time and ON at a later time, you must set 1 schedule to turn OFF and 1 schedule to turn ON . Otherwise, use RESET a.
- Page 7 1. Open a web browser to https://cloud4UIS.com and log in 2. Select your EZ-62B from the Device List 3. A pop up window will display a Menu 4. Select the menu option you need to configure 5. Click Save at the top right when complete Cloud Configuration Menu: 1.
- Page 8 Manual Control : User must access the Mobile App or Cloud website to manually reset or power outlet ON/OFF b. Ping Delay : This is the time the EZ-62B will wait after a Reset, before it starts the ping tests. This gives your equipment enough time to reboot.
- Page 9 If you do not want/ need to use the mobile application or Cloud4UIS account, you will need to locate the IP address your router is assigning to the EZ-62B. This IP address will get you to its web administration page where you can configure settings. If you’re not familiar with how to locate IP addresses connected to your network, we recommend using either the Windows Utility program or LanScan for Mac users.
- Page 10 1. Status : This is just an overview of your network info (IP address, DNS, etc), the current Time/ Date, Outlet Status and Mode, as well as your device’s Serial number and Firmware Version 2. Network a. Name : If changing the Hostname, enter it here b.
- Page 11 Manual Control: User must access the Mobile App or Cloud website to manually reset or power outlet ON/OFF b. Ping Delay After Power On : This is the time the EZ-62B will wait after a Reset, before it starts the ping tests. Default is 0 . Configurable between 0-1440 minutes (1 day) - e.g.
- Page 12 If connection times out, the ping interval is fixed at 5 seconds by default. g. Cloud : Allows EZ-62B to be added to the Cloud Service. Set to Enable by default. h. Username : For logging into the WebUI. admin is the Default.
- Page 13 5. Schedule : Set up to 6 schedules. If you want the outlet to be turned off at one time and on at a later time, you must set one schedule to turn it OFF and another to turn it back ON. Otherwise, use the Reset action. a.
- Page 14 6. Ping Address : This section allows you to enter 1 address with the option to HTTP (TCP) or Ping (default). Leave the field blank to ping the predefined IPs. If desired, enter a specific web address OR a local device’s IP address 7.
-
Page 15: Upgrading Firmware
4. Your EZ-62B should be listed here (along with any others you have saved). NOTE: If you don’t see your EZ-62B listed, click the Search in LAN button. If the app still cannot locate your EZ-62B, click Manual Upgrade at the top 5.
