All manuals and user guides at all-guides.com FHD228 FULL HD FORWARD VIEW CAMERA 1/3” COLOUR CAMERA SPECIFICATIONS - Image Device: 1/3” Sony CMOS - Diagonal Viewing Angle: 150° - Signal System: - Sync System: Internal - Orientation: Normal View - Night Vision:...
Page 2
All manuals and user guides at all-guides.com FHD228 Camera HD Wiring configuration: Monitor Camera Note: Compatible with HD monitors only Assembly Camera Accessories...
Page 3
All manuals and user guides at all-guides.com Installation the bracket. U-bracket 3M Double-sided adhesive Loose Screws 3. Clean the installation area and attach the camera as below. 4. Adjust the lens to the desired viewing angle and tighten 4 screws. Installation area 3M Double-sided adhesive Camera...
