Summary of Contents for Vissani HVBC430ST
- Page 1 USE AND CARE GUIDE 4.3 CU FT BEVERAGE AND WINE CENTER Questions, problems, missing parts? Before returning to the store, call Vissani Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-847-7264 HOMEDEPOT.COM...
-
Page 2: Table Of Contents
Table of Contents Safety Information .............2 Door Reversal Instructions ........7 Warranty..............4 Operating Instructions ..........10 Pre-Operation ............5 Startup ..............10 Before You Begin ............5 Setting Temperature – Adjustable Thermostat Transport ..............5 Control ..............10 Ventilation ..............5 Loading Beverages and Wine Bottles ....10 Stabilization ............5 LED Light ..............11 Protect From Heat ..........5 Shutdown .............11... - Page 3 POWER SUPPLY CAUTION: The surface of the compressor may become hot during normal operation. Do not touch IMPORTANT: Do not cut or remove the third as this may cause injury. ground prong from the power cord. WARNING: Keep the beverage cooler away from any combustible or volatile liquids or gases, □...
-
Page 4: Warranty
Warranty MC Appliance Corporation warrants this beverage LIMITATIONS OF REMEDIES AND cooler to be free from defects in material and EXCLUSIONS workmanship, and agrees to remedy any such defect Product repair in accordance with the terms herein, or to furnish a new part(s), at the company’s option, is your sole and exclusive remedy under this limited for any part(s) of the unit that have failed during warranty. -
Page 5: Pre-Operation
Pre-Operation BEFORE YOU BEGIN STABILIZATION □ The beverage cooler must be placed on a flat, IMPORTANT: Before you begin, do not plug the stable surface. Adjust the unit’s front leveling beverage cooler into a power outlet until it has legs to assure quiet operation and prevent been resting in its upright position for at least six rattling when the compressor activates. -
Page 6: Tools Required
Pre-Operation (continued) TOOLS REQUIRED #2 Phillips 5/16-inch (8 mm) Flat head screwdriver Socket tool screwdriver PRODUCT DESCRIPTION Part Description Part Description 4.3 cu ft beverage and wine center Adjustable wine bottle racks Adjustable glass shelves Adjustable front leveling legs Reversible double-pane glass door Fan and LED light with stainless-steel frame... -
Page 7: Door Reversal Instructions
Door Reversal Instructions IMPORTANT: Remove glass shelves before reversing the door. IMPORTANT: Never lay the beverage cooler on its back. The compressor and motor components are installed at the back of the beverage cooler and may easily be damaged if the unit is placed on its back. Removing Plastic Hole Insert Removing the Triangular Bracket Plugs... - Page 8 Door Reversal Instructions (continued) Removing the Bottom Base Reattaching the Bottom Base Bracket from Right Side Bracket to Left Side □ □ Carefully place the unit on its side. Gently place the beverage cooler on its opposite side. □ Remove the bottom metal base bracket with □...
- Page 9 Door Reversal Instructions (continued) Reattaching the Triangular Bracket and Door to Right Side □ Place the top bracket into the door, and align the metal bracket holes over the holes in the top of the unit cabinet. □ Tighten the three screws (4) to hold it in place. IMPORTANT: The rubber gasket should be compressed on all sides of the door.
-
Page 10: Operating Instructions
Operating Instructions STARTUP Connect the power cord to a standard wall outlet. Do not use a GFCI outlet to connect the unit (see Safety Information). After connection, you will immediately hear a short beep. SETTING TEMPERATURE – ADJUSTABLE THERMOSTAT CONTROL The default temperature is 43 °F (6 °C). -
Page 11: Led Light
□ For replacement components, they must be Inspect, clean, and maintain the rubber gasket around obtained from Vissani Customer Service. This the door. A small amount of petroleum jelly applied to ensures the correct replacement components the bracket side of gaskets will keep the gasket pliable are provided, and minimizes risk of possible and ensure a good seal. -
Page 12: Troubleshooting
□ Align the door using a 5/16-inch (8 mm) socket, adjusting the screws under the triangular bracket cover. For assistance, please contact Vissani’s Customer Service Department. □ Side panel of beverage cooler is hot. The unit exchange heats through the side walls; therefore, does not indicate malfunction. - Page 13 HOMEDEPOT.COM Please contact 1-855-847-7264 for further assistance.
- Page 14 Questions, problems, missing parts? Before returning to the store, call Vissani Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-855-847-7264 HOMEDEPOT.COM Retain this manual for future use.
